2.0L - Engine Assembly - Engine Code(s): Cbfa & Ccta: Overview Volkswagen Eos I рестайлинг

Mechanical 1 illustration ~294 words

Scheme 60

Scheme 60: ENGINE AND TRANSMISSION MOUNT OVERVIEW
Scheme 60: ENGINE AND TRANSMISSION MOUNT OVERVIEW
  1. Bolt Tightening specifications, refer to one of the following: GTI, Eos, Passat and CC with a Direct Shift Gearbox (DSG R), refer to «[For transmission(s) 02E] Specifications»(ref-475567-S01106248412012052300000) . GTI, Eos, Passat and CC with a manual transmission, refer to «[For transmission(s) 02Q] Specifications»(ref-475548-S09812210032012052300000) . Transmission mount bracket to transmission.
  2. Bolt Tightening specification. Refer to «Specifications»(ref-475524-S26484574402012052300000) . Pendulum support to transmission.
  3. Engine Mount Bracket
  4. Bolt 40 Nm + an additional 180° (1/2) turn. Always replace. Engine mount bracket to engine.
  5. Engine Mount
  6. Bolt 40 Nm + an additional 90° (1/4) turn. Always replace. Engine mount to body.
  7. Support
  8. Bolt 20 Nm + an additional 90° (1/4) turn. Always replace. Support to engine mount.
  9. Bolt 20 Nm + an additional 90° (1/4) turn. Always replace. Support to body.
  10. Bolt 40 Nm + an additional 90° (1/4) turn. Always replace. Engine mount to body.
  11. Bolt 60 Nm + an additional 90° (1/4) turn. Always replace. Engine mount to engine mount bracket.
  12. Pendulum Support
  13. Bolt 100 Nm + an additional 90° (1/4) turn. Always replace. Pendulum support to subframe. First, install the pendulum support to transmission bolt, then install the pendulum support to subframe bolt.
  14. Bolt 60 Nm + an additional 90° (1/4) turn. Always replace. Transmission mount to transmission mount bracket.
  15. Bolt 40 Nm + an additional 90° (1/4) turn. Always replace. Transmission mount to body
  16. Transmission Mount The illustration shows the DSG R version.
  17. Bolt Tightening specifications, refer to one of the following: GTI, Eos, Passat and CC with a DSG R, refer to «[For transmission(s) 02E] Specifications»(ref-475567-S01106248412012052300000) . GTI, Eos, Passat and CC with a manual transmission, refer to «[For transmission(s) 02Q] Specifications»(ref-475548-S09812210032012052300000) . Transmission mount bracket to transmission.
  18. Transmission Mount Bracket
