Air Conditioning: Removal & Installation Toyota Sienna II рестайлинг

INSTALLATION

1. INSTALL AIR CONDITIONING NO.2 CONTROL ASSEMBLY

Scheme 275

Scheme 276

Scheme 277

1. REMOVE INSTRUMENT CLUSTER FINISH PANEL CENTER NO.1 (See «REMOVAL»(ref-282145-S40783459792008032900000) )
2. REMOVE INSTRUMENT CLUSTER FINISH PANEL CENTER NO.2
3. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY HINT: (See «REMOVAL»(ref-282123-S05255501732008032900000) for U151E, «REMOVAL»(ref-282124-S08538173542008032900000) for U151F)
4. REMOVE INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY CENTER (See «REMOVAL»(ref-282145-S40783459792008032900000) )
5. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH (See «REMOVAL»(ref-282145-S40783459792008032900000) )
6. REMOVE RADIO RECEIVER ASSEMBLY WITH BRACKET (w/o Navigation System) (See «REMOVAL»(ref-282152-S39999237862008032900000) )
7. REMOVE RADIO RECEIVER ASSEMBLY WITH BRACKET (w/ Navigation System)
8. REMOVE INTEGRATION CONTROL AND PANEL ASSEMBLY Remove the 4 screws, and release the integration control & panel assembly. Disconnect the connectors and remove the integration control & panel assembly.

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

1. REMOVE CENTER CLUSTER MODULE KNOB NO.1 (for Manual Air Conditioning System) Remove the center cluster module knob No. 1.
2. REMOVE CENTER CLUSTER MODULE KNOB NO.2 (for Manual Air Conditioning System) Release the 2 claws fittings and remove the center cluster module knob No. 2. NOTE: Take care not to break the claws on the knob.
3. REMOVE AIR CONDITIONER AMPLIFIER ASSEMBLY (for Manual Air Conditioning System) Remove the plate. Release the lock of the connector and disconnect the cable. Remove the 4 screws, and the heater control housing. Remove the 4 screws, and the air conditioner amplifier assembly.
4. REMOVE AIR CONDITIONER AMPLIFIER ASSEMBLY (for Automatic Air Conditioning System) Release the 8 claw fittings and remove the 4 screws and the heater control housing. Disconnect the 2 connectors. Remove the 5 screws and the air conditioner amplifier assembly.
5. REMOVE INTEGRATION CONTROL AND PANEL BULB (for Manual Air Conditioning System) Remove the integration control & panel bulb.
6. REMOVE HEATER BLOWER SWITCH (for Manual Air Conditioning System) Remove the 3 nuts, and the 3 washers. Release the 6 claw fittings and remove the 5 screws and printed wire integration board sub-assembly. Remove the screw and the heater blower switch.
7. REMOVE PRINTED WIRE INTEGRATION BOARD SUB-ASSEMBLY (for Automatic Air Conditioning System) Remove the 12 screws and the printed wire integration board sub-assembly.
8. REMOVE CLOCK ORNAMENT Remove the clock ornament.
9. REMOVE CENTER CLUSTER MODULE KNOB NO.5 (for Automatic Air Conditioning System)
10. REMOVE CENTER CLUSTER MODULE KNOB NO.6 (for Automatic Air Conditioning System)

1. INSTALL INTEGRATION CONTROL AND PANEL ASSEMBLY
2. INSTALL RADIO RECEIVER WITH BRACKET (w/ Navigation System)
3. INSTALL RADIO RECEIVER WITH BRACKET (w/o Navigation System)
4. INSTALL INSTRUMENT CLUSTER FINISH PANEL GARNISH
5. INSTALL INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY CENTER
6. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY
7. INSTALL INSTRUMENT CLUSTER FINISH PANEL CENTER NO.2
8. INSTALL INSTRUMENT CLUSTER FINISH PANEL CENTER NO.1
