Automatic Transmission Automatic (Diagnostic Codes): Other — Automatic Transmission Automatic (Diagnostic Codes) — Automatic Trans

MONITOR STRATEGY

Related DTCs	P0705: Park/neutral position switch/Verify switch input
Required sensors/Components	Park/neutral position switch, Transmission control switch
Frequency of operation	Continuous
Duration	Condition (A), (C): 2 seconds Condition (B): 60 seconds
MIL operation	2 driving cycles
Sequence of operation	None

TYPICAL ENABLING CONDITIONS

The monitor runs whenever the following DTCs are not present	None
Ignition switch	ON
Battery voltage	10.5 V or more

TYPICAL MALFUNCTION THRESHOLDS

One of the following conditions is met: Condition (A), (B) or (C)

When 2 or more of the following signals are input at the same time

Number of the following signals input at same time	2 or more
One of the following conditions is met; P switch N switch Park/neutral position switch (STAR)	ON
R switch	ON
D switch	ON
2 switch	ON
L switch	ON

CONDITION (A)

All of the following conditions are met

P switch	OFF
N switch	OFF
Park/neutral position switch (STAR)	OFF
R switch	OFF
D switch	OFF
2 switch	OFF
L switch	OFF

CONDITION (B)

When any of following conditions is met, the 3 position input signal is ON for 2 seconds or more (2-trip detection logic).

P switch	ON
N switch	ON
Park/neutral position switch (STAR)	ON
R switch	ON
2 switch	ON
L switch	ON

CONDITION (C)

Scheme 457

Scheme 457: WIRING DIAGRAM

Related DTCs	P0712: ATF temperature sensor/Range check (Low resistance) P0713: ATF temperature sensor/Range check (High resistance)
Required sensors/Components	ATF temperature sensor
Frequency of operation	Continuous
Duration	0.5 seconds
MIL operation	Immediate
Sequence of operation	None

The monitor runs whenever the following DTCs are not present.

None

P0712: RANGE CHECK (LOW RESISTANCE)

P0713: Range check (High resistance)

One of the following conditions is met: Condition (A) or (B)

Engine coolant temperature or intake air temperature at engine start	29.375 °C (-20.875 °F) or less
Time after engine start	10 minutes or more
ECT sensor circuit fail (P0115, P0117, P0118)	Not detected
IAT sensor circuit fail (P0097, P0098, P0110, P0112, P0113)	Not detected

CONDITION (A)

Engine coolant temperature and intake air temperature at engine start	More than -29.375 °C (-20.875 °F)
Time after engine start	10 seconds or more
ECT sensor circuit fail (P0115, P0117, P0118)	Not detected
IAT sensor circuit fail (P0097, P0098, P0110, P0112, P0113)	Not detected

CONDITION (B)

ATF temperature sensor resistance

Less than 79 ohms

P0712: RANGE CHECK (LOW RESISTANCE)

ATF temperature sensor resistance

More than 176 kohms

P0713: RANGE CHECK (HIGH RESISTANCE)

COMPONENT OPERATING RANGE

ATF temperature

Atmospheric temperature to approximately 130 °C (266 °F)

Scheme 458

Scheme 458: WIRING DIAGRAM

Related DTCs	P0711: ATF temperature sensor/Rationality check
Required sensors/Components	ATF temperature sensor
Frequency of operation	Continuous
Duration	Condition (A), (B), (C), and (D): 3 seconds Condition (E): Continuous
MIL operation	2 driving cycles
Sequence of operation	None

Transmission Fluid Temperature Sensor "A" circuit	No circuit malfunction (P0712, P0713)
ECT sensor circuit	No circuit malfunction (P0115, P0117, P0118)
IAT sensor circuit	No circuit malfunction (P0110, P0112, P0113)
Electronic Throttle Control System	No circuit malfunction (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135)
Soak Timer circuit	No circuit malfunction (P2610)

ALL

Time after engine start	10 minutes or more
Driving distance after engine start	5 km (3.1 miles) or more
IAT (12 seconds after engine start)	15 °C (59 °F) or more
ECT (12 seconds after engine start)	15 °C (59 °F) or more
Soak time	5 hours
Accumulated driving time*1	100 seconds or more
*1: Following conditions are met
Engine speed - Input (Turbine) speed	50 RPM or more
Output speed	400 RPM or more
Throttle valve opening angle	3%
Shift position	Not "N" or "P"
Engine speed	300 RPM or more

CONDITION (A)

Time after engine start	18 minutes and 20 seconds or more
Accumulated driving time*1	3 minutes and 50 seconds or more
Driving distance after engine start	9 km (5.6 miles) or more
IAT (12 seconds after engine start)	10 °C (50 °F) or more
ECT (12 seconds after engine start)	10 °C (50 °F) or more

CONDITION (B)

Time after engine start	30 minutes or more
Accumulated driving time*1	6 minutes and 20 seconds or more
Driving distance after engine start	15 km (9.3 miles) or more
IAT (12 seconds after engine start)	15 °C (5 °F) or more
ECT (12 seconds after engine start)	15 °C (5 °F) or more

CONDITION (C)

Time after engine start	40 minutes or more
Accumulated driving time*1	9 minutes and 10 seconds or more
Driving distance after engine start	20 km (12.4 miles) or more

CONDITION (D)

Time after ECT reaches 60 °C (140 °F)	10 seconds or more
Transmission fluid temperature (12 seconds after engine start)	100 °C (212 °F) or more
ECT (12 seconds after engine start)	Less than 35 °C (95 °F)

CONDITION (E)

ATF temperature

Less than 10 °C (50 °F)

CONDITION (A)

ATF temperature

100 °C (212 °F) or more

CONDITION (B)

ATF temperature

10 to 100 °C (50 to 212 °F)

PROCEDURE

CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0711) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Display (DTC output) Proceed to P0711 A P0711 and other DTCs B HINT: If any DTCs codes besides P0711 are output, perform troubleshooting for those DTCs first. B --> See step 4 A: Go to next step
CHECK TRANSMISSION FLUID LEVEL OK Automatic transmission fluid level is correct. NG --> ADD FLUID OK --> See step 3
REPLACE TRANSMISSION WIRE (ATF TEMPERATURE SENSOR). Refer to «REMOVAL»(ref-394505-S03479659542011040800000)
GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394515-S17127186292011040800000)

Related DTCs	P0717: Turbine speed sensor/Verify pulse input
Required sensors/Components	Transmission revolution sensor (Speed sensor (NT))
Frequency of operation	Continuous
Duration	5 seconds
MIL operation	Immediate
Sequence of operation	None

Shift change	After shift change is completed and before starting next shift change operation
ECM selected gear	3rd or 4th
Output shaft RPM	1000 RPM or more
R switch	OFF
L switch	OFF
Transmission range switch fail (P0705)	Not detected
Battery voltage	8 V or more
Ignition switch	ON
Starter	OFF
Engine	Running

Sensor signal RPM

Less than 300 RPM

Transmission revolution sensor (speed sensor (NT))

Input turbine speed is equal to engine speed when lock-up ON

Scheme 459

Scheme 459: WIRING DIAGRAM

Related DTCs	P0751: Shift solenoid valve S1/OFF malfunction Shift solenoid valve S1/ON malfunction
Required sensors/Components	Shift solenoid valve S1, Speed sensor (NT), Speed sensor (SPD)
Frequency of operation	Continuous
Duration	OFF malfunction (a): 0.85 seconds OFF malfunction (b): 0.8 seconds ON malfunction (a): 0.8 seconds ON malfunction (b): 0.8 seconds
MIL operation	2 driving cycle
Sequence of operation	None

The following conditions are common to all OFF malfunctions and ON malfunctions.

ECT (Engine Coolant Temperature)	60 °C (140 °F) or more
Time after shifting N to D	4.5 seconds or more
Transmission shift position	D
Shift Solenoid "A" (S1) circuit	No circuit malfunction (P0973, P0974)
Shift Solenoid "B" (S2) circuit	No circuit malfunction (P0976, P0977)
ECT sensor circuit	No circuit malfunction (P0115, P0117, P0118)
Turbine Speed Sensor circuit	No circuit malfunction (P0717)
Vehicle Speed Sensor "A" circuit	No circuit malfunction (P0500)
Electronic Throttle Control System	No circuit malfunction (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135)

ECM gearshift command	1st
Vehicle speed	9 to 40 km/h (5.6 to 24.9 mph)
Throttle valve opening angle	9% or more 7% or more at engine speed of 1900 RPM (Conditions vary with engine speed)

OFF MALFUNCTION (A)

ECM gearshift command	4th
Last ECM selected gear	3rd

OFF MALFUNCTION (B)

ECM gearshift command	4th
Last ECM selected gear	3rd

ON MALFUNCTION (A)

ECM gearshift command	4th
V current - V last V current: Vehicle speed at current ECM selected gear V last: Vehicle speed at last ECM selected gear	Less than 15 km/h (9.3 mph)
TH current - TH last TH current: Throttle valve opening angle at current ECM selected gear TH last: Throttle valve opening angle at last ECM selected gear	Less than 30%
Vehicle speed (current)	Less than 85 km/h (52.8 mph)
Throttle valve opening angle (current)	Less than 45%
Engine speed (current)	3200 RPM or more

ON MALFUNCTION (B)

[OFF malfunction]

Both of the following conditions met: OFF malfunctions (a) and (b) 2 detections are necessary per driving cycle. 1st detection: Temporary flag ON 2nd detection: Pending fault code ON

Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed

0.64 to 0.78

OFF MALFUNCTION (A)

Input speed/Output speed (NT/NO)

Changes as follows 0.95 to 1.09 (Last) to 0.64 to 0.78 (Current)

OFF MALFUNCTION (B)

[ON malfunction]

Both of the following conditions met: ON malfunctions (a) and (b)

Input speed/Output speed (NT/NO)

Does not change as follows 0.95 to 1.09 (Last) to 0.64 to 0.78 (Current)

ON MALFUNCTION (A)

NE change HINT: NE current - NE last NE current: Engine speed at current ECM selected gear NE last: Engine speed at last ECM selected gear

1100 RPM or more

ON MALFUNCTION (B)

Related DTCs	P0756: Shift solenoid valve S2/OFF malfunction Shift solenoid valve S2/ON malfunction
Required sensors/Components	Shift solenoid valve S2, Speed sensor (NT), Speed sensor (SPD)
Frequency of operation	Continuous
Duration	0.85 seconds
MIL operation	2 driving cycle
Sequence of operation	None

The following conditions are common to all OFF malfunctions and ON malfunctions.

ECT (Engine Coolant Temperature)	60 °C (140 °F) or more
Transmission shift position	D
Time after shifting N to D	4.5 seconds or more
Shift Solenoid "A" (S1) circuit	No circuit malfunction (P0973, P0974)
Shift Solenoid "B" (S2) circuit	No circuit malfunction (P0976, P0977)
ECT sensor circuit	No circuit malfunction (P0115, P0117, P0118)
Turbine Speed Sensor circuit	No circuit malfunction (P0717)
Vehicle Speed Sensor "A" circuit	No circuit malfunction (P0500)
Electronic Throttle Control System	No circuit malfunction (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135)

ECM gearshift command	1st
Vehicle speed	9 to 40 km/h (5.6 to 24.9 mph)
Throttle valve opening angle	7% or more at engine speed of 1900 RPM (Conditions vary with engine speed)

OFF MALFUNCTION (A)

ECM gearshift command	3rd
Vehicle speed	9 km/h (5.6 mph) or more
Throttle valve opening angle	7% or more at engine speed of 1900 RPM (Conditions vary with engine speed)

OFF MALFUNCTION (B)

ECM gearshift command	4th
Vehicle speed	9 km/h (5.6 mph) or more
Throttle valve opening angle	7% or more at engine speed of 1900 RPM (Conditions vary with engine speed)

OFF MALFUNCTION (C)

ECM gearshift command	2nd
Vehicle speed	9 km/h (5.6 mph) or more
Throttle valve opening angle	7% or more at engine speed of 1900 RPM (Conditions vary with engine speed)

ON MALFUNCTION (A)

ECM gearshift command	3rd
Vehicle speed	9 km/h (5.6 mph) or more
Throttle valve opening angle	7% or more at engine speed of 1900 RPM (Conditions vary with engine speed)

ON MALFUNCTION (B)

ECM gearshift command	4th
Vehicle speed	9 km/h (5.6 mph) or more
Throttle valve opening angle	7% or more at engine speed of 1900 RPM (Conditions vary with engine speed)

ON MALFUNCTION (C)

[OFF malfunction]

All of the following conditions met: OFF malfunctions (a), (b) and (c) 2 detections are necessary per driving cycle. 1st detection: Temporary flag ON 2nd detection: Pending fault code ON

Input speed/Output speed (NT/NO) NT: Input (turbine) speed NO: Internal counter shaft speed

1.50 to 1.80

OFF MALFUNCTION (A)

Input speed/Output speed (NT/NO)

0.95 to 1.09

OFF MALFUNCTION (B)

Input speed/Output speed (NT/NO)

0.95 to 1.09

OFF MALFUNCTION (C)

[ON malfunction]

All of the following conditions met: ON malfunctions (a), (b) and (c)

Input speed/Output speed (NT/NO)

2.75 to 3.35

ON MALFUNCTION (A)

Input speed/Output speed (NT/NO)

0.64 to 0.78

ON MALFUNCTION (B)

Input speed/Output speed (NT/NO)

0.64 to 0.78

ON MALFUNCTION (C)

Related DTCs	P0787: Shift timing solenoid/Range check (Low resistance) P0788: Shift timing solenoid/Range check (High resistance)
Required sensors/Components	Shift solenoid valve ST
Frequency of operation	Continuous
Duration	0.128 seconds
MIL operation	Immediate
Sequence of operation	None

The monitor runs whenever the following DTCs are not present	None
Solenoid	ON
Time after solenoid OFF to ON	0.008 seconds or more
Battery voltage	8 V or more
Ignition switch	ON
Starter	OFF

P0787: RANGE CHECK (LOW RESISTANCE)

The monitor runs whenever the following DTCs are not present	None
Solenoid	OFF
Time after solenoid ON to OFF	0.008 seconds or more
Battery voltage	8 V or more
Ignition switch	ON
Starter	OFF

P0788: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve ST resistance

8 ohms or less

P0787: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve ST resistance

100 kohms or more

P0788: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve ST resistance

11 to 15 ohms at 20 °C (68 °F)

Scheme 460

Scheme 460: WIRING DIAGRAM

Related DTCs	P0973: Shift solenoid valve S1/Range check (Low resistance) P0974: Shift solenoid valve S1/Range check (High resistance)
Required sensors/Components	Shift solenoid valve S1
Frequency of operation	Continuous
Duration	0.128 seconds or more
MIL operation	Immediate
Sequence of operation	None

The monitor runs whenever the following DTCs are not present.	None
Solenoid	ON
Time after solenoid OFF to ON	0.008 seconds or more

P0973: RANGE CHECK (LOW RESISTANCE)

The monitor runs whenever the following DTCs are not present.	None
Solenoid	OFF
Time after solenoid ON to OFF	0.008 seconds or more

P0974: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S1 resistance

8 ohms or less

P0973: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve S1 resistance

100 kohms or more

P0974: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S1 resistance

11 to 15 ohms at 20 °C (68 °F)

Scheme 461

Scheme 461: WIRING DIAGRAM

Related DTCs	P0976: Shift solenoid valve S2/Range check (Low resistance) P0977: Shift solenoid valve S2/Range check (High resistance)
Required sensors/Components	Shift solenoid valve S2
Frequency of operation	Continuous
Duration	0.128 seconds or more
MIL operation	Immediate
Sequence of operation	None

The monitor runs whenever the following DTCs are not present.	None
Solenoid	ON
Time after solenoid OFF to ON	0.008 seconds or more

P0976: RANGE CHECK (LOW RESISTANCE)

The monitor runs whenever the following DTCs are not present.	None
Solenoid	OFF
Time after solenoid ON to OFF	0.008 seconds or more

P0977: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S2 resistance

8 ohms or less

P0976: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve S2 resistance

100 kohms or more

P0977: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S2 resistance

11 to 15 ohms at 20 °C (68 °F)

Scheme 462

Scheme 462: WIRING DIAGRAM

Related DTCs	P2714: Shift solenoid valve SLT/ON malfunction
Required sensors/Components	Shift solenoid valve SLT, Speed sensor (NT), Speed sensor (SPD)
Frequency of operation	Continuous
Duration	1.0 second
MIL operation	2 driving cycles
Sequence of operation	None

The following conditions are common to ON malfunctions (a), (b), (c) and (d).

Transmission shift position	D
Time after shifting N to D	4.5 seconds or more
ATF (Automatic Transmission Fluid) temperature	10 °C (14 °F) or more
Turbine Speed Sensor circuit	No circuit malfunction (P0717)
Vehicle Speed Sensor "A" circuit	No circuit malfunction (P0500)
Transmission Fluid Temperature Sensor "A" circuit	No circuit malfunction (P0712, P0713)
Shift Solenoid "A" (S1) circuit	No circuit malfunction (P0973, P0974)
Shift Solenoid "B" (S2) circuit	No circuit malfunction (P0976, P0977)
Torque Converter Clutch Pressure Control Solenoid (SLU) circuit	No circuit malfunction (P2759)
Pressure Control Solenoid "D" (SLT) circuit	No circuit malfunction (P2716)
Electronic Throttle Control System	No circuit malfunction (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135)

ECM gearshift command	1st
Input (turbine) speed	200 RPM or more
Output speed	300 RPM or more

ON MALFUNCTION (A)

ECM gearshift command	2nd
Input (turbine) speed	200 RPM or more
Output speed	300 RPM or more

ON MALFUNCTION (B)

ECM gearshift command	3rd
Input (turbine) speed	200 RPM or more
Output speed	300 RPM or more

ON MALFUNCTION (C)

ECM gearshift command	4th
Input (turbine) speed	200 RPM or more
Output speed	300 RPM or more

ON MALFUNCTION (D)

[ON malfunction]

Detection condition: Total accumulated time of ON malfunctions (a), (b), (c) and (d) is 1 second or more

NT - NO x 1st gear ratio NT: Input (turbine) speed NO: Internal counter shaft speed	More than 300 RPM at output speed of 1000 RPM (Conditions vary with output speed)
Duration	0.85 seconds or more

ON MALFUNCTION (A)

NT - NO x 2nd gear ratio	More than 300 RPM at output speed of 1000 RPM (Conditions vary with output speed)
Duration	0.85 seconds or more

ON MALFUNCTION (B)

NT - NO x 3rd gear ratio	More than 300 RPM at output speed of 1000 RPM (Conditions vary with output speed)
Duration	0.85 seconds or more

ON MALFUNCTION (C)

NT - NO x 4th gear ratio	More than 300 RPM at output speed of 1000 RPM (Conditions vary with output speed)
Duration	0.85 seconds or more

ON MALFUNCTION (D)

Related DTCs	P2716: Shift solenoid valve SLT/Range check
Required sensors/Components	Shift solenoid valve SLT
Frequency of operation	Continuous
Duration	1.0 second
MIL operation	Immediate
Sequence of operation	None

The monitor runs whenever the following DTCs are not present	None
Solenoid current cut status	Not cut
Battery voltage	11 V or more
CPU commanded duty ratio	19 % or more
Ignition switch	ON
Starter	OFF

Solenoid status (SLT) from MIC

Fail

Shift solenoid valve SLT

Resistance: 5.0 ohms to 5.6 ohms at 20 °C (68 °F)

Scheme 463

Scheme 463: WIRING DIAGRAM

Related DTCs	P2757: Shift solenoid valve SLU/OFF malfunction Shift solenoid valve SLU/ON malfunction
Required sensors/Components	Shift solenoid valve SLU, Speed sensor (NT), Crankshaft position sensor (NE)
Frequency of operation	Continuous
Duration	OFF malfunction: 3.5 seconds ON malfunction: 1.8 seconds
MIL operation	2 driving cycles
Sequence of operation	None

The following conditions are common to OFF malfunction and ON malfunction.

Time after shifting N to D	4.5 seconds or more
ECT (Engine Coolant Temperature)	60 °C (140 °F) or more
Transmission shift position	D
ECM selected gear	3rd or 4th
Vehicle speed	25 km/h (15.5 mph) or more
Shift Solenoid "A" (S1) circuit	No circuit malfunction (P0973, P0974)
Shift Solenoid "B" (S2) circuit	No circuit malfunction (P0976, P0977)
Torque Converter Clutch Pressure Control Solenoid (SLU) circuit	No circuit malfunction (P2759)
ECT sensor circuit	No circuit malfunction (P0115, P0117, P0118)
Turbine Speed Sensor circuit	No circuit malfunction (P0717)
Vehicle Speed Sensor "A" circuit	No circuit malfunction (P0500)
Electronic Throttle Control System	No circuit malfunction (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P0604, P0606, P060A, P060D, P060E, P0657, P1607, P2102, P2103, P2111, P2112, P2118, P2119, P2135)

ECM lock-up command	ON
Duration time from lock-up on command	3 seconds or more
Actual gear	3rd or 4th

OFF MALFUNCTION

ECM lock-up command	OFF
Throttle valve opening angle	8 % or more
Vehicle speed	Less than 60 km/h (37.3 mph)
Actual gear	3rd
Calculated load value	22 % or more

ON MALFUNCTION

Engine speed - Input (turbine) speed (NE - NT)

100 RPM or more

OFF MALFUNCTION

[ON malfunction]

2 detections are necessary per driving cycle. 1st detection: Temporary flag ON 2nd detection: Pending fault code ON Vehicle speed must be under 10 km/h (6.2 mph) once before 2nd detection.

Difference between engine speed and Input (turbine) speed

Less than 35 RPM

ON MALFUNCTION

Related DTCs	P2759: Shift solenoid valve SLU/Range check
Required sensors/Components	Shift solenoid valve SLU
Frequency of operation	Continuous
Duration	1.0 second
MIL operation	Immediate
Sequence of operation	None

The monitor runs whenever the following DTCs are not present.	None
Solenoid current cut status	Not cut
Battery voltage	11 V or more
CPU commanded duty ratio	19 % or more
Ignition switch	ON
Starter	OFF

Solenoid status (SLU) from MIC

Fail

Solenoid status (SLU)

Resistance: 5.0 to 5.6 ohms at 20 °C (68 °F)

Scheme 464

Scheme 464: WIRING DIAGRAM

Automatic Transmission Automatic (Diagnostic Codes): Other Toyota Yaris II рестайлинг

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

TYPICAL MALFUNCTION THRESHOLDS

Scheme 457

COMPONENT OPERATING RANGE

Scheme 458

PROCEDURE

Scheme 459

Scheme 460

Scheme 461

Scheme 462

Scheme 463

Scheme 464

More articles — Automatic Transmission Automatic (Diagnostic Codes)

Login / Signup

Enter the code

You have successfully logged in!
