Wiper/washer Systems (Hatchback): Overview Volkswagen Beetle A4

Scheme 1

1. Wiper Blade Adjusting park position, refer to «WINDSHIELD WIPER BLADES, ADJUSTING PARK POSITION»(ref-492832-S07163648932012080600000) .
2. Wiper Blade Removing and installing, refer to «WINDSHIELD WIPER BLADE»(ref-492832-S28319274632012080600000) .
3. Lever
4. Linkage
5. Crank
6. Windshield Wiper Motor -V- Removing and installing, refer to «WINDSHIELD WIPER SYSTEM»(ref-492832-S01315533862012080600000) .
7. Nut 20 Nm
8. Wiper Frame Removing and installing, refer to «WINDSHIELD WIPER SYSTEM»(ref-492832-S01315533862012080600000) .
9. Bolt 7 Nm
10. Grommet
11. Cap
12. Nut 20 Nm
13. Wiper Arm
14. Clip
15. Bolts
16. Spoiler

Scheme 2

1. Securing Strip
2. Electrical Wire for Heated Spray Nozzles
3. Hose
4. Cap With connector for heated spray nozzles.
5. Spray Nozzles Removing, refer to «WINDSHIELD WASHER SYSTEM SPRAY NOZZLES»(ref-492832-S17512992462012080600000) .
6. Tank for Window Washer System Remove the right front wheel housing liner.
7. Windshield Washer Pump -V5- Pull upward out of the rubber grommet.
8. Connector
9. Bolt 5 Nm
10. Connection for the Windshield Washer System Reservoir
11. Through Piece
12. Connector for the Heated Spray Nozzles
13. Hose Clip

Scheme 3

1. Spray Nozzle Holder with Spray Nozzles Removing and installing, refer to «HEADLAMP WASHER SYSTEM SPRAY NOZZLE HOLDER AND SPRAY NOZZLES»(ref-492832-S01067758422012080600000) .
2. Front Bumper Removing and installing, refer to «Removal and Installation»(ref-492841-S21271774222012080600000) .
3. Headlamp Washer System Hose
4. To the Headlamp Washer System Pump -V11
5. Retaining Spring
6. Bolt 5 Nm
7. Auxiliary Reservoir for the Headlamp Washer System Capacity: 2.85 liters Removing and installing, refer to «HEADLAMP WASHER SYSTEM AUXILIARY RESERVOIR»(ref-492832-S21083370942012080600000) .
8. Nut 2 Nm
9. Tank for Window Washer System Removing and installing, refer to -item
10. Headlamp Washer System Pump -V11- Removing and installing, refer to -item
11. Bolt 3.5 Nm
