Maintenance Information Toyota Tercel L30

MODEL IDENTIFICATION

Note. For scheduled maintenance intervals and the related fluid capacities, fluid specifications and labor times for major service intervals, see SCHEDULED SERVICES article in this section. Warranty information and specifications for fluid capacities, lubrication specifications, wheel and tire size, and battery type are covered in this article.

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 2

SEVERE & NORMAL SERVICE DEFINITIONS

Service is recommended at mileage intervals based on vehicle operation and engine type. Service schedules are based on the following primary operating conditions

Normal Service

1. Driven More Than 10 Miles Daily
2. No Operating Conditions From Severe Service Schedule

Severe Service (Unique Driving Conditions)

1. Towing A Trailer, Using A Camper Or Car Top Carrier
2. Repeated Short Trips Less Than 5 Miles When Temperatures Are Below Freezing
3. Extensive Idling Conditions (Taxi Or Delivery Type Service)
4. Operating On Dusty, Rough, Muddy Or Salt Spread Roads

CAMSHAFT TIMING BELT

The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".

Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.

Belts or components should be inspected and replaced if any of the following conditions exist

1. Cracks Or Tears In Belt Surface
2. Missing, Damaged, Cracked Or Rounded Teeth
3. Oil Contamination
4. Damaged Or Faulty Tensioners
5. Incorrect Tension Adjustment

Replace camshaft timing belt every 72 months or 60,000 miles if the vehicle is idled frequently or used extensively for long distance driving at low speeds such as taxi, police or door-to-door delivery.

Scheme 3

Scheme 4

SERVICE LABOR TIMES

Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

TIRE INFLATION

Tire inflation pressure can be found on the tire information label located on the inside of the glove compartment lid.

WHEEL TIGHTENING

Tighten all wheel lug nuts to 76 ft. lbs. (103 N.m).

BATTERY SPECIFICATIONS

All years and models use batteries with BCI group number 24.

RADIATOR FAN & CAP

CATALYTIC CONVERTER

WARRANTY INFORMATION

NEW VEHICLE LIMITED WARRANTY

Covers any repair or replacement of parts which becomes necessary due to defects in materials or workmanship under normal use for 36 months or 36,000 miles from in-service date.

CORROSION PERFORATION

Covers any repair or replacement to body sheet metal which develops corrosion perforation, in normal use, due to defects in material or workmanship for a period of 5 years, regardless of mileage.

BATTERY

Covers replacement of defective original battery for first 12 months or 12,000 miles. After the first 12 months or 12,000 miles, warranty covers a pro-rated amount based on months in service, up to a maximum of 36 months.

AIR CONDITIONER REFRIGERANT CHARGE

Covers the air conditioner refrigerant for the first 12 months, regardless of mileage, unless done as a warranty repair.

ADJUSTMENTS

Service adjustments are covered for the first 12 months or 12,500 miles, whichever occurs first.

EMISSION DEFECT WARRANTY (EXCEPT CALIFORNIA)

Warrants to the retail purchaser, and subsequent purchaser that vehicle was designed, built, and equipped so as to conform at the time of sale with applicable emission regulations and that it is free from defects in materials or workmanship which may cause the vehicle to fail to conform with applicable regulations for 5 years or 50,000 miles, whichever occurs first.

EMISSION PERFORMANCE WARRANTY (EXCEPT CALIFORNIA)

Covers all repairs, adjustments, or replacements if vehicle fails to conform to applicable emission standards and such failure results or will result in the vehicle owner having to bear any penalty or other sanctions under local, state or federal law for 5 years or 50,000 miles, whichever comes first. After 24 months or 24,000 miles, the manufacturer will make the necessary adjustments, repairs or replacements at no cost to the owner when noncompliance is caused by a failure of any of the following parts

1. Cold Start Enrichment System
2. Deceleration Control
3. Air/Fuel Ratio Feedback Control System
4. HAC Valve
5. Automatic Hot Air Intake
6. Heat Control Valve
7. Mixture Control Valve
8. Cold Mixture Heater
9. Spark Control Devices
10. PCV Valve Or Orifice
11. Charcoal Canister
12. Vapor Liquid Separator
13. EGR Valve And Associated Parts
14. Air Pump
15. Airflow Control Valves
16. Air Injection Manifold
17. Catalytic Converter
18. Fuel Filler Neck Restrictor
19. Sensors, Switches, Valves And Electronic Controls Used In Above Systems
20. Hoses, Clamps, Belts, Pulleys, Tubes, Fittings And Gaskets Used In Above Systems

EMISSION DEFECT WARRANTY (CALIFORNIA)

Warrants to the retail purchaser, and subsequent purchaser that vehicle was designed, built, and equipped so as to conform at the time of sale with applicable U.S. and California emission regulations and that it is free from defects in materials or workmanship which may cause the vehicle to fail to conform with applicable regulations. The following components are covered for 24 months or 24,000 miles

1. Carburetor And Internal Parts
2. EFI Components
3. Cold Start Enrichment System
4. Distributor And Internal Parts
5. Spark Plugs
6. Ignition Wires
7. Hoses, Clamps, Fittings, Tubing, Sealing Gaskets Or Devices, And Mounting Hardware Used In Above Systems
8. Pulleys, Belts And Idlers Used In Above Systems

The following components are covered by the California Emission Defect Warranty for 5 years or 50,000 miles, whichever occurs first

1. Deceleration Control
2. Air/Fuel Ratio Feedback Control System
3. HAC Valve
4. Automatic Hot Air Intake
5. Heat Control Valve
6. Mixture Control Valve
7. Cold Mixture Heater
8. Intake Manifold
9. Supercharger
10. Turbocharger
11. Intercooler
12. Spark Control Devices
13. Ignition Coil And Ignitor
14. PCV Valve Or Orifice
15. Oil Filler Cap
16. Charcoal Canister
17. Vapor Liquid Separator
18. Fuel Tank And Filler Cap
19. EGR Valve And Associated Parts
20. Air Pump
21. Airflow Control Valves
22. Air Injection Manifold
23. Catalytic Converter
24. Fuel Filler Neck Restrictor
25. Exhaust Manifold
26. Exhaust Pipe
27. Sensors, Switches, Valves And Electronic Controls Used In Above Systems
28. Hoses, Clamps, Belts, Pulleys, Tubes, Fittings And Gaskets Used In Above Systems

FUSE PANEL LOCATION

The passenger compartment fuse panels are located behind the driver's side kick panel and behind the passenger's side kick panel. The engine compartment fuse panel is in the engine compartment.

Scheme 5

Fuse & Circuit Breaker Identification

1. 1 - 7.5 Amp Spare
2. 2 - 15 Amp Spare
3. 3 - 7.5 Amp Turn Signal Lights
4. 4 - 7.5 Amp Discharge Warning Light & Charging System, Electric Engine Cooling Fan Relay
5. 5 - 7.5 Amp Radio & Cassette Player
6. 6 - 15 Amp Cigarette Lighter & Clock
7. 7 - 7.5 Amp Clock & Interior Light, Trunk, Open Door & Personal Lights, Seat Belt Warning Light & Buzzer
8. 8 - 15 Amp Stoplights
9. 9 - 15 Amp Tail, Park & License Lights, Side Marker & Instrument Panel Lights
10. 10 - Blank
11. 11 - 7.5 Amp Gauges & Warning Lights, Back-Up Lights, Heater Main & Sun Roof Relays
12. 12 - 20 Amp Wipers & Washers
13. 13 - 10 Amp Air Conditioner
14. 14 - 30 Amp (Circuit Breaker) Electric Sun Roof (1986)
15. 15 - 30 Amp (Circuit Breaker) Rear Window Defogger (1986)
16. 16 - 30 Amp (Circuit Breaker) Heater Blower Motor (1986)

Scheme 6

1. 1 - Blank
2. 2 - Blank
3. 3 - 15 Amp Charging & Emission Control Systems
4. 4 - 15 Amp Right Headlight
5. 5 - 15 Amp Left Headlight
6. 6 - 7.5 Amp Charging System & Discharge Warning Light, Automatic Choke & Emission Control System
7. 7 - Blank
8. 8 - Blank
9. 9 - Blank
10. 10 - 15 Amp Hazard Flashers & Horns

Scheme 7

1. 1 - 7.5 Amp Radio & Cassette Player
2. 2 - 15 Amp Charging & Emission Control Systems, Discharge Warning Light, Electric Underhood Cooling Fans
3. 3 - 7.5 Amp Turn Signal Lights
4. 4 - 20 Amp Stoplights & Cruise Control Cancel, Parking Lights
5. 5 - 15 Amp Cigarette Lighter
6. 6 - 7.5 Amp Gauges, Warning & Back-Up Lights, Air Conditioner & Rear Window Defogger
7. 7 - 7.5 Amp Interior & Trunk Lights, Clock & Open Door Warning Light
8. 8 - 10 Amp Cruise Control System, Electronically Controlled A/T System
9. 9 - 10 Amp Charging System
10. 10 - 15 Amp Tail, Park & License Lights, Side Marker & Instrument Panel Lights
11. 11 - 20 Amp Wipers & Washers
12. 12 - 30 Amp Air Conditioner
13. 13 - 10 Amp Air Conditioner

Scheme 8

1. 1 - 7.5 Amp Environmental Control System (1990)
2. 2 - 7.5 Amp Charging System, Emission Control System, Discharge Warning Light, Automatic Choke
3. 3 - 15 Amp Left Headlight
4. 4 - 15 Amp Right Headlight
5. 5 - 15 Amp Radio & Cassette Player
6. 6 - 15 Amp Hazard Flashers & Horns
7. 7 - 15 Amp EFI System (1990)
8. 8 - Blank
