Maintenance Information: Component Locations Toyota Tacoma I

VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

FUSE LOCATIONS

Fuse box is located below instrument panel to left of steering column on all vehicles. An additional fuse and relay box located in the engine compartment.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. 1 - STOP 15 Amp - Stop Lights, High Mounted Stoplight, Cruise Control System
2. 2 - ALT-S 7.5 Amp - Charging System
3. 3 - STA 7.5 Amp - Multiport Fuel Injection System/Sequential Fuel Injection System, Starting System, Gauges & Meters
4. 4 - OBD 10 Amp - On-Board Diagnosis System
5. 5 - EFI 15 Amp - Multiport Fuel Injection System/Sequential Fuel Injection System
6. 6 - HORN 15 Amp - Emergency Flashers, Horns
7. 7 - DOME 15 Amp - Car Audio System, Power Antenna, Interior Light, Clock, Ignition Switch Light, Personal Lights, Door Courtesy Lights
8. 8 - TAIL 10 Amp - Tail Lights, License Plate Lights
9. 9 - PANEL 10 Amp - Emergency Flashers, Heater Control System, Air Conditioning Cooling System, Gauges & Meters, Clock, Car Audio System, Overdrive Indicator Light, Glove Box Light, Cigarette Lighter, Instrument Panel Lights
10. 10 - A.C 10 Amp - Air Conditioning Cooling System
11. 11 - HEAD (RH) 10 Amp - Right-Hand Headlight
12. 12 - HEAD (LH) 10 Amp - Left-Hand Headlight
13. 13 - HEAD (HI RH) 10 Amp - Right-Hand Headlight HI-Beam, High Beam Indicator Light
14. 14 - HEAD (HI LH) 10 Amp - Left-Hand Headlight HI-Beam
15. 15 - HEAD (LO RH) 10 Amp - Right-Hand Headlight LO-Beam
16. 16 - HEAD (LO LH) 15 Amp - Left-Hand Headlight LO-Beam
17. 17 - DRL 7.5 Amp - Daytime Running Light System (DRL)
18. 18 - 4WD 15 Amp - A.D.D. Control System, Four Wheel Drive Control System
19. 19 - GAUGE 10 Amp - Gauges and Meters, Back-up Lights, Cruise Control System, Power Antenna, Power Door Lock Control System, Electronically Controlled Automatic Transmission, Starting System, Charging System, Heater Control System
20. 20 - TURN 10 Amp - Turn Signal Lights
21. 21 - ECU-IG 15 Amp - Cruise Control System, Anti-Lock Brake System, Shift Lock Interlock
22. 22 - WIPER 20 Amp - Windshield Wipers/Washers
23. 23 - IGN 7.5 Amp - Discharge Warning Light, SRS Air Bag System
24. 24 - RADIO 7.5 Amp - Car Audio System, Power Antenna
25. 25 - CIG 15 Amp - Cigarette Lighter, Digital Clock, Shift Lock Control, Power Mirrors, Back-up Lights
26. 26 - ECU-B 15 Amp - SRS Air Bag Warning Light, Daytime Running Light System, Cruise Control System, Anti-Lock Brake System
27. 27 - HEATER 40 Amp - "A.C" Fuse
28. 28 - AM1 40 Amp - Power Distribution (Fuse 3,18,19,20,21,22,24,25,26 & 30)
29. 29 - AM2 30 Amp - Power Distribution (Fuse #23)
30. 30 - POWER 30 Amp - Power Windows, Power Door Lock Control System
31. 31 - ABS 60 Amp - Anti-Lock Brake System
32. 32 - ALT 80 Amp - Main Power Distribution

Scheme 5

Scheme 6

Scheme 7

1. 1 - PWR OUTLET 15 Amp - Power Outlet
2. 2 - DRL 7.5 Amp - Daytime Running Light System
3. 3 - HEAD (HI RH) 10 Amp - Right Hand Headlight (High Beam), High Beam Indicator Light
4. 4 - HEAD (HI LH) 10 Amp - Left Hand Headlight (High Beam)
5. 5 - HEAD (LO RH) 10 Amp - Right Hand Headlight (Low Beam)
6. 6 - HEAD (LO LH) 10 Amp - Left Hand Headlight (Low Beam)
7. 7 - TAIL 10 Amp - Tail Lights, License Plate Light
8. 8 - PANEL 10 Amp - Emergency Flashers, Heater Control System, Air Conditioning System, Gauges & Meters, Clock, Car Audio System, Overdrive Indicator Light, Glovebox Light, Cigarette Lighter, Instrument Panel Lights, Rear Differential Lock System, Multiport Fuel Injection System/Sequential Multiport Fuel Injection System, Electronically Controlled Automatic Transmission System
9. 9 - A.C 10 Amp - Air Conditioning System
10. 10 - STOP 15 Amp - Stop Lights, High Mounted Stop Light, Cruise Control System
11. 11 - ALT-S 7.5 Amp - Charging System
12. 12 - DOME 15 Amp - Car Audio System, Power Antenna, Interior Light, Clock, Ignition Switch Light, Personal Lights, Door Courtesy Lights
13. 13 - OBD 10 Amp - On-Board Diagnosis System
14. 14 - HORN 15 Amp - Emergency Flashers, Horns
15. 15 - EFI 15 Amp - Multiport Fuel Injection System/Sequential Multiport Fuel Injection System
16. 16 - HEAD (RH) 10 Amp - Right Hand Headlight
17. 17 - HEAD (RH) 10 Amp - Left Hand Headlight
18. 18 - STA 7.5 Amp - Clutch Start Cancel System, Starting System, Gauges & Meters
19. 19 - 4WD 20 Amp - A.D.D Control System, Four Wheel Drive Control System, Rear Differential Lock System
20. 20 - GAUGE 10 Amp - Gauges and Meters, Back-up Lights, Cruise Control System, Power Antenna, Power Door Lock Control System, Electronically Controlled Automatic Transmission System, Starting System, Charging System, A/C System
21. 21 - TURN 10 Amp - Turn Signal Lights, Emergency Flashers
22. 22 - ECU-IG 15 Amp - Cruise Control System, Anti-Lock Brake System, Automatic Transmission Shift Lock System
23. 23 - WIPER 20 Amp - Windshield Wipers & Washer
24. 24 - IGN 7.5 Amp - Discharge Warning Light, SRS Airbag System, Multiport Fuel Injection System/Sequential Multiport Fuel Injection System
25. 25 - RADIO 7.5 Amp - Car Audio System, Power Antenna
26. 26 - CIG 15 Amp - Cigarette Lighter, Clock, Power Rear View Mirrors, Back-Up Lights, Automatic Transmission Shift Lock System
27. 27 - ECU-B 15 Amp - SRS Air Bag Warning Light, Daytime Running Light System, Cruise Control System
28. 28 - POWER 30 Amp - Power Windows
29. 29 - AM1 40 Amp - Starting System
30. 30 - AM2 30 Amp - Ignition System
31. 31 - ABS 60 Amp - Anti-Lock Brake System
32. 32 - HEATER 40 Amp - "A.C" Fuse
33. 33 - ALT 80 Amp - "ABS", "AM1", "HEATER", "A.C", "TAIL", "PANEL", "STOP", "ALT-S", & "PWR OUTLET" Fuses
