Scheme 1
Scheme 2
ON-VEHICLE INSPECTION
Note. In this part of the article, the terms "cold" and "hot" refer to the temperature of the coils. "Cold" means approximately - 10 to 50°C (14 to 122°F). "Hot" means approximately 50 to 100°C (122 to 212°F).
Scheme 3
Scheme 4
Scheme 5
Scheme 6
- PERFORM SPARK TEST Check for DTCs. NOTE: If a DTC is present, perform troubleshooting procedures for that DTC. Check if sparks occur. Remove the ignition coil. Remove the spark plug. Install the spark plug to the ignition coil and connect the ignition coil connector. Disconnect the 4 injector connectors. Ground the spark plug. Visually check that sparks occur while the engine is being cranked. NOTE: Be sure to ground the spark plug when checking. If the ignition coil has been struck or dropped, replace it. Do not crank the engine for more than 2 seconds. Spark test flow chart. Check that the wire harness side connector of the ignition coil with igniter is securely connected. Result RESULT Result Proceed to NG Connect securely OK Go to next step Perform spark test on each ignition coil with igniter. Replace ignition coil with igniter with a normal one. Perform spark test again. Result RESULT Result Proceed to OK Replace ignition coil with igniter NG Go to next step Check power supply to ignition coil with igniter. Turn the ignition switch ON. Check that there is battery voltage at ignition coil positive (+) terminal. Result RESULT Result Proceed to NG Check wiring between engine switch and ignition coil with igniter OK Go to next step Check resistance of camshaft position sensor. Standard resistance RESISTANCE REFERENCE TABLE Temperature Specified Condition Cold 835 to 1,400 ohms Hot 1,060 to 1,645 ohms Result RESULT Result Proceed to NG Replace camshaft position sensor OK Go to next step Check resistance of crankshaft position sensor. Standard resistance RESISTANCE REFERENCE TABLE Temperature Specified Condition Cold 1,690 to 2,740 ohms Hot 2,065 to 3,225 ohms Result RESULT Result Proceed to NG Replace crankshaft position sensor. OK Go to next step Check IGT signal from ECM. Result RESULT Result Proceed to NG Check ECM OK Repair wiring between ignition coil and ECM Using a 16 mm plug wrench, install the spark plug. Torque: 18 N*m (183 kgf*cm, 13 ft.*lbf) Install the ignition coil. Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf)
- CHECK SPARK PLUG NOTE: Do not use a wire brush for cleaning. Do not attempt to adjust the electrode gap of a used spark plug. Check the electrode. Using a megaohmmeter, measure the insulation resistance. Insulation resistance: 10 Mohms or more HINT: If a megaohmmeter is not available, perform the following simple inspection instead. Alternative inspection method: Quickly accelerate the engine to 4,000 rpm 5 times. Remove the spark plug. Visually check the spark plug. If the electrode is dry, the spark plug is functioning properly. If the electrode is damp, proceed to the next step. Check the spark plug for any damage on its thread and insulator. If there is damage, replace the spark plug. If not, reinstall the spark plug. Recommended spark plug SPARK PLUG SPECIFICATION TABLE Manufacturer Spark Plug Type DENSO made SK20R11 NGK made ILFR6C11 Check the spark plug electrode gap. Maximum electrode gap for used spark plug: 1.3 mm (0.051 in.) If the gap is greater than the maximum, replace the spark plug. Electrode gap for new spark plug: 1.1 mm (0.043 in.) NOTE: When adjusting the gap of a new spark plug, bend only the base of the ground electrode. Do not touch the tip. Never attempt to adjust the gap of a used plug. Clean the spark plugs. If the electrode has traces of wet carbon, clean the electrode with a spark plug cleaner and then dry it. Air pressure: 588 kPa (6 kgf/cm 2 , 85 psi) Duration: 20 seconds or less HINT: Only use the spark plug cleaner when the electrode is free of oil. If the electrode has traces of oil, use gasoline to clean off the oil before using the spark plug cleaner.
