Wheel Alignment Specifications & Procedures Toyota Tercel L30

Wheel Alignment 1 illustration
ApplicationSpecification
Except Wagon - W/out Power Steering
Front
Camber in Degrees
Fraction0 +/- 3/4
Decimal0 +/- .75
Caster in Degrees
Fraction1 +/- 3/4
Decimal1.00 +/- .75
Toe-In in Inches
Fraction0 +/- 1/16
Decimal0 +/- .06
Toe-In in Degrees
Fraction0 +/- 1/8
Decimal0 +/- .13
Toe-Out on Turns
Inner37 1/2°
Outer32 13/16°
Steering Axis Inclination (SAI)11 1/2°
Except Wagon - W/Power Steering
Front
Camber in Degrees
Fraction0 +/- 3.4
Decimal0 +/- .75
Caster in Degrees
Fraction2 1/2 +/- 3/4
Decimal2.50 +/- .75
Toe-In in Inches
Fraction0 +/- 1/16
Decimal0 +/- .06
Toe-In in Degrees
Fraction0 +/- 1/8
Decimal0 +/- .13
Toe-Out on Turns
Inner37 1/2°
Outer32 13/16°
Wagon - 2WD - W/out Power Steering
Front
Camber in Degrees
Fraction0 +/- 3/4
Decimal0 +/- .75
Caster in Degrees
Fraction3/4 +/- 3/4
Decimal.75 +/- .75
Toe-In in Inches
Fraction1/32 +/- 1/16
Decimal.03 +/- .06
Toe-In in Degrees
Fraction1/16 +/- 1/8
Decimal.06 +/- .13
Toe-Out on Turns
Inner36 3/16 +/- 1°
Outer33 +/- 1°
Steering Axis Inclination (SAI)12 9/16°
Wagon - 2WD - W/Power Steering
Front
Caster in Degrees
Fraction2 1/4 +/- 3/4
Decimal2.25 +/- .75
Toe-Out on Turns
Inner35 13/16 +/- 1°
Outer32 27/32 +/- 1°
Steering Axis Inclination (SAI)12 9/16°
Wagon - 4WD - W/out Power Steering
Front
Camber in Degrees
Fraction9/16 +/- 3/4
Decimal.56 +/- .75
Caster in Degrees
Fraction2 1/4 +/- 3/4
Decimal2.25 +/- .75
Toe-In in Inches
Fraction1/32 +/- 1/16
Decimal.03 +/- .06
Toe-In in Degrees
Fraction1/16 +/- 1/8
Decimal.06 +/- .03
Toe-Out on Turns
Inner35 3/16 +/- 1°
Outer33 +/- 1°
Steering Axis Inclination (SAI)12°
Wagon - 4WD - W/Power Steering
Front
Camber in Degrees
Fraction9/16 +/- 3/4
Decimal.56 +/- .75
Caster in Degrees
Fraction2 1/4 +/- 3/4
Decimal2.25 +/- .75
Toe-Out on Turns
Inner36 5/16 +/- 1°
Outer33 5/16 +/- 1°
Steering Axis Inclination (SAI)12°

WHEEL ALIGNMENT SPECIFICATIONS

ALIGNMENT PROCEDURES

Note. Alignment procedures not available.

Caster Adjustment To adjust caster, lengthen or shorten strut rod as shown. Scheme 2

Scheme 2: Caster Adjustment To adjust caster, lengthen or shorten strut rod as shown.
Scheme 2: Caster Adjustment To adjust caster, lengthen or shorten strut rod as shown.
