Communication (Hatchback): Overview Volkswagen Beetle A4

Communication Devices 9 illustrations ~1514 words

CELLULAR PHONE AND TWO-WAY RADIO OPERATION

Cellular Phones and Portable Two-Way Radios with Separate External Antenna

  1. Radio remote controls (garage door opener) and wireless units (keyboard or PC mouse) may only be used in the vehicle if the transmitted output is maximum 100 mW.
  2. Please follow exactly the operating instructions and installation instructions of the manufacturer of mobile telephones, radio-based devices, and antennas.
  3. The devices' optimal range will only be reached with an exterior antenna.
  4. When telephone and two-way radio systems are installed properly, there is no danger to safety systems such as the ABS or the airbag. A prerequisite is however that there has been no intervention in their installations. Parallel wiring to such systems must be avoided.
  5. Excessively high electromagnetic fields can arise if mobile telephones and radio devices, with or without an incorrectly installed exterior antenna, are used.

NOTES ON OPERATION

  1. Never remove the memory device if you have selected the USB connection baseplate as the source. It may destroy the storage medium.
  2. Do not insert an MP3 player directly in the USB connection baseplate, the connection could be damaged. Always use a USB extension cable instead.
  3. Do not connect any other devises to the USB connection baseplate other than a USB memory stick or an MP3 player. It is not possible to play hard drives or USB hubs via the USB connection baseplate.
  4. The maximum input of the USB memory device must not exceed 2.5 W (500 mA/5 V).
  5. Never insert metal objects into the USB connection baseplate. They may cause a short circuit and damage the unit.
  6. If the USB connection baseplate does not recognize the device after 15 seconds, remove the device and insert it again.
  7. Some MP3 players must be activated with a button to create the USB connection. Refer to the Operating Instructions.
  8. The permissible temperature range of USB sticks and MP3 players is limited and often lies between 0° C and 40° C. For this reason, inform the customer that the storage medium must not be left in the vehicle for extended periods.

Scheme 13

Scheme 13: AMPLIFIER -R12- CONNECTORS
Scheme 13: AMPLIFIER -R12- CONNECTORS
  1. Left Rear Speaker -R4- (+)
  2. Left Rear Speaker -R4- (-)
  3. Right Rear Speaker -R5- (+)
  4. Right Rear Speaker -R5- (-)
  5. Left Front Bass Speaker -R21- (+)
  6. Left Front Bass Speaker -R21- (-)
  7. Right Front Bass Speaker -R23- (+)
  8. Right Front Bass Speaker -R23- (-)
  9. Left Front Bass Speaker -R21- (+)
  10. Right Front Bass Speaker -R23- (+)
  11. Left Front Bass Speaker -R21- (-)
  12. Right Front Bass Speaker -R23- (-)
  13. Left Front Treble Speaker -R20- (+)
  14. Left Front Treble Speaker -R20- (-)
  15. Right Front Treble Speaker -R22- (+)
  16. Right Front Treble Speaker -R22- (-)
  17. Not used
  18. Terminal 30
  19. Terminal 31
  20. Terminal 31
  21. Terminal 30
  22. Terminal 31
  23. Terminal 30

1 through 13 - not used

14 - Left rear signal input (+)

15 - Left rear signal input (-)

16 - Not used

17 - Right rear signal input (-)

18 - Right rear signal input (+)

19 - Not used

20 - Left front signal input (+)

21 - Left front signal input (-)

22 - Not used

23 - Right front signal input (-)

24 - Right front signal input (+)

Scheme 14

Scheme 14: ANTENNA -R11- OVERVIEW
Scheme 14: ANTENNA -R11- OVERVIEW
  1. Antenna Mast (Antenna -R11-)
  2. Antenna Base With Antenna amplifier -R24- (AM/FM)
  3. Antenna Wire AM/FM To the radio Black
  4. Nut M14 7 Nm
  5. Gasket

Scheme 15

Scheme 15: CD CHANGER -R41- HARNESS CONNECTORS
Scheme 15: CD CHANGER -R41- HARNESS CONNECTORS
  1. Data in
  2. Clock
  3. Terminal 31
  4. Data out
  5. Not used
  6. Terminal 30
  7. Right audio output wire
  8. Control wire
  9. Audio ground
  10. Left audio output wire
  11. Not used
  12. Terminal 58d

PREMIUM 5.5 OVERVIEW

Only the position of the speaker on the left vehicle side is shown. The position of the speaker on the right vehicle side is identical.

Scheme 16

Scheme 16: PREMIUM 5.5 OVERVIEW
Scheme 16: PREMIUM 5.5 OVERVIEW
  1. Radio In center of the instrument panel. Premium 5.5 with cassette or CD player. Gamma with cassette player. Gamma CD with CD player. Connectors, refer to «PREMIUM 5.5 MULTI-PIN CONNECTORS»(ref-492830-S23078210982012080600000) . Removing and installing, refer to «RADIO»(ref-492830-S06147958692012080600000)
  2. Front Treble Speaker In the trim at the top of the A-pillar. Removing and installing, refer to «FRONT TREBLE SPEAKER»(ref-492830-S12836668712012080600000) .
  3. CD Changer -R41- Inside the luggage compartment or inside the center console. Connectors, refer to «CD CHANGER -R41- HARNESS CONNECTORS»(ref-492830-S13655538052012080600000) . Removing and installing, refer to «CD CHANGER -R41»(ref-492830-S27802536282012080600000) - USB Connection Baseplate -R193- In center console. Connectors, refer to «USB CONNECTION BASEPLATE -R193- CONNECTOR»(ref-492830-S16912452452012080600000) . Removing and installing, refer to «USB CONNECTION BASEPLATE -R193»(ref-492830-S30444442952012080600000) .
  4. Roof Antenna Removing and installing, refer to «ROOF ANTENNA -R11»(ref-492830-S37562467262012080600000) .
  5. Rear Bass Speaker In the side trim. Removing and installing, refer to «REAR BASS SPEAKER»(ref-492830-S01616018282012080600000) .
  6. Front Bass Speaker In the door. Removing and installing, refer to «FRONT BASS SPEAKER»(ref-492830-S21334718942012080600000) .
  7. External Audio Source Connection -R199- Inside the instrument panel under the switches/next to the glove compartment on the left side. Removing and installing, refer to «EXTERNAL AUDIO SOURCE CONNECTION -R199»(ref-492830-S01379366792012080600000) .

PREMIUM 5.5 - MONSOON OVERVIEW

Only the position of the speaker on the left vehicle side is shown. The position of the speaker on the right vehicle side is identical.

Scheme 17

Scheme 17: PREMIUM 5.5 - MONSOON OVERVIEW
Scheme 17: PREMIUM 5.5 - MONSOON OVERVIEW
  1. Radio In center of the instrument panel. Premium 5.5 with cassette or CD player. Gamma CD with CD player. Connectors, refer to «PREMIUM 5.5 - MONSOON MULTI-PIN CONNECTORS»(ref-492830-S28056855092012080600000) . Removing and installing, refer to «RADIO»(ref-492830-S06147958692012080600000) .
  2. Midrange Speaker In plenum chamber. Removing and installing, refer to «MIDRANGE SPEAKER IN INSTRUMENT PANEL»(ref-492830-S22347006232012080600000) .
  3. Front Treble Speaker In plenum chamber. Removing and installing, refer to «TREBLE SPEAKER IN INSTRUMENT PANEL»(ref-492830-S25443112732012080600000) .
  4. CD Changer -R41- Inside the luggage compartment or inside the center console. Connectors, refer to «CD CHANGER -R41- HARNESS CONNECTORS»(ref-492830-S13655538052012080600000) . Removing and installing, refer to «CD CHANGER -R41»(ref-492830-S27802536282012080600000) . - USB Connection Baseplate -R193- In center console. Connectors, refer to «USB CONNECTION BASEPLATE -R193- CONNECTOR»(ref-492830-S16912452452012080600000) . Removing and installing, refer to «USB CONNECTION BASEPLATE -R193»(ref-492830-S30444442952012080600000) .
  5. Roof Antenna Removing and installing, refer to «ROOF ANTENNA -R11»(ref-492830-S37562467262012080600000) .
  6. Digital Sound System Control Module -R12- In the luggage compartment. Connectors, refer to «AMPLIFIER -R12- CONNECTORS»(ref-492830-S40765374652012080600000) . Removing and installing, refer to «AMPLIFIER -R12»(ref-492830-S08955079992012080600000) .
  7. Rear Bass Speaker In the side trim. Removing and installing, refer to «REAR BASS SPEAKER»(ref-492830-S01616018282012080600000) .
  8. Front Bass Speaker In the door. Removing and installing, refer to «FRONT BASS SPEAKER»(ref-492830-S21334718942012080600000) .
  9. External Audio Source Connection -R199- Inside the instrument panel under the switches/next to the glove compartment on the left side. Removing and installing, refer to «EXTERNAL AUDIO SOURCE CONNECTION -R199»(ref-492830-S01379366792012080600000) .

RADIO/GPS/TELEMATICS ANTENNA OVERVIEW

Vehicles with telematics have a rear triplex antenna on the roof.

This antenna has connections for radio/GPS/telematics.

Scheme 18

Scheme 18: RADIO/GPS/TELEMATICS ANTENNA OVERVIEW
Scheme 18: RADIO/GPS/TELEMATICS ANTENNA OVERVIEW
  1. Antenna Base With Antenna amplifier -R24- (AM/FM)/Navigation system antenna -R50
  2. Antenna Mast Antenna -R11- /Telematics auxiliary antenna -R90
  3. Gasket
  4. Antenna Connection GPS To the Telematics control module -J499- Blue
  5. Nut M14 7 Nm
  6. Antenna Connection AM/FM To the radio Black
  7. Antenna Connection Telematics To the Telematics control module -J499- Gray

Scheme 19

Scheme 19: TELEMATICS SYSTEM OVERVIEW
Scheme 19: TELEMATICS SYSTEM OVERVIEW
  1. Antenna -R11- /Antenna amplifier -R24- /Navigation system antenna -R50- Roof antenna Removing and installing, refer to «RADIO/GPS/TELEMATICS ANTENNA»(ref-492830-S39476149192012080600000) .
  2. Alarm Horn Relay -J641- Installed on central electronics relay carrier. Refer to the appropriate SYSTEM WIRING DIAGRAMS information.
  3. Alarm System Flasher Relay -J237- Installed on central electronics relay carrier. Refer to Refer to the appropriate SYSTEM WIRING DIAGRAMS information.
  4. Not Installed
  5. Telephone Microphone -R38- In Front Interior Light -W1- Removing and installing, refer to «TELEPHONE MICROPHONE -R38»(ref-492830-S29756809162012080600000) .
  6. Telematics Control Head -E264- Inside the interior rearview mirror. OnStar button «ONSTAR BUTTON»(ref-492830-S41542257562012080600000) . With Telematics indicator lamp -K186-. Removing and installing, refer to «TELEMATICS CONTROL HEAD -E264»(ref-492830-S15196294602012080600000) .
  7. Telematics Indicator Lamp -K186- In the Telematics control head -E264-. Fault finding with Telematics indicator lamp -K186-, refer to «TELEMATICS INDICATOR LAMP -K186- MALFUNCTION RECOGNITION»(ref-492830-S14137976082012080600000) .
  8. Radio In center console.
  9. Telematics Control Module -J499- Behind the right side trim under the speaker. Removing and installing, refer to «TELEMATICS CONTROL MODULE -J499»(ref-492830-S23249382862012080600000) . Connector assignment, refer to «TELEMATICS CONTROL MODULE -J499- CONNECTORS»(ref-492830-S34214516612012080600000) .

Scheme 20

Scheme 20: TELEMATICS CONTROL MODULE -J499- CONNECTORS
Scheme 20: TELEMATICS CONTROL MODULE -J499- CONNECTORS

A - Blue 42-pin connector, T42

B - Antenna connection (GPS)

C - Antenna connection (telematics)

Scheme 21

Scheme 21
Scheme 21
  1. Alarm horn relay -J641- activation
  2. Lock vehicle activation
  3. Audio in cellular telephone (not used)
  4. Cellular telephone battery charge status (not used)
  5. Cellular telephone ground (not used)
  6. Cellular telephone TXD (not used)
  7. Cellular telephone RTS (not used)
  8. Cellular telephone shielding (not used)
  9. Not used
  10. LF signal output (+) to radio
  11. Telematics auxiliary speaker -R91- (+) (not used)
  12. Telephone Microphone -R38- (+)
  13. K diagnostic
  14. Terminal 15
  15. Telematics indicator lamp -K186- status red
  16. Telematics indicator lamp -K186- status green
  17. Not used
  18. Terminal 31
  19. Terminal 31
  20. Not used
  21. Not used
  22. Alarm system flasher relay -J237- activation
  23. Unlock vehicle activation
  24. Cellular telephone audio out (not used)
  25. Cellular telephone ground (not used)
  26. Cellular telephone power supply (not used)
  27. RXD cellular telephone (not used)
  28. Cellular telephone RTS (not used)
  29. Cellular telephone signal status (not used)
  30. Not used
  31. LF signal output (-) to radio
  32. Telematics auxiliary speaker -R91- (-) (not used)
  33. Telephone Microphone -R38- (-)
  34. Telephone mute to radio
  35. Emergency button signal input from the Telematics control head -E264
  36. OnStar button signal input from the Telematics control head -E264
  37. Not used
  38. Crash signal from Airbag Control Module -J234
  39. Terminal 30
  40. Terminal 30
  41. Telematics emergency battery -A16- (+) (not used)
  42. Telematics emergency battery -A16- (-) (not used)
