Engine Cooling System (1GR-FE): Overview Toyota Tacoma II

Scheme 53

Scheme 54

1. CHECK COOLING SYSTEM FOR LEAKAGE Remove the radiator cap. CAUTION: To avoid the danger of being burned, do not remove the radiator cap while the engine and radiator are still hot. Thermal expansion will cause hot engine coolant and steam to blow out from the radiator. Fill the radiator with coolant and attach a radiator cap tester. Warm up the engine. Pump it to 118 kPa (1.2 kgf/cm 2 , 17.1 psi), then check that the pressure does not drop. If the pressure drops, check the hoses, radiator and water pump for leakage. If there are no signs of external coolant leakage, check the heater core, cylinder block and head. Reinstall the radiator cap.
2. CHECK COOLANT LEVEL OF RESERVOIR The engine coolant should be between the LOW and FULL lines when the engine is cold. If low, check for leakage and add Toyota Super Long Life Coolant or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology up to the FULL line.
3. CHECK ENGINE COOLANT QUALITY Remove the radiator cap. CAUTION: To avoid the danger of being burned, do not remove the radiator cap while the engine and radiator are still hot. Thermal expansion will cause hot engine coolant and steam to blow out from the radiator. Check for any excessive deposits of rust or scale around the radiator cap and radiator filler hole; the coolant should be free of oil. If excessively dirty, replace the coolant. Reinstall the radiator cap.

Scheme 55

Scheme 56

1. DRAIN ENGINE COOLANT CAUTION: To avoid the danger of being burned, do not remove the radiator cap while the engine and radiator are still hot. Thermal expansion will cause hot engine coolant and steam to blow out from the radiator. Remove the service hole cover from the engine under cover. Install a vinyl hose onto the drain on the radiator side. Fix the vinyl hose with tape. Loosen the 3 drain plugs on the engine and radiator, and drain the coolant. Remove the radiator cap. Drain the coolant from the reservoir tank. Tighten the 3 drain plugs. Torque: 13 N*m (130 kgf*cm, 9 ft.*lbf) for the engine Remove the vinyl hose from the radiator.
2. ADD ENGINE COOLANT Pour coolant into the radiator until it overflows. Capacity TRANSMISSION AND CAPACITY Transmission Capacity Manual Transmission 9.7 liters (10.3 Us qts, 8.5 Imp. qts) Automatic Transmission 9.8 liters (10.4 Us qts, 8.6 Imp. qts) HINT: Use of improper coolants may damage the engine cooling system. Use only Toyota Super Long Life Coolant or similar high quality ethylene glycol based non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology (coolant with long-life hybrid organic acid technology consists of a combination of low phosphates and organic acids). New Toyota vehicles are filled with Toyota Super Long Life Coolant (color is pink, premixed ethylene glycol concentration is approximately 50% and freezing temperature is -35°C (-31°F)). When replacing the coolant, Toyota Super Long Life Coolant is recommended. NOTE: Do not substitute plain water for engine coolant. Check the coolant level inside the radiator by squeezing the inlet and outlet radiator hoses several times by hand. If the coolant level goes down, add coolant. Install the radiator cap securely. Slowly pour coolant into the radiator reservoir until it reaches the FULL line. Warm up the engine until the cooling fan operates. Set the air conditioning as follows while warming up the engine. ITEM CONDITION TABLE Item Condition Fan Speed Any setting except OFF Temperature Toward WARM Air Conditioning Switch OFF Maintain the engine speed at 2,000 to 2,500 rpm and warm up the engine until the cooling fan operates. Squeeze the inlet and outlet radiator hoses several times by hand while warming up the engine. Stop the engine and wait until the coolant cools down. Remove the radiator cap and check the coolant level inside the radiator. If the coolant level is below the full level, perform the steps from ( a ) through ( h ) and repeat the operation until the coolant level remains at the full level. Check the coolant level inside the radiator reservoir tank again. If it is below the full level, add coolant.
3. CHECK FOR ENGINE COOLANT LEAKAGE Fill the radiator with coolant and attach a radiator cap tester. Pump it to 118 kPa (1.2 kgf/cm 2 17.1 psi), then check for leakage.

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE NO. 1 ENGINE UNDER COVER SUBASSEMBLY (for Pre Runner and 4WD Type) Remove the 4 bolts, then remove the engine under cover.
3. DRAIN ENGINE COOLANT (See «COOLANT»(ref-263626-S39394347042007091100000) )
4. REMOVE RADIATOR SUPPORT TO FRAME SEAL LH (See «REMOVAL»(ref-263626-S32200610762007091100000) )
5. REMOVE V-BANK COVER (See «REMOVAL»(/toyota/tacoma/ii-2004-2011/remont/testing-diagnostics/#engine-control-system-1gr-fe) )
6. REMOVE FAN SHROUD (See «REMOVAL»(ref-263626-S32200610762007091100000) )
7. REMOVE AIR CLEANER ASSEMBLY (See «REMOVAL»(/toyota/tacoma/ii-2004-2011/remont/testing-diagnostics/#engine-control-system-1gr-fe) )
8. REMOVE WATER INLET Disconnect the 2 oil cooler hoses (with oil cooler). Disconnect the 2 radiator hoses. Disconnect the 5 water by-pass hoses. Remove the 5 bolts and water inlet. Remove the O-ring from the water outlet pipe. Remove the gasket from the water pump.
9. REMOVE NO. 2 IDLER PULLEY SUB-ASSEMBLY Remove the 2 bolts, then remove the 2 idler pulleys.
10. REMOVE GENERATOR ASSEMBLY (See «REMOVAL»(ref-263636-S17400661852007091100000) )
11. SEPARATE COOLER COMPRESSOR ASSEMBLY (See «CRANKSHAFT POSITION SENSOR»(/toyota/tacoma/ii-2004-2011/remont/testing-diagnostics/#engine-control-system-1gr-fe) )
12. REMOVE V-RIBBED BELT TENSIONER ASSEMBLY HINT: DRIVE TYPE AND REFERENCE TABLE Drive Type Reference 2WD «REMOVAL»(ref-263620-S11565117702007091100000) Pre Runner and 4WD «REMOVAL»(ref-263620-S38727182432007091100000)
13. REMOVE WATER PUMP ASSEMBLY Remove the 17 bolts, then remove the water pump and gasket.

Scheme 63

1. INSPECT WATER PUMP ASSEMBLY Visually check the water hole for coolant leakage. If leakage is found, replace the water pump assembly. Turn the pulley and check that the water pump bearing moves smoothly and quietly. If necessary, replace the water pump assembly.

Scheme 64

Scheme 65

Scheme 66

1. INSTALL WATER PUMP ASSEMBLY Install a new gasket and the water pump with the 17 bolts. Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf) for bolt A 23 N*m (235 kgf*cm, 17 ft.*lbf) for bolt B
2. INSTALL V-RIBBED BELT TENSIONER ASSEMBLY HINT: DRIVE TYPE AND REFERENCE TABLE Drive Type Reference 2WD «INSTALLATION»(ref-263620-S03930477642007091100000) Pre Runner and 4WD «INSTALLATION»(ref-263620-S01802223722007091100000)
3. INSTALL COOLER COMPRESSOR ASSEMBLY (See «INSTALLATION»(/toyota/tacoma/ii-2004-2011/remont/testing-diagnostics/#engine-control-system-1gr-fe) )
4. INSTALL GENERATOR ASSEMBLY (See «INSTALLATION»(ref-263636-S21179071572007091100000) )
5. INSTALL NO. 2 IDLER PULLEY SUB-ASSEMBLY Install the 2 idler pulleys with the 2 bolts. Torque: 39 N*m (398 kgf*cm, 29 ft.*lbf)
6. INSTALL WATER INLET Install a new O-ring onto the water outlet pipe. Install a new gasket onto the water pump. Apply soapy water to the O-ring. Install the water inlet with the 5 bolts. Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf) Connect the 5 water by-pass hoses. Connect the 2 radiator hoses. Connect the 2 oil cooler hoses (with oil cooler).
7. INSTALL AIR CLEANER ASSEMBLY (See «INSTALLATION»(/toyota/tacoma/ii-2004-2011/remont/testing-diagnostics/#engine-control-system-1gr-fe) )
8. INSTALL FAN SHROUD (See «INSTALLATION»(ref-263626-S14308694572007091100000) )
9. INSTALL RADIATOR SUPPORT TO FRAME SEAL LH
10. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)
11. ADD ENGINE COOLANT (See «COOLANT»(ref-263626-S39394347042007091100000) )
12. CHECK FOR ENGINE COOLANT LEAKAGE (See «REPLACEMENT»(ref-263626-S34865161462007091100000) )
13. INSTALL V-BANK COVER Install the V-bank cover with the 2 nuts. Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf)
14. INSTALL NO. 1 ENGINE UNDER COVER SUBASSEMBLY (for Pre Runner and 4WD Type) Install the engine under cover with the 4 bolts. Torque: 30 N*m (306 kgf*cm, 22 ft.*lbf)
