Starting System [2GR-FE]: Removal & Installation Toyota Sienna III

INSTALLATION

1. INSTALL STARTER ASSEMBLY Install the starter assembly with the 2 bolts. Torque: 37 N*m (377 kgf*cm, 27 ft.*lbf) Connect the starter connector. Connect the terminal 30 with the nut. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) Close the terminal cap.
2. INSTALL AIR CLEANER AND HOSE . Refer to «INSTALLATION - Step 4»(ref-493957-S34549740422012081000000)
3. INSTALL BATTERY . Refer to «INSTALLATION - Step 61»(ref-494105-S15240956452012081000000)
4. INSTALL AIR CLEANER INLET COVER ASSEMBLY SEAL . Refer to «INSTALLATION - Step 62»(ref-494105-S15240956452012081000000)
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION»(ref-493943-S13306943882012081000000)

Scheme 76

Scheme 77

Scheme 78

1. REMOVE STEERING WHEEL ASSEMBLY Refer to «REMOVAL»(ref-493944-S38109709332012081000000)
2. SEPARATE FRONT DOOR OPENING TRIM WEATHERSTRIP LH
3. REMOVE NO. 2 INSTRUMENT CLUSTER FINISH PANEL GARNISH . Refer to «REMOVAL - Step 23»(ref-494157-S03717663822012081000000)
4. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY . Refer to «REMOVAL - Step 24»(ref-494157-S03717663822012081000000)
5. REMOVE FLOOR SHIFT POSITION INDICATOR HOUSING SUB-ASSEMBLY . Refer to «REMOVAL - Step 25»(ref-494157-S03717663822012081000000)
6. REMOVE INSTRUMENT SIDE PANEL LH . Refer to «REMOVAL - Step 35»(ref-494157-S03717663822012081000000)
7. REMOVE INSTRUMENT PANEL FINISH PANEL . Refer to «REMOVAL - Step 22»(ref-494157-S03717663822012081000000)
8. REMOVE NO. 1 INSTRUMENT CLUSTER FINISH PANEL . Refer to «REMOVAL - Step 13»(ref-494154-S15879814982012081000000)
9. REMOVE ENGINE SWITCH Disengage the 2 claws and remove the engine switch. Disconnect the engine switch connector.

Scheme 79

1. INSPECT ENGINE SWITCH Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *1 Indicator *2 Illumination *a Component without harness connected (Engine Switch) Standard Resistance Tester Connection Switch Condition Specified Condition 7 (SS1) - 5 (GND) Not pushed 10 kohms or higher 2 (SS2) - 5 (GND) Not pushed 10 kohms or higher 7 (SS1) - 5 (GND) Pushed Below 1 ohms 2 (SS2) - 5 (GND) Pushed Below 1 ohms If the result is not as specified, replace the engine switch. Apply battery voltage between the terminals of the switch, and check the illumination condition of the engine switch. HINT: If a positive (+) battery lead and a negative (-) battery lead are incorrectly connected, the engine switch indicator light will not illuminate. If the voltage is too low, the indicator light will not illuminate. OK Measurement Condition Condition Specified Condition Battery positive (+) --> Terminal 11 (SWIL) Battery negative (-) --> Terminal 4 (COM) or 5 (GND) Always Illuminates Battery positive (+) --> Terminal 12 (INDS) Battery negative (-) --> Terminal 4 (COM) or 5 (GND) Always Illuminates Battery positive (+) --> Terminal 13 (INDW) Battery negative (-) --> Terminal 4 (COM) or 5 (GND) Always Illuminates If the result is not as specified, replace the engine switch.

1. INSTALL ENGINE SWITCH Connect the engine switch connector. Engage the 2 claws to install the engine switch.
2. INSTALL NO. 1 INSTRUMENT CLUSTER FINISH PANEL . Refer to «INSTALLATION - Step 2»(ref-494154-S05915974992012081000000)
3. INSTALL INSTRUMENT PANEL FINISH PANEL . Refer to «INSTALLATION - Step 36»(ref-494157-S22618471172012081000000)
4. INSTALL INSTRUMENT SIDE PANEL LH . Refer to «INSTALLATION - Step 23»(ref-494157-S22618471172012081000000)
5. INSTALL FLOOR SHIFT POSITION INDICATOR HOUSING SUB-ASSEMBLY . Refer to «INSTALLATION - Step 33»(ref-494157-S22618471172012081000000)
6. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY . Refer to «INSTALLATION - Step 34»(ref-494157-S22618471172012081000000)
7. INSTALL NO. 2 INSTRUMENT CLUSTER FINISH PANEL GARNISH . Refer to «INSTALLATION - Step 35»(ref-494157-S22618471172012081000000)
8. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH
9. INSTALL STEERING WHEEL ASSEMBLY Refer to «INSTALLATION»(ref-493944-S39512110512012081000000)

Scheme 80

Scheme 81

Scheme 82

1. REMOVE LOWER STEERING COLUMN COVER . Refer to «REMOVAL - Step 1»(ref-494179-S40154354102012081000000)
2. REMOVE IGNITION SWITCH ASSEMBLY Remove the 2 screws and the ignition switch. Disconnect the connector. Disconnect the connector clamp from the ignition switch.

Scheme 83

1. INSPECT IGNITION SWITCH Check the ignition switch resistance. Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *1 LOCK *2 ACC *3 ON *4 START *a Component without harness connected (Ignition Switch) Standard Resistance Tester Connection Switch Condition Specified Condition Between all terminals LOCK 10 kohms or higher 2 (AM1) - 3 (ACC) ACC Below 1 ohms 2 (AM1) - 3 (ACC) - 4 (IG1) ON Below 1 ohms 6 (IG2) - 7 (AM2) 1 (ST1) - 2 (AM1) - 4 (IG1) START Below 1 ohms 6 (IG2) - 7 (AM2) - 8 (ST2) If the result is not as specified, replace the switch assembly.

1. INSTALL IGNITION SWITCH ASSEMBLY Connect the connector. Connect the connector clamp to the ignition switch. Install the ignition switch with the 2 screws.
2. INSTALL LOWER STEERING COLUMN COVER . Refer to «INSTALLATION - Step 4»(ref-494179-S34217441692012081000000)

Scheme 84

1. INSPECT STARTER RELAY Check the resistance. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 Battery voltage not applied 10 kohms or higher 3 - 5 Battery voltage applied to terminals 1 and 2 Below 1 ohms If the resistance is not as specified, replace the relay.
