Clearance Warning ECU: Removal & Installation Toyota Sienna II

REPLACEMENT

Note. For component locations: See COMPONENTS

Scheme 3

1. REMOVE FRONT DOOR SCUFF PLATE LH (See «INSTRUMENT PANEL/METER»(ref-195198) )
2. REMOVE COWL SIDE TRIM BOARD LH (See «INSTRUMENT PANEL/METER»(ref-195198) )
3. REMOVE INSTRUMENT PANEL FINISH PANEL SUB-ASSY LOWER LH (See «INSTRUMENT PANEL/METER»(ref-195198) )
4. REMOVE INSTRUMENT PANEL SAFETY PAD INSERT SUB-ASSY NO. 1 (See «INSTRUMENT PANEL/METER»(ref-195198) )
5. REMOVE CLEARANCE WARNING ECU ASSY Disconnect the connectors. Remove the nut and the clearance warning ECU assy.

Note. For component locations: See COMPONENTS

Scheme 4

Scheme 5

1. REMOVE FRONT FENDER LINER LH (See «FRONT BUMPER»(ref-182177) )
2. REMOVE FRONT FENDER LINER RH (See «FRONT BUMPER»(ref-182177) )
3. REMOVE FRONT BUMPER COVER (See «FRONT BUMPER»(ref-182177) )
4. REMOVE REAR BUMPER COVER (See «FRONT BUMPER»(ref-182177) )
5. REMOVE ULTRASONIC SENSOR RETAINER NO. 1 Remove the ultrasonic sensor retainer No. 1 as shown in the illustration.
6. REMOVE ULTRASONIC SENSOR NO. 1 Disconnect the connector and remove the ultrasonic sensor No. 1.
7. INSTALL REAR BUMPER COVER (See «REAR BUMPER»(ref-195211-S36673957122005093000000) )
8. INSTALL FRONT BUMPER COVER (See «REAR BUMPER»(ref-195211-S36673957122005093000000) )
9. INSTALL FRONT FENDER LINER LH (See «REAR BUMPER»(ref-195211-S36673957122005093000000) )
10. INSTALL FRONT FENDER LINER RH (See «REAR BUMPER»(ref-195211-S36673957122005093000000) )

Note. For component locations: See COMPONENTS

Scheme 6

Scheme 7

1. REMOVE REAR BUMPER COVER (See «REAR BUMPER»(ref-195211-S36673957122005093000000) )
2. REMOVE ULTRASONIC SENSOR RETAINER NO. 1 Remove the ultrasonic sensor retainer No. 1 as shown in the illustration.
3. REMOVE ULTRASONIC SENSOR NO. 2 Disconnect connector and remove the ultrasonic sensor No. 2.
4. INSTALL REAR BUMPER COVER (See «REAR BUMPER»(ref-195211-S36673957122005093000000) )
