Scheme 1
Note. The warning lights come on for a function test when the ignition is switched on. They should go out once the engine has started.
"BRAKE" INDICATOR LIGHT
Indicates the brake fluid level is low in the reservoir or the parking brake is still on.
HIGH BEAM INDICATOR LIGHT
Light indicates that the head light high beam is on.
TURN SIGNAL INDICATOR LIGHTS
Indicate signal operation & direction.
SEAT BELT WARNING LIGHT
The warning light stays on until the driver's seat belt is fastened.
ALTERNATOR WARNING LIGHT
Light comes on if alternator is not charging.
REAR WINDOW DEFOGGER INDICATOR
Indicates the rear defogger is on.
EMERGENCY FLASHER INDICATOR
Indicates the emergency flashers are in operation.
"ECS" MALFUNCTION WARNING (IF EQUIPPED)
Warns of a malfunction in the emission control system.
OIL PRESSURE WARNING LIGHT
Indicates no, or low, oil pressure.
COOLANT TEMPERATURE & LEVEL WARNING (IF EQUIPPED)
Warns of excessive engine coolant temperature or low coolant level in system.
"ABS" WARNING LIGHT (IF EQUIPPED)
Warns of a malfunction in the anti-lock brake system.
GLOW PLUG/WATER SEPARATOR WARNING (DIESEL)
Indicates glow plug function and, when flashing, the need to drain the water separator.
"OXS" OXYGEN SENSOR LIGHT (IF EQUIPPED)
Indicates service due on emission control system.
