MONITOR STRATEGY
| Monitor | Specification |
|---|---|
| Related DTCs | P0031: A/F Sensor Heater Current (Low Current) P0032: A/F Sensor Heater Current (High Current) |
| Required sensors / components | A/F sensor, ECM |
| Frequency of operation | Continuous |
| Duration | 10 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
TYPICAL ENABLING CONDITIONS
P0031
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Battery voltage | 10.5 V or more |
| Heater duty ratio-cycle | 50 % or more |
| Time after engine start | 10 seconds or more |
TYPICAL ENABLING CONDITIONS (P0031)
P0032
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Time after engine start | 10 seconds or more |
TYPICAL ENABLING CONDITIONS (P0032)
TYPICAL MALFUNCTION THRESHOLDS
P0031
| Detection Criteria | Threshold |
|---|---|
| A/F sensor heater current | Less than 3.0 A |
TYPICAL MALFUNCTION THRESHOLDS (P0031)
P0032
| Detection Criteria | Threshold |
|---|---|
| Hybrid IC high current limiter port | Fail |
TYPICAL MALFUNCTION THRESHOLDS (P0032)
COMPONENT OPERATING RANGE
| Parameter | Standard Value |
|---|---|
| A/F sensor heater current | 3.1 A (at 20°C (68°F)) or more |
COMPONENT OPERATING RANGE
MONITOR RESULT
The detailed information is described in "CHECKING MONITOR STATUS" (see PRE-CHECK ).
- TID (Test Identification) is assigned to each emission-related component.
- TLT (Test Limit Type): If TLT is 0, the component is malfunctioning when the test value is higher than the test limit. If TLT is 1, the component is malfunctioning when the test value is lower than the test limit. CID (Component Identification) is assigned to each test value.
- Unit Conversion is used to calculate the test value indicated on generic OBD scan tools.
TID $07: A/F Sensor Heater
| TLT | CID | Unit Conversion | Description of Test Value | Description of Test Limit |
|---|---|---|---|---|
| 1 | $01 | Multiply by 0.0001 7 (A) | Maximum A/F sensor heater current (bank 1) | Malfunction criterion |
A/F SENSOR HEATER DESCRIPTION
| Monitor | Specification |
|---|---|
| Related DTCs | P0037: Heated Oxygen Sensor Heater Current Bank 1 Sensor 2 (Low Current) P0038: Heated Oxygen Sensor Heater Current Bank 1 Sensor 2 (High Current) |
| Required sensors/ components | Main sensors: Heated oxygen sensor Related sensor: Vehicle speed sensor |
| Frequency of operation | Continuous |
| Duration | 0.3 second |
| MIL operation | 1 driving cycle |
| Sequence of operation | None |
MONITOR STRATEGY
P0037
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Following condition is met | A or B |
| A. Following conditions are met | 1, 2, 3, 4 and 5 |
| 1. Time after engine start | 250 seconds or more, and less than 500 seconds |
| 2. Battery voltage | More than 10.5V |
| 3. Vehicle speed | Less than 56 mph (90 km/h) |
| 4. Misfire | Not detected |
| 5. Pass/ Fail detection in this driving cycle | Not detected |
| B. Following conditions are met | 1, 2, 3, 4 and 5 |
| 1. Time after engine start | 500 seconds or more |
| 2. Battery voltage | More than 10.5V |
| 3. Vehicle speed | More than 25 mph (40 km/h) |
| 4. Misfire | Not detected |
| 5. Pass/ Fail detection in this driving cycle | Pass and fail detection has not occurred yet |
TYPICAL ENABLING CONDITIONS (P0037)
P0038
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Intrusive heating | OFF |
TYPICAL ENABLING CONDITIONS (P0038)
P0037
| Detection Criteria | Threshold |
|---|---|
| Heated oxygen sensor heater current | Less than 0.25 A (while supplemental heating is OFF) |
TYPICAL MALFUNCTION THRESHOLDS (P0037)
P0038
| Detection Criteria | Threshold |
|---|---|
| Heated oxygen sensor heater current | More than 2 A (at 0.3 second after heater ON) |
TYPICAL MALFUNCTION THRESHOLDS (P0038)
| Parameter | Standard Value |
|---|---|
| Heated oxygen sensor heater current | 0.4 to 1 A (at idle and HOt and battery voltage 11 to 14 V) |
COMPONENT OPERATING RANGE
The detailed information is described in "CHECKING MONITOR STATUS" (see PRE-CHECK ).
- TID (Test Identification) is assigned to each emission-related component.
- TLT (Test Limit Type): If TLT is 0, the component is malfunctioning when the test value is higher than the test limit. If TLT is 1, the component is malfunctioning when the test value is lower than the test limit.
- CID (Component Identification) is assigned to each test value.
- Unit Conversion is used to calculate the test value indicated on generic OBD scan tools.
TID $04: HO2S Heater
| TLT | CID | Unit Conversion | Description of Test Value | Description of Test Limit |
|---|---|---|---|---|
| 1 | $02 | Multiply by 0.000076 (A) | Maximum HO2S heater current (bank 1 sensor 2) | Malfunction criterion |
HO2S HEATER
| Monitor | Specification |
|---|---|
| Related DTCs | P0100: MAF Meter Circuit Range Check (Fluttering) |
| Related DTCs | P0102: MAF Meter Circuit Range Check (Low Voltage) |
| Related DTCs | P0103: MAF Meter Circuit Range Check (High Voltage) |
| Required sensors / components | MAF meter |
| Frequency of operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediately (when engine speed at less than 4,000 rpm) 2 driving cycles (when engine speed at 4,000 rpm or more) |
| Sequence operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of disable a Monitor" ( PRE-CHECK ) |
TYPICAL ENABLING CONDITIONS
P0100
| Detection Criteria | Threshold |
|---|---|
| MAF meter voltage | Less than 0.2 V, or more than 4.9 V |
TYPICAL MALFUNCTION THRESHOLDS (P0100)
P0102
| Detection Criteria | Threshold |
|---|---|
| MAF meter voltage | Less than 0.2 V |
TYPICAL MALFUNCTION THRESHOLDS (P0102)
P0103
| Detection Criteria | Threshold |
|---|---|
| MAF meter voltage | More than 4.9 V |
TYPICAL MALFUNCTION THRESHOLDS (P0103)
| Parameter | Standard Value |
|---|---|
| MAF meter voltage | 0.4 to 2.2V |
COMPONENT OPERATING RANGE
Scheme 208
P0101: MAF meter rationality (high voltage)
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Engine speed | Less than 900 rpm |
| Idle | ON |
| Engine coolant temperature | 70°C (158°F) or more |
TYPICAL ENABLING CONDITIONS (HIGH VOLTAGE)
P0101: MAF meter rationality (low voltage)
| Item | Specification |
|---|---|
| Engine speed | 0 rpm or more |
| Throttle position | 0.1 V or more |
TYPICAL ENABLING CONDITIONS (LOW VOLTAGE)
P0101: MAF meter rationality (high voltage)
| Detection Criteria | Threshold |
|---|---|
| MAF meter voltage (high voltage) | More than 2.2 V |
TYPICAL MALFUNCTION THRESHOLDS (HIGH VOLTAGE)
P0101: MAF meter rationality (low voltage)
| Detection Criteria | Threshold |
|---|---|
| MAF meter voltage (low voltage) | Less than 0.4 V |
TYPICAL MALFUNCTION THRESHOLDS (LOW VOLTAGE)
| Monitor | Specification |
|---|---|
| Related DTC | P0110: Intake Air Temperature Sensor Range Check (Fluttering) |
| Related DTC | P0112: Intake Air Temperature Sensor Range Check (Low Resistance) |
| Related DTC | P0113: Intake Air Temperature Sensor Range Check (High Resistance) |
| Required sensors / components | Intake air temperature sensor |
| Frequency of operation | Continuous |
| Duration | 0.5 second |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
TYPICAL ENABLING CONDITIONS
P0110: Intake air temperature sensor range check (fluttering)
| Detection Criteria | Threshold |
|---|---|
| Intake air temperature sensor resistance (Intake air temperature) | Less than 98.5 ohm, or more than 156 kohm (More than 140°C (284°F) or -40°C (-40°F) or less) |
TYPICAL MALFUNCTION THRESHOLDS (FLUTTERING)
P0112: Intake air temperature sensor range check (low resistance)
| Detection Criteria | Threshold |
|---|---|
| Intake air temperature sensor resistance (Intake air temperature) | Less than 98.5 ohm (More than 140°C (284°F)) |
TYPICAL MALFUNCTION THRESHOLDS (LOW RESISTANCE)
P0113: Intake air temperature sensor range check (high resistance)
| Detection Criteria | Threshold |
|---|---|
| Intake air temperature sensor resistance (Intake air temperature) | More than 156 kohm-40°C (-40°F) or less) |
TYPICAL MALFUNCTION THRESHOLDS (HIGH RESISTANCE)
| Parameter | Standard Value |
|---|---|
| Intake air temperature sensor resistance | 98.5 ohm (140°C ((284°F)) to 156 kohm (-40°C (-40°F)) |
COMPONENT OPERATING RANGE
Scheme 209
| Monitor | Specification |
|---|---|
| Related DTC | P115: ECT Sensor Range Check (Fluttering) |
| Related DTC | P117: ECT Sensor Range Check (Low resistance) |
| Related DTC | P118: ECT Sensor Range Check (High resistance) |
| Required sensors / components | ECT sensor |
| Frequency of operation | Continuous |
| Duration | 0.5 second |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
TYPICAL ENABLING CONDITIONS
P0115
| Detection Criteria | Threshold |
|---|---|
| ECT sensor resistance (coolant temperature) | Less than 79 ohm, or more than 156 kohm (more than 140°C (284°F) or -40°C (-40°F) or less) |
TYPICAL MALFUNCTION THRESHOLDS (P0115)
P0117
| Detection Criteria | Threshold |
|---|---|
| ECT sensor resistance (coolant temperature) | Less than 79 ohm (more than 140°C (284°F) |
TYPICAL MALFUNCTION THRESHOLDS (P0117)
P0118
| Detection Criteria | Threshold |
|---|---|
| ECT sensor resistance (coolant temperature) | More than 156 kohm (-40 °C (-40 °F) or less) |
TYPICAL MALFUNCTION THRESHOLDS (P0118)
| Parameter | Standard Value |
|---|---|
| ECT sensor resistance | 79 ohm (140°C (284°F)) to 156 kohm (-40°C (-40°F) |
COMPONENT OPERATING RANGE
Scheme 210
| Monitor | Specification |
|---|---|
| Related DTC P0116 | ECT Sensor Range Check (Stuck) |
| Required sensors / components | Main: ECT sensor Related: Intake air temperature sensor, crankshaft position sensor MAF meter |
| Frequency of operation | Continuous |
| Duration | 250 seconds |
| MIL Operation | 2 driving cycles: When temperature is fixed between 35°C (95°F) and 60°C (140°F) 6 driving cycles: When temperature is fixed at 60°C (140°F) or more |
| Sequence operation | None |
MONITOR STRATEGY
Case 1
When temperature is fixed between 35°C (95°F) and 60°C (140°F)
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Cumulative idle off period | 250 seconds or more |
| Speed increase by 19 mph (30 km/h) or more | 10 times or more |
| Engine coolant temperature | 35°C (95°F) or more, and less then 60°C (140°F) |
| Intake air temperature | 6.7°C (20°F) or more |
TYPICAL ENABLING CONDITIONS
Case 2
When temperature is fixed at 60°C (140°F) or more
| Item | Specification |
|---|---|
| Engine coolant temperature | 60°C (140°F) or more |
| Intake air temperature | 6.7°C (20°F) or more |
| "Stop and go" (1) | Once or more |
| "Steady driving and stop (2) | Once or more |
| (1) *1 Vehicle is stopped for 20 seconds or more and accelerated to more than 44 mph (70 km/h) within 40 seconds. | |
| (2) *2 Vehicle is driven by 40 mph (65 km/h) or more for 30 seconds or more and the vehicle speed reaches 44 mph (70 km/h). The vehicle is decelerated from 40 mph (65 km/h) to 2 mph (3 km/h) or less within 35 seconds and stopped for 10 seconds. | |
| (1) | *1 Vehicle is stopped for 20 seconds or more and accelerated to more than 44 mph (70 km/h) within 40 seconds. |
| (2) | *2 Vehicle is driven by 40 mph (65 km/h) or more for 30 seconds or more and the vehicle speed reaches 44 mph (70 km/h). The vehicle is decelerated from 40 mph (65 km/h) to 2 mph (3 km/h) or less within 35 seconds and stopped for 10 seconds. |
COOLANT TEMPERATURE
Case 1
When temperature fixed between 35°C (95°F) and 60°C (140°F)
| Detection Criteria | Threshold |
|---|---|
| Change of ECT value | Less than 3°C (5.4°F) |
TYPICAL MALFUNCTION THRESHOLDS (CASE 1)
Case 2
When temperature is fixed at 60°C (140°F) or more
| Detection Criteria | Threshold |
|---|---|
| Change of ECT value | 1°C (1.8°F) or less |
TYPICAL MALFUNCTION THRESHOLDS (CASE 2)
| Parameter | Standard Value |
|---|---|
| ECT | Changing with the actual ECT |
COMPONENT OPERATING RANGE
| Monitor | Specification |
|---|---|
| Related DTCs | P0120: Throttle position sensor (VTA) open/short (Fluttering) |
| Related DTCs | P0122: Throttle position sensor (VTA) open/short (Low voltage) |
| Related DTCs | P0123: Throttle position sensor (VTA) open/short (High voltage) |
| Related DTCs | P0220: Throttle position sensor VTA2) open/short (Fluttering) |
| Related DTCs | P0222: Throttle position sensor (VTA2) open/short (Low voltage) |
| Related DTCs | P0223: Throttle position sensor (VTA2) open/short (High voltage) |
| Related DTCs | P2135: Throttle position sensor (Between VTA and VTA2) open |
| Related DTCs | P2135: Throttle position sensor (Between VTA and VTA2) short |
| Required sensors/components (Main) | Throttle position sensor |
| Required sensors/components (Related) | |
| Frequency of operation | Continuous |
| Duration | 2 seconds |
| MIL operation | Immediate |
| Sequence operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
TYPICAL ENABLING CONDITIONS
P0120
| Detection Criteria | Threshold |
|---|---|
| VTA voltage | 0.2 V or less, or 4.8 V or more |
TYPICAL MALFUNCTION THRESHOLDS (P0120)
P0122
| Detection Criteria | Threshold |
|---|---|
| VTA voltage | 0.2 V or less |
TYPICAL MALFUNCTION THRESHOLDS (P0122)
P0123
| Detection Criteria | Threshold |
|---|---|
| VTA voltage | 4.8 V or more |
TYPICAL MALFUNCTION THRESHOLDS (P0123)
P0220
| Detection Criteria | Threshold |
|---|---|
| VTA voltage | 0.5 V or less, or 4.8 V or more |
TYPICAL MALFUNCTION THRESHOLDS (P0220)
P0222
| Detection Criteria | Threshold |
|---|---|
| VTA2 voltage | 0.5 V or less |
TYPICAL MALFUNCTION THRESHOLDS (P0222)
P0223
| Detection Criteria | Threshold |
|---|---|
| VTA2 voltage when the VTA is 0.2 to 1.8 V | 4.97 V or more |
TYPICAL MALFUNCTION THRESHOLDS (P0223)
P2135 Throttle position sensor (Between VTA and VTA2) open
| Detection Criteria | Threshold |
|---|---|
| Difference between VTA and VTA2 voltage | 0.02 V or less |
TYPICAL MALFUNCTION THRESHOLDS (P2135 OPEN)
P2135 Throttle position sensor (Between VTA and VTA2) short
| Detection Criteria | Threshold |
|---|---|
| Both of the following conditions are met | |
| VTA voltage | 0.2 V or less |
| VTA2 voltage | 0.5 V or less |
TYPICAL MALFUNCTION THRESHOLDS (P2135 SHORT)
| Parameter | Standard Value |
|---|---|
| VTA voltage | 0.6 to 3.96V |
| VTA2 voltage | 2.25 to 4.8 V |
COMPONENT OPERATING RANGE
Scheme 211
| Monitor | Specification |
|---|---|
| Related DTCs | P0121: Throttle Position Sensor Rationality |
| Required sensors / components | Throttle Position sensor |
| Frequency of operation | Continuous |
| Duration | 2 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| VTA2 voltage | 4.6 V or less |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| Different between VTA and VTA2 [VTA - (VTA2 x 0.8 to 1.2)]* * Corrected by learning value | Less than 0.8 V, and more than 1.6 V |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard Value |
|---|---|
| Closed throttle position learning value | Between 7.5° and 21° |
COMPONENT OPERATING RANGE
| Monitor | Specification |
|---|---|
| Related DTCs | P0125: In sufficient coolant temperature for closed loop fuel control |
| Related DTCs | Main |
| Required sensors / components | ECT sensor, cooling system, thermostat |
| Required sensors / components | Related |
| Required sensors / components | MAF meter |
| Frequency of operation | Continuous |
| Duration | 2 minutes: Engine start ECT is 10°C (50°F) or more |
| Duration | 5 minutes: Engine start ECT is -6.6°C (20°F) to 10°C (50°F) |
| Duration | 20 minutes: Engine start ECT is less than -6.6°C (20°F) |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Engine | Running |
| Fuel cut | OFF |
TYPICAL ENABLING CONDITIONS
Time until "ECT" detection temperature reaches feedback start temperature
| Detection Criteria | Threshold |
|---|---|
| When the temperature at the time of engine starting is 10°C (50°F) or more | ECT is less than "closed-loop enable temperature" when 2 minutes or more after engine start |
| When the temperature at the time of engine starting is "-6.6 °C (20°F)" to "10°C (50°F)" | ECT is less than "closed-loop enable temperature" when 5 minutes or more after engine start |
| When the temperature at the time of engine starting is -6.6°C (20°F) or less | ECT is less than "closed-loop enable temperature" when 20 minutes or more after engine start |
TYPICAL MALFUNCTION THRESHOLDS
| Monitor | Specification |
|---|---|
| Related DTCs | P0128: Thermostat |
| Related DTCs | Main |
| Required sensors / components | ECT sensor, engine cooling system, thermostat |
| Required sensors / components | Related |
| Required sensors / components | Intake air temperature sensor, vehicle speed sensor |
| Frequency of operation | Once per drive cycle |
| Duration | 15 minutes |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Battery voltage | 11 V or more |
| Intake air temperature (at engine start) | 10 °C (14°F) or more, and 35 °C (95°F) or less |
| Engine coolant temperature (at engine start) | 10 °C (14°F) or more, and 35 °C (95°F) or less |
| Difference between ECT and IAT (at engine start) | 15 °C (27°F) or more, and 7°C (12.6°F) or less |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| (1) Estimated ECT | 75 °C (167 °F) or more |
| (2) Estimated ECT sensor output value | Less than 75 °C (167°F) |
| Duration period of both (1) and (2) | 5 sec or more |
TYPICAL MALFUNCTION THRESHOLDS
The detailed information is described in "CHECKING MONITOR STATUS" (see PRE-CHECK ).
- TID (Test Identification) is assigned to each emission-related component.
- TLT (Test Limit Type): If TLT is 0, the component is malfunctioning when the test value is higher than the test limit. If TLT is 1, the component is malfunctioning when the test value is lower than the test limit.
- CID (Component Identification) is assigned to each test value.
- Unit Conversion is used to calculate the test value indicated on generic OBD scan tools.
TID $08: Thermostat
| TLT | CID | Unit Conversion | Description of Test Value | Description of Test Limit |
|---|---|---|---|---|
| 1 | $01 | Multiply by 0.625 and subtract 40 (°C) | ECT sensor output when estimated ECT reaches malfunction criterion | Malfunction criterion |
THERMOSTAT TEST VALUE
CONFIRMATION DRIVING PATTERN
Refer to DTC P2195: OXYGEN (A/F) SENSOR SIGNAL STUCK LEAN (BANK 1 SENSOR 1); DTC P2196: OXYGEN (A/F) SENSOR SIGNAL STUCK RICH (BANK 1 SENSOR 1) .
| Monitor | Specification |
|---|---|
| Related DTCs | P0136: Heated Oxygen Sensor Output Voltage |
| Required sensors / components | Main |
| Required sensors / components | Heated rear oxygen sensor |
| Required sensors / components | Related |
| Required sensors / components | MAF meter, vehicle speed sensor |
| Frequency of operation | Once per drive cycle |
| Duration | 300 seconds |
| MIL operation | 2 driving cycles |
| Sequence operation | None |
MONITOR STRATEGY
Case 1
P0136: Heated oxygen sensor output voltage (bank 1) Crack
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Vehicle speed | 2 mph (3 km/h) or more |
| Idle | OFF |
| Fuel cut | OFF |
| Time after fuel cut from ON to OFF | 10 seconds or more |
| Intake air amount per revolution | 0.36 g/rev or more |
| Fuel system status | Closed-loop |
TYPICAL ENABLING CONDITIONS (CASE 1)
Case 2
P0136: Heated oxygen sensor output voltage (bank 1)
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Engine | Running |
| Time after engine start | 0 second or more |
| One of the following conditions is met | |
| Cumulative time shile oxygen sensor heater is ON | 22 seconds or more |
| At once or more oxygen sensor voltage | 0.2V or more |
TYPICAL ENABLING CONDITIONS (CASE 2)
Case 1
| Detection Criteria | Threshold |
|---|---|
| Following conditions are met | 1, 2 and 3 |
| 1. Cumulative heated oxygen sensor monitor time | 300 seconds or more |
| 2. Time while heated oxygen sensor voltage is less than 0.05V | 180 seconds or more |
| 3. Maximum heated oxygen sensor rich time (0.45 V or more) | Less than 20 seconds |
TYPICAL MALFUNCTION THRESHOLDS (CASE 1)
Case 2
| Detection Criteria | Threshold |
|---|---|
| Number of heated oxygen sensor voltage "switching" (1) | 0 time or less |
| Minimum voltage | 0.4 V or less |
| Maximum voltage | 0.6 V or more |
| (1) : Switching is being counted when the sensor signal crosses the minimum or maximum voltage. | |
| (1) | Switching is being counted when the sensor signal crosses the minimum or maximum voltage. |
TYPICAL MALFUNCTION THRESHOLDS (CASE 2)
| Parameter | Standard Value |
|---|---|
| Heated oxygen sensor voltage | 0 to 1V |
COMPONENT OPERATING RANGE
| Monitor | Specification |
|---|---|
| Related DTCs | P0171: Fuel system lean (bank 1) |
| Related DTCs | P0172: Fuel system rich (bank 1) |
| Required sensors / components | Main |
| Required sensors / components | A/F sensor |
| Required sensors / components | Related |
| Required sensors / components | Engine coolant temperature sensor, MAF meter, crankshaft position sensor |
| Frequency of operation | Continuous |
| Duration | 10 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not preset | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Battery voltage | 11 V or more |
| Fuel system: Closed-loop | 13 seconds or more |
| One of the following conditions is met | (a) or (b) |
| (a) Engine speed | Less than 1,100 rpm |
| (b) Intake air amount per revolution | 0.22 g/sec or more |
| Warm-up condition to enable air fuel ratio learning control | Conditions are met |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| Following conditions continue for 3 seconds | (a) or (b) |
| (a) Smoothed fuel trim learning value (lean) | 35 % (1) or more |
| (b) Smoothed fuel trim learning value (rich) | 35 % (1) or less |
| (1) *: The threshold value varies with the ECT. | |
| (1) | *: The threshold value varies with the ECT. |
TYPICAL MALFUNCTION THRESHOLDS
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not preset | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Battery voltage | More than 8 V |
| Engine speed fluctuation | Engine speed should not have changed rapidly |
| Engine speed (2 revolutions after engine has started) | More than 450 rpm, and less than 5,500 rpm |
| Either of following are met | (a), (b) or (c) |
| (a) Engine coolant temperature | 10°C (14°F) or more |
| (b) Both of following conditions are met | Intake air temperature: -10°C (14°F) or more Engine coolant temperature: 75°C (167°F) or more |
| (c) Both of following conditions are met | Intake air temperature: (at engine start): More than -7°C (19°F) Engine coolant temperature: More than 20°C (68°F) |
| Intake air amount per revolution (varies with engine speed) | 0.26 g/rev or more (M/T) (1) 0.27 g/rev or more (A/T) (1) |
| Throttle position learning | Completed |
| Throttle position | Rapid throttle opening or closing operation has not occurred |
| Transient spark retard (The spark timing delay control in a short time for preventing surge at the time of a sudden acceleration) | Not commanded |
| Rough road counter | Less than 14 times/1,000 revolutions (not running on rough road): A/T (1) |
| Rough road counter | Less than 20 times/1,000 revolutions (not running on rough road): M/T (1) |
| (1) *: A/T stands for Automatic Transmission. M/T stands for Manual Transmission. | |
| (1) | *: A/T stands for Automatic Transmission. M/T stands for Manual Transmission. |
TYPICAL ENABLING CONDITIONS
Scheme 212
Scheme 213
- Connect the hand-held tester or the OBD II scan tool to the DLC3.
- Record DTC and the freeze frame data.
- Use the hand-held tester to set to the Check Mode (See «PRE-CHECK»(ref-181812-S42723497822005080500000) ).
- Read the value on the misfire counter for each cylinder when idling. If the value is displayed on the misfire counter, skip the following procedure of confirmation driving.
- Drive the vehicle several times with the engine speed, load and its surrounding range shown with ENGINE SPD, CALC LOAD in the freeze frame data or MISFIRE RPM, MISFIRE LOAD in the data list. If you have no hand-held tester, turn the ignition switch OFF after the symptom is simulated the first time. Then repeat the simulation process again. HINT: In order to memorize the DTC of misfire, it is necessary to drive around MISFIRE RPM, MISFIRE LOAD for the following period of time in the data list. Take care not to turn the ignition switch OFF. Turning the ignition switch OFF switches the diagnosis system from check (test) mode to normal mode. So all DTCs, etc., are erased. ENGINE SPEED TIME Engine Speed Time Ignition 3 minutes 30 seconds or more 1,000 rpm 3 minutes or more 2,000 rpm 1 minute 30 seconds or more 3,000 rpm 1 minute or more
- Check whether there is misfire or not by monitoring DTC and the freeze frame data. After that, record them.
- Turn the ignition switch OFF and wait at least 5 seconds.
| Monitor | Specification |
|---|---|
| Related DTCs | P0325: Knock Sensor (Bank 1) Range Check or Rationality |
| Related DTCs | P0330: Knock Sensor (Bank 1) Range Check Rationality |
| Required sensors / components | Main: Knock sensor Related |
| Required sensors / components | Crankshaft position sensor, camshaft position sensor, engine coolant temperature sensor, mass air flow meter |
| Frequency of operation | Continuous |
| Duration | 10 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not preset | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Battery voltage | 10 V or more |
| Idle | OFF |
| Time after engine start | 5 seconds or more |
| Engine coolant temperature | 60 °C (140 °F) or more |
| Intake air amount per revolution | 0.45 g/rev or more |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| Knock sensor's voltage output remains at a low level for a specific period of time | 10 seconds |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 214
P0335
| Monitor | Specification |
|---|---|
| Related DTCs | P0335: Crankshaft Position Sensor Range Check or Rationality |
| Required sensors / components | Crankshaft Position sensor |
| Frequency of operation | Continuous |
| Duration | 4.7 seconds |
| MIL Operation | 2 driving cycles |
| Sequence operation | None |
MONITOR STRATEGY
P0335: Case 1
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Starter | ON |
| Minimum battery voltage while starter ON | Less than 11 V |
TYPICAL ENABLING CONDITIONS (CASE 1)
P0335: Case 2
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Engine speed | 600 rpm or more |
| Starter | OFF |
| Time after starter ON to OFF | 3 seconds or more |
TYPICAL ENABLING CONDITIONS (CASE 2)
P0335: Case 1
| Detection Criteria | Threshold |
|---|---|
| Engine speed signal | No signal for 4.7 seconds |
TYPICAL MALFUNCTION THRESHOLDS (CASE 1)
P0335: Case 2
| Detection Criteria | Threshold |
|---|---|
| Engine speed signal | No signal for 0.5 second |
TYPICAL MALFUNCTION THRESHOLDS (CASE 1)
| Parameter | Standard Value |
|---|---|
| CKP signal | CKP sensor voltage fluctuate when the crankshaft rotates 34 CKP signals per 1 revolution crankshaft |
COMPONENT OPERATING RANGE
Scheme 215
| Monitor | Specification |
|---|---|
| Related DTCs | P0340: Camshaft Position Sensor (Bank 1) Range Check or Rationality |
| Related DTCs | P0341: Camshaft Position Sensor (Bank 1) Range Check or Rationality |
| Required sensors / components | Main: Camshaft position sensor Related |
| Required sensors / components | Crankshaft position sensor, engine speed sensor |
| Frequency of operation | Continuous |
| Duration | 5 seconds |
| MIL operation | P0340 Case 1 (no-signal): 2 driving cycles |
| MIL operation | P0340 Case 2 (miss-aligned), P0341: Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
P0340: No signal
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Starter | ON |
| Battery voltage while starter is ON | Less than 11 V |
TYPICAL ENABLING CONDITIONS (P0340: NO SIGNAL)
P0340: Miss-aligned
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Engine speed | 600 rpm or more |
| Starter | OFF |
TYPICAL ENABLING CONDITIONS (P0340: MISS-ALIGNED)
P0341
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Starter | After OFF to ON timing |
TYPICAL ENABLING CONDITIONS (P0341)
P0340: No signal
| Detection Criteria | Threshold |
|---|---|
| Camshaft position signal | No signal for 4 seconds |
TYPICAL MALFUNCTION THRESHOLDS (P0340: NO SIGNAL)
P0340: Misaligned
| Detection Criteria | Threshold |
|---|---|
| Camshaft position signal / Camshaft position signal | Misaligned for 5 seconds |
TYPICAL MALFUNCTION THRESHOLDS (P0340: MISALIGNED)
P0341
| Detection Criteria | Threshold |
|---|---|
| Camshaft position signal / Camshaft position signal | Misaligned |
| Camshaft position signal per 2 revolutions crankshaft | 12 counts or more |
TYPICAL MALFUNCTION THRESHOLDS (P0341)
| Monitor | Specification |
|---|---|
| Related DTCs | P0351: Ignition Coil With Igniter Circuit Malfunction |
| Required sensors / components | Igniter |
| Frequency of operation | Continuous |
| Duration | 0.256 second |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Either of the following conditions is met | A) or (b) |
| (a) Starter | OFF |
| (b) Engine speed | 1,500 rpm or more |
| Either of the following conditions is met | A) or (b) |
| (a) following conditions are met | 1 & 2 |
| 1. Engine speed | 500 rpm or less |
| 2. Battery voltage | 6 V or more |
| (b) Following conditions are met | 1 & 2 |
| 1. Engine speed | More than 500 rpm |
| 2. Battery voltage | 10 V or more |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| Ignition signal fail count | More than 2 times |
| "Ignition signal fail count" is as follows | When IGF should have returned despite sending IGT. |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard Value |
|---|---|
| Confirmed signal number | Confirmed signal number is equal to ignition signal |
COMPONENT OPERATING RANGE
Scheme 216
| Monitor | Specification |
|---|---|
| Related DTCs | P0420: Bank 1 Catalyst is Deterioration |
| Required sensors / components | Main: A/F sensor, heated oxygen sensor Related: MAF meter, engine coolant temperature sensor, engine speed sensor, intake air temperature sensor |
| Frequency of operation | Once per driving cycles |
| Duration | 150 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Battery voltage | 11 V or more |
| Intake air temperature | 10 °C (14 °F) or more |
| Idle | OFF |
| Intake air amount | 6 g/sec or more, and less than 28 g/sec |
| Engine speed | Less than 2,500 rpm |
| Engine coolant temperature | 75°C (157°F) or more |
| Estimated catalyst temperature conditions are met | 1 & 2 |
| 1. Up stream estimated catalyst | 450°C (842°F) or more, and 700°C (1,652°F) or less |
| 2. Down stream estimated catalyst temperature | 450°C (842°F) or more, and 700°C (1,652°F) or less |
| Fuel system status | Closed-loop |
| A/F sensor voltage | 3 V or more, and 3.5 V or less |
| Accumulated time with above parameters are met | 30 seconds multiply 3 times |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| Number condition is set that the following | 3 to 5 times |
| Catalyst deterioration level (heated oxygen sensor locus length) | 18 V or more (vary with front A/F sensor locus length) |
TYPICAL MALFUNCTION THRESHOLDS
The detailed information is described in "CHECKING MONITOR STATUS" (see PRE-CHECK ).
- TID (Test Identification) is assigned to each emission-related component.
- TLT (Test Limit Type): If TLT is 0, the component is malfunctioning when the test value is higher than the test limit. If TLT is 1, the component is malfunctioning when the test value is lower than the test limit.
- CID (Component Identification) is assigned to each test value.
- Unit Conversion is used to calculate the test value indicated on generic OBD scan tools.
TID $01: Catalyst - Using A/F Sensor and HO2S
| TLT | CID | Unit Conversion | Description of Test Value | Description of Test Limit |
|---|---|---|---|---|
| 0 | $01 | Multiply by 0.0078 (no dimension) | Catalyst deterioration level bank 1: Determined by waveform of A/F sensor and HO2S | Malfunction criterion |
TLD $01
Scheme 217
- Connect the hand-held tester or the OBD II scan tool to the DLC3.
- Start the engine and warm it up with all the accessories switched OFF until the water temperature is stable.
- Race the engine at 2,500 to 3,000 RPM for about 3 minutes
- When racing the engine at 3,000 RPM for 2 sec. and 2,000 RPM for 2 sec. alternately, check the waveform of the heated oxygen sensor (bank 1 sensor 2).
EVAP VSV stuck close (P0441)
| Detection Criteria | Threshold |
|---|---|
| Change FTP during "negative pressure introduction" | Less than 5 mmHg (0.7 kPa) |
TYPICAL MALFUNCTION THRESHOLDS (P0441 STUCK CLOSED)
EVAP VSV stuck open (P0441)
| Detection Criteria | Threshold |
|---|---|
| Time that both of the following conditions is met | 4 seconds or more |
| FTP before "negative pressure introduction" | 10 mmHg (-1.33 kPa) |
TYPICAL MALFUNCTION THRESHOLDS (P0441 STUCK OPEN)
CCV stuck close (P0446)
| Detection Criteria | Threshold |
|---|---|
| Time that both of the following conditions are met | 4 seconds or more |
| Accumulated EVAP purge volume | 0.5 g or more |
| FTP | Less than -13 mmHg (-1.7 kPa) |
TYPICAL MALFUNCTION THRESHOLDS (P0446 STUCK CLOSED)
CCV stuck open (P0446)
| Detection Criteria | Threshold |
|---|---|
| EVAP VSV stuck close | Detected |
TYPICAL MALFUNCTION THRESHOLDS (P0446 STUCK OPEN)
EVAP 0.04 inch leak (P0442)
| Detection Criteria | Threshold |
|---|---|
| All of the following conditions are met | |
| FTP increase for 5 seconds from -20 mmHg (-2.67 kPa) | More than 1.2 mmHg (0.16 kPa) |
| FTP increase for 5 seconds from -17 mmHg (-2.27 kPa) | More than 1.2 mmHg (0.16 kPa) |
| Minimum FTP after "negative pressure introduction" | Less than -18 mmHg (-2.4 kPa) |
TYPICAL MALFUNCTION THRESHOLDS (P0442 LEAK)
EVAP 0.02 inch leak (P0456)
| Detection Criteria | Threshold |
|---|---|
| FTP increase for 5 seconds from -20 mmHg (-2.67 kPa) | More than 0.5 mmHg (0.07 kPa) |
| FTP increase for 5 seconds from -17 mmHg (-2.27 kPa) | More than 0.5 mmHg (0.07 kPa) |
TYPICAL MALFUNCTION THRESHOLDS (P0456 LEAK)
The detailed information is described in "CHECKING MONITOR STATUS" (see PRE-CHECK ).
- TID (Test Identification) is assigned to each emission-related component.
- TLT (Test Limit Type): If TLT is 0, the component is malfunctioning when the test value is higher than the test limit. If TLT is 1, the component is malfunctioning when the test value is lower than the test limit.
- CID (Component Identification) is assigned to each test value.
- Unit Conversion is used to calculate the test value indicated on generic OBD scan tools.
TID $02: EVAP - LEVII Vacuum Monitor
| TLT | CID | Unit Conversion | Description of Test Value | Description of Test Limit |
|---|---|---|---|---|
| 1 | $01 | Multiply by 0.183 (mmHg) | Test value of EVAP VSV stuck closed: Determined by fuel tank pressure change during vacuum introduction | Malfunction criterion |
| 0 | $02 | Multiply by 0.0655 (Seconds) | Test value of EVAP VSV stuck open: Determined by abnormal state continuation time | Malfunction criterion |
| 0 | $03 | Multiply by 0.0655 (Seconds) | Test value of CCV: Determined by abnormal state continuation time | Malfunction criterion |
| 0 | $04 | Multiply by 0.0458 (mmHg) | Test value of 0.04 inch leak: Determined by fuel tank pressure change | Malfunction criterion |
| 0 | $05 | Multiply by 0.0458 (mmHg) | Test value of 0.02 inch leak: Determined by fuel tank pressure change | Malfunction criterion |
LEVII VACUUM MONITOR DESCRIPTION
Scheme 218
Scheme 219
- Vehicle must be cold, ambient temperature approximately between 50°F - 95°F.
- Intake Air Temp. (IAT) and Engine Coolant Temp. (ECT) sensor almost same value.
- Clear DTC's. Disconnecting the battery terminals or EFI No. 1 fuse. Readiness tests will show INCMPL (incomplete).
- Drive the vehicle according to LA#4 drive cycle. Note the state of Readiness Tests. They will change to COMPL as the evaluation monitors operate and if the system passes. This procedure may take approximately 20 minutes or more.
Note. Do not shut off the engine - the results will be invalid.
Pass Condition - No Problem Found by the ECM
If the EVAP evaluation monitor shows COMPL, go to the Non-Continuous Test screen.
Note. Do not shut off the engine - the results will be invalid.
Scheme 220
Scheme 221
- To get there, go to Advanced OBD II, Onboard Tests, Non-continuous Tests.
- If all of the tests in the time $02 category Tests show Pass, the evaluation monitor has operated and no problem was detected.
Fail Condition - Problem Detected by the ECM
If the EVAP evaluation monitor shows INCMPL, go to the Non-Continuous Test screen.
Scheme 222
Scheme 223
- If all Tests show Pass, the following may have occurred. The EVAP evaluation monitor did not operate. The EVAP evaluation monitor did not finish. The ECM withheld judgement.
- If one or more of the tests in the time $02 category show Fail, the EVAP evaluation monitor did operate and the ECM detected a problem.
- Go to Continuous Tests screen. This is the only place DTC's are listed for the first trip.
Note. The DTC listed may not be valid. A second trip is needed to confirm the DTC.
Scheme 224
Second Trip Procedure
- Vehicle must be cold, ambient temperature approximately between 50°F - 95°F.
- Go to Readiness Tests screen.
- Drive the vehicle according to LA#4 drive cycle. Note the state of EVAP evaluation monitor. This procedure may take approximately 20 minutes or more.
Note. Do not shut off the engine - the results will be invalid.
Scheme 225
If Readiness Tests changes to COMPL, the EVAP evaluation monitor has operated. Check for any stored DTC's.
Scheme 226
- If a DTC has stored, the problem has been detected and confirmed by the ECM.
- If no DTC was found, the EVAP monitor operated but no problem was detected.
| Monitor | Specification |
|---|---|
| Related DTCs | P0451: Vapor Pressure Sensor Range/Performance (Noise Monitoring) (Stuck monitoring) |
| Related DTCs | P0452: Vapor Pressure Sensor Range Check (Low input) |
| Related DTCs | P0453: Vapor Pressure Sensor Range Check (High input) |
| Required sensors / components | Main: Vapor pressure sensor |
| Required sensors / components | Related: Mass air flow meter, engine coolant temperature sensor |
| Frequency of operation | Once per driving cycle |
| Duration | P0451 (Noise monitoring): 10 seconds P0451 (Stuck monitoring): 20 minutes P0452, P0453: 7 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
P0451: Noise monitoring
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Altitude | Less than 2,4000 m (7,872 ft) |
| Battery voltage | 11 V or more |
| Difference between intake air temperature and engine coolant temperature at engine start | 7°C (19.4°F) or more, and 11.1°C (52°F) or less |
| Engine coolant temperature at engine start | 4.4°C (40°F) or more, and 35°C (95°F) |
| Intake air temperature at engine start | 4.4°C (40°F) or more, and 35°C (95°F) |
| Vehicle stop and idling | 5 sec. or more, and 15 sec. or more |
TYPICAL ENABLING CONDITIONS (NOISE MONITORING)
P0451: Stuck monitoring
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Altitude | Less than 2,4000 m (7,872 ft) |
| Battery voltage | 11 V or more |
| Vapor pressure sensor | No malfunction |
| Difference between intake air temperature and engine coolant temperature at engine start | 7°C (19.4°F) or more, and 11.1°C (52°F) or less |
| Engine coolant temperature at engine start | 4.4°C (40°F) or more, and 35°C (95°F) |
| Intake air temperature at engine start | 4.4°C (40°F) or more, and 35°C (95°F) |
| Time after engine start | 5 sec. or more |
TYPICAL ENABLING CONDITIONS (STUCK MONITORING)
P0452: Low input, P0453: high input
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Difference between intake air temperature and engine coolant temperature at engine start | 12°C (54°F) or less |
| Engine coolant temperature at engine start | 10°C (50°F) or more, and less than 35°C (95°F) |
| Intake air temperature at engine start | 10°C (50°F) or more, and less than 35°C (95°F) |
| Engine | Running |
TYPICAL ENABLING CONDITIONS (LOW OR HIGH INPUT)
P0451: Noise monitoring
| Detection Criteria | Threshold |
|---|---|
| Number that the following condition is met | 5 times from 5 to 15 seconds after idling start |
| Fuel tank pressure change | +/-5 mmHg (0.267 kPa) or more |
TYPICAL MALFUNCTION THRESHOLDS (P0451 NOISE MONITORING)
P0451: Stuck monitoring
| Detection Criteria | Threshold |
|---|---|
| Fuel tank pressure change value for 5 minutes | Less than 0.135 mmHg (0.018kpa) |
TYPICAL MALFUNCTION THRESHOLDS (P0451 STUCK MONITORING)
P0452: Low input
| Detection Criteria | Threshold |
|---|---|
| Fuel tank pressure | Less than -3.999 kPa (-30 mmHg) / when engine running |
TYPICAL MALFUNCTION THRESHOLDS (P0452 LOW INPUT)
P0453: High input
| Detection Criteria | Threshold |
|---|---|
| Fuel tank pressure | 1.999 kPa (15 mmHg) or more / when engine running |
TYPICAL MALFUNCTION THRESHOLDS (P0453 HIGH INPUT)
| Parameter | Standard Value |
|---|---|
| Fuel tank pressure | 26 to 11 mmHg (-3.5 to 1.5 kPa) [734 to 771 mmHg] |
COMPONENT OPERATING RANGE
P0500
| Monitor | Specification |
|---|---|
| Related DTC | P0500: Vehicle Speed Sensor |
| Required sensors / components | Vehicle speed sensor |
| Frequency of operation | Continuous |
| Duration | A/T: 8 seconds |
| Duration | M/T: 4 pulses x 500 transmission output shaft |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
P0500 M/T
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Engine coolant temperature | More than 70°C (158°F) |
| Engine speed | 1800 rpm or more, and less than 4800 rpm |
| Intake air amount per engine revolution | 0.75 g/rev or more |
| Fuel cut at high engine speed | Not executed |
TYPICAL ENABLING CONDITIONS (M/T)
P0500 A/T
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Vehicle speed (at 5.6 mph (9 km/h) or more) | 4 sec or more |
| Park/Neutral position switch | OFF (except P or N position) |
| Transfer Neutral switch (4WD) | Not N position |
TYPICAL ENABLING CONDITIONS (A/T)
P0500 M/T
| Detection Criteria | Threshold |
|---|---|
| Sensor signal | No pulse input |
TYPICAL MALFUNCTION THRESHOLDS (M/T)
P0500 A/T
| Detection Criteria | Threshold |
|---|---|
| Number of "no pulse input" | 500 times or more |
TYPICAL MALFUNCTION THRESHOLDS (A/T)
Scheme 227
Case 1
| Monitor | Specification |
|---|---|
| Related DTCs | P0505: Idle Air Control Malfunction (Functional Check) |
| Required sensors / components | Main: Crankshaft position sensor |
| Required sensors / components | Related: Vehicle speed sensor, engine coolant temperature sensor |
| Frequency of operation | Once per driving cycle |
| Duration | 10 minutes |
| MIL operation | 2 driving cycle |
| Sequence of operation | None |
MONITOR STRATEGY (CASE 1)
Case 2
| Monitor | Specification |
|---|---|
| Related DTCs | P0505: Idle Air Control Malfunction (Range Check) |
| Required sensors / components | Main: Crankshaft position sensor |
| Required sensors / components | Related: Vehicle speed sensor, engine coolant temperature sensor |
| Frequency of operation | Continuous |
| Duration | 10 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY (CASE 2)
Case 1
P0505: Idle air control malfunction (Functional check)
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Engine | Running |
| IAC flow rate learning is enabled for | 3 seconds |
| Engine speed | 400 rpm or more |
TYPICAL ENABLING CONDITIONS (CASE 1)
Case 2
P0505: Idle air control malfunction (Range check)
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Output signal duty | 10 % or more, and 90 % or less |
| Battery voltage | 10 V or more |
TYPICAL ENABLING CONDITIONS (CASE 2)
Case 1
P0505: Idle air control malfunction (Functional check)
| Detection Criteria | Threshold |
|---|---|
| Following conditions are met: (at idle (after driving greaterthanequalto 6.2 mph (10 km/h)) per cycle | A & B & C |
| A. Either of the following conditions is met | 1 or 2 |
| 1. Deviation of engine speed (when shift position N or A/C ON) | Less than -100 rpm or more than 200 rpm |
| 2. Deviation of engine speed (when shift position D or A/C OFF) | Less than -100 rpm or more than 150 rpm |
| B. IAC flow rate (learned value) | 2 L/sec or less, or 8 L/sec or more |
| C. Number of detection | 5 times/trip |
TYPICAL MALFUNCTION THRESHOLDS (CASE 1)
Case 2
P0505: Idle air control malfunction (Range check)
| Detection Criteria | Threshold |
|---|---|
| Output duty change | Missing |
TYPICAL MALFUNCTION THRESHOLDS (CASE 2)
| Monitor | Specification |
|---|---|
| Related DTCs | P0560: System Voltage Malfunction |
| Required sensors / components | ECM |
| Frequency of operation | Continuous |
| Duration | 3 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Stand-by RAM | Initialized |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| Battery voltage | Less than 3.5 V |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 228
| Monitor | Specification |
|---|---|
| Related DTCs | P0604: Internal Control Module Random Access Memory (RAM) Error |
| Related DTCs | P0606: ECM/PCM Processor |
| Related DTCs | P0657: Actuator Supply Voltage Circuit/Open |
| Required sensors / components | ECM |
| Frequency of operation | Continuous |
| Duration | Within 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
TYPICAL ENABLING CONDITIONS
P0604: ECM RAM errors
| Detection Criteria | Threshold |
|---|---|
| Difference between main and sub CPU output | Larger than the specified range |
TYPICAL MALFUNCTION THRESHOLDS (P0604)
P0606: ECM CPU malfunctions
| Detection Criteria | Threshold |
|---|---|
| Either of the following conditions is met | |
| Difference between throttle position of main CPU and throttle position of sub CPU | 0.3 V or more |
| Difference between accelerator pedal position of main CPU and accelerator pedal position of sub CPU | 0.3 V or more |
TYPICAL MALFUNCTION THRESHOLDS (P0606)
P0657: ETCS power supply function of ECM malfunction
| Detection Criteria | Threshold |
|---|---|
| Electronic throttle control system power supply when ignition switch OFF to On | 4 V or more |
TYPICAL MALFUNCTION THRESHOLDS (P0657)
| Monitor | Specification |
|---|---|
| Related DTCs | P0617: Starter Signal Circuit High |
| Required sensors / components | Starter relay, Park/neutral position switch, Ignition switch |
| Frequency of operation | Continuous |
| Duration | 20 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Battery voltage | 10.5 V or more |
| Vehicle speed | 12.4 mph (20 km/h) or more |
| Engine speed | 1,000 rpm |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| Starter signal | ON |
TYPICAL MALFUNCTION THRESHOLDS
Scheme 229
| Monitor | Specification |
|---|---|
| Related DTCs | P0724: Brake switch circuit high |
| Required sensors / components | Brake switch |
| Frequency of operation | Once per drive cycle |
| Duration | Go and stop 10 times |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Number of "go and stop" defined as follows | 10 times |
| Go | 30 km/h (18.6 mph) or more |
| Stop | Less than 3km/h (1.8 mph) |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| Switch status | ON stuck |
TYPICAL MALFUNCTION THRESHOLDS
| Monitor | Specification |
|---|---|
| Related DTCs | P1126: Magnetic Clutch Circuit |
| Required sensors/Components | Throttle control motor |
| Frequency of operation | Continuous |
| Duration | Within 1.5 seconds |
| MIL operation | 1 driving cycle |
| Sequence of operation | None |
MONITOR STRATEGY
Case 1, 2
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Magnet clutch | ON |
| Actuator power supply | 8.0 V or more |
TYPICAL ENABLING CONDITIONS (CASE 1 & 2)
Case 3
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| "Clutch Fail Counter" increments every 0.004 second while the following conditions are met | |
| Magnet clutch | ON |
| Actuator power supply | 8.0 V or more |
| Power MOS Fail signal | Fail |
| System down request | OFF |
TYPICAL ENABLING CONDITIONS (CASE 3)
Case 1
| Detection Criteria | Threshold |
|---|---|
| Clutch current | More than 1.4 A, or less than 0.4 A |
TYPICAL MALFUNCTION THRESHOLDS (CASE 1)
Case 2
| Detection Criteria | Threshold |
|---|---|
| Clutch current | More than 1.0 A, or less than 0.8 A |
TYPICAL MALFUNCTION THRESHOLDS (CASE 2)
Case 3
| Detection Criteria | Threshold |
|---|---|
| Clutch Fail Count | 25 times or more |
TYPICAL MALFUNCTION THRESHOLDS (CASE 3)
| Monitor | Specification |
|---|---|
| Related DTCs | P2102: Throttle actuator control motor current (low current) |
| Related DTCs | P2013: Throttle actuator control motor current (high current) |
| Required sensors / components | Throttle actuator motor |
| Frequency of operation | Continuous |
| Duration | 0.5 second: low current |
| 2 second: high current | |
| MIL Operation | Immediately: low current |
| 1 driving cycle: high current | |
| Sequence operation | None |
MONITOR STRATEGY
P2102: Throttle actuator control motor current (low current)
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Electronic throttle actuator drive duty | 80 % or more |
| Actuator power supply voltage | 8 V or more |
| Throttle motor | ON |
| Current motor current - Motor current at 0.016 second before | Less than 0.2 A |
TYPICAL ENABLING CONDITIONS (LOW CURRENT)
P2103: Throttle actuator control motor current (high current)
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Throttle motor | ON |
TYPICAL ENABLING CONDITIONS (HIGH CURRENT)
P2102: Throttle actuator control motor current (low current)
| Detection Criteria | Threshold |
|---|---|
| Throttle motor current | Less than 0.5 A (when motor drive duty 80 % or more) |
TYPICAL MALFUNCTION THRESHOLDS (P2102)
P2103: Throttle actuator control motor current (high current)
| Detection Criteria | Threshold |
|---|---|
| Hybrid IC diagnosis signal | Fail (for 0.1 seconds) |
| Hybrid IC current limiter port | Fail (for 0.6 seconds) |
TYPICAL MALFUNCTION THRESHOLDS (P2103)
Scheme 230
| Monitor | Specification |
|---|---|
| Related DTCs | P2111: Throttle Actuator Stuck Open |
| Related DTCs | P2112: Throttle Actuator Stuck Close |
| Required sensors / components | Throttle actuator motor, throttle valve |
| Frequency of operation | Continuous |
| Duration | 0.5 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
TYPICAL ENABLING CONDITIONS
P2111
| Item | Specification |
|---|---|
| Throttle motor electrical current | 2 A or more |
| Duty cycle ratio to close throttle valve | 80 % or more |
TYPICAL ENABLING CONDITIONS (P2111)
P2112
| Item | Specification |
|---|---|
| Throttle motor electrical current | 2 A or more |
| Duty cycle ratio to open throttle valve | 80 % or more |
TYPICAL ENABLING CONDITIONS (P2112)
| Detection Criteria | Threshold |
|---|---|
| Throttle position sensor voltage change | Less than 0.1 V |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard Value |
|---|---|
| TP sensor voltage | 0.2 to 4.8 V |
COMPONENT OPERATING RANGE
| Monitor | Specification |
|---|---|
| Related DTCs | P2118: Throttle Actuator Motor Power Supply Line Range Check (Low Voltage) |
| Required sensors / components | Throttle actuator motor |
| Frequency of operation | Continuous |
| Duration | 0.8 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Actuator power | ON |
| Battery voltage | 8 V or more |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| Throttle actuator motor power supply voltage | 4 V or less |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard Value |
|---|---|
| Throttle actuator motor power supply voltage | 9 to 14V |
COMPONENT OPERATING RANGE
Scheme 231
| Monitor | Specification |
|---|---|
| Related DTCs | P2119: Electronic Throttle Control System Failure |
| Required sensors / components | Main |
| Required sensors / components | Throttle actuator motor |
| Required sensors / components | Related |
| Required sensors / components | Throttle position sensor |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| Difference between commanded throttle position and current throttle position | 0.3 V or more |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard Value |
|---|---|
| Commanded throttle position | Same as current throttle position |
COMPONENT OPERATING RANGE
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
TYPICAL ENABLING CONDITIONS
P2120
| Detection Criteria | Threshold |
|---|---|
| VPA voltage | 0.2 V or less, or 4.7 V or more |
TYPICAL MALFUNCTION THRESHOLDS (P2120)
P2122
| Detection Criteria | Threshold |
|---|---|
| VPA voltage when VPA2 is 0.97° or more | 0.2 V or less |
TYPICAL MALFUNCTION THRESHOLDS (P2122)
P2123
| Detection Criteria | Threshold |
|---|---|
| VPA voltage | 4.7 V or more |
TYPICAL MALFUNCTION THRESHOLDS (P2123)
P2125
| Detection Criteria | Threshold |
|---|---|
| VPA2 voltage | 0.5 or less, 4.97 V or more |
TYPICAL MALFUNCTION THRESHOLDS (P2125)
P2127
| Detection Criteria | Threshold |
|---|---|
| VPA2 voltage when VPA is 0.97° or more | 0.5 V or less |
TYPICAL MALFUNCTION THRESHOLDS (P2127)
P2128
| Detection Criteria | Threshold |
|---|---|
| VPA2 voltage when VPA is 0.2 to 1.8 V | 4.97 V or more |
TYPICAL MALFUNCTION THRESHOLDS (P2128)
P2138: Accelerator pedal position sensor (Between VPA and VPA2) open
| Detection Criteria | Threshold |
|---|---|
| Voltage difference between VPA and VPA2 | 0.02 V or less |
TYPICAL MALFUNCTION THRESHOLDS (P2138 OPEN)
P2138: Accelerator pedal position sensor (Between VPA and VPA2) short
| Detection Criteria | Threshold |
|---|---|
| Both of the following conditions are met | |
| VPA voltage | 0.2 V or less |
| VPA2 voltage | 0.5 V or less |
TYPICAL MALFUNCTION THRESHOLDS (P2138 SHORT)
| Parameter | Standard Value |
|---|---|
| VPA voltage | 0.5 to 4.5 V |
| VPA2 voltage | 1.2 to 4.8 V |
COMPONENT OPERATING RANGE
Scheme 232
| Monitor | Specification |
|---|---|
| Related DTCs | P0121: Throttle position sensor rationality |
| Required sensors / components | Throttle position sensor |
| Frequency of operation | Continuous |
| Duration | 0.5 second |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| [VPA - (VPA2 - 0.8)] * * Corrected by learning value | More than 1.6 V or Less than 0.8 V |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard Value |
|---|---|
| TP sensor voltage | 0.2 to 4.8 V |
COMPONENT OPERATING RANGE
| Monitor | Specification |
|---|---|
| Related DTCs | P2195: A/F Sensor Signal Stuck Lean |
| Related DTCs | P2196: A/F Sensor Signal Stuck Rich |
| Required sensors / components | Main: A/F sensor |
| Required sensors / components | Related: Heated oxygen sensor |
| Frequency of operation | Continuous |
| Duration | 10 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Time after engine start | 30 seconds or more |
| A/F status | Activated |
| A/F sensor admittance | 0.0024 1/ohm |
| Fuel system status | Closed-loop |
| Engine | Running |
| Sub-feedback status | Executing |
TYPICAL ENABLING CONDITIONS
P2195: Stuck lean
| Detection Criteria | Threshold |
|---|---|
| Time while the following condition is met | 10 seconds or more |
| A/F output voltage | More than 3.8 V |
| Rear Heated oxygen sensor voltage | 0.15 V or more |
TYPICAL MALFUNCTION THRESHOLDS (P2195)
P2196: Stuck rich
| Detection Criteria | Threshold |
|---|---|
| Time while the following condition is met | 10 seconds or more |
| A/F output voltage | Less than 2.8 V |
| Rear Heated oxygen sensor voltage | Less than 0.85 V |
TYPICAL MALFUNCTION THRESHOLDS (P2196)
Scheme 233
Scheme 234
- Connect the hand-held tester to the DLC3.
- Switch the hand-held tester from the normal mode to the check mode (See «PRE-CHECK»(ref-181812-S42723497822005080500000) ).
- Start the engine and warm it up for 2 min. with all the accessory switched OFF.
- Drive the vehicle at 38 to 75 mph (60 to 120 km/h) and the engine speed at 1,600 to 3,200 RPM for 3 to 5 min.
HINT
If a malfunction exists, the MIL will light up during step (d).
Note. If the conditions in this test are not strictly followed, detection of the malfunction will not be possible. If you do not have a hand-held tester, turn the ignition switch OFF after performing steps (c) and (d), then perform steps (c) and (d) again.
| Monitor | Specification |
|---|---|
| Related DTCs | P2238: A/F Sensor Pumping Current Circuit Low |
| Related DTCs | P2239: A/F Sensor Pumping Current Circuit High |
| Required sensors / components | Main: A/F sensor |
| Required sensors / components | Related: Engine speed sensor, vehicle speed sensor, engine coolant temperature sensor |
| Frequency of operation | Once per driving cycle |
| Duration | 5 seconds |
| MIL operation | Immediately |
| Sequence of operation | None |
MONITOR STRATEGY
"A/F sensor voltage precondition" is defined as follows
| Item | Specification |
|---|---|
| Time after engine start | 120 seconds or more |
| Time after ignition switch is ON | 1 second or more |
| Engine | Running |
TYPICAL ENABLING CONDITIONS (A/F SENSOR VOLTAGE PRECONDITION)
"A/F sensor admittance precondition" is defined as follows
| Item | Specification |
|---|---|
| Battery voltage | 10.5 V or more |
| Time after ignition switch is ON | 1 second or more |
| Engine coolant temperature | 20°C (68°F) or more |
| Engine | Running |
| Fuel cut | OFF |
| Time after fuel cut is OFF | 5 seconds or more |
| Heater electricity cut | OFF |
| Time after heater electricity cut OFF | 20 seconds or more |
| AF+ voltage | More than 0.5 V, and 4.5 V or less |
| Heater drive duty | 25 % or more |
TYPICAL ENABLING CONDITIONS (A/F SENSOR ADMITTANCE PRECONDITION)
P2238: A/F sensor pumping current circuit low (AF+, AF- open) (AF+, AF- short)
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Time while "A/F sensor admittance pre condition" is met | 20 seconds or more |
TYPICAL ENABLING CONDITIONS (P2238: A/F SENSOR PUMPING CURRENT CIRCUIT LOW (AF+, AF- OPEN) (AF+, AF- SHORT))
P2238: A/F sensor pumping current circuit low (AF+, GND short)
| Item | Specification |
|---|---|
| "A/F sensor voltage precondition" | Met |
TYPICAL ENABLING CONDITIONS (P2238: A/F SENSOR PUMPING CURRENT CIRCUIT LOW (AF+, GND SHORT))
P2239: A/F sensor pumping current circuit high
| Item | Specification |
|---|---|
| "A/F sensor voltage precondition" | Met |
TYPICAL ENABLING CONDITIONS (P2239)
P2238: A/F sensor pumping current circuit low (AF+, AF- open) (AF+, AF- short)
| Detection Criteria | Threshold |
|---|---|
| A/F sensor admittance | Less than 0.016 1/ohm |
TYPICAL MALFUNCTION THRESHOLDS P2238 (AF+, AF- open) (AF+, AF- short)
P2238: A/F sensor pumping current circuit low (AF+, GND short)
| Detection Criteria | Threshold |
|---|---|
| A/F+ terminal voltage | 0.5 V or less |
TYPICAL MALFUNCTION THRESHOLDS P2238 (AF+, GND short)
P2239: A/F sensor pumping current circuit high
| Detection Criteria | Threshold |
|---|---|
| A/F+ terminal voltage (AF+ - +B, VCC short) | More than 4.5 V |
TYPICAL MALFUNCTION THRESHOLDS (P2239)
| Monitor | Specification |
|---|---|
| Related DTCs | P2A00: A/F Sensor Circuit Slow Response |
| Required sensors / components | Main: A/F sensor Related: Engine speed sensor, vehicle speed sensor |
| Frequency of operation | Once per driving cycle |
| Duration | 60 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
MONITOR STRATEGY
| Item | Specification |
|---|---|
| The monitor will run whenever the following DTCs are not present | See "List of Disable a Monitor" ( PRE-CHECK ) |
| Engine | Running |
| Time after engine start | 120 seconds |
| Driving for 20 seconds after conditions are met | (a) and (b) |
| (a) Vehicle speed | 25 mph (40 km/h) or more |
| (b) Engine speed | 900 rpm or more |
| Fuel system status | Closed-loop |
| A/F sensor status | Activated |
| Idle | OFF |
| Time after idle off | 2 seconds |
| Engine speed | 1,400 rpm or more, and 3,200 rpm or less |
| Vehicle speed | 37.5 mph (60 km/h) or more, and 75 mph (120 km/h) or less |
| Fuel cut | OFF |
| Time after fuel cut is off | 2 seconds or more |
TYPICAL ENABLING CONDITIONS
| Detection Criteria | Threshold |
|---|---|
| Response rate deterioration level | 6 or more |
| "Response level" | 0.4 to 1.0 A (at idle and HOT and battery voltage 11 to 14 V) |
TYPICAL MALFUNCTION THRESHOLDS
| Parameter | Standard Value |
|---|---|
| Heated oxygen sensor heater current | 3.1 A (at 20°C (68°F)) or more |
COMPONENT OPERATING RANGE
MONITOR RESULT (MODE 06 DATA)
Refer to PRE-CHECK for detailed information.
| Test ID/Comp ID | Description of Test Data | Conversion Factor | Unit | Description of Test Limit |
|---|---|---|---|---|
| $06/$81 to $82 | Parameter for identifying A/F sensor response rate Locus length of fuel compensation amount (fuel trim)/Locus length of A/F sensor output | Multiply by 1/4096 (no dimension) | N/A | Threshold A/F sensor response rate to detect A/F sensor deterioration level |
MONITOR RESULT
