A/C SYSTEM SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | Nippondenso 10-Cyl. |
| Compressor Belt Tension (1) |
| Compressor Oil Capacity | (2) 4.1 ozs. |
| Refrigerant (R-134a) Capacity | 23.2.9-26.7 ozs. |
| System Operating Pressures |
| High Side | 199-228 psi (14-16 kg/cm 2 ) |
| Low Side | 28-36 psi (2.0-2.5 kg/cm 2 ) |
| (1) See COMPRESSOR BELT TENSION under ADJUSTMENTS. (2) Use ND-Oil 8 (Part No. 08885-09109). |
| (1) | See COMPRESSOR BELT TENSION under ADJUSTMENTS. |
| (2) | Use ND-Oil 8 (Part No. 08885-09109). |
AUTOMATIC A/C SYSTEM SPECIFICATIONS
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures in appropriate AIR BAG RESTRAINT SYSTEM article in ACCESSORIES/SAFETY EQUIPMENT section. |
| CAUTION | When battery is disconnected, radio will go into anti-theft protection mode. Obtain radio anti-theft protection code from owner prior to servicing vehicle. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Compressor Mounting Bolts | 38 (52) |
| Compressor Stud Bolt | 19 (26) |
| Instrument Panel Reinforcement Bolts | 15 (21) |
| Power Steering Bolt | 43 (58) |
| INCH Lbs. (N.m) |
| Condenser Mounting Bolts | 36 |
| Coolant Temperature Sensor | 65 (7.4) |
| Refrigerant Hoses |
| Condenser | 87 (10) |
| Compressor | 87 (10) |
| Evaporator | 87 (10) |
| Receiver-Drier | 48 (5.4) |
| RPM Sensor | 52 |
| Steering Wheel Pad Bolts | 62 |
Automatic A/C-Heater System Wiring Diagram (1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (2 Of 2)
