Power Window Control System (Diagnostic Codes & Symptom Tests): Overview Toyota Sienna III

Windows 14 illustrations ~1255 words

DESCRIPTION

The power window regulator motor is operated by the multiplex network master switch assembly or power window regulator switch assembly. The power window regulator motor assembly has motor, regulator and ECU functions.

This DTC is output when the power window regulator motor assembly has a malfunction, or the ECU built into the regulator motor assembly determines that the fully closed window position has deviated approximately 20 mm (0.787 in.) or more from the normal position.

HINT

DTC B2311 can be stored in each power window regulator motor assembly (power window ECU).

DTC No.DTC Detection ConditionTrouble Area
B2311Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal positionBattery disconnected when ignition switch ON Front power window regulator motor assembly LH Incorrect installation of power window components Overheated front power window regulator motor assembly LH

D-DOOR MOTOR (FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH)

DTC No.DTC Detection ConditionTrouble Area
B2311Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal positionBattery disconnected when ignition switch ON Front power window regulator motor assembly RH Incorrect installation of power window components Overheated front power window regulator motor assembly RH

P-DOOR MOTOR (FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH)

DTC No.DTC Detection ConditionTrouble Area
B2311Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal positionBattery disconnected when ignition switch ON Rear power window regulator motor assembly LH Incorrect installation of power window components Overheated rear power window regulator motor assembly LH

RL-DOOR MOTOR (REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LH)

DTC No.DTC Detection ConditionTrouble Area
B2311Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal positionBattery disconnected when ignition switch ON Rear power window regulator motor assembly RH Incorrect installation of power window components Overheated rear power window regulator motor assembly RH

RR-DOOR MOTOR (REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RH)

The power window regulator motor assembly is operated by the multiplex network master switch assembly or power window regulator switch assembly. The power window regulator motor assembly has motor, regulator and ECU functions.

This DTC is output when the ECU built into the regulator motor determines that the multiplex network master switch assembly or power window regulator switch assembly is stuck.

HINT

DTC B2312 can be stored in the multiplex network master switch assembly and in each power window regulator motor assembly (power window ECU).

DTC No.DTC Detection ConditionTrouble Area
B2312Multiplex network master switch assembly stuck Multiplex network master switch assembly held in same position for more than 20 secondsMultiplex network master switch assembly

MASTER SWITCH (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY)

DTC No.DTC Detection ConditionTrouble Area
B2312Multiplex network master switch assembly stuck Multiplex network master switch assembly held in same position for more than 20 secondsMultiplex network master switch assembly Front power window regulator motor assembly LH Wire harness or connector

D-DOOR MOTOR (FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH)

DTC No.DTC Detection ConditionTrouble Area
B2312Power window regulator switch assembly stuck Power window regulator switch assembly held in same position for more than 20 secondsFront power window regulator switch assembly RH Front power window regulator motor assembly RH Wire harness or connector

P-DOOR MOTOR (FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH)

DTC No.DTC Detection ConditionTrouble Area
B2312Power window regulator switch assembly stuck Power window regulator switch assembly held in same position for more than 20 secondsRear power window regulator switch assembly LH Rear power window regulator motor assembly LH Wire harness or connector

RL-DOOR MOTOR (REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LH)

DTC No.DTC Detection ConditionTrouble Area
B2312Power window regulator switch assembly stuck Power window regulator switch assembly held in same position for more than 20 secondsRear power window regulator switch assembly RH Rear power window regulator motor assembly RH Wire harness or connector

RR-DOOR MOTOR (REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RH)

Scheme 26

Scheme 26: WIRING DIAGRAM

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29
  1. for Driver Side
  2. for Front Passenger Side
  3. for Rear LH Side
  4. for Rear RH Side

The power window regulator motor assembly is operated by the multiplex network master switch assembly or power window regulator switch assembly. The power window regulator motor assembly has motor, regulator and ECU functions.

When the ECU determines that the power window regulator motor assembly has not been initialized, DTC B2313 is set.

HINT

DTC B2313 can be stored in each power window regulator motor assembly (power window ECU).

DTC No.DTC Detection ConditionTrouble Area
B2313Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctionsFront power window regulator motor assembly LH not initialized Front power window regulator motor assembly LH

D-DOOR MOTOR (FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH)

DTC No.DTC Detection ConditionTrouble Area
B2313Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctionsFront power window regulator motor assembly RH not initialized Front power window regulator motor assembly RH

P-DOOR MOTOR (FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH)

DTC No.DTC Detection ConditionTrouble Area
B2313Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctionsRear power window regulator motor assembly LH not initialized Rear power window regulator motor assembly LH

RL-DOOR MOTOR (REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LH)

DTC No.DTC Detection ConditionTrouble Area
B2313Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctionsRear power window regulator motor assembly RH not initialized Rear power window regulator motor assembly RH

RR-DOOR MOTOR (REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RH)

When the ignition switch is ON, the multiplex network master switch assembly sends remote up/down signals to each power window regulator motor assembly via the LIN communication line.

Scheme 30

Scheme 30: WIRING DIAGRAM

When the engine is running or the ignition switch is ON, the front power window regulator motor assembly LH is operated by the multiplex network master switch assembly. The front power window regulator motor assembly LH has motor, regulator, and ECU functions.

HINT

If the pulse sensor built into the front power window regulator motor assembly LH malfunctions, the power window control system enters fail-safe mode. The remote up/down and auto up/down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the multiplex network master switch assembly at the auto up position, and opened manually by pushing down the multiplex network master switch assembly.

Scheme 31

Scheme 31: WIRING DIAGRAM

When the engine is running or the ignition switch is ON, the front power window regulator motor assembly RH is operated by the front power window regulator switch assembly RH. The front power window regulator motor assembly RH has motor, regulator, and ECU functions.

HINT

If the pulse sensor built into the front power window regulator motor assembly RH malfunctions, the power window control system enters fail-safe mode. The remote up/down and auto up/down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the front power window regulator switch assembly RH at the auto up position, and opened manually by pushing down the front power window regulator switch assembly RH.

Scheme 32

Scheme 32: WIRING DIAGRAM

When the engine is running or the ignition switch is ON, the rear power window regulator motor assembly LH is operated by the rear power window regulator switch assembly LH. The power window regulator motor has motor, regulator, and ECU functions.

HINT

If the pulse sensor built into the rear power window regulator motor assembly LH malfunctions, the power window control system enters fail-safe mode. The remote up/down and auto up/down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the rear power window regulator switch assembly LH at the auto up position, and opened manually by pushing down the rear power window regulator switch assembly LH.

Scheme 33

Scheme 33: WIRING DIAGRAM

When the engine is running or the ignition switch is ON, the rear power window regulator motor assembly RH is operated by the rear power window regulator switch assembly RH. The rear power window regulator motor assembly RH has motor, regulator, and ECU functions.

HINT

If the pulse sensor built into the rear power window regulator motor RH malfunctions, the power window control system enters fail-safe mode. The remote up/down and auto up/down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the rear power window regulator switch assembly RH at the auto up position, and opened manually by pushing down the rear power window regulator switch assembly RH.

Scheme 34

Scheme 34: WIRING DIAGRAM

If the manual up/down function can be performed but the auto up/down function cannot, then the fail-safe mode may be functioning.

If the power window initialization. Refer to INITIALIZATION has not been performed, the auto up/down function will not operate.

Scheme 35

Scheme 35: WIRING DIAGRAM

If the manual up/down function can be performed but the auto up/down function cannot, the fail-safe mode may be functioning.

If the power window initialization. Refer to INITIALIZATION has not been performed, the auto up/down function will not operate.

Scheme 36

Scheme 36: WIRING DIAGRAM

If the manual up/down function can be performed but the auto up/down function cannot, the fail-safe mode may be functioning.

If the power window initialization. Refer to INITIALIZATION has not been performed, the auto up/down function will not operate.

Scheme 37

Scheme 37: WIRING DIAGRAM

If the manual up/down function can be performed but the auto up/down function cannot, the fail-safe mode may be functioning.

If the power window initialization. Refer to INITIALIZATION has not been performed, the auto up/down function will not operate.

Scheme 38

Scheme 38: WIRING DIAGRAM
  1. When the front doors are closed, each power window regulator motor assembly can control its power window operation for approximately 43 seconds after the ignition switch is turned from ON to off by receiving operation permission signals from the main body ECU.
  2. However, when approximately 43 seconds have elapsed, or the driver side door or front passenger side door is opened within approximately 43 seconds of the ignition switch being turned off, the power window regulator motor assembly stops operating.
  3. During an auto operation, when 43 seconds have passed and key-off operation is prohibited, the window operation stops immediately.

If a door glass or a power window regulator motor assembly does not operate smoothly, the jam protection function may be triggered automatically, resulting in the auto up function being unable to fully close the window.

HINT

This symptom may occur for any of the windows.

This symptom may occur for any of the windows.

The jam protection function operates within a specified range during the manual up or auto up operation.

The power quarter windows are operated by power quarter window switch on the instrument panel while the ignition switch is in the ON position.

Scheme 39

Scheme 39: WIRING DIAGRAM
