Power Mirror Control (W/ Memory) (Diagnostics - Introduction): Overview Toyota Sienna III

Scheme 47

Scheme 48

Scheme 49

COMMUNICATION TABLE

SYSTEM DESCRIPTION

1. POWER MIRROR CONTROL SYSTEM DESCRIPTION This system has the following functions: automatic glare-resistant electrochromic (EC) mirror function, reverse shift-linked function, electrical remote control function, memory function, and mirror heater function.
2. FUNCTION OF MAIN COMPONENTS Component Function Vertical mirror motor Receives a signal from the outer mirror control ECU assembly and adjusts the mirror surface position vertically. Horizontal mirror motor Receives a signal from the outer mirror control ECU assembly and adjusts the mirror surface position horizontally. Power retract mirror motor Receives a signal from the outer mirror control ECU assembly, and retracts and returns the outer rear view mirrors. Mirror heater When the rear defogger switch on the air conditioning control panel assembly is operated, the A/C amplifier detects the switch operation via LIN communication. The A/C amplifier operates the integration relay and mirror heater in accordance with the switch operation. EC mirror cell Varies reflection rate of the mirror through function of EC elements. Outer mirror retract switch Retracts and returns the outer rear view mirrors. Mirror retract and return signals are sent to each outer mirror control ECU assemblies from the main body ECU. Mirror select switch Consists of R and L switches. One must be chosen to operate the outer mirror switch assembly. Mirror adjust switch Mirror R and L signals are sent to each outer mirror control ECU assemblies from the outer mirror switch assembly. After selecting the R or L switch, the right, left, up and down control switches can be operated to change the angle of the mirror. Mirror position sensor Detects the mirror surface position. This data is detected by the outer mirror control ECU assembly. Seat memory switch When the seat memory M1 or M2 switch are pressed while the SET switch is being pressed, or M1 or M2 switch is pressed within 3 seconds after the SET switch being pressed, a signal is input to the outer mirror control ECU assembly (driver side), which records the mirror surface position. When the seat memory switch is pressed, a signal is input to the outer mirror control ECU assembly (driver side) and sent to main body ECU, which changes the mirror surface position to the recorded position. Outer mirror control ECU assembly Operates each mirror motor based on signals from the outer mirror retract switch, mirror select switch and mirror adjust switch. Based on information from the mirror position sensor, 2 different mirror surface positions can be stored. By operating a seat memory switch, the mirror surface moves to the stored position.
3. SYSTEM OPERATION The remote control mirror has the following features. Function Outline Power retract mirror function Retracts and returns the outer rear view mirrors when the outer mirror retract switch is pressed. Reverse shift-linked function of mirrors Directs the mirror surface downward to improve visibility when driving in reverse and all the conditions below are met: Engine switch on (IG). Shift lever is moved to R. The mirror select switch is in the R or L position. Electrical remote control mirror function When the outer mirror switch assembly is operated, this function moves the mirror surface vertically or horizontally to enable the driver to attain an optimal mirror angle. Setting the mirror select switch to the R position operates the right mirror, and setting it to the L position operates the left mirror. Memory and reactivation function Stores the adjusted mirror position in the outer mirror control ECU assembly. Automatic glare-resistant EC mirror function Reduces glare/reflection in the mirror during nighttime driving for safe driving conditions. Glare/reflection from vehicle headlights behind could blind driver and cause dangerous driving conditions. Mirror heater function Automatically turns on mirror heater when the rear window defogger switch is turned on. The rear window defogger and mirror heaters automatically turn off after 15 min.
