CABLE GUIDE INSIDE ENGINE COMPARTMENT
| CAUTION | When disconnecting and connecting the battery -A-, the procedure must be followed as described in the Repair Information! Refer to BATTERY, DISCONNECTING AND CONNECTING . |
Removing
Remove battery. Refer to BATTERY .
Note. Air Filter, removing and installing, refer to [For engine(s) APH, BNU, AWP, AWV, BKF] Removal and Installation , or refer to [For engine(s) BPR, BPS] Removal and Installation , or refer to [For engine(s) BDC, BEV, BGD, AVH, AZG, AEG] Removal and Installation or [For engine(s) APH, BNU, AWP, AWV, BKF] Removal and Installation , or refer to [For engine(s) BPR, BPS] Removal and Installation , or refer to [For engine(s) BDC, BEV, BGD, AVH, AZG, AEG] Removal and Installation .
Disconnect the connectors and the hose connections on the air filter housing. Refer to [For engine(s) APH, BNU, AWP, AWV, BKF] Removal and Installation , or refer to [For engine(s) BPR, BPS] Removal and Installation , or refer to [For engine(s) BDC, BEV, BGD, AVH, AZG, AEG] Removal and Installation .
Remove the bolts -arrows- and then remove the battery tray.
Scheme 118
Unclip the cable router cover at the tabs -arrows- and fold the cover in the direction of travel.
Scheme 119
Unclip the remaining tabs -arrows- and remove the cover.
Scheme 120
Disconnect all necessary connectors and remove the wiring harness from the cable guide.
Unclip the cable guide completely and remove it.
Installing
Install in reverse order of removal, noting the following
Tighten the battery tray bolts to 6 Nm.
