Power Window Control (Diagnostics): Overview Toyota Yaris II рестайлинг

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

SYSTEM DESCRIPTION

1. POWER WINDOW CONTROL SYSTEM DESCRIPTION The power window control system controls the power window UP / DOWN function using the regulator motors. 3 Door: The main controls of this system are: the power window regulator master switch, which is built into the driver side door, and the power window regulator switch, which is built into the passenger side door. Pressing the regulator switch or either of the switches on the master switch transmits an UP / DOWN signal to the corresponding power window regulator motor. Except 3 door: The main controls of this system are: the power window regulator master switch, which is built into the driver side door, and the power window regulator switches, which are built into the passenger side door and rear doors. Pressing the regulator switch or any of the switches on the master switch transmits an UP / DOWN signal to the corresponding power window regulator motor.
2. FUNCTION OF MAIN COMPONENT Component Outline Power Window Regulator Master Switch Assembly Controls window operations for all windows When window lock switch is set to lock position, window operation is only possible with master switch Power Window Regulator Switch Assembly 3 Door: Located on passenger side door Except 3 door: Located on passenger side door and rear doors Each regulator switch controls window operations for its respective window Power Window Regulator Motor Assembly Receives switch signals and changes signals into motor activation to change window position
3. SYSTEM FUNCTION The power window control system has the following functions. Function Outline Manual UP / DOWN function Driver side power window: Function that raises window while power window switch is pulled up, and lowers window while pushed halfway down (window stops as soon as switch is released) Other power windows: Function that raises window while power window switch is pulled up, and lowers window while pushed down (window stops as soon as switch is released) AUTO DOWN function Function that enables window of driver side door to be fully opened by one full push downward on power window switch Remote UP / DOWN function 3 Door: Function that allows power window master switch to control manual UP / DOWN operation of passenger side power window Except 3 door: Function that allows power window master switch to control manual UP / DOWN operation of passenger side power window and rear power windows Window lock function 3 Door: Function where passenger side power window operation is disabled when window lock switch of master switch is pressed Passenger side power window can be operated when window lock switch is pressed again Except 3 door: Function where passenger side power window and rear power window operation is disabled when window lock switch of master switch is pressed Passenger side power window and rear power windows can be operated when window lock switch is pressed again

DESCRIPTION

3 Door

With the ignition switch ON, the power window regulator master switch transmits remote switch signals to the regulator switch of the passenger door power window. Then, the regulator switch drives the passenger power window regulator motor.

Except 3 door

With the ignition switch ON, the power window regulator master switch transmits remote switch signals to the regulator switches of the passenger door power window and rear door power windows. Then, each regulator switch drives its respective power window regulator motor.

Scheme 9

If the manual UP / DOWN and AUTO DOWN functions do not operate, a malfunction may exist in the power window regulator master switch, power window regulator motor or wire harness.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. INSPECT POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (DRIVER SWITCH) 3 Door: Inspect the driver switch. Remove the power window regulator master switch assembly. Measure the resistance of the switch when the switch is operated. Standard resistance Window Lock Switch Condition Power Window Switch Condition Tester Connection Specified Condition Always (ON / OFF) UP 7 (E) - 12 (D) 10 (U) - 15 (B) Below 1 ohms Always (ON / OFF) OFF 7 (E) - 10 (U) 7 (E) - 12 (D) Below 1 ohms Always (ON / OFF) DOWN 7 (E) - 10 (U) 12 (D) - 15 (B) Below 1 ohms Always (ON / OFF) AUTO DOWN 7 (E) - 10 (U) 12 (D) - 15 (B) Below 1 ohms Reinstall the power window regulator master switch assembly. Except 3 door: Inspect the driver switch. Remove the power window regulator master switch assembly. Measure the resistance of the switch when the switch is operated. Standard resistance Window Lock Switch Condition Power Window Switch Condition Tester Connection Specified Condition Always (ON / OFF) UP 1 (E) - 4 (D) 3 (U) - 6 (B) Below 1 ohms Always (ON / OFF) OFF 1 (E) - 3 (U) 1 (E) - 4 (D) Below 1 ohms Always (ON / OFF) DOWN 1 (E) - 3 (U) 6 (B) - 4 (D) Below 1 ohms Always (ON / OFF) AUTO DOWN 1 (E) - 3 (U) 6 (B) - 4 (D) Below 1 ohms Reinstall the power window regulator master switch assembly. NG --> REPLACE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - MOTOR (DRIVER SIDE)) Disconnect the G1 power window regulator master switch assembly connector. Disconnect the G4 power window regulator motor assembly connector. Measure the resistance of the wire harness side connectors. Standard resistance 3 Door Tester Connection Specified Condition G1-12 (D) - G4-1 Below 1 ohms G1-10 (U) - G4-2 Below 1 ohms G1-12 (D) or G4-1 - Body ground 10 kohms or higher G1-10 (U) or G4-2 - Body ground 10 kohms or higher Except 3 door Tester Connection Specified Condition G1-4 (D) - G4-1 Below 1 ohms G1-3 (U) - G4-2 Below 1 ohms G1-4 (D) or G4-1 - Body ground 10 kohms or higher G1-3 (U) or G4-2 - Body ground 10 kohms or higher Reconnect the G1 power window regulator master switch assembly connector. Reconnect the G4 power window regulator motor assembly connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (DRIVER SIDE) Remove the power window regulator motor assembly. Apply battery voltage to connector terminals 1 and 2. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. Check that the motor gear rotates smoothly as follows. OK Measurement Condition Specified Condition Battery positive (+) --> 1 Battery negative (-) --> 2 Motor gear rotates counterclockwise Battery positive (+) --> 2 Battery negative (-) --> 1 Motor gear rotates clockwise Reinstall the power window regulator motor assembly NG --> REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (DRIVER SIDE) OK --> GO TO «POWER WINDOWS DO NOT OPERATE AT ALL»(ref-394605-S41989992372011040800000)

If the passenger side manual UP / DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window regulator switch, power window regulator master switch or wire harness.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

1. CHECK POWER WINDOW REGULATOR SWITCH ASSEMBLY (PASSENGER SIDE) (POWER SOURCE) Disconnect the F1 power window regulator switch assembly connector. Measure the voltage of the wire harness side connector. Standard voltage Tester Connection Condition Specified Condition F1-3 - Body ground Ignition switch ON 11 to 14 V Reconnect the F1 power window regulator switch assembly connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (PASSENGER SIDE) Remove the power window regulator switch assembly. Measure the resistance of the switch when the switch is operated. Standard resistance Tester Connection Switch Condition Specified Condition 3 - 4 2 - 1 UP Below 1 ohms 5 - 4 2 - 1 OFF Below 1 ohms 5 - 4 3 - 1 DOWN Below 1 ohms Reinstall the power window regulator switch assembly. NG --> REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (PASSENGER SIDE) OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (SWITCH (PASSENGER SIDE) - MOTOR (PASSENGER SIDE)) Disconnect the F1 power window regulator switch assembly connector. Disconnect the F4 power window regulator motor assembly connector. Measure the resistance of the wire harness side connectors. Standard resistance Tester Connection Specified Condition F1-1 - F4-1 Below 1 ohms F1-4 - F4-2 Below 1 ohms F1-1 or F4-1 - Body ground 10 kohms or higher F1-4 or F4-2 - Body ground 10 kohms or higher Reconnect the F1 power window regulator switch assembly connector. Reconnect the F4 power window regulator motor assembly connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (PASSENGER SIDE) Remove the power window regulator motor assembly. Apply battery voltage to connector terminals 1 and 2. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. Check that the motor gear rotates smoothly as follows. OK Measurement Condition Specified Condition Battery positive (+) --> 1 Battery negative (-) --> 2 Motor gear rotates clockwise Battery positive (+) --> 2 Battery negative (-) --> 1 Motor gear rotates counterclockwise Reinstall the power window regulator motor assembly. NG --> REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (PASSENGER SIDE) OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - SWITCH (PASSENGER SIDE)) Disconnect the G1 power window regulator master switch assembly connector. Disconnect the F1 power window regulator switch assembly connector. Measure the resistance of the wire harness side connectors. Standard resistance 3 Door Tester Connection Specified Condition G1-16 (U) - F1-5 Below 1 ohms G1-18 (D) - F1-2 Below 1 ohms G1-16 (U) or F1-5 - Body ground 10 kohms or higher G1-18 (D) or F1-2 - Body ground 10 kohms or higher Except 3 door Tester Connection Specified Condition G1-16 (U) - F1-5 Below 1 ohms G1-15 (D) - F1-2 Below 1 ohms G1-16 (U) or F1-5 - Body ground 10 kohms or higher G1-15 (D) or F1-2 - Body ground 10 kohms or higher Reconnect the G1 power window regulator master switch assembly connector. Reconnect the F1 power window regulator switch assembly connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
6. INSPECT POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (FRONT PASSENGER SWITCH) 3 Door: Inspect the front passenger switch. Remove the power window regulator master switch. Measure the resistance of the switch when the switch is operated. Standard resistance Window Lock Switch Condition Power Window Switch Condition Tester Connection Specified Condition OFF UP 7 (E) - 18 (D) 16 (U) - 15 (B) Below 1 ohms OFF OFF 7 (E) - 16 (U) 7 (E) - 18 (D) Below 1 ohms OFF DOWN 7 (E) - 16 (U) 15 (B) - 18 (D) Below 1 ohms ON UP 7 (E) - 18 (D) 10 kohms or higher 16 (U) - 15 (B) Below 1 ohms ON OFF 16 (U) - 18 (D) Below 1 ohms ON DOWN 7 (E) - 16 (U) 10 kohms or higher 15 (B) - 18 (D) Below 1 ohms Reinstall the power window master switch. Except 3 door: Inspect the front passenger switch. Remove the power window regulator master switch. Measure the resistance of the switch when the switch is operated. Standard resistance Window Lock Switch Condition Power Window Switch Condition Tester Connection Specified Condition OFF UP 1 (E) - 15 (D) 6 (B) - 16 (U) Below 1 ohms OFF OFF 1 (E) - 16 (U) 1 (E) - 15 (D) Below 1 ohms OFF DOWN 1 (E) - 16 (U) 6 (B) - 15 (D) Below 1 ohms ON UP 1 (E) - 15 (D) 10 kohms or higher 6 (B) - 16 (U) Below 1 ohms ON OFF 15 (D) - 16 (U) Below 1 ohms ON DOWN 1 (E) - 16 (U) 10 kohms or higher 6 (B) - 15 (D) Below 1 ohms Reinstall the power window regulator master switch. NG --> REPLACE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY OK --> GO TO «POWER WINDOWS DO NOT OPERATE AT ALL»(ref-394605-S41989992372011040800000)

If the rear LH side manual UP/DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window regulator switch, power window regulator master switch or wire harness.

Scheme 23

If the rear RH side manual UP/DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window regulator switch, power window regulator master switch or wire harness.

Scheme 24

If none of the power windows operates, the power window regulator master switch may have no power or may be malfunctioning.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. INSPECT FUSES (ECU-B, ECU-IG) Remove the ECU-B fuse from the engine room relay block. Remove the ECU-IG fuse from the main body ECU. Measure the resistance. Standard resistance Below 1ohms Reinstall the fuses. NG --> REPLACE FUSE OK: Go to next step
2. INSPECT MAIN BODY ECU (PWR RELAY) Remove the POWER fuse from the main body ECU. Turn the ignition switch to ON. Measure the voltage between the POWER fuse terminal of the main body ECU and body ground. Standard voltage Tester Connections Ignition Switch Conditions Specified Conditions POWER fuse terminal (1) - Body ground ON 11 to 14 V Reinstall the POWER fuse. NG --> REPLACE MAIN BODY ECU (PWR RELAY) OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (POWER WINDOW MASTER SWITCH - BATTERY AND BODY GROUND) Disconnect the G1 power window regulator master switch assembly connector. Measure the voltage of the wire harness side connector. Standard voltage 3 Door Tester Connection Condition Specified Condition G1-15 (B)- Body ground Ignition switch ON 11 to 14 V Standard voltage Except 3 door Tester Connection Condition Specified Condition G1-6 (B)- Body ground Ignition switch ON 11 to 14 V Measure the resistance of the wire harness side connector. Standard resistance 3 Door Tester Connection Specified Condition G1-7 (E)- Body ground Below 1 ohms Standard resistance Except 3 door Tester Connection Specified Condition G1-1 (E)- Body ground Below 1 ohms Reconnect the G1 power window regulator master switch assembly connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY
