Starting System: Specifications — Toyota Tercel L50 рестайлинг (1997-1999)

Starting System: Specifications Toyota Tercel L50 рестайлинг

Starter 16 illustrations

PARK/NEUTRAL SWITCH SPECIFICATIONS

Application & Gearshift Position		Continuity Between Terminals No.
Camry, Celica, Corolla & RAV4
Park		5 & 6, 2 & 7
Reverse		2 & 8
Neutral		5 & 6, 2 & 9
Drive		2 & 10
2		2 & 3
Low		2 & 4
Tacoma, T100 & 4Runner
Park		5 & 6, 4 & 7
Reverse		4 & 8
Neutral		5 & 6, 4 & 10
Drive		4 & 9
2		4 & 2
Low		4 & 3
Tercel
Park		2 & 3, 1 & 6
Reverse		5 & 6
Neutral		2 & 3, 6 & 7
Drive		6 & 8
2		6 & 9
Low		6 & 4

PARK/NEUTRAL SWITCH SPECIFICATIONS (4-CYLINDER)

Application & Gearshift Position		Continuity Between Terminals No.
Supra
Park		5 & 6, 4 & 7
Reverse		4 & 8
Neutral		5 & 6, 4 & 10
Drive		4 & 9
2		4 & 2
Low		4 & 3

PARK/NEUTRAL SWITCH SPECIFICATIONS (6-CYLINDER)

Application & Gearshift Position		Continuity Between Terminals No.
Avalon, Camry & Sienna
Park		5 & 6, 2 & 7
Reverse		2 & 8
Neutral		5 & 6, 2 & 9
Drive		2 & 10
2		2 & 3
Low		2 & 4
Tacoma, T100 & 4Runner
Park		5 & 6, 4 & 7
Reverse		4 & 8
Neutral		5 & 6, 4 & 10
Drive		4 & 9
2		4 & 2
Low		4 & 3

PARK/NEUTRAL SWITCH SPECIFICATIONS (V6)

Application & Gearshift Position		Continuity Between Terminals No.
Land Cruiser
Park		5 & 6, 4 & 7
Reverse		4 & 8
Neutral		5 & 6, 4 & 10
Drive		4 & 9
2		2 & 4
Low		3 & 4

PARK/NEUTRAL SWITCH SPECIFICATIONS (V8)

Application		Ft. Lbs. (N.m)
Intake Manifold Support
Tercel		13 (18)
Starter Mounting Bolts
Avalon, Corolla, Land Cruiser,RAV4, T100 & 4Runner		29 (39)
Camry, Sienna, Supra, Tacoma & Tercel		27 (37)
Celica		28 (38)
INCH Lbs. (N.m)
Park Neutral Position Switch
Land Cruiser, Tacoma, T100 & 4Runner		116 (13)
All Others		48 (5.4)
