Maintenance Information: Overview Toyota T100 I

Fuse & Circuit Breaker Identification

1. 1 - 10 Amp Left Headlight
2. 2 - 15 Amp Right Headlight
3. 3 - 10 Amp A/C Cooling System
4. 4 - 15 Amp Electronic Fuel Injection System, A/T Electronic Controls
5. 5 - 15 Amp Hazard Flasher, Horn
6. 6 - 15 Amp Interior Lights, Step Light, Ignition Switch Light, Radio, Cassette, Power Antenna, Clock
7. 7 - 40 Amp Starting System, Power Door Locks
8. 8 - 30 Amp Starting System
9. 9 - 40 Amp A/C & Heater System
10. 10 - 80 Amp Protection For Fuse 7
11. 11 - 10 Amp Charging System, Cruise Control
12. 12 - 7.5 Amp Emission Control System, Discharge Warning, EFI System
13. 13 - 15 Amp Taillights, Parking & License Lights, Instrument Panel Lights
14. 14 - 20 Amp Windshield Wipers/Washers
15. 15 - 10 Amp Gauges & Meters, Backup Lights, A.D.D. Control System, AOD Control System, Service Reminder Indicators, Power Locks (1994)
16. 16 - 15 Amp Stoplights, Cruise Control Cancel, Electronically Controlled Automatic Transmission
17. 17 - 7.5 Amp Radio, Power Antenna, Power Rear Mirrors
18. 18 - 15 Amp Cigarette Lighter, Digital Clock, Shift Lock Control
19. 19 - 10 Amp Hazard Flashers, Turn Signals
20. 20 - 15 Amp Rear Wheel Anti-Lock, Cruise Control, SRS Airbag (1994), Daytime Running Lights (Canada)
21. 21 - 7.5 Amp Daytime Running Lights
22. 22 - 20 Amp Cruise Control, Rear Wheel Anti-Lock
23. 23 - 30 Amp (1993), 7.5 Amp (1994) Power Door Locks, Power Windows

Scheme 1

Scheme 2

1. 1 - 10 Amp Left Headlight (USA)
2. 2 - 15 Amp Right Headlight (USA)
3. 3 - 10 Amp A/C Cooling System
4. 4 - 15 Amp Multi-Port Fuel Injection System, Sequential Multi-Port Fuel Injection, Automatic Transmission Electronic Controls
5. 5 - 15 Amp Hazard Flasher, Horn
6. 6 - 15 Amp Interior Lights, Step Light, Ignition Switch Light, Radio, Cassette, Power Antenna, Clock
7. 7 - 10 Amp Left Headlight HI-Beam (Canada)
8. 8 - 10 Amp Right Headlight HI-Beam (Canada)
9. 9 - 10 Amp Left Headlight LO-Beam (Canada)
10. 10 - 10 Amp Right Headlight LO-Beam (Canada)
11. 11 - 10 Amp Charging System, Cruise Control
12. 12 - 7.5 Amp Multi-Port Fuel Injection System, Sequential Multi-Port Fuel Injection, Charging System, Discharge Warning Light
13. 13 - 15 Amp Taillights, Parking & License Lights, Instrument Panel Lights
14. 14 - 20 Amp Windshield Wipers/Washers
15. 15 - 10 Amp Gauges & Meters, Back-up Lights, A.D.D. Control System, AOD Control System, Service Reminder Indicators, Power Locks, Cruise Control System
16. 16 - 15 Amp Stoplights, Cruise Control Cancel, Electronically Controlled Automatic Transmission, High Mounted Stop Light
17. 17 - 7.5 Amp Radio, Cassette, Power Antenna, Power Mirrors
18. 18 - 15 Amp Cigarette Lighter, Digital Clock, Shift Lock Control (A/T)
19. 19 - 10 Amp Hazard Flashers, Turn Signals
20. 20 - 15 Amp Rear Wheel Anti-Lock, Cruise Control, SRS Airbag, Daytime Running Lights (Canada)
21. 21 - 7.5 Amp Daytime Running Lights
22. 22 - 20 Amp Cruise Control, Rear Wheel Anti-Lock
23. 23 - 7.5 Amp OBD II Connector
24. 24 - 40 Amp Starting System, Power Distribution (Fuses 11,12,14,15,17,18,19,27)
25. 25 - 30 Amp Starting System, Power Distribution (Fuses 11,12,14,15,17,18,19)
26. 26 - 40 Amp Air Conditioning Heating System
27. 27 - 30 Amp Power Door Lock, Power Window
28. 28 - 60 Amp Anti-Lock Brake System
29. 29 - 80 Amp Main Power Distribution (Fuses 3,13,16,20,24,26)
