- INSPECT POWER SLIDE BACK WINDOW SWITCH CONTINUITY TESTER CONNECTION SPECIFIED CONDITION Switch Position Tester Connection Specified Condition OPEN 1 - 3, 2 - 6 Continuity OFF 2 - 3, 2 - 6 Continuity CLOSE 1 - 6, 2 - 3 Continuity If the continuity is not as specified, replace the switch.
- CHECK POWER SLIDE BACK WINDOW MOTOR PTC THERMISTOR OPERATION Disconnect the connector from the window motor. Connect the positive (+) lead from the ammeter to terminal 1 of the motor connector and the negative (-) lead to the negative terminal of the battery. Connect the positive (+) lead from the battery to terminal 2 of the motor connector, and slide the window to the fully closed position. Continue to apply voltage and check that the current changes to less than 1 A in 4 to 90 seconds. Disconnect the leads from the terminals. Approximately 60 seconds later, connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2, and check that the window begins to slide open. If operation is not as specified, replace the regulator and motor assembly.
- INSPECT POWER RELAY CONTINUITY POWER RELAY CONTINUITY Tester Connection Specified Condition 3 - 5 No continuity 3 - 5 Continuity (When battery voltage is applied to terminals 1 and 2) If the continuity is not as specified, replace the relay.
- CHECK INTEGRATION RELAY Remove the integration relay from the driver side J/B, and check the voltage or continuity of each terminal on the driver side J/B side (see POWER DOOR LOCK CONTROL SYSTEM (EXCEPT DOUBLE CAB) ).
