Instrument cluster — Electronic compass circuit Volkswagen Bora III
All systems — 47 systems
- Air conditioning 4
- Anti-lock brakes 2
- Anti-theft 4
- Body control modules 3
- Computer data lines 2
- Cooling fan
- Cruise control 1.4l turbo hybrid
- Cruise control 1.8l turbo
- Cruise control 2.0l
- Cruise control 2.0l turbo
- Cruise control 2.0l turbo diesel
- Defoggers 2
- Electronic power steering
- Engine performance 1.4l turbo hybrid
- Engine performance 1.8l turbo
- Engine performance 2.0l
- Engine performance 2.0l turbo
- Engine performance 2.0l turbo diesel
- Exterior lights 4
- Ground distribution 2
- Headlights 4
- Horn 2
- Instrument cluster 3
- Interior lights 4
- Navigation 6
- Power distribution 2
- Power door locks 2
- Power mirrors 5
- Power seats 3
- Power top/sunroof
- Power windows 2
- Radio 5
- Shift interlock 1.8l turbo
- Shift interlock 2.0l
- Starting/charging 1.8l turbo 2
- Starting/charging 2.0l 2
- Starting/charging 2.0l turbo 2
- Starting/charging 2.0l turbo diesel 2
- Supplemental restraints
- Transmission 1.4l turbo hybrid
- Transmission 1.8l turbo
- Transmission 2.0l
- Transmission 2.0l turbo
- Transmission 2.0l turbo diesel
- Trunk, tailgate, fuel door 2
- Warning systems 3
- Wiper/washer 3
Components on these wiring diagrams 7
Click a component to highlight it on every diagram it appears on.
