Wiring Diagrams Toyota Tacoma I facelift (2000-2004)

28 systems 56 wiring diagrams 813 components
Contents — 28 systems, 56 diagrams
Air conditioning
Anti-lock brakes
Body computer
Computer data lines
Cruise control
Engine performance 2.4l
Engine performance 2.7l
Engine performance 3.4l
Exterior lights
Ground distribution
Headlights
Horn
Instrument cluster
Interior lights
Power distribution
Power door locks
Power mirrors
Power seats
Power windows
Radio
Shift interlocks
Starting/charging
Supplemental restraints
Transmission 2.4l
Transmission 2.7l
Transmission 3.4l
Warning systems
Wiper/washer

Air conditioning

# Heater circuit

Air conditioning — Heater circuit — Heater circuit. Toyota Tacoma I facelift (2000-2004)
Components on the diagram

    # Manual a/c circuit

    Air conditioning — Manual a/c circuit — Manual a/c circuit. Toyota Tacoma I facelift (2000-2004)
    Components on the diagram

      Anti-lock brakes

      # Anti-lock brake circuits

      Anti-lock brakes — Anti-lock brake circuits — Anti-lock brake circuits. Toyota Tacoma I facelift (2000-2004)
      Components on the diagram

        Body computer

        # Body computer circuits

        Body computer — Body computer circuits — Body computer circuits. Toyota Tacoma I facelift (2000-2004)
        Components on the diagram

          Computer data lines

          Computer data lines — Computer data lines. Toyota Tacoma I facelift (2000-2004)
          Components on the diagram

            Cruise control

            # Cruise control circuit

            Cruise control — Cruise control circuit — Cruise control circuit. Toyota Tacoma I facelift (2000-2004)
            Components on the diagram

              Engine performance 2.4l

              # Wiring diagram engine performance 2.4ls

              # Wiring diagram engine performance 2.4ls (1 of 4)

              Engine performance 2.4l — Wiring diagram engine performance 2.4ls — Wiring diagram engine performance 2.4ls (1 of 4). Toyota Tacoma I facelift (2000-2004)
              Components on the diagram

                # Wiring diagram engine performance 2.4ls (2 of 4)

                Engine performance 2.4l — Wiring diagram engine performance 2.4ls — Wiring diagram engine performance 2.4ls (2 of 4). Toyota Tacoma I facelift (2000-2004)
                Components on the diagram

                  # Wiring diagram engine performance 2.4ls (3 of 4)

                  Engine performance 2.4l — Wiring diagram engine performance 2.4ls — Wiring diagram engine performance 2.4ls (3 of 4). Toyota Tacoma I facelift (2000-2004)
                  Components on the diagram

                    # Wiring diagram engine performance 2.4ls (4 of 4)

                    Engine performance 2.4l — Wiring diagram engine performance 2.4ls — Wiring diagram engine performance 2.4ls (4 of 4). Toyota Tacoma I facelift (2000-2004)
                    Components on the diagram

                      Engine performance 2.7l

                      # Wiring diagram engine performance 2.7ls

                      # Wiring diagram engine performance 2.7ls (1 of 4)

                      Engine performance 2.7l — Wiring diagram engine performance 2.7ls — Wiring diagram engine performance 2.7ls (1 of 4). Toyota Tacoma I facelift (2000-2004)
                      Components on the diagram

                        # Wiring diagram engine performance 2.7ls (2 of 4)

                        Engine performance 2.7l — Wiring diagram engine performance 2.7ls — Wiring diagram engine performance 2.7ls (2 of 4). Toyota Tacoma I facelift (2000-2004)
                        Components on the diagram

                          # Wiring diagram engine performance 2.7ls (3 of 4)

                          Engine performance 2.7l — Wiring diagram engine performance 2.7ls — Wiring diagram engine performance 2.7ls (3 of 4). Toyota Tacoma I facelift (2000-2004)
                          Components on the diagram

                            # Wiring diagram engine performance 2.7ls (4 of 4)

                            Engine performance 2.7l — Wiring diagram engine performance 2.7ls — Wiring diagram engine performance 2.7ls (4 of 4). Toyota Tacoma I facelift (2000-2004)
                            Components on the diagram

                              Engine performance 3.4l

                              # Wiring diagram engine performance 3.4ls

                              # Wiring diagram engine performance 3.4ls (1 of 4)

                              Engine performance 3.4l — Wiring diagram engine performance 3.4ls — Wiring diagram engine performance 3.4ls (1 of 4). Toyota Tacoma I facelift (2000-2004)
                              Components on the diagram

                                # Wiring diagram engine performance 3.4ls (2 of 4)

                                Engine performance 3.4l — Wiring diagram engine performance 3.4ls — Wiring diagram engine performance 3.4ls (2 of 4). Toyota Tacoma I facelift (2000-2004)
                                Components on the diagram

                                  # Wiring diagram engine performance 3.4ls (3 of 4)

                                  Engine performance 3.4l — Wiring diagram engine performance 3.4ls — Wiring diagram engine performance 3.4ls (3 of 4). Toyota Tacoma I facelift (2000-2004)
                                  Components on the diagram

                                    # Wiring diagram engine performance 3.4ls (4 of 4)

                                    Engine performance 3.4l — Wiring diagram engine performance 3.4ls — Wiring diagram engine performance 3.4ls (4 of 4). Toyota Tacoma I facelift (2000-2004)
                                    Components on the diagram

                                      Exterior lights

                                      # Back-up lamps circuit

                                      Exterior lights — Back-up lamps circuit — Back-up lamps circuit. Toyota Tacoma I facelift (2000-2004)
                                      Components on the diagram

                                        # Exterior lamps circuit

                                        Exterior lights — Exterior lamps circuit — Exterior lamps circuit. Toyota Tacoma I facelift (2000-2004)
                                        Components on the diagram

                                          Ground distribution

                                          # Ground distribution circuit

                                          # Ground distribution circuit (1 of 2)

                                          Ground distribution — Ground distribution circuit — Ground distribution circuit (1 of 2). Toyota Tacoma I facelift (2000-2004)
                                          Components on the diagram

                                            # Ground distribution circuit (2 of 2)

                                            Ground distribution — Ground distribution circuit — Ground distribution circuit (2 of 2). Toyota Tacoma I facelift (2000-2004)
                                            Components on the diagram

                                              Headlights

                                              # Headlight circuit, with drl

                                              Headlights — Headlight circuit, with drl — Headlight circuit, with drl. Toyota Tacoma I facelift (2000-2004)
                                              Components on the diagram

                                                # Headlight circuit, without drl

                                                Headlights — Headlight circuit, without drl — Headlight circuit, without drl. Toyota Tacoma I facelift (2000-2004)
                                                Components on the diagram

                                                  Horn

                                                  # Horn circuit

                                                  Horn — Horn circuit — Horn circuit. Toyota Tacoma I facelift (2000-2004)
                                                  Components on the diagram

                                                    Instrument cluster

                                                    # Clock circuit

                                                    Instrument cluster — Clock circuit — Clock circuit. Toyota Tacoma I facelift (2000-2004)
                                                    Components on the diagram

                                                      # Instrument cluster circuit, with tachometer

                                                      Instrument cluster — Instrument cluster circuit, with tachometer — Instrument cluster circuit, with tachometer. Toyota Tacoma I facelift (2000-2004)
                                                      Components on the diagram

                                                        # Instrument cluster circuit, without tachometer

                                                        Instrument cluster — Instrument cluster circuit, without tachometer — Instrument cluster circuit, without tachometer. Toyota Tacoma I facelift (2000-2004)
                                                        Components on the diagram

                                                          Interior lights

                                                          # Courtesy lamps circuit

                                                          Interior lights — Courtesy lamps circuit — Courtesy lamps circuit. Toyota Tacoma I facelift (2000-2004)
                                                          Components on the diagram

                                                            # Instrument illumination circuit

                                                            Interior lights — Instrument illumination circuit — Instrument illumination circuit. Toyota Tacoma I facelift (2000-2004)
                                                            Components on the diagram

                                                              Power distribution

                                                              # Power distribution circuit

                                                              # Power distribution circuit (1 of 2)

                                                              Power distribution — Power distribution circuit — Power distribution circuit (1 of 2). Toyota Tacoma I facelift (2000-2004)
                                                              Components on the diagram

                                                                # Power distribution circuit (2 of 2)

                                                                Power distribution — Power distribution circuit — Power distribution circuit (2 of 2). Toyota Tacoma I facelift (2000-2004)
                                                                Components on the diagram

                                                                  Power door locks

                                                                  # Power door lock circuit

                                                                  Power door locks — Power door lock circuit — Power door lock circuit. Toyota Tacoma I facelift (2000-2004)
                                                                  Components on the diagram

                                                                    Power mirrors

                                                                    # Power mirror circuit

                                                                    Power mirrors — Power mirror circuit — Power mirror circuit. Toyota Tacoma I facelift (2000-2004)
                                                                    Components on the diagram

                                                                      Power seats

                                                                      # Power seat circuits

                                                                      Power seats — Power seat circuits — Power seat circuits. Toyota Tacoma I facelift (2000-2004)
                                                                      Components on the diagram

                                                                        Power windows

                                                                        # Power window circuit

                                                                        Power windows — Power window circuit — Power window circuit. Toyota Tacoma I facelift (2000-2004)
                                                                        Components on the diagram

                                                                          Radio

                                                                          # Radio circuits

                                                                          Radio — Radio circuits — Radio circuits. Toyota Tacoma I facelift (2000-2004)
                                                                          Components on the diagram

                                                                            Shift interlocks

                                                                            # Shift interlock circuit

                                                                            Shift interlocks — Shift interlock circuit — Shift interlock circuit. Toyota Tacoma I facelift (2000-2004)
                                                                            Components on the diagram

                                                                              Starting/charging

                                                                              # Charging circuit

                                                                              Starting/charging — Charging circuit — Charging circuit. Toyota Tacoma I facelift (2000-2004)
                                                                              Components on the diagram

                                                                                # Starting circuit

                                                                                Starting/charging — Starting circuit — Starting circuit. Toyota Tacoma I facelift (2000-2004)
                                                                                Components on the diagram

                                                                                  Supplemental restraints

                                                                                  # Supplemental restraint circuit

                                                                                  Supplemental restraints — Supplemental restraint circuit — Supplemental restraint circuit. Toyota Tacoma I facelift (2000-2004)
                                                                                  Components on the diagram

                                                                                    Transmission 2.4l

                                                                                    # 2.4l, a/t circuit

                                                                                    Transmission 2.4l — 2.4l, a/t circuit — 2.4l, a/t circuit. Toyota Tacoma I facelift (2000-2004)
                                                                                    Components on the diagram

                                                                                      # 4wd circuit, with 2-4 select switch

                                                                                      Transmission 2.4l — 4wd circuit, with 2-4 select switch — 4wd circuit, with 2-4 select switch. Toyota Tacoma I facelift (2000-2004)
                                                                                      Components on the diagram

                                                                                        # 4wd circuit, without 2-4 select switch

                                                                                        Transmission 2.4l — 4wd circuit, without 2-4 select switch — 4wd circuit, without 2-4 select switch. Toyota Tacoma I facelift (2000-2004)
                                                                                        Components on the diagram

                                                                                          # Rear differential lock circuit

                                                                                          Transmission 2.4l — Rear differential lock circuit — Rear differential lock circuit. Toyota Tacoma I facelift (2000-2004)
                                                                                          Components on the diagram

                                                                                            Transmission 2.7l

                                                                                            # 2.7l, a/t circuit

                                                                                            Transmission 2.7l — 2.7l, a/t circuit — 2.7l, a/t circuit. Toyota Tacoma I facelift (2000-2004)
                                                                                            Components on the diagram

                                                                                              # 4wd circuit, with 2-4 select switch

                                                                                              Transmission 2.7l — 4wd circuit, with 2-4 select switch — 4wd circuit, with 2-4 select switch. Toyota Tacoma I facelift (2000-2004)
                                                                                              Components on the diagram

                                                                                                # 4wd circuit, without 2-4 select switch

                                                                                                Transmission 2.7l — 4wd circuit, without 2-4 select switch — 4wd circuit, without 2-4 select switch. Toyota Tacoma I facelift (2000-2004)
                                                                                                Components on the diagram

                                                                                                  # Rear differential lock circuit

                                                                                                  Transmission 2.7l — Rear differential lock circuit — Rear differential lock circuit. Toyota Tacoma I facelift (2000-2004)
                                                                                                  Components on the diagram

                                                                                                    Transmission 3.4l

                                                                                                    # 3.4l, a/t circuit

                                                                                                    Transmission 3.4l — 3.4l, a/t circuit — 3.4l, a/t circuit. Toyota Tacoma I facelift (2000-2004)
                                                                                                    Components on the diagram

                                                                                                      # 4wd circuit, with 2-4 select switch

                                                                                                      Transmission 3.4l — 4wd circuit, with 2-4 select switch — 4wd circuit, with 2-4 select switch. Toyota Tacoma I facelift (2000-2004)
                                                                                                      Components on the diagram

                                                                                                        # 4wd circuit, without 2-4 select switch

                                                                                                        Transmission 3.4l — 4wd circuit, without 2-4 select switch — 4wd circuit, without 2-4 select switch. Toyota Tacoma I facelift (2000-2004)
                                                                                                        Components on the diagram

                                                                                                          # Rear differential lock circuit

                                                                                                          Transmission 3.4l — Rear differential lock circuit — Rear differential lock circuit. Toyota Tacoma I facelift (2000-2004)
                                                                                                          Components on the diagram

                                                                                                            Warning systems

                                                                                                            # Warning system circuits

                                                                                                            Warning systems — Warning system circuits — Warning system circuits. Toyota Tacoma I facelift (2000-2004)
                                                                                                            Components on the diagram

                                                                                                              Wiper/washer

                                                                                                              # 2-speed wiper/washer circuit

                                                                                                              Wiper/washer — 2-speed wiper/washer circuit — 2-speed wiper/washer circuit. Toyota Tacoma I facelift (2000-2004)
                                                                                                              Components on the diagram

                                                                                                                # Interval wiper/washer circuit

                                                                                                                Wiper/washer — Interval wiper/washer circuit — Interval wiper/washer circuit. Toyota Tacoma I facelift (2000-2004)
                                                                                                                Components on the diagram
