Accessory Power Socket Toyota Tundra I facelift

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. Double cab (115 V):INSPECT MAIN SWITCH CONTINUITY TESTER CONNECTION SPECIFIED CONDITION Switch Position Tester Connection Specified Condition ON 3 - 6 Continuity OFF 3 - 6 No continuity If the continuity is not as specified, replace the switch.
2. Double cab (115 V):INSPECT MAIN SWITCH INDICATOR LIGHT OPERATION Connect the positive (+) lead from the battery to terminal 3 and the negative (-) lead to terminal 2. Push the main switch and check that the indicator light turns on. If operation is not as specified, replace the switch.
3. Double cab (115 V):INSPECT INVERTER RELAY CONTINUITY INVERTER RELAY - DOUBLE CAB (115 V) Tester Connection Specified Condition 3 - 5 No continuity 3 - 5 Continuity (When battery voltage is applied to terminals 1 and 2) If the continuity is not as specified, replace the switch.
4. Double cab (12 V):INSPECT ACC RELAY AND ACC CUT RELAY CONTINUITY ACC RELAY AND ACC CUT RELAY - DOUBLE CAB (12 V) Tester Connection Specified Condition 3 - 5 No continuity 3 - 5 Continuity (When battery voltage is applied to terminals 1 and 2) If the continuity is not as specified, replace the switch.
5. Except double cab:INSPECT POWER OUTLET RELAY (Marking: PWR OUTLET) CONTINUITY POWER OUTLET RELAY - EXCEPT DOUBLE CAB Tester Connection Specified Condition 3 - 5 No continuity 3 - 5 Continuity (When battery voltage is applied to terminals 1 and 2) If the continuity is not as specified, replace the switch.
6. Double cab (115 V):INSPECT VOLTAGE INVERTER CIRCUIT Disconnect the connector from the voltage inverter and check the connector on the wire harness side, as shown in the table. VOLTAGE INVERTER CIRCUIT - DOUBLE CAB (115 V) Main Switch Position Tester Connection Specified Condition ON 1 - 4 10 - 14V OFF 1 - 4 No continuity If the result is not as specified, replace the inverter.
