Audio System & Visual System: Removal & Installation Toyota Tacoma II

REMOVAL

HINT

1. Use the same procedures for the RH and LH sides.
2. The procedures listed below are for the LH side.

Scheme 65

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE FRONT DOOR WINDOW REGULATOR HANDLE ASSEMBLY (See DISASSEMBLY )
3. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See DISASSEMBLY )
4. REMOVE FRONT DOOR TRIM PANEL ASSEMBLY LH (See DISASSEMBLY )
5. REMOVE FRONT NO. 1 SPEAKER ASSEMBLY Disconnect the connector. Remove the 3 screws and the front No. 1 speaker assembly.

INSTALLATION

HINT

1. Use the same procedures for the RH and LH sides.
2. The procedures listed below are for the LH side.

Scheme 66

1. INSTALL FRONT NO. 1 SPEAKER ASSEMBLY Install the front No. 1 speaker assembly with the 3 screws. Connect the connector.
2. INSTALL FRONT DOOR TRIM PANEL ASSEMBLY LH (See REASSEMBLY )
3. INSTALL FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See REASSEMBLY )
4. INSTALL FRONT DOOR WINDOW REGULATOR HANDLE ASSEMBLY (See REASSEMBLY )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)

Scheme 67

Scheme 68

HINT

1. Use the same procedures for the RH and LH sides.
2. The procedures listed below are for the LH side.

Scheme 69

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE FRONT DOOR WINDOW REGULATOR HANDLE ASSEMBLY (w/o Power Door Lock) (See DISASSEMBLY )
3. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (w/ Power Door Lock) (See DISASSEMBLY )
4. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See DISASSEMBLY )
5. REMOVE FRONT DOOR TRIM PANEL ASSEMBLY LH (See DISASSEMBLY )
6. REMOVE FRONT NO. 1 SPEAKER ASSEMBLY Disconnect the connector. Remove the 4 screws and the front No. 1 speaker assembly.

HINT

1. Use the same procedures for the RH and LH sides.
2. The procedures listed below are for the LH side.

Scheme 70

1. INSTALL FRONT NO. 1 SPEAKER ASSEMBLY Install the front No. 1 speaker assembly with the 4 screws. Connect the connector.
2. INSTALL FRONT DOOR TRIM PANEL ASSEMBLY LH (See REASSEMBLY )
3. INSTALL FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See REASSEMBLY )
4. INSTALL POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (w/ Power Door Lock) (See REASSEMBLY )
5. INSTALL FRONT DOOR WINDOW REGULATOR HANDLE ASSEMBLY (w/o Power Door Lock) (See REASSEMBLY )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)

Scheme 71

Scheme 72

Scheme 73

HINT

1. Use the same procedures for the RH and LH sides.
2. The procedures listed below are for the LH side.

Scheme 74

Scheme 75

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE FRONT DOOR WINDOW REGULATOR HANDLE ASSEMBLY (w/o Power Door Lock) (See DISASSEMBLY )
3. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (w/ Power Door Lock) (See DISASSEMBLY )
4. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See DISASSEMBLY )
5. REMOVE FRONT DOOR TRIM PANEL ASSEMBLY LH (See DISASSEMBLY )
6. REMOVE FRONT NO. 2 SPEAKER ASSEMBLY Disconnect the connector. Remove the 2 bolts. Disengage the claw and remove the front No. 2 speaker assembly.

HINT

1. Use the same procedures for the RH and LH sides.
2. The procedures listed below are for the LH side.

Scheme 76

Scheme 77

1. INSTALL FRONT NO. 2 SPEAKER ASSEMBLY Engage the claw. Install the front No. 2 speaker assembly with the 2 bolts. Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf) Connect the connector.
2. INSTALL FRONT DOOR TRIM PANEL ASSEMBLY LH (See REASSEMBLY )
3. INSTALL FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See REASSEMBLY )
4. INSTALL POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (w/ Power Door Lock) (See REASSEMBLY )
5. INSTALL FRONT DOOR WINDOW REGULATOR HANDLE ASSEMBLY (w/o Power Door Lock) (See REASSEMBLY )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)

Scheme 78

HINT

1. Use the same procedures for the RH and LH sides.
2. The procedures listed below are for the LH side.

Scheme 79

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (See DISASSEMBLY )
3. REMOVE REAR DOOR TRIM PANEL ASSEMBLY LH (See DISASSEMBLY )
4. REMOVE REAR DOOR INSIDE HANDLE SUB-ASSEMBLY LH (See DISASSEMBLY )
5. REMOVE REAR SPEAKER ASSEMBLY Disconnect the connector. Remove the 3 screws and the rear speaker assembly.

HINT

1. Use the same procedures for the RH and LH sides.
2. The procedures listed below are for the LH side.

Scheme 80

1. INSTALL REAR SPEAKER ASSEMBLY Install the rear speaker assembly with the 3 screws. Connect the connector.
2. INSTALL REAR DOOR INSIDE HANDLE SUB-ASSEMBLY LH (See REASSEMBLY )
3. INSTALL REAR DOOR TRIM PANEL ASSEMBLY LH (See REASSEMBLY )
4. INSTALL REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (See REASSEMBLY )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)

Scheme 81

HINT

1. Use the same procedures for the RH and LH sides.
2. The procedures listed below are for the LH side.

Scheme 82

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE LAP BELT OUTER ANCHOR COVER (See DISASSEMBLY )
3. REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (See DISASSEMBLY )
4. REMOVE REAR ACCESS PANEL WEATHERSTRIP LH (See DISASSEMBLY )
5. REMOVE REAR SPEAKER ASSEMBLY Disconnect the connector. Remove the 3 screws and the rear speaker assembly.

Scheme 83

1. INSTALL REAR SPEAKER ASSEMBLY Install the rear speaker assembly with the 3 screws. Connect the connector.
2. INSTALL REAR ACCESS PANEL WEATHERSTRIP LH (See REASSEMBLY )
3. INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY (See REASSEMBLY )
4. INSTALL LAP BELT OUTER ANCHOR COVER (See REASSEMBLY )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)

Scheme 84

Scheme 85

Scheme 86

Scheme 87

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE REAR SEATBACK ASSEMBLY RH (See REMOVAL )
3. REMOVE REAR SEATBACK ASSEMBLY LH (See REMOVAL )
4. REMOVE LUGGAGE COMPARTMENT SIDE TRAY (See REMOVAL )
5. REMOVE NO. 1 SPEAKER ASSEMBLY WITH BOX Disconnect the 3 connectors. Remove the clamp. Remove the 4 bolts and the No. 1 speaker assembly with box.
6. REMOVE STEREO COMPONENT AMPLIFIER ASSEMBLY Using a Torx socket wrench T20, remove the 4 screws and the stereo component amplifier assembly.

Scheme 88

Scheme 89

Scheme 90

1. INSTALL STEREO COMPONENT AMPLIFIER ASSEMBLY Using a Torx socket wrench T20, install the 4 screws and the stereo component amplifier assembly.
2. INSTALL NO. 1 SPEAKER ASSEMBLY WITH BOX Install the No. 1 speaker assembly with box with the 4 bolts. Torque: 8.4 N*m (85 kgf*cm, 74 in.*lbf) NOTE: Install the bolts in the order (Scheme 89) Connect the connector. Install the clamp.
3. INSTALL LUGGAGE COMPARTMENT SIDE TRAY (See INSTALLATION )
4. INSTALL REAR SEATBACK ASSEMBLY LH (See INSTALLATION )
5. INSTALL REAR SEATBACK ASSEMBLY RH (See INSTALLATION )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)

Scheme 91

Scheme 92

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE FRONT FLOOR FOOTREST (See FRONT FLOOR FOOTREST )
3. REMOVE FRONT DOOR SCUFF PLATE LH (See REMOVAL )
4. REMOVE FRONT DOOR SCUFF PLATE RH (See REMOVAL )
5. REMOVE COWL SIDE TRIM BOARD LH (See REMOVAL )
6. REMOVE COWL SIDE TRIM BOARD RH (See REMOVAL )
7. SEPARATE FRONT DOOR OPENING TRIM WEATHERSTRIP LH (See REMOVAL )
8. SEPARATE FRONT DOOR OPENING TRIM WEATHERSTRIP RH (See REMOVAL )
9. REMOVE FRONT PILLAR GARNISH LH (See REMOVAL )
10. REMOVE FRONT PILLAR GARNISH RH (See REMOVAL )
11. REMOVE INSTRUMENT PANEL UNDER TRAY (for Pedal Type Parking Brake) (See REMOVAL )
12. REMOVE INSTRUMENT PANEL HOLE COVER (for Lever Type Parking Brake) (See REMOVAL )
13. REMOVE CONSOLE UPPER REAR PANEL SUB-ASSEMBLY (for Automatic Transmission on Separate Seat Type) (See REMOVAL )
14. REMOVE CONSOLE UPPER REAR PANEL SUB-ASSEMBLY (for Manual Transmission on Separate Seat Type) (See REMOVAL )
15. REMOVE REAR CONSOLE BOX ASSEMBLY (for Separate Seat Type) (See REMOVAL )
16. REMOVE INSTRUMENT PANEL CUP HOLDER TRAY (for Automatic Transmission on Separate Seat Type) (See REMOVAL )
17. REMOVE FRONT CONSOLE BOX (for Automatic Transmission on Separate Seat Type) (See REMOVAL )
18. REMOVE FRONT CONSOLE BOX (for Manual Transmission on Separate Seat Type) (See REMOVAL )
19. REMOVE FRONT CONSOLE BOX (for Automatic Transmission on Bench Seat Type) (See REMOVAL )
20. REMOVE FRONT CONSOLE BOX (for Manual Transmission on Bench Seat Type) (See REMOVAL )
21. REMOVE AIR CONDITIONER CONTROL ASSEMBLY (See REMOVAL )
22. REMOVE RADIO RECEIVER ASSEMBLY (See RADIO RECEIVER )
23. SEPARATE HOOD LOCK CONTROL LEVER SUB-ASSEMBLY (See DISASSEMBLY )
24. REMOVE NO. 1 LOWER INSTRUMENT PANEL FINISH PANEL (See REMOVAL )
25. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See REMOVAL )
26. REMOVE COMBINATION METER ASSEMBLY (See REMOVAL )
27. REMOVE INSTRUMENT CLUSTER CENTER FINISH PANEL SUB-ASSEMBLY (See REMOVAL )
28. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY (See REMOVAL )
29. REMOVE INSTRUMENT PANEL LOWER FINISH PANEL SUB-ASSEMBLY RH (See REMOVAL )
30. REMOVE LOWER INSTRUMENT PANEL LH (See REMOVAL )
31. REMOVE INSTRUMENT LOWER COVER SUB-ASSEMBLY (See REMOVAL )
32. REMOVE INSTRUMENT SIDE PANEL RH (See REMOVAL )
33. DISCONNECT PASSENGER AIRBAG CONNECTOR (See REMOVAL )
34. REMOVE INSTRUMENT PANEL PASSENGER AIRBAG ASSEMBLY (See REMOVAL )
35. REMOVE INSTRUMENT PANEL SUB-ASSEMBLY
36. REMOVE RADIO ANTENNA CORD SUB-ASSEMBLY Disengage the 4 claws and remove the radio antenna cord sub-assembly.

Scheme 93

1. INSTALL RADIO ANTENNA CORD SUB-ASSEMBLY Engage the 4 claws and install the Radio antenna cord.
2. INSTALL INSTRUMENT PANEL SUB-ASSEMBLY
3. INSTALL INSTRUMENT PANEL PASSENGER AIRBAG ASSEMBLY (See INSTALLATION )
4. CONNECT PASSENGER AIRBAG CONNECTOR (See INSTALLATION )
5. INSTALL INSTRUMENT SIDE PANEL RH (See INSTALLATION )
6. INSTALL INSTRUMENT LOWER COVER SUB-ASSEMBLY (See INSTALLATION )
7. INSTALL LOWER INSTRUMENT PANEL LH (See INSTALLATION )
8. INSTALL INSTRUMENT PANEL LOWER FINISH PANEL SUB-ASSEMBLY RH (See INSTALLATION )
9. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY (See INSTALLATION )
10. INSTALL CENTER INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See INSTALLATION )
11. INSTALL COMBINATION METER ASSEMBLY (See INSTALLATION )
12. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See INSTALLATION )
13. INSTALL NO. 1 LOWER INSTRUMENT PANEL FINISH PANEL (See INSTALLATION )
14. INSTALL HOOD LOCK CONTROL LEVER SUB-ASSEMBLY (See REASSEMBLY )
15. INSTALL RADIO RECEIVER ASSEMBLY (See INSTALLATION )
16. INSTALL AIR CONDITIONING CONTROL ASSEMBLY (See INSTALLATION )
17. INSTALL FRONT CONSOLE BOX (for Manual Transmission on Bench Seat Type) (See INSTALLATION )
18. INSTALL FRONT CONSOLE BOX (for Automatic Transmission on Bench Seat Type) (See INSTALLATION )
19. INSTALL FRONT CONSOLE BOX (for Manual Transmission on Separate Seat Type) (See INSTALLATION )
20. INSTALL FRONT CONSOLE BOX (for Automatic Transmission on Separate Seat Type) (See INSTALLATION )
21. INSTALL INSTRUMENT PANEL CUP HOLDER TRAY (for Automatic Transmission on Separate Seat Type) (See INSTALLATION )
22. INSTALL REAR CONSOLE BOX ASSEMBLY (for Separate Seat Type) (See INSTALLATION )
23. INSTALL CONSOLE UPPER REAR PANEL SUBASSEMBLY (for Manual Transmission on Separate Seat Type) (See INSTALLATION )
24. INSTALL CONSOLE UPPER REAR PANEL SUB-ASSEMBLY (for Automatic Transmission on Separate Seat Type) (See INSTALLATION )
25. INSTALL INSTRUMENT PANEL HOLE COVER (for Lever Type Parking Brake) (See INSTALLATION )
26. INSTALL INSTRUMENT PANEL UNDER TRAY (for Pedal Type Parking Brake) (See INSTALLATION )
27. INSTALL FRONT PILLAR GARNISH RH (See INSTALLATION )
28. INSTALL FRONT PILLAR GARNISH LH (See INSTALLATION )
29. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH (See INSTALLATION )
30. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH (See INSTALLATION )
31. INSTALL COWL SIDE TRIM BOARD RH (See INSTALLATION )
32. INSTALL COWL SIDE TRIM BOARD LH (See INSTALLATION )
33. INSTALL FRONT DOOR SCUFF PLATE RH (See INSTALLATION )
34. INSTALL FRONT DOOR SCUFF PLATE LH (See INSTALLATION )
35. INSTALL FRONT FLOOR FOOTREST (See FRONT FLOOR FOOTREST )
36. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY (See REMOVAL )
3. REMOVE INSTRUMENT PANEL LOWER FINISH PANEL SUB-ASSEMBLY RH (See REMOVAL )
4. REMOVE ASSIST GRIP SUB-ASSEMBLY (See REMOVAL )
5. REMOVE FRONT PILLAR GARNISH RH (See REMOVAL )
6. REMOVE PULL TOP ANTENNA POLE SUB - ASSEMBLY (See REMOVAL )
7. REMOVE ANTENNA ORNAMENT Remove the nut and the antenna ornament.
8. REMOVE WITH HOLDER ANTENNA ASSEMBLY Disconnect the connector and remove the 3 clamps. Tie a piece of string to the tip of the cable of the with holder antenna assembly. HINT: Use a string that is longer than the antenna assembly (with holder). Remove the bolt and the with holder antenna assembly. NOTE: Leave the string inside the pillar for the installation of a new antenna.

Scheme 99

Scheme 100

Scheme 101

1. INSTALL WITH HOLDER ANTENNA ASSEMBLY Tie the string inside the pillar to the new antenna assembly (with holder). Using the string, fit the antenna assembly (with holder) into the pillar. Connect the connector and install the 3 clamps. Install the antenna ornament with the nut. Install the with holder antenna assembly with the bolt.
2. INSTALL PULL TOP ANTENNA POLE SUB - ASSEMBLY (See INSTALLATION )
3. INSTALL FRONT PILLAR GARNISH RH (See INSTALLATION )
4. INSTALL ASSIST GRIP SUB-ASSEMBLY (See INSTALLATION )
5. INSTALL INSTRUMENT PANEL LOWER FINISH PANEL SUB-ASSEMBLY RH (See INSTALLATION )
6. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY (See INSTALLATION )
7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)

Scheme 102

Scheme 103

1. REMOVE PULL TOP ANTENNA POLE SUB - ASSEMBLY Remove the pull top antenna pole sub-assembly by turning it counterclockwise.

Scheme 104

1. INSTALL PULL TOP ANTENNA POLE SUB - ASSEMBLY Install the pull top antenna pole sub-assembly by turning it clockwise.

Scheme 105

Scheme 106

Scheme 107

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE CONSOLE UPPER REAR PANEL SUB-ASSEMBLY (See REMOVAL )
3. REMOVE REAR CONSOLE BOX ASSEMBLY (See REMOVAL )
4. REMOVE VOLTAGE INVERTER ASSEMBLY Remove the 6 bolts. Disconnect the 2 connectors and remove the 2 wire harness clamps.

Scheme 108

1. INSPECT VOLTAGE INVERTER ASSEMBLY TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition +B (L2-2) - PGND (L2-1) IG switch ON 10 to 14 V AC1 (L1-5) - PGND (L2-1) IG switch ON, main switch ON Pulse generation P/T (L1-1) - Body Ground Always Below 1 AC2 (L1-11) - PGND (L2-1) IG switch ON, main switch ON Pulse generation

Scheme 109

Scheme 110

1. INSTALL VOLTAGE INVERTER ASSEMBLY Connect the 2 connectors and install the 2 wire harness clamps. Install the 6 bolts. Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf) for bolt A: Go to next step Torque: 15 N*m (153 kgf*cm, 11 ft.*lbf) for bolt B: Go to next step
2. INSTALL REAR CONSOLE BOX ASSEMBLY (See INSTALLATION )
3. INSTALL CONSOLE UPPER REAR PANEL SUB-ASSEMBLY (See INSTALLATION )
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL Wait for 90 seconds after disconnecting the cable to prevent the airbag working.
2. REMOVE NO. 2 LOWER STEERING WHEEL COVER (See REMOVAL )
3. REMOVE NO. 3 LOWER STEERING WHEEL COVER (See REMOVAL )
4. REMOVE HORN BUTTON ASSEMBLY (See REMOVAL )
5. REMOVE STEERING PAD SWITCH LH Disconnect the connector. Remove the screw. Disengage the 2 pins and remove the steering pad switch LH. Release the tab of the steering pad switch cable from the steering pad switch LH (Scheme 114) Disengage the 2 claws and open the latch on the top of the connector (Scheme 115) Pull out the connector while pinching the latch with fingers and disconnect the steering pad switch cable from the steering pad switch LH.

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

1. INSTALL STEERING PAD SWITCH LH Install the steering pad switch cable onto the steering pad switch LH while holding the connector cover. Hold the connector cover down to engage the 2 claws (Scheme 118) Install the tab of the steering pad switch cable onto the steering pad switch LH (Scheme 119) Engage the 2 pins and install the steering pad switch LH. Install the screw. Connect the connector.
2. INSTALL HORN BUTTON ASSEMBLY (See ON-VEHICLE INSPECTION )
3. INSTALL NO. 3 LOWER STEERING WHEEL COVER (See INSTALLATION )
4. INSTALL NO. 2 LOWER STEERING WHEEL COVER (See INSTALLATION )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 3.9 N*m (40 kgf*cm, 35 in.*lbf)
6. INSPECT HORN BUTTON ASSEMBLY (See ON-VEHICLE INSPECTION )
7. INSPECT SRS WARNING LIGHT (See INSTALLATION )
