- Disconnect electrical connector from Throttle Position Sensor (TPS). Loosen mounting screws. Connect ohmmeter between terminals IDL and E1 (MR2 2.2L with M/T) or E2 (all others). (Scheme 25)-29.
- Apply vacuum to throttle opener (if equipped). (Scheme 25)-29. To set initial clearance, insert proper thickness feeler gauge between throttle stop screw and throttle lever. See «4-CYLINDER THROTTLE POSITION SENSOR ADJUSTMENT»(ref-21088-S00513260702001010300000) table.
- With ohmmeter showing no continuity, rotate TPS clockwise until continuity exists. Tighten mounting screws. Using specified feeler gauge, recheck adjusted clearance. Disconnect ohmmeter and install electrical connector on TPS.
| Model | Clearance In. (mm) | Initial Clearance In. (mm) | Ohms |
|---|
| Camry (1) | .024 (.61) | .020 (.51) | Continuity |
| " | " | .028 (.71) | No Continuity |
| Celica |
| 1.6L (4A-FE) | .028 (.71) | .024 (.61) | Continuity |
| " | " | .031 (.79) | No Continuity |
| All Others (1) | .024 (.61) | .020 (.51) | Continuity |
| " | " | .028 (.71) | No Continuity |
| Corolla | .028 (.71) | .024 (.61) | Continuity |
| " | " | .031 (.79) | No Continuity |
| MR2 |
| 2.0L Turbo | .024 (.61) | .020 (.51) | Continuity |
| " | " | .028 (.71) | No Continuity |
| 2.2L (1) |
| A/T | .024 (.61) | .020 (.51) | Continuity |
| " | " | .028 (.71) | No Continuity |
| M/T | .028 (.71) | .020 (.51) | Continuity |
| " | " | .035 (.89) | No Continuity |
| Paseo (1) | .024 (.61) | .020 (.51) | Continuity |
| " | " | .028 (.71) | No Continuity |
| Pickup & 4Runner | .027 (.69) | .022 (.56) | Continuity |
| " | " | .033 (.84) | No Continuity |
| Previa | .033 (.84) | .033 (.84) | Continuity |
| Tercel (1) | .024 (.61) | .020 (.51) | Continuity |
| " | " | .028 (.71) | No Continuity |
| (1) Apply vacuum to throttle opener (if equipped) before checking TPS adjustment. |
| (1) | Apply vacuum to throttle opener (if equipped) before checking TPS adjustment. |
4-CYLINDER THROTTLE POSITION SENSOR ADJUSTMENT
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
