BALL JOINT, CHECKING Volkswagen Beetle A4 facelift

Front Suspension (Convertible) 2 illustrations

BALL JOINT, CHECKING

Axial Play, Checking

Pull control arm firmly downward and press back up again.

Scheme 137

Scheme 137: BALL JOINT, CHECKING

Scheme 137: BALL JOINT, CHECKING

Radial Clearance, Checking

Press wheel firmly in and out at bottom.

Scheme 138

Scheme 138

Scheme 138

Note. There should be no noticeable or visible "play" in either of the two checks. Observe lower ball joint while performing checks. Make allowance for any wheel bearing play or "play" in strut mounting at top. Check rubber boot for damage, replace lower ball joint, if necessary.
