EXAMPLE Volkswagen Beetle A4 facelift

Controls, Housing - Automatic Transmission 01M (Convertible) 1 illustration

EXAMPLE

Measured value 2.00 mm =

Insert 1.7 mm thick shim.

Remove small input shaft bolt.

Insert correct shim -3- on small input shaft -arrow-.

Scheme 217

Scheme 217: EXAMPLE

Scheme 217: EXAMPLE

Tighten small input shaft bolt -1- with washer -2-.

Tightening torque 30 Nm.

Carry out planet carrier check measurement, PLANET CARRIER, CHECKING MEASUREMENT .
