VIN LOCATION

The Vehicle Identification Number (VIN) is located on the left side of the dash panel at the base of the windshield. The VIN chart explains the code characters.

VIN CODE ID EXPLANATION

Numbers preceding the explanations in the legend below refer to the sequence of characters as listed on VIN identification label. See VIN example below.

VIN Code ID Explanation. Scheme 2

Scheme 2: VIN Code ID Explanation

SEVERE & NORMAL SERVICE DEFINITIONS

Service is recommended at mileage intervals based on vehicle operation and engine type. Service schedules are based on the following primary operating conditions

Normal Service

  1. Driven More Than 10 Miles Daily
  2. No Operating Conditions From Severe Service Schedule

Severe Service (Unique Driving Conditions)

  1. Towing A Trailer, Using A Camper Or Car Top Carrier
  2. Repeated Short Trips Less Than 5 Miles When Temperatures Are Below Freezing
  3. Extensive Idling Conditions (Taxi Or Delivery Type Service)
  4. Operating On Dusty, Rough, Muddy Or Salt Spread Roads

CAMSHAFT TIMING BELT

CAUTIONFailure to replace a faulty camshaft timing belt may result in serious engine damage.

The condition of camshaft drive belts should always be checked on vehicles which have more than 50,000 miles. Although some manufacturers do not recommend belt replacement at a specified mileage, others require it at 60,000-100,000 miles. A camshaft drive belt failure may cause extensive damage to internal engine components on most engines, although some designs do not allow piston-to-valve contact. These designs are often called "Free Wheeling".

Many manufacturers changed their maintenance and warranty schedules in the mid-1980's to reflect timing belt inspection and/or replacement at 50,000-60,000 miles. Most service interval schedules in this manual reflect these changes.

Belts or components should be inspected and replaced if any of the following conditions exist

  1. Cracks Or Tears In Belt Surface
  2. Missing, Damaged, Cracked Or Rounded Teeth
  3. Oil Contamination
  4. Damaged Or Faulty Tensioners
  5. Incorrect Tension Adjustment

Replace the camshaft timing belt every 72 months or 60,000 miles if the vehicle is operated under Severe Service conditions such as frequent idling or extensive long distance driving at low speeds (taxi, police or door-to-door delivery).

Scheme 3

Scheme 3: SERVICE POINT LOCATIONS

Scheme 4

Scheme 4

Scheme 5

Scheme 5: INFORMATION LABEL LOCATIONS

SERVICE LABOR TIMES

Note. For 1990 and newer vehicles, labor times are provided, where available, within appropriate SERVICE INTERVAL table in SCHEDULED SERVICES article.

TIRE INFLATION

All conventional tires should be inflated to 32 psi (2.2 kg/cm 2 ) and spare tires should be inflated to 36 psi (2.5 kg/cm 2 ). For sustained speeds above 75 MPH, add 4 psi (.3 kg/cm 2 ) but never exceed the maximum cold tire pressure molded on the side wall.

WHEEL TIGHTENING

Tighten all wheel lug nuts to 76 ft. lbs. (103 N.m).

BATTERY SPECIFICATIONS

CAUTIONWhen battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section.

If battery is replaced, it should be of the same group number as shown on the original battery's label. All years and models use batteries with BCI group number 27F.

RADIATOR FAN & CAP

To avoid injury, stay clear of the radiator fan when the ignition key is in the ON position. The fan is thermostatically controlled and may come on suddenly. DO NOT loosen or remove radiator cap when cooling system is hot.

CATALYTIC CONVERTER

CAUTIONTo prevent catalytic converter overheating and possibly creating a fire hazard, do not allow engine to idle for more than 20 minutes, avoid spark jump test and prolonged engine compression measurement.

SUPPLEMENTAL RESTRAINT SYSTEM (AIR BAG SYSTEM)

Note. For information on air bag DIAGNOSIS & TESTING or DISPOSAL PROCEDURES, see AIR BAGS article in the ACCESSORIES/SAFETY EQUIPMENT Section.

When servicing vehicles equipped with SRS, always allow at least 20 seconds after turning ignition switch to LOCK position and disconnecting the negative terminal cable before beginning work on the SRS. The system has a back-up power supply and may deploy air bag if these precautions are not followed.

WARRANTY INFORMATION

CAUTIONAlways refer to customer's copy of warranty information for specific model application and/or coverage limitations.

NEW VEHICLE LIMITED WARRANTY

Covers any repair or replacement of parts which becomes necessary due to defects in materials or workmanship under normal use for 36 months or 36,000 miles from in-service date.

POWERTRAIN WARRANTY

Engine, transmission, front wheel drive, rear wheel drive and restraint system are warranted against defects in materials or workmanship under normal use for 5 years or 60,000 miles, whichever occurs first. See copy of warranty for specific components covered.

CORROSION PERFORATION WARRANTY

Covers any repair or replacement to body sheet metal which develops corrosion perforation (hole through panel), in normal use, due to defects in material or workmanship for a period of 5 years, regardless of mileage.

BATTERY WARRANTY

Covers replacement of defective original battery for first 12 months or 12,000 miles. After the first 12 months or 12,000 miles, warranty covers a pro-rated amount based on months in service, up to a maximum of 36 months.

AIR CONDITIONER REFRIGERANT CHARGE WARRANTY

Covers the air conditioner refrigerant for the first 12 months, regardless of mileage, unless done as a warranty repair.

ADJUSTMENTS WARRANTY

Service adjustments - minor repairs not usually associated with the replacement of parts - are covered for the first 12 months or 12,500 miles, whichever occurs first.

EMISSION SYSTEM DEFECT WARRANTY (EXCEPT CALIFORNIA)

Warrants to the retail purchaser and subsequent purchaser that vehicle was designed, built, and equipped so as to conform at the time of sale with applicable emission regulations, and that it is free from defects in materials or workmanship which may cause the vehicle to fail to conform with applicable regulations for 5 years or 50,000 miles, whichever occurs first.

EMISSION SYSTEM PERFORMANCE WARRANTY (EXCEPT CALIFORNIA)

Covers all repairs, adjustments, or replacements if vehicle fails to conform to applicable emission standards and such failure results in the vehicle owner having to bear a penalty or other sanction under local, state or federal law for 5 years or 50,000 miles, whichever comes first. If the vehicle has been in use for more than 24 months or 24,000 miles, the manufacturer will make the necessary adjustments, repairs or replacements at no cost to the owner only when noncompliance is caused by failure of components which have been installed in the vehicle for the sole or primary purpose of reducing vehicle emissions. See copy of warranty for specific components covered.

EMISSION SYSTEM PERFORMANCE WARRANTY (CALIFORNIA)

For a period of 3 years or 50,000 miles, manufacturer will make all necessary repairs and adjustments to ensure vehicle passes a required Smog Check inspection.

EMISSION SYSTEM DEFECT WARRANTY (CALIFORNIA)

For a period of 5 years or 50,000 miles, whichever occurs first, vehicle is free from defects in materials or workmanship which may cause it to fail to conform with applicable California emission regulations. Certain emission-related parts are covered for repair or replacement for 7 years or 70,000 miles, whichever occurs first. See copy of warranty for specific components covered.

FUSE PANEL LOCATION

There are 3 fuse panels on this vehicle. The driver's side fuse panel is located behind the driver's kick panel. The passenger's side fuse panel is behind the passenger's side kick panel. The main fuse and relay panel is in the engine compartment.

Scheme 6

Scheme 6: PASSENGER COMPARTMENT FUSE PANELS IDENTIFICATION

Fuse & Circuit Breaker Identification

  1. 1 - 7.5 Amp Gauges, Warning Lights & Buzzers, Back-Up Lights & A/C, A/T Overdrive System & Rear Window Defogger, Power Windows & Door Locks, Power Antenna & Power Seats
  2. 2 - 7.5 Amp Interior, Door Courtesy & Vanity Lights (1987), Trunk, Step & Ignition Switch Lights (1987), Clock & Open Door Warning Light (1987), Blank (1991-92)
  3. 3 - 20 Amp Stoplights & Cruise Control Cancel Device, Anti-Lock Brake System (1988)
  4. 4 - 15 Amp Taillights, Park Lights, Side Marker Lights, License Lights, Instrument Panel Lights, Glove Box Lights, Foglights
  5. 5 - 15 Amp Cigarette Lighter & Digital Clock, Power Antenna & A/C Control Systemm, Theft Deterrent System (1988-92), A/T Shift Lock System (1989-92), Air Bag System (1990-92)
  6. 6 - 7.5 Amp Radio, Cassette, Compact Disc Player & Power Mirrors, Electronically Controlled A/T System (1987-88)
  7. 7 - 7.5 Amp Turn Signal Lights, Emergency Flashers (1988-92)
  8. 8 - 10 Amp Outside Mirror Defogger
  9. 9 - Blank
  10. 10 - 15 Amp Charging System
  11. 11 - 20 Amp Wipers & Washers
  12. 12 - 15 Amp Cruise Control & Anti-Lock Brake Systems, Electronically Controlled A/T System, Electronic Suspension Systems, Super Monitor Display (1988), Power Antenna (1988-92), Retractable Headlights & Power Door Locks (1989-92), Air Bag System (1990-92), ECU & Ignition (1991-92)
  13. 13 - Blank
  14. 14 - 7.5 Amp Charging System, Discharge Warning Light, Super Monitor Display (1988), EFI System (1989-92), Ignition (1991), SRS Air Bag System (1990-92)
  15. 15 - 30 Amp (Circuit Breaker) Rear Window Defogger, Outside Mirror Defogger (1989-92)
  16. 16 - 30 Amp (Circuit Breaker) Power Windows, Seats & Door Locks
  17. 17 - 10 Amp Air Conditioning System
  18. 18 - 40 Amp (Circuit Breaker) Environmental Control System

Relay Identification

  1. A - Defogger
  2. B - Taillight
  3. C - Turn Signal Control
  4. D - Power Main
  5. E - Horn
  6. F - Circuit Opening Relay
  7. G - Heater
  8. H - Clutch Starter

Scheme 7

Scheme 7: ENGINE COMPARTMENT FUSE & RELAY PANEL IDENTIFICATION
  1. 1 - 30 Amp Retractable Headlight System
  2. 2 - 15 Amp Charging System & Discharge Warning Light (1987-88), Blank (1989-92)
  3. 3 - 15 Amp Left Side Headlight
  4. 4 - 15 Amp Right Side Headlight
  5. 5 - 15 Amp Hazard Flashers & Horns, Theft Deterrent System (1989-92)
  6. 6 - 15 Amp (1987-90), 20 Amp (1991-92) Radio, Cassette & Compact Disc Player, 4EAT, Power Antenna & A/C Control System, Interior, Door Courtesy & Vanity Lights (1988-92), Trunk, Step & Ignition Switch Lights (1988-92), Clock & Open Door Warning Light (1988-92)
  7. 7 - 15 Amp EFI System
  8. 8 - 100 Amp Engine Main
  9. 9 - 60 Amp Anti-Lock Brake System (If Equipped)
  10. 10 - 40 Amp CDS
  11. 11 - 40 Amp AM1
  12. 12 - 30 Amp AM2
  1. A - Headlight
  2. B - EFI Main
