2.0L - Engine Assembly - Engine Code(s): Aeg, Avh, BDC, Bev & Bgd (Hatchback): Specifications Volkswagen Beetle A4

Mechanical 5 illustrations ~116 words

ENGINE AND TRANSMISSION MOUNT, ALIGNMENT SPECIFICATIONS

WARNINGBefore loosening bolts, secure assembly using engine support bridge 10-222 A.

Engine Mount

Scheme 148

Scheme 148
Scheme 148

a - = 14.0 mm

b- = minimum 10.0 mm

Both bolt heads -1- must be flush with edge -c-.

Transmission Mount

Scheme 149

Scheme 149
Scheme 149

Edges -a- and -b- must be parallel to each other.

c- = 18 to 20 mm

Note. Tightening specifications of engine and transmission mounts ENGINE AND TRANSMISSION MOUNT TIGHTENING SPECIFICATIONS .

FASTENER TIGHTENING SPECIFICATIONS

Bolted connectionsTightening Specifications
Bolts and NutsM 610 Nm
M 715 Nm
M 825 Nm
M1040 Nm
M1260 Nm
Deviation from
Engine to transmission bolts, refer to [For transmission(s) 02E] FASTENER TIGHTENING SPECIFICATIONS , or refer to [For transmission(s) 02J] TRANSMISSION TO ENGINE TIGHTENING SPECIFICATIONS , or refer to [For transmission(s) 0A4] FASTENER TIGHTENING SPECIFICATIONS , or refer to [For transmission(s) 02M] FASTENER TIGHTENING SPECIFICATIONS [For transmission(s) 09G] FASTENER TIGHTENING SPECIFICATIONS or refer to [For transmission(s) 01M] FASTENER TIGHTENING SPECIFICATIONS
Converter to drive plate, refer to [For transmission(s) 09G] FASTENER TIGHTENING SPECIFICATIONS or refer to [For transmission(s) 01M] FASTENER TIGHTENING SPECIFICATIONS
Starter to transmission Removal and Installation
Install drive axle Removal and Installation

Note. Tightening specifications of engine and transmission mounts ENGINE AND TRANSMISSION MOUNT TIGHTENING SPECIFICATIONS .

ENGINE AND TRANSMISSION MOUNT TIGHTENING SPECIFICATIONS

Engine Mount

Scheme 150

Scheme 150: ENGINE AND TRANSMISSION MOUNT TIGHTENING SPECIFICATIONS
Scheme 150: ENGINE AND TRANSMISSION MOUNT TIGHTENING SPECIFICATIONS
1Mount to body (1)40 Nm + 90° ( 1 / 4 turn)
2Mount/bracket to body25 Nm
3Mount to engine bracket100 Nm
(1) Replace bolts
(1)Replace bolts

Transmission Mount

Scheme 151

Scheme 151
Scheme 151
1Mount to body (1)40 Nm + 90° ( 1 / 4 turn)
2Mounting to body25 Nm
3Mounting to transmission console100 Nm
(1) Replace bolts
(1)Replace bolts

Pendulum Support

Scheme 152

Scheme 152
Scheme 152
1Pendulum support to transmission (1)40 Nm + 90° ( 1 / 4 turn)
2Pendulum support to transmission (1)40 Nm + 90° ( 1 / 4 turn)
3Pendulum support to subframe (1)20 Nm + 90° ( 1 / 4 turn)
(1) Replace bolts
(1)Replace bolts
