SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Sanden SD7-V16 7-Cyl. |
| Compressor Belt Tension | (1) |
| System Oil Capacity (2) |
| With One Evaporator | 4.6 ozs. |
| With Two Evaporators | 8.1 ozs. |
| Refrigerant (R-134a) Capacity |
| With One Evaporator | 33.5 ozs |
| With Two Evaporators (Short Wheelbase) | 47.6 ozs. |
| With Two Evaporators (Long Wheelbase) | 49.0 ozs. |
| System Operating Pressures |
| High Side | 232 psi (16.3 kg/cm 2 ) |
| Low Side | 22-36 psi (1.5-2.5 kg/cm 2 ) |
| (1) Belt tension is automatically adjusted by tensioner pulley. (2) Use SP-10 PAG Compressor Oil (Part No. G 052 154 A2). |
| (1) | Belt tension is automatically adjusted by tensioner pulley. |
| (2) | Use SP-10 PAG Compressor Oil (Part No. G 052 154 A2). |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor Bolt | 33 (45) |
| A/C Compressor Bracket Nut | 18 (25) |
| Steering Wheel Mounting Nut | 37 (50) |
| INCH Lbs. (N.m) |
| Driver's Air Bag Module | 58 (6.5) |
| Passenger's Air Bag Module | 84 (10) |
Automatic A/C-Heater System Wiring Diagram (EuroVan - 1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (EuroVan - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (EuroVan - 2 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (EuroVan - 2 Of 2)
