MATERIALS Volkswagen Beetle A4 facelift

Glass, Window Regulators (Convertible) 2 illustrations ~150 words

MATERIALS

2K window adhesiveDA 004 600 A2 (1) , (2)
1K window adhesiveDH 009 100 03 (3) , (4)
ActivatorD 181 801 A1 (5)
Glass primer/paint primerD 009 200 02 (5)
Cleaning solutionD 009 401 04 (5)
Primer applicatorD 009 500 25 (5)
Adhesive removerD 002 000 10 (5)
(1) Observe minimum curing time. Refer to MINIMUM CURING TIME . (2) Double cartridge pistol VAS 5237 must be used to process this material. (3) Heat according to manufacturer's instructions using cartridge heater V.A.G 1939. (4) Small cartridge (110 ml) for sealing and/or when a 400 ml double cartridge is not enough. (5) Materials are stored in box D 004 700.
(1)Observe minimum curing time. Refer to MINIMUM CURING TIME .
(2)Double cartridge pistol VAS 5237 must be used to process this material.
(3)Heat according to manufacturer's instructions using cartridge heater V.A.G 1939.
(4)Small cartridge (110 ml) for sealing and/or when a 400 ml double cartridge is not enough.
(5)Materials are stored in box D 004 700.

Scheme 108

Scheme 108: WINDSHIELD ASSEMBLY OVERVIEW
Scheme 108: WINDSHIELD ASSEMBLY OVERVIEW
  1. Windshield Windshield, Installing, refer to «WINDSHIELD, INSTALLING»(ref-493016-S29546892802012080600000)
  2. PUR adhesive sealant Bead diameter: width = 7 mm, height = 11 mm (including pre-coating, residual material on window glass and window flange) Minimum curing time, refer to «MINIMUM CURING TIME»(ref-493016-S16049724682012080600000)
  3. Dimension -a- = 4 mm
  4. Sealing lip (component part of pre-coating)
  5. A-pillar
  6. A-pillar trim
  7. Window adjuster 443 845 631 A
  8. Outer plenum chamber cover
  9. PUR adhesive sealant joint Central within area of dimension -b- = 130 to 170 mm

Scheme 109

Scheme 109: SIDE WINDOW ASSEMBLY OVERVIEW
Scheme 109: SIDE WINDOW ASSEMBLY OVERVIEW
  1. Side window Remove side window, refer to «UNDAMAGED SIDE WINDOW, REMOVING»(ref-493016-S17604505052012080600000) Installing side window, refer to «SIDE WINDOW, INSTALLING»(ref-493016-S15049030532012080600000)
  2. Ceramic coating
  3. PUR adhesive sealant Bead diameter: width = 7 mm, height = 11 mm (including pre-coating, residual material on window glass and window flange) Minimum curing time, refer to «MINIMUM CURING TIME»(ref-493016-S16049724682012080600000)
  4. Sealing lip (component part of pre-coating)
  5. Securing pin Quantity: 2 Cut off before removing window
