Car Wiring Diagrams for Ground distribution circuit, w/ low equipment for Volkswagen Bora III (2012-2018)

1.8L TURBO 12 V SOCKET 2.0L 2.0L TURBO DIESEL A/C CLUTCH RELAY A/C CONTROL MODULE ACCESS/ START AUTHORIZATION CONTROL MODULE AIR QUALITY SENSOR ASR SWITCH/ PUSH BUTTON ILLUMINATION LAMP ASR/ESP BUTTON AUTOMATIC A/C BACKREST ADJUSTMENT BUTTON 2 BLK/WHT WIRE BLOCKING DIODE BRN WIRE CLIMATRONIC CONTROL MODULE DIAGNOSTIC CONNECTOR EMERGENCY FLASHER BUTTON, INDICATOR LAMP FRONT PASSENGER BACKREST HEATING ELEMENT FRONT PASSENGER DOOR AMBIENT LIGHTING BULB FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR LOCK UNIT FRONT PASSENGER EXTERIOR DOOR HANDLE TOUCH SENSOR FRONT PASSENGER EXTERIOR REAR VIEW MIRROR FRONT PASSENGER HEATED SEAT TEMPERATURE SENSOR/SEAT HEATING ELEMENT FRONT PASSENGER INTERIOR LOCKING BUTTON FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH GLOVE COMPARTMENT LAMP LEFT STEERING COLUMN SWITCH LEFT WASHER NOZZLE HEATER LIGHTER CIGARETTE NCA WIRE PARKING AID BUTTON PARKING AID CONTROL MODULE PARKING BRAKE INDICATOR LAMP SWITCH PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE PASSENGER OCCUPANT DETECTION SYSTEM PRESSURE SENSOR POWER SUNROOF CONTROL MODULE REAR CENTER INTERIOR LOCKING SWITCH RIGHT REAR DOOR CONTROL MODULE RIGHT REAR DOOR LOCK UNIT RIGHT WASHER NOZZLE HEATER SELECTOR LEVER SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE TIPTRONIC SWITCH TIRE PRESSURE MONITORING DISPLAY BUTTON TWO-WAY RADIO SOCKET VOLTAGE STABILIZER W/O ESP

2.0L TURBO DIESEL ABS CONTROL MODULE AMPLIFIER AUTOMATIC A/C BLIND SPOT DETECTION CONTROL MODULE 2 BLK WIRE BRN WIRE CELL PHONE OPERATING ELECTRONICS CONTROL MODULE CELLULAR TELEPHONE PREPARATION CONTROL HEAD DRIVER EXTERIOR REAR VIEW MIRROR EMERGENCY CALL BUTTON EMERGENCY CALL CONTROL MODULE, COMMUNICATION UNIT CONTROL MODULE FM FREQUENCY FILTER (IN NEGATIVE WIRE) FRESH AIR BLOWER CONTROL MODULE FRONT PASSENGER EXTERIOR REAR VIEW MIRROR FUEL DELIVERY UNIT FUEL PUMP CONTROL MODULE HIGH-MOUNTED BRAKE LAMP BULB LOW TONE HORN MULTIMEDIA SYSTEM CONTROL MODULE NCA WIRE RADIO RADIO SHIELD RADIO/ NAVIGATION DISPLAY UNIT CONTROL MODULE SHIELD RADIO/NAVIGATION DISPLAY UNIT CONTROL MODULE REAR VIEW CAMERA REDUCING AGENT LINE HEATER REDUCING AGENT METERING SYSTEM DELIVERY UNIT REDUCING AGENT QUALITY SENSOR RIGHT FRONT FOG LAMP BULB RIGHT FRONT HEADLAMP RIGHT TAIL LAMP TELEPHONE BASE PLATE TELEPHONE TRANSCEIVER W/ ESP W/O ESP W/ HID HEADLAMPS W/ NAVIGATION W/O HID HEADLAMPS W/O NAVIGATION

2.0L TURBO DIESEL 2.0L, 1.8L TURBO A/C COMPRESSOR REGULATOR VALVE A/C CONTROL MODULE AIR BAG SPIRAL SPRING/ RETURN SPRING (W/ SLIP RING) AIR BAG SPIRAL SPRING/RETURN SPRING W/ SLIPRING ALARM HORN RELAY ALARM SYSTEM HORN AUTOMATIC GLOW TIME CONTROL MODULE BLK WIRE BRAKE FLUID LEVEL WARNING SWITCH BRAKE LAMP SWITCH/BRAKE PEDAL SWITCH BRN WIRE CHARGE AIR COOLING PUMP CLUTCH POSITION SENSOR CONVERTER BOX CORNERING LAMP, HEADLAMP RANGE CONTROL MODULE DISTANCE REGULATION CONTROL MODULE ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE ENGINE HOOD CONTACT SWITCH FROM DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH (DIAGRAM 4 OF 5) FROM DSG TRANSMISSION MECHATRONIC (DIAGRAM 4 OF 5) FROM ENGINE CONTROL MODULE (DIAGRAM 4 OF 5) FROM INTERIOR LAMP W/ DELAY SWITCH (DIAGRAM 4 OF 5) FROM LEFT REAR DOOR CONTROL MODULE (DIAGRAM 4 OF 5) HEATER CONTROL MODULE HEATER SUPPORT PUMP HIGH PRESSURE SENSOR HORN SIGNAL ACTIVATION INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE INSTRUMENT PANEL, SWITCH ILLUMINATION DIMMER SWITCH LEFT FRONT BRAKE PAD WEAR SENSOR LEFT FRONT FOG LAMP BULB LEFT FRONT HEADLAMP LEFT STEERING COLUMN SWITCH LIGHT SWITCH M/T MANUAL A/C MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE OIL LEVEL THERMAL SENSOR PARKING HEATER OPERATION RELAY PARKING HEATER OPERATION RELAY 2 POSITIVE CRANKCASE VENTILATION HEATING ELEMENT RADIATOR SHUTTER MOTOR RED WIRE RIGHT STEERING COLUMN SWITCH START SYSTEM BUTTON STARTER RELAY 1 STARTER RELAY 2 STEERING ANGLE SENSOR STRUCTURE BORNE SOUND CONTROL MODULE TERMINAL 15 POWER SUPPLY RELAY TERMINAL 75 POWER SUPPLY RELAY 1 VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ HID HEADLAMPS W/ MULTI-FUNCTION STEERING WHEEL CONTROLS W/O HID HEADLAMPS W/O MULTI-FUNCTION STEERING WHEEL CONTROLS WINDSHIELD WIPER MOTOR

1.8L TURBO 2.0L TURBO DIESEL 1.8L TURBO 2.0L AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR AUXILIARY HEATER HEATING ELEMENT BATTERY BATTERY MONITORING CONTROL MODULE BLK WIRE BLK/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE CENTRAL LOCKING SAFE INDICATOR LAMP DRIVER BACKREST HEATING ELEMENT DRIVER DOOR AMBIENT LIGHTING BULB DRIVER DOOR CONTROL MODULE DRIVER DOOR LOCK UNIT DRIVER EXTERIOR DOOR HANDLE TOUCH SENSOR DRIVER EXTERIOR REAR VIEW MIRROR DRIVER HEATED SEAT TEMPERATURE SENSOR/ HEATING ELEMENT DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER VANITY MIRROR LAMP CONTACT SWITCH DRIVER'S INTERIOR LOCKING BUTTON DSG TRANSMISSION MECHATRONIC ELECTRIC DRIVE POWER, CONTROL ELECTRONICS ENGINE CONTROL MODULE FRESH AIR BLOWER FRONT INTERIOR LAMP FRONT SEAT HEATING CONTROL MODULE GARAGE DOOR OPENER CONTROL MODULE IGNITION COIL 1 W/ POWER OUTPUT STAGE IGNITION COIL 2 W/ POWER OUTPUT STAGE IGNITION COIL 3 W/ POWER OUTPUT STAGE IGNITION COIL 4 W/ POWER OUTPUT STAGE INTERIOR LAMP W/ DELAY SWITCH LEFT REAR DOOR CONTROL MODULE LEFT REAR DOOR LOCK UNIT MIRROR ADJUSTING SWITCH MULTI-FUNCTION TRANSMISSION RANGE SWITCH NCA WIRE PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE TO ALARM HORN RELAY (DIAGRAM 3 OF 5) TRANSMISSION CONTROL MODULE W/O HEATED SEATS

1.8L TURBO 2.0L 2.0L TURBO DIESEL AFTER-RUN COOLANT PUMP AUXILIARY COOLANT HEATER RADIO FREQUENCY RECEIVER BLK WIRE BRAKE SYSTEM VACUUM PUMP BRN WIRE CLUTCH POSITION SENSOR COMPASS MAGNETIC FIELD SENSOR COOLING CIRCUIT SOLENOID VALVE ENGINE COOLANT CIRCULATION PUMP 2 HIGH TONE HORN IGNITION COIL IGNITION COIL 1 W/ POWER OUTPUT STAGE IGNITION COIL 2 W/ POWER OUTPUT STAGE IGNITION COIL 3 W/ POWER OUTPUT STAGE IGNITION COIL 4 W/ POWER OUTPUT STAGE IGNITION COIL 5 W/ POWER OUTPUT STAGE LEFT LICENSE PLATE LAMP LEFT TAIL LAMP LEFT TAIL LAMP 2 LICENSE PLATE LAMP LUGGAGE COMPARTMENT LAMP SWITCH/REAR LID LOCK UNIT/REAR LID OPENING MOTOR M/T NOX SENSOR CONTROL MODULE OIL PRESSURE SWITCH POWER STEERING CONTROL MODULE REAR INTERIOR LAMP REAR LID HANDLE RELEASE BUTTON REAR LID LOCK UNIT REDUCED OIL PRESSURE SWITCH RIGHT LICENSE PLATE LAMP RIGHT RADIATOR FAN CONTROL MODULE RIGHT TAIL LAMP 2 SECONDARY AIR INJECTION PUMP MOTOR VEHICLE POSITIONING SYSTEM CONTROL MODULE
