Engine Control System (1GR-FE) (Service Information): Removal & Installation Toyota Tundra II

INSTALLATION

1. INSTALL THROTTLE BODY WITH MOTOR ASSEMBLY Install a new gasket and the throttle body with motor with the 4 bolts. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf) Connect the throttle position sensor and throttle control motor connector. Connect the No. 4 water by-pass hose. Connect the No. 5 water by-pass hose.
2. INSTALL AIR CLEANER ASSEMBLY WITH ELEMENT . Refer to «INSTALLATION - Step 4»(ref-389345-S13091461642011032200000)
3. INSTALL NO. 2 AIR CLEANER HOSE . Refer to «INSTALLATION - Step 5»(ref-389345-S13091461642011032200000)
4. ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 3»(ref-389307-S31806286302011032200000)
5. INSPECT FOR ENGINE COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-389303-S24434070642011032200000)
6. INSTALL V-BANK COVER . Refer to «INSTALLATION - Step 10»(ref-389345-S13091461642011032200000)
7. INSTALL FRONT COWL TOP OUTER PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 11»(ref-389345-S13091461642011032200000)
8. INSTALL FRONT WIPER MOTOR AND LINK ASSEMBLY Install the front wiper motor and link assembly. Refer to «INSTALLATION»(ref-389347-S06269039622011032200000) .
9. INSTALL NO. 1 ENGINE UNDER COVER . Refer to «INSTALLATION - Step 2»(ref-389291-S30400948902011032200000)
10. PERFORM INITIALIZATION NOTE: Be sure to perform this procedure after reassembling the throttle body assembly or removing and reinstalling any throttle body component. Perform the following procedure after replacing the ECM, throttle body assembly or any throttle body components. The following procedure should also be performed if the throttle body is cleaned. Be sure to perform this procedure after reconnecting the battery cable and replacing the ECM. Disconnect the EFI NO. 1 fuse and ETCS fuse at the same time. Wait at least 60 seconds and reconnect the fuses. Turn the ignition switch to the ON position without operating the accelerator pedal. NOTE: If the accelerator pedal is operated, perform the above steps again. Connect the Techstream to the DLC3 and clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-389327-S24648340122011032200000) . Start the engine and check that the MIL is not illuminated and that the idle speed is within the specified range when the A/C is switched off after the engine is warmed up. Standard Condition Engine Idle Speed A/C switched off 650 to 750 rpm NOTE: Be sure to perform this step with all accessories off. Make sure that the shift lever is in N or P. Enter the following menus: Powertrain / Engine and ETC / Data List / All Data / Throttle Sensor Position. Sensor Output. Fully depress the accelerator pedal and check that the value is 60% or more. Perform a road test and confirm that there are no abnormalities.

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. DISCONNECT CONNECTOR HOLDER BLOCK Remove the 3 bolts and move the connector holder block so that the ECM can be removed in the next step.
2. REMOVE ECM NOTE: Make sure that the lock lever is raised 90° as shown in the illustration before disconnecting the ECM connectors. Failure to do this may cause the ECM connectors to break. Raise the 2 levers while pushing the locks on the 2 levers. Disconnect the 2 connectors. Remove the 4 bolts and ECM.
3. REMOVE ECM GASKET Peel off the rubber part of the gasket. NOTE: When using gasket remover or equivalent, cover the ECM connector with a cloth. Spray gasket remover or equivalent on the remaining tape of the gasket. NOTE: Do not damage the ECM seal's surface with the knife. Use a cutter knife to remove the tape of the gasket.

Scheme 41

1. INSTALL ECM GASKET Clean the ECM seal's surface with non-residue solvent. Attach a new gasket to the ECM.
2. INSTALL ECM NOTE: Make sure the gasket is not folded or caught on any area on the surrounding part. Make sure there is no foreign matter caught between the gasket and surrounding part. Do not damage the gasket. Install the ECM with the 4 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) NOTE: Make sure that the lock lever is raised 90° before connecting the ECM connectors. Failure to do this may cause the lock lever and terminals to break. Do not twist the wire harness when connecting the ECM connectors. Connect the 2 ECM connectors and push each lock lever down to lock the ECM connectors.
3. CONNECT CONNECTOR HOLDER BLOCK Connect the connector holder block with the 3 bolts. Torque: 7.3 N*m (74 kgf*cm, 65 in.*lbf)

Scheme 42

1. INSTALL ACCELERATOR PEDAL ROD ASSEMBLY NOTE: Avoid physical shocks to the accelerator pedal rod assembly. Do not disassemble the accelerator pedal rod assembly. Install the accelerator pedal rod with the 2 nuts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Connect the accelerator pedal position sensor connector.

Scheme 43

1. INSTALL MASS AIR FLOW METER Install the MAF meter with the 2 screws. Connect the MAF meter connector.
2. INSTALL V-BANK COVER . Refer to «INSTALLATION - Step 10»(ref-389345-S13091461642011032200000)

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. REMOVE NO. 1 ENGINE UNDER COVER . Refer to «REMOVAL - Step 2»(ref-389291-S20997037722011032200000)
2. DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 2»(ref-389307-S31806286302011032200000)
3. REMOVE FRONT WIPER MOTOR AND LINK ASSEMBLY Remove the front wiper motor and link assembly. Refer to «REMOVAL»(ref-389347-S11977668572011032200000) .
4. REMOVE FRONT COWL TOP OUTER PANEL SUB-ASSEMBLY . Refer to «REMOVAL - Step 6»(ref-389345-S39181255922011032200000)
5. REMOVE V-BANK COVER . Refer to «REMOVAL - Step 7»(ref-389345-S39181255922011032200000)
6. REMOVE NO. 2 AIR CLEANER HOSE . Refer to «REMOVAL - Step 8»(ref-389345-S39181255922011032200000)
7. REMOVE AIR CLEANER ASSEMBLY WITH ELEMENT . Refer to «REMOVAL - Step 9»(ref-389345-S39181255922011032200000)
8. REMOVE VVT SENSOR (for Bank 1) Disconnect the sensor connector. Remove the bolt and sensor.
9. REMOVE VVT SENSOR (for Bank 2) Disconnect the No. 4 and No. 5 water by-pass hoses. Disconnect the sensor connector. Remove the bolt and sensor.

1. INSTALL VVT SENSOR (for Bank 2) Apply a light coat of engine oil to the O-ring of the VVT sensor. Install the VVT sensor with the bolt. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Connect the sensor connector. Connect the No. 4 and No. 5 water by-pass hoses.
2. INSTALL VVT SENSOR (for Bank 1) Apply a light coat of engine oil to the O-ring of the sensor. Install the sensor with the bolt. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Connect the sensor connector.
3. INSTALL AIR CLEANER ASSEMBLY WITH ELEMENT . Refer to «INSTALLATION - Step 4»(ref-389345-S13091461642011032200000)
4. INSTALL NO. 2 AIR CLEANER HOSE . Refer to «INSTALLATION - Step 5»(ref-389345-S13091461642011032200000)
5. ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 3»(ref-389307-S31806286302011032200000)
6. INSPECT FOR ENGINE COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-389303-S24434070642011032200000)
7. INSTALL V-BANK COVER . Refer to «INSTALLATION - Step 10»(ref-389345-S13091461642011032200000)
8. INSTALL FRONT COWL TOP OUTER PANEL SUB-ASSEMBLY . Refer to «INSTALLATION - Step 11»(ref-389345-S13091461642011032200000)
9. INSTALL FRONT WIPER MOTOR AND LINK ASSEMBLY Install the front wiper motor and link assembly. Refer to «INSTALLATION»(ref-389347-S06269039622011032200000) .
10. INSTALL NO. 1 ENGINE UNDER COVER . Refer to «INSTALLATION - Step 2»(ref-389291-S30400948902011032200000)

Scheme 49

Scheme 50

Scheme 51

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE NO. 1 ENGINE UNDER COVER . Refer to «REMOVAL - Step 2»(ref-389291-S20997037722011032200000)
3. REMOVE FAN & GENERATOR V BELT . Refer to «REMOVAL - Step 3»(ref-389291-S20997037722011032200000)
4. REMOVE GENERATOR ASSEMBLY . Refer to «REMOVAL - Step 6»(ref-389348-S30871035322011032200000)
5. DISCONNECT COOLER COMPRESSOR ASSEMBLY . Refer to «REMOVAL - Step 37»(ref-389291-S40685127792011032200000)
6. REMOVE CRANKSHAFT POSITION SENSOR Disconnect the sensor connector. Remove the bolt and sensor.

Scheme 52

1. INSPECT CRANKSHAFT POSITION SENSOR NOTE: In the table above, the terms "cold" and "hot" refer to the temperature of the sensor. "Cold" means approximately -10 to 50°C (14 to 122°F). "Hot" means approximately 50 to 100°C (122 to 212°F). Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 Cold 1630 to 2740 ohms Hot 2065 to 3225 ohms If the resistance is not as specified, replace the sensor.

1. INSTALL CRANKSHAFT POSITION SENSOR Apply a light coat of engine oil to the O-ring of the sensor. Install the sensor with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the sensor connector.
2. CONNECT COOLER COMPRESSOR ASSEMBLY . Refer to «INSTALLATION - Step 17»(ref-389291-S41347991342011032200000)
3. INSTALL GENERATOR ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-389348-S08887141252011032200000)
4. INSTALL FAN & GENERATOR V BELT . Refer to «INSTALLATION - Step 1»(ref-389291-S30400948902011032200000)
5. INSTALL NO. 1 ENGINE UNDER COVER . Refer to «INSTALLATION - Step 2»(ref-389291-S30400948902011032200000)
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE INTAKE AIR SURGE TANK Remove the intake air surge tank. Refer to «REMOVAL»(ref-389345-S13057959412011032200000) .
3. DISCONNECT NO. 1 FUEL PIPE SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(ref-389334-S18571691512011032200000)
4. DISCONNECT NO. 2 FUEL PIPE SUB-ASSEMBLY . Refer to «REMOVAL - Step 12»(ref-389334-S18571691512011032200000)
5. REMOVE INTAKE MANIFOLD Disconnect the 6 fuel injector connectors. Remove the 10 bolts, intake manifold and 2 gaskets.
6. REMOVE ENGINE COOLANT TEMPERATURE SENSOR Disconnect the sensor connector. Remove the sensor. Remove the gasket from the sensor.

Scheme 58

1. INSPECT ENGINE COOLANT TEMPERATURE SENSOR Partially soak the sensor in water and warm up the water. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 Approx. 20°C (68°F) 2.32 to 2.59 kohms Approx. 80°C (176°F) 0.310 to 0.326 kohms NOTE: When checking the sensor in water, keep the terminals dry. After the check, wipe the sensor dry. If the result is not as specified, replace the sensor.

Scheme 59

1. INSTALL ENGINE COOLANT TEMPERATURE SENSOR Install a new gasket to the sensor. Install the sensor. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) Connect the sensor connector.
2. INSTALL INTAKE MANIFOLD NOTE: Align the port holes of the gasket and cylinder head. Be careful of the installation direction. Set a new gasket on each cylinder head. Set the intake manifold on the cylinder heads. Install and uniformly tighten the 10 bolts in several passes. Torque: 26 N*m (265 kgf*cm, 19 ft.*lbf) Connect the 6 fuel injector connectors.
3. INSTALL INTAKE AIR SURGE TANK Install the intake air surge tank. Refer to «INSTALLATION»(ref-389345-S09613473482011032200000) .
4. CONNECT NO. 2 FUEL PIPE SUB-ASSEMBLY . Refer to «INSTALLATION - Step 3»(ref-389334-S07605365102011032200000)
5. CONNECT NO. 1 FUEL PIPE SUB-ASSEMBLY . Refer to «INSTALLATION - Step 4»(ref-389334-S07605365102011032200000)
6. ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 3»(ref-389307-S31806286302011032200000)
7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
8. INSPECT FOR ENGINE COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(ref-389303-S24434070642011032200000)

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

1. REMOVE ENGINE ASSEMBLY Remove the engine. Refer to «REMOVAL»(ref-389291-S10421425702011032200000) .
2. REMOVE CYLINDER HEAD SUB-ASSEMBLY RH (for Bank 1) Remove the cylinder head RH. Refer to «REMOVAL»(ref-389291-S00347560182011032200000) .
3. REMOVE NO. 1 WATER OUTLET PIPE Remove the 4 wire harness clamps. Remove the bolt, 2 nuts and water outlet pipe.
4. REMOVE KNOCK SENSOR Disconnect the 2 sensor connectors. Remove the 2 bolts and 2 sensors.

Scheme 69

1. INSPECT KNOCK SENSOR Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 120 to 280 kohms If the resistance is not as specified, replace the sensor.

Scheme 70

1. INSTALL KNOCK SENSOR Install the 2 sensors with the 2 bolts as shown in the illustration. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf) Connect the 2 sensor connectors.
2. INSTALL NO. 1 WATER OUTLET PIPE Install the water outlet pipe with the bolt and 2 nuts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Install the 4 wire harness clamps.
3. INSTALL CYLINDER HEAD SUB-ASSEMBLY RH (for Bank 1) Install the cylinder head RH. Refer to «INSTALLATION»(ref-389291-S28844684902011032200000) .
4. INSTALL ENGINE ASSEMBLY Install the engine. Refer to «INSTALLATION»(ref-389291-S07699184572011032200000) .

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. INSPECT AIR FUEL RATIO SENSOR Disconnect the 2 sensor connectors. Measure the heater resistance according to the value(s) in the table below. Standard resistance (for Bank 1 sensor 1) Tester Connection Condition Specified Condition 1 (HA1A) - 2 (+B) 20°C (68°F) 1.8 to 3.4 ohms Standard resistance (for Bank 2 sensor 1) Tester Connection Condition Specified Condition 1 (HA2A) - 2 (+B) 20°C (68°F) 1.8 to 3.4 ohms If the result is not as specified, replace the air fuel ratio sensor. Connect the 2 sensor connectors.
2. INSPECT AIR-FUEL RATIO COMPENSATION SYSTEM HINT: Malfunctioning areas can be identified by performing the Control the Injection Volume for A/F sensor function provided in the Active Test. The Control the Injection Volume for A/F sensor function can help to determine whether the Air-Fuel Ratio (A/F) sensor, Heated Oxygen (HO2) sensor and other potential trouble areas are malfunctioning. The following instructions describe how to conduct the Control the Injection Volume for A/F sensor operation using the Techstream. Connect the Techstream to the DLC3. Start the engine and turn the Techstream main switch ON. Warm up the engine at an engine speed of 2500 rpm for approximately 90 seconds. Enter the following menus: Engine and ECT / Active Test / Control the Injection Volume for A/F sensor. Perform the Active Test operation with the engine in an idling condition (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the output voltages of the A/F and HO2 sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. Tester Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 or AFS Voltage B2S1 (A/F) +25% Rich Less than 3.0 V AFS Voltage B1S1 or AFS Voltage B2S1 (A/F) -12.5% Lean More than 3.35 V O2S B1S2 or O2S B2S2 (HO2) +25% Rich More than 0.55 V O2S B1S2 or O2S B2S2 (HO2) -12.5% Lean Less than 0.4 V NOTE: The Air-Fuel Ratio (A/F) sensor has an output delay of a few seconds and the Heated Oxygen (HO2) sensor has a maximum output delay of approximately 20 seconds. Case A/F Sensor (Sensor 1) Output Voltage HO2 Sensor (Sensor 2) Output Voltage Main Suspected Trouble Area 1 - 2 A/F sensor A/F sensor heater A/F sensor circuit 3 HO2 sensor HO2 sensor heater HO2 sensor circuit 4 Injector Fuel pressure Gas leakage from exhaust system (Air-fuel ratio extremely rich or lean) Following the Control the Injection Volume for A/F sensor procedure enables technicians to check and graph the voltage outputs of both the A/F and HO2 sensors. To display the graph, enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor / A/F Control System / AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2.

Scheme 78

Scheme 79

1. REMOVE FRONT NO. 3 EXHAUST PIPE SUB-ASSEMBLY (for Regular Cab Standard Deck) Remove the 4 bolts and 2 nuts. Disconnect the exhaust pipe from the exhaust pipe support, and remove the 2 gaskets.
2. REMOVE FRONT NO. 2 EXHAUST PIPE ASSEMBLY (for Regular Cab Standard Deck) Disconnect the air fuel ratio sensor connector. Disconnect the heated oxygen sensor connector. Remove the 3 nuts, exhaust pipe and gasket.
3. REMOVE FRONT NO. 2 EXHAUST PIPE ASSEMBLY (except Regular Cab Standard Deck) Disconnect the air fuel ratio sensor connector. Disconnect the heated oxygen sensor connector. Remove the 3 nuts, 2 bolts, exhaust pipe and gasket.
4. REMOVE FRONT EXHAUST PIPE ASSEMBLY Disconnect the air fuel ratio sensor connector. Disconnect the heated oxygen sensor connector and 2 clamps. Remove the 2 bolts. Remove the 3 nuts, exhaust pipe and 2 gaskets.
5. REMOVE AIR FUEL RATIO SENSOR (for Bank 1 Sensor 1) Using SST, remove the sensor. SST: 09224-00010
6. REMOVE AIR FUEL RATIO SENSOR (for Bank 2 Sensor 1) Using SST, remove the sensor. SST: 09224-00010

Scheme 80

Scheme 81

1. INSTALL AIR FUEL RATIO SENSOR (for Bank 1 Sensor 1) Using SST, install the sensor. SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) HINT: Use a torque wrench with a fulcrum length of 30 cm (11.8 in.). If using a torque wrench with a length that is not 30 cm (11.8 in.), calculate the torque specification for the torque wrench and SST based on the "without SST" torque specification. Refer to «PRECAUTION»(ref-389124-S05111986592011032200000) . Make sure SST and wrench are connected in a straight line.
2. INSTALL AIR FUEL RATIO SENSOR (for Bank 2 Sensor 1) Using SST, install the sensor. SST: 09224-00010 without SST Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) HINT: Use a torque wrench with a fulcrum length of 30 cm (11.8 in.). If using a torque wrench with a length that is not 30 cm (11.8 in.), calculate the torque specification for the torque wrench and SST based on the "without SST" torque specification. Refer to «PRECAUTION»(ref-389124-S05111986592011032200000) . Make sure SST and wrench are connected in a straight line.
3. INSTALL FRONT EXHAUST PIPE ASSEMBLY Install a new gasket and the exhaust pipe to the exhaust manifold RH with 3 new nuts. Torque: 54 N*m (551 kgf*cm, 40 ft.*lbf) Install a new gasket and the exhaust pipe to the center exhaust pipe with the 2 bolts. Torque: 48 N*m (489 kgf*cm, 35 ft.*lbf) Connect the air fuel ratio sensor connector. Connect the heated oxygen sensor connector and 2 clamps.
4. INSTALL FRONT NO. 2 EXHAUST PIPE ASSEMBLY (except Regular Cab Standard Deck) Connect the front No. 2 exhaust pipe to the exhaust pipe support. Install a new gasket and the front No. 2 exhaust pipe to the exhaust manifold LH with 3 new nuts. Torque: 54 N*m (551 kgf*cm, 40 ft.*lbf) Install a new gasket and the front No. 2 exhaust pipe to the center exhaust pipe with the 2 bolts. Torque: 48 N*m (489 kgf*cm, 35 ft.*lbf) Connect the air fuel ratio sensor connector. Connect the heated oxygen sensor connector.
5. INSTALL FRONT NO. 2 EXHAUST PIPE ASSEMBLY (for Regular Cab Standard Deck) Install a new gasket and the front No. 2 exhaust pipe to the exhaust manifold LH with 3 new nuts. Torque: 54 N*m (551 kgf*cm, 40 ft.*lbf) Connect the air fuel ratio sensor connector. Connect the heated oxygen sensor connector and 2 clamps.
6. INSTALL FRONT NO. 3 EXHAUST PIPE SUB-ASSEMBLY (for Regular Cab Standard Deck) Install a new gasket to the front No. 2 exhaust pipe. Install a new gasket to the front No. 3 exhaust pipe. Connect the front No. 3 exhaust pipe to the exhaust pipe support. Install the front No. 3 exhaust pipe with the 4 bolts and 2 new nuts. Torque: 48 N*m (489 kgf*cm, 35 ft.*lbf)

Scheme 82

Scheme 83

Scheme 84

1. INSPECT HEATED OXYGEN SENSOR Disconnect the 2 sensor connectors. Measure the resistance according to the value(s) in the table below. Standard resistance (for Bank 1 sensor 2) Tester Connection Condition Specified Condition 1 (HT1B) - 2 (+B) 20°C (68°F) 11 to 16 ohms Standard resistance (for Bank 2 sensor 2) Tester Connection Condition Specified Condition 1 (HT2B) - 2 (+B) 20°C (68°F) 11 to 16 ohms If the result is not as specified, replace the sensor. Connect the 2 sensor connectors.

Scheme 85

Scheme 86

1. REMOVE FRONT NO. 3 EXHAUST PIPE SUB-ASSEMBLY (for Regular Cab Standard Deck) See step 1
2. REMOVE FRONT NO. 2 EXHAUST PIPE ASSEMBLY (for Regular Cab Standard Deck) See step 2
3. REMOVE FRONT NO. 2 EXHAUST PIPE ASSEMBLY (except Regular Cab Standard Deck) See step 3
4. REMOVE FRONT EXHAUST PIPE ASSEMBLY See step 4
5. REMOVE HEATED OXYGEN SENSOR (for Bank 1 Sensor 2) Using SST, remove the sensor. SST: 09224-00010
6. REMOVE HEATED OXYGEN SENSOR (for Bank 2 Sensor 2) Using SST, remove the sensor. SST: 09224-00010

Scheme 87

Scheme 88

1. INSTALL HEATED OXYGEN SENSOR (for Bank 1 Sensor 2) Using SST, install the sensor. without SST Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) HINT: Use a torque wrench with a fulcrum length of 30 cm (11.8 in.). If using a torque wrench with a length that is not 30 cm (11.8 in.), calculate the torque specification for the torque wrench and SST based on the "without SST" torque specification. Refer to «PRECAUTION»(ref-389124-S05111986592011032200000) . Make sure SST and wrench are connected in a straight line.
2. INSTALL HEATED OXYGEN SENSOR (for Bank 2 Sensor 2) Using SST, install the sensor. without SST Torque: 44 N*m (449 kgf*cm, 32 ft.*lbf) with SST Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) HINT: Use a torque wrench with a fulcrum length of 30 cm (11.8 in.). If using a torque wrench with a length that is not 30 cm (11.8 in.), calculate the torque specification for the torque wrench and SST based on the "without SST" torque specification. Refer to «PRECAUTION»(ref-389124-S05111986592011032200000) . Make sure SST and wrench are connected in a straight line.
3. INSTALL FRONT EXHAUST PIPE ASSEMBLY See step 3
4. INSTALL FRONT NO. 2 EXHAUST PIPE ASSEMBLY (except Regular Cab Standard Deck) See step 4
5. INSTALL FRONT NO. 2 EXHAUST PIPE ASSEMBLY (for Regular Cab Standard Deck) See step 5
6. INSTALL FRONT NO. 3 EXHAUST PIPE SUB-ASSEMBLY (for Regular Cab Standard Deck) See step 6

Scheme 89

Scheme 90

Scheme 91

1. REMOVE INTEGRATION RELAY (UNIT E) Remove the engine room relay block cover. Using a screwdriver, detach the 2 claws and disconnect the integration relay from the engine room relay block. HINT: Tape the screwdriver tip before use. Disconnect the 3 connectors.
2. INSPECT INTEGRATION RELAY (IGNITION RELAY NO. 2) NOTE: Some relays are built into the integration relay (unit E). The integration relay cannot be disassembled. If there is a malfunction in the circuit of the integration relay, replace the integration relay. The internal circuit of the integration relay is as shown in the illustration below. Inspect the integration relay using the following procedures. Measure the resistance of the IG2 MAIN fuse. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition IG2 MAIN fuse Always Below 1 ohms If the result is not as specified, replace the IG2 MAIN fuse. Measure the resistance of the ignition relay No. 2 (IG2) circuit. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1C-1 - 1B-8 When battery voltage is not applied between 1B-6 and 1B-7 10 kohms or higher When battery voltage is applied between 1B-6 and 1B-7 Below 1 ohms If the result is not as specified, replace the integration relay.
3. INSTALL INTEGRATION RELAY (UNIT E) Connect the 3 connectors. Install the integration relay to the engine room relay block. Install the engine room relay block cover.
