CONDENSER
Special tools and workshop equipment required
- A/C Service station ROB 134APF
- Rinsing Device For Refrigerant Circuits VAS6337/1
Note. Refrigerant must be extracted before hand using ROB 134APF. The previously used A/C Service Station can still be used. To prevent the entry of dampness all components of the refrigerant circuit which have been opened must be sealed with suitable plugs.
Scheme 99
- Protective Grate Only for vehicles with rough terrain equipment. Only in vehicles with "Showa" condenser. Position protective grate from below on the 2nd rib.
- Clip Quantity: 8
- Condenser Secure to radiator with 4 bolts. Removing and installing, refer to «REMOVAL»(ref-475571-S23560011752012052300000) .
- Sealing Strips Adhere the upper sealing strips from above onto the 6th row of fins on the condenser before installing. Adhere the lower sealing strips from below onto the 1st row of fins on the condenser before installing. Adhere the side sealing strips from below onto the condenser collector from the 1st row of fins before installing.
- Spacer NOTE: Replace the spacer if it is damaged or missing.
- Screw 5 Nm
- Radiator
- Screws 5 Nm Quantity 4
- Fluid Reservoir With Dryer Cartridge Removing and installing, refer to «FLUID RESERVOIR WITH DRYER CARTRIDGE»(ref-475571-S37732185982012052300000) . NOTE: Under certain conditions, fluid reservoir with dryer is no longer to be replaced after each time the refrigerant circuit is opened. Refer to «Removal and Installation»(ref-475566-S42819581602012052300000)
