LEFT OR RIGHT POWER MIRROR INOPERATIVE
Check power mirror switch. See POWER MIRROR SWITCH under COMPONENT TESTS. Check power mirror motor(s). See POWER MIRROR MOTOR under COMPONENT TESTS. Check ground circuit and wiring harness. See WIRING DIAGRAMS .
UP/DOWN OR LEFT/RIGHT FUNCTION INOPERATIVE
Check power mirror motor(s). See POWER MIRROR MOTOR under COMPONENT TESTS. Check power mirror switch. See POWER MIRROR SWITCH under COMPONENT TESTS. Check ground circuit and wiring harness. See WIRING DIAGRAMS .
POWER MIRROR SWITCH
Note. Mirror motor connectors may vary in configuration from vehicle to vehicle of the same model.
Remove power mirror switch. Using ohmmeter, check continuity between appropriate mirror switch terminals. Continuity should exist between specified terminals. See appropriate POWER MIRROR SWITCH CONTINUITY TEST table. (Scheme 1)- see scheme 27. If switch fails any test, replace switch.
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 3 & 4; 7 & 8 |
| Down | 3 & 8; 4 & 7 |
| Left | 4 & 9; 7 & 8 |
| Right | 4 & 7; 8 & 9 |
| Switch In Right Position |
| Up | 2 & 4; 7 & 8 |
| Down | 2 & 8; 4 & 7 |
| Left | 4 & 10; 7 & 8 |
| Right | 4 & 7; 8 & 10 |
| (1) Continuity should exist between specified terminals. (Scheme 1)- (Scheme 3). |
POWER MIRROR SWITCH CONTINUITY TEST (AVALON WITHOUT MEMORY)
| Application | Terminals No. (1) | Resistance |
|---|
| Left | 8 & 9 | 100 |
| Right | 8 & 9 | 0 |
| Illumination | 5 & 6 | Continuity |
| (1) Check resistance between appropriate terminals. (Scheme 1)and (Scheme 4). |
POWER MIRROR SWITCH CONTINUITY TEST (AVALON WITH MEMORY)
| Switch Position | (1) Resistance (Ohms) |
|---|
| UP | 100 |
| RIGHT | 250 |
| DOWN | 470 |
| LEFT | 800 |
| (1) Measure resistance between terminals No. 7 and 9 at mirror switch. (Scheme 1)and (Scheme 4). |
MIRROR SWITCH RESISTANCE (AVALON WITH MEMORY)
| Check Between Ground & Terminal No. (1) | Condition | Specified Condition |
|---|
| 8 | At All Times | Continuity |
| 4 | Ignition Switch At Lock Position | No Voltage |
| 4 | Ignition Switch In ACC or RUN Position | Battery Voltage |
| (1) For harness connector identification, refer to illustration. (Scheme 1) |
| (1) | For harness connector identification, refer to illustration. (Scheme 1) |
MIRROR SWITCH CIRCUITS (AVALON)
Scheme 1
Identifying Power Mirror Motor Harness Connector Terminals (Avalon Without Driving Position Memory - Without Mirror Heater). Scheme 2
Scheme 2: Identifying Power Mirror Motor Harness Connector Terminals (Avalon Without Driving Position Memory - Without Mirror Heater)
Scheme 3
Scheme 4
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 9; 6 & 10 |
| Down | 1 & 10; 6 & 9 |
| Left | 5 & 9; 6 & 10 |
| Right | 5 & 10; 6 & 9 |
| Switch In Right Position |
| Up | 6 & 10; 7 & 9 |
| Down | 6 & 9; 7 & 10 |
| Left | 6 & 10; 8 & 9 |
| Right | 6 & 9; 8 & 10 |
| (1) Continuity should exist between specified terminals. (Scheme 5)- (Scheme 9). |
POWER MIRROR SWITCH CONTINUITY TEST (CAMRY & CAMRY SOLARA)
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 4 & 8; 6 & 7 |
| Down | 4 & 7; 6 & 8 |
| Left | 5 & 8; 6 & 7 |
| Right | 5 & 7; 6 & 8 |
| Switch In Right Position |
| Up | 3 & 8; 6 & 7 |
| Down | 3 & 7; 6 & 8 |
| Left | 2 & 8; 6 & 7 |
| Right | 2 & 7; 6 & 8 |
| (1) Continuity should exist between specified terminals. (Scheme 10)and (Scheme 11). |
POWER MIRROR SWITCH CONTINUITY TEST (CELICA)
Scheme 10
Scheme 11
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 9; 6 & 10 |
| Down | 1 & 10; 6 & 9 |
| Left | 5 & 9; 6 & 10 |
| Right | 5 & 10; 6 & 9 |
| Switch In Right Position |
| Up | 6 & 10; 7 & 9 |
| Down | 6 & 9; 7 & 10 |
| Left | 6 & 10; 8 & 9 |
| Right | 6 & 9; 8 & 10 |
| (1) Continuity should exist between specified terminals. see scheme 12- see scheme 13. |
| (1) | Continuity should exist between specified terminals. see scheme 12- see scheme 13. |
POWER MIRROR SWITCH CONTINUITY TEST (COROLLA)
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 3 & 4; 7 & 8 |
| Down | 3 & 8; 4 & 7 |
| Left | 4 & 9; 7 & 8 |
| Right | 4 & 7; 8 & 9 |
| Switch In Right Position |
| Up | 2 & 4; 1, 7 & 8 |
| Down | 4 & 7; 1, 2 & 8 |
| Left | 4 & 10; 1, 7 & 8 |
| Right | 4 & 7; 1, 8 & 10 |
| (1) Continuity should exist between specified terminals. (Scheme 12)- (Scheme 13). |
POWER MIRROR SWITCH CONTINUITY TEST (LAND CRUISER)
Scheme 12
Scheme 13
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 4 & 8; 6 & 7 |
| Down | 4 & 7; 6 & 8 |
| Left | 5 & 8; 6 & 7 |
| Right | 5 & 7; 6 & 8 |
| Switch In Right Position |
| Up | 3 & 8; 6 & 7 |
| Down | 3 & 7; 6 & 8 |
| Left | 2 & 8; 6 & 7 |
| Right | 2 & 7; 6 & 8 |
| (1) Continuity should exist between specified terminals. (Scheme 14)(Scheme 15). |
POWER MIRROR SWITCH CONTINUITY TEST (MR2)
Scheme 14
Scheme 15
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 9; 6 & 10 |
| Down | 1 & 10; 6 & 9 |
| Left | 5 & 9; 6 & 10 |
| Right | 5 & 10; 6 & 9 |
| Switch In Right Position |
| Up | 6 & 10; 7 & 9 |
| Down | 6 & 9; 7 & 10 |
| Left | 6 & 10; 8 & 9 |
| Right | 6 & 9; 8 & 10 |
| (1) Continuity should exist between specified terminals. (Scheme 16)- (Scheme 17). |
POWER MIRROR SWITCH CONTINUITY TEST (RAV4)
Scheme 16
Scheme 17
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 9; 6 & 10 |
| Down | 1 & 10; 6 & 9 |
| Left | 5 & 9; 6 & 10 |
| Right | 5 & 10; 6 & 9 |
| Switch In Right Position |
| Up | 6 & 10; 7 & 9 |
| Down | 6 & 9; 7 & 10 |
| Left | 6 & 10; 8 & 9 |
| Right | 6 & 9; 8 & 10 |
| (1) Continuity should exist between specified terminals. see scheme 20- (Scheme 18). |
| (1) | Continuity should exist between specified terminals. see scheme 20- (Scheme 18). |
POWER MIRROR SWITCH CONTINUITY TEST (SIENNA)
Scheme 18
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 9; 6 & 10 |
| Down | 1 & 10; 6 & 9 |
| Left | 5 & 9; 6 & 10 |
| Right | 5 & 10; 6 & 9 |
| Switch In Right Position |
| Up | 6 & 10; 7 & 9 |
| Down | 6 & 9; 7 & 10 |
| Left | 6 & 10; 8 & 9 |
| Right | 6 & 9; 8 & 10 |
| (1) Continuity should exist between specified terminals. (Scheme 19)- (Scheme 20). |
POWER MIRROR SWITCH CONTINUITY TEST (TACOMA)
Scheme 19
Scheme 20
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 4 & 8; 6 & 7 |
| Down | 4 & 7; 6 & 8 |
| Left | 5 & 8; 6 & 7 |
| Right | 5 & 7; 6 & 8 |
| Switch In Right Position |
| Up | 3 & 8; 6 & 7 |
| Down | 3 & 7; 6 & 8 |
| Left | 5 & 8; 6 & 7 |
| Right | 5 & 7; 6 & 8 |
| (1) Continuity should exist between specified terminals. (Scheme 21)- (Scheme 22). |
POWER MIRROR SWITCH CONTINUITY TEST (TUNDRA)
Scheme 21
Scheme 22
| Application | (1) Terminals No. |
|---|
| Switch In Left Position |
| Up | 1 & 9; 6 & 10 |
| Down | 1 & 10; 6 & 9 |
| Left | 5 & 9; 6 & 10 |
| Right | 5 & 10; 6 & 9 |
| Switch In Right Position |
| Up | 6 & 10; 7 & 9 |
| Down | 6 & 9; 7 & 10 |
| Left | 6 & 10; 8 & 9 |
| Right | 6 & 9; 8 & 10 |
| (1) Continuity should exist between specified terminals. see scheme 27- (Scheme 23). |
| (1) | Continuity should exist between specified terminals. see scheme 27- (Scheme 23). |
POWER MIRROR SWITCH CONTINUITY TEST (4RUNNER)
Scheme 23
POWER MIRROR MOTOR
Note. Mirror motor harness connectors may vary in configuration from vehicle to vehicle of the same model.
Disconnect power mirror motor harness connector. Using a 12-volt power source, connect positive and negative leads to specified pins or terminals. See appropriate POWER MIRROR MOTOR TEST table. (Scheme 1)- (Scheme 23). If power mirror motor fails any test, replace power mirror assembly.
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 3 | 1 | Up |
| 1 | 3 | Down |
| 1 | 2 | Left |
| 2 | 1 | Right |
| (1) (Scheme 1)- (Scheme 4). |
POWER MIRROR MOTOR TEST (AVALON - WITHOUT MIRROR HEATER)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 4 | 2 | Up |
| 2 | 4 | Down |
| 1 | 2 | Left |
| 2 | 1 | Right |
| (1) (Scheme 1)- (Scheme 4). |
POWER MIRROR MOTOR TEST (AVALON - WITH MIRROR HEATER)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 1 | 2 | Up |
| 2 | 1 | Down |
| 3 | 2 | Left |
| 2 | 3 | Right |
| (1) (Scheme 6) |
POWER MIRROR MOTOR TEST (CAMRY - JAPAN BUILT - WITH MIRROR HEATER)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 3 | 2 | Up |
| 2 | 3 | Down |
| 1 | 2 | Left |
| 2 | 1 | Right |
| (1) (Scheme 7) |
POWER MIRROR MOTOR TEST (CAMRY - USA BUILT - WITHOUT MIRROR HEATER)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 1 | 2 | Up |
| 2 | 1 | Down |
| 3 | 2 | Left |
| 2 | 3 | Right |
| (1) (Scheme 8) |
POWER MIRROR MOTOR TEST (CAMRY - USA BUILT - WITH MIRROR HEATER)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 3 | 4 | Up |
| 4 | 3 | Down |
| 3 | 4 | Left |
| 4 | 2 | Right |
| (1) (Scheme 9) |
POWER MIRROR MOTOR TEST (CAMRY SOLARA)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 5 | 3 | Up |
| 3 | 5 | Down |
| 1 | 3 | Left |
| 3 | 1 | Right |
| (1) (Scheme 10) |
POWER MIRROR MOTOR TEST (CELICA)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 3 | 2 | Up |
| 2 | 3 | Down |
| 1 | 2 | Left |
| 2 | 1 | Right |
| (1) see scheme 13 |
POWER MIRROR MOTOR TEST (COROLLA)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 8 | 7 | Left |
| 7 | 8 | Right |
| 6 | 7 | Up |
| 7 | 6 | Down |
| (1) (Scheme 13) |
POWER MIRROR MOTOR TEST (LAND CRUISER)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 2 | 1 | Right |
| 1 | 2 | Left |
| 2 | 3 | Down |
| 3 | 2 | Up |
| (1) (Scheme 15) |
POWER MIRROR MOTOR TEST (MR2)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 2 | 3 | Left |
| 3 | 2 | Right |
| 2 | 1 | Up |
| 1 | 2 | Down |
| (1) see scheme 21or (Scheme 18). |
POWER MIRROR MOTOR TEST (SIENNA)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 2 | 1 | Up |
| 1 | 2 | Down |
| 3 | 1 | Left |
| 1 | 3 | Right |
| (1) (Scheme 20) |
POWER MIRROR MOTOR TEST (TACOMA)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 2 | 1 | Up |
| 1 | 2 | Down |
| 3 | 1 | Left |
| 1 | 3 | Right |
| (1) (Scheme 22) |
POWER MIRROR MOTOR TEST (TUNDRA)
| Apply 12 Volts To Pin No. | (1) Ground Pin No. | Mirror Operation |
|---|
| 5 | 4 | Up |
| 4 | 5 | Down |
| 1 | 4 | Left |
| 4 | 1 | Right |
| (1) (Scheme 23) |
POWER MIRROR MOTOR TEST (4RUNNER)
Note. Power mirror switch removal and installation procedures are not available from manufacturer.
Memory Power Mirror System Wiring Diagram (Avalon). Scheme 24
Scheme 24: Memory Power Mirror System Wiring Diagram (Avalon)
Power Mirror System Wiring Diagram (Avalon). Scheme 25
Scheme 25: Power Mirror System Wiring Diagram (Avalon)
Power Mirror System Wiring Diagram (Camry 2.2L & 3.0L). Scheme 26
Scheme 26: Power Mirror System Wiring Diagram (Camry 2.2L & 3.0L)
Power Mirror System Wiring Diagram (Camry 2.2L CNG). Scheme 27
Scheme 27: Power Mirror System Wiring Diagram (Camry 2.2L CNG)
Power Mirror System Wiring Diagram (Camry Solara). Scheme 28
Scheme 28: Power Mirror System Wiring Diagram (Camry Solara)
Power Mirror System Wiring Diagram (Celica). Scheme 29
Scheme 29: Power Mirror System Wiring Diagram (Celica)
Power Mirror System Wiring Diagram (Corolla). Scheme 30
Scheme 30: Power Mirror System Wiring Diagram (Corolla)
Power Mirror System Wiring Diagram (Land Cruiser). Scheme 31
Scheme 31: Power Mirror System Wiring Diagram (Land Cruiser)
Power Mirror System Wiring Diagram (MR2). Scheme 32
Scheme 32: Power Mirror System Wiring Diagram (MR2)
Power Mirror System Wiring Diagram (RAV4). Scheme 33
Scheme 33: Power Mirror System Wiring Diagram (RAV4)
Power Mirror System Wiring Diagram (Sienna). Scheme 34
Scheme 34: Power Mirror System Wiring Diagram (Sienna)
Power Mirror System Wiring Diagram (Tacoma). Scheme 35
Scheme 35: Power Mirror System Wiring Diagram (Tacoma)
Power Mirror System Wiring Diagram (Tundra). Scheme 36
Scheme 36: Power Mirror System Wiring Diagram (Tundra)
Power Mirror System Wiring Diagram (4Runner - With Power Windows). Scheme 37
Scheme 37: Power Mirror System Wiring Diagram (4Runner - With Power Windows)
Power Mirror System Wiring Diagram (4Runner - Without Power Windows). Scheme 38
Scheme 38: Power Mirror System Wiring Diagram (4Runner - Without Power Windows)
