Horn circuit, w/ high equipment for Volkswagen Bora III (2012-2018)
Horn circuit, w/ high equipment
AIR BAG SPIRAL SPRING/ RETURN SPRING (W/ SLIP RING)
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DUAL TONE HORN RELAY
FUSE 27
FUSE 35
FUSE 36
FUSE 43
FUSE PANEL C
HIGH TONE HORN
HORN SIGNAL ACTIVATION
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LOW TONE HORN
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED/BRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
STEERING COLUMN ELECTRONICS CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
W/ MULTI-FUNCTION STEERING WHEEL CONTROLS
W/O MULTI-FUNCTION STEERING WHEEL CONTROLS
