Interior Equipment (Hatchback): Overview Volkswagen Beetle A4 facelift

Seats 1 illustration

SILL PANEL TRIM ASSEMBLY OVERVIEW

Note. The sill panel trim is covered by lower A-pillar trim at front and by side trim at rear. Retaining clips of these trim parts are located in recesses at end of sill panel.

Scheme 1

Scheme 1: SILL PANEL TRIM ASSEMBLY OVERVIEW
Scheme 1: SILL PANEL TRIM ASSEMBLY OVERVIEW
  1. Sill Panel Trim
  2. Clips Qty. 5
  3. Inner Door Seal
  4. Carpet
