Starting System: Other Toyota Sienna II рестайлинг

SYSTEM DIAGRAM

The starting system rotates the starter motor according to the signals from the ignition switch and PNP switch.

Identifying Starter Components With Torque Specifications (1 Of 2). Scheme 7

Identifying Starter Components With Torque Specifications (2 Of 2). Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. REMOVE BATTERY (See «REMOVAL»(ref-282118-S19305882932008032900000) )
2. REMOVE NO. 2 AIR CLEANER INLET (See «REMOVAL»(ref-282118-S19305882932008032900000) )
3. REMOVE AIR CLEANER CAP SUB-ASSEMBLY (See «REMOVAL»(ref-282130-S04614499162008032900000) )
4. REMOVE AIR CLEANER FILTER ELEMENT (See «REMOVAL»(ref-282118-S19305882932008032900000) )
5. REMOVE AIR CLEANER CASE SUB-ASSEMBLY (See «REMOVAL»(ref-282118-S19305882932008032900000) )
6. REMOVE AIR CLEANER BRACKET Remove the 2 bolts and the air cleaner bracket. (Scheme 9): Locating Air Cleaner Bracket Bolts
7. REMOVE NO. 1 AIR CLEANER INLET Remove the bolt and the No. 1 air cleaner inlet. (Scheme 10): Locating No.1 Air Cleaner Inlet Bolt
8. REMOVE STARTER ASSEMBLY Disconnect the starter connector. Open the terminal cap and remove the nut and the starter wire. (Scheme 11): Identifying Terminal Cap Remove the 2 bolts and the starter. (Scheme 12): Locating Starter Bolts

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. REMOVE REPAIR SERVICE STARTER KIT Remove the nut and disconnect the lead wire from the repair service starter kit. (Scheme 13): Locating Lead Wire Nut Remove the 2 screws which are used to secure the repair service starter kit to the repair service starter kit. (Scheme 14): Locating Repair Service Starter Kit Screws Remove the repair service starter kit. Remove the return spring and the plunger from the repair service starter kit.
2. REMOVE STARTER YOKE ASSEMBLY Remove the 2 through bolts and pull out the starter yoke together with the starter commutator end frame. (Scheme 15): Locating Starter Yoke Through Bolts Remove the starter yoke from the starter commutator end frame. (Scheme 16): Identifying Starter Commutator End Frame
3. REMOVE STARTER ARMATURE PLATE Remove the starter armature plate from the starter yoke. (Scheme 17): Identifying Starter Armature Plate
4. REMOVE DRIVE HOUSING STARTER BEARING COVER Using a screwdriver, remove the drive housing starter bearing cover. (Scheme 18): Removing Drive Housing Starter Bearing Cover
5. REMOVE STARTER ARMATURE ASSEMBLY Using snap ring pliers, remove the snap ring and plate washer. Remove the starter armature from the commutator end frame. (Scheme 19): Removing Snap Ring And Plate Washer
6. REMOVE PLANETARY GEAR Remove the 3 planetary gears from the repair service starter kit. (Scheme 20): Locating Planet Gears

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. INSPECT STARTER ASSEMBLY NOTE: These tests must be performed within 3 to 5 seconds to avoid burning out the coil. Perform the pull-in test. Disconnect the lead wire from terminal C. Connect the battery to the magnetic switch as shown in the illustration. Check that the clutch pinion gear extends. If the clutch pinion gear does not move, replace the magnetic switch. (Scheme 21): Inspecting Starter Assembly (Pull-In Test) Perform the hold-in test. Maintain the battery connections in step (a), but disconnect the negative (-) lead from terminal C. Check that the pinion gear remains extended. If the clutch pinion gear returns inward, replace the magnetic switch. (Scheme 22): Inspecting Starter Assembly (Hold-In Test) Check the clutch pinion gear return. Disconnect the negative (-) lead from the switch body. Check that the clutch pinion gear returns. If the clutch pinion gear does not return, replace the magnetic switch. (Scheme 23): Checking Clutch Pinion Gear Return Perform the no-load performance test. Connect the lead wire to terminal C. Make sure that the lead is not grounded. Clamp the starter in a vise. Connect the battery and an ammeter to the starter as shown in the illustration. Check that the starter rotates smoothly and steadily with the clutch pinion gear extended. Check that the ammeter reads the specified current. Specified current: 90 A or less at 11.5 V (Scheme 24): Inspecting Starter Assembly (No-Load Performance Test)
2. INSPECT REPAIR SERVICE STARTER KIT Check the plunger. Push in the plunger and check that it returns quickly to its original position. If necessary, replace the repair service starter kit. (Scheme 25): Checking Plunger Check if the pull-in coil has an open circuit. Measure the resistance between terminals 50 and C. Resistance: Below 1 ohms If the result is not as specified, replace the repair service starter kit. (Scheme 26): Measuring Resistance Between Terminals 50 And C Check if the hold-in coil has an open circuit. Measure the resistance between terminal 50 and the switch body. Resistance: Below 2 ohms If the result is not as specified, replace the repair service starter kit. (Scheme 27): Measuring Resistance Between Terminal 50 And Switch Body
3. INSPECT STARTER ARMATURE ASSEMBLY Measure if the commutator has an open circuit. Check the resistance between the segments of the commutator. Resistance: Below 1 ohms If the result is not as specified, replace the armature assembly. (Scheme 28): Checking Resistance Between Segments Of Commutator Check if the commutator is grounded. Measure the resistance between the commutator and armature coil core. Resistance: 10 kohms or higher If the result is not as specified, replace the armature assembly. Check the commutator for contamination and burns on its surface. If the surface is dirty or burnt, correct it with sandpaper (No. 400) or a lathe. (Scheme 29): Measuring Resistance Between Commutator And Armature Coil Core Using a vernier caliper, measure the commutator's length. Standard length: 3.3 to 4.0 mm (0.1299 to 0.1575 in.) If the length is greater than the maximum, replace the starter armature. (Scheme 30): Identifying Commutator's Length
4. INSPECT STARTER COMMUTATOR END FRAME ASSEMBLY Using a vernier caliper, measure the brush length. Specified length: 4.0 to 9.0 mm (0.158 to 0.354 in.) If the length is less than the minimum, replace the starter commutator end frame. (Scheme 31): Identifying Brush Length Check the brush insulation. Measure the resistance between the positive (+) and negative (-) brush. Resistance: 10 kohms or higher If the result is not as specified, repair or replace starter commutator end frame. (Scheme 32): Measuring Resistance Between Positive (+) And Negative (-) Brush
5. INSPECT REPAIR SERVICE STARTER KIT Check the starter clutch. Rotate the clutch pinion gear counterclockwise and check that it turns freely. Try to rotate the clutch pinion gear clockwise and check that it locks. If necessary, replace the service starter kit. (Scheme 33): Rotating Clutch Pinion Gear

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

1. INSTALL PLANETARY GEAR Apply grease to the planetary gears and pin parts of the planetary shaft. (Scheme 34): Applying Grease To Planetary Gears And Pin Parts Of Planetary Shaft Install the 3 planetary gears.
2. INSTALL STARTER ARMATURE ASSEMBLY Apply grease to the plate washer and the armature shaft. Install the starter armature to the starter commutator end frame. Using snap ring pliers, install the plate washer and a new snap ring. (Scheme 35): Installing Plate Washer And Snap Ring Using a vernier caliper, measure length of the snap ring. Maximum length: 5.0 mm (0.197 in.) If the length is greater than the maximum, replace it with a new snap ring. (Scheme 36): Identifying Length Of Snap Ring
3. INSTALL DRIVE HOUSING STARTER BEARING COVER Install the drive housing starter bearing cover to the starter commutator end frame. (Scheme 37): Installing Drive Housing Starter Bearing Cover To Starter Commutator End Frame
4. INSTALL STARTER ARMATURE PLATE Insert the starter armature plate to the starter yoke. Align the keyway of the starter plate with the key inside the starter yoke, and install the starter plate. (Scheme 38): Identifying Keyway And Key
5. INSTALL STARTER COMMUTATOR END FRAME ASSEMBLY Align the rubber with the convex cutout of starter yoke. Install starter commutator end frame to the starter yoke. (Scheme 39): Identifying Rubber And Cutout Of Field Frame
6. INSTALL STARTER YOKE ASSEMBLY Align the key of the starter yoke with the keyway of repair service starter kit. (Scheme 40): Aligning Protrusion Of Starter Field Frame With Cutout Of Starter Drive Housing Install the starter yoke with the 2 through bolts. Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf) see scheme 37: Locating Starter Yoke Through Bolts
7. INSTALL REPAIR SERVICE STARTER KIT Apply grease to the plunger and the hook. Hang the plunger hook of the repair service starter kit to the drive lever. Install the plunger and return spring. (Scheme 41): Installing Plunger And Return Spring Install the repair service starter kit with the 2 screws. Torque: 7.5 N*m (76 kgf*cm, 66 in.*lbf) see scheme 39: Locating Starter Kit Screws Connect the lead wire to the repair service starter kit with the nut. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) see scheme 40: Locating Magnetic Switch Nut
