Front Wiper System & Washer System: Overview Toyota Sequoia I рестайлинг

Scheme 16

Scheme 17

Scheme 18

1. REMOVE WIPER ARMS Using a screwdriver, remove the 2 caps. HINT: Tape the screwdriver tip before use. Remove the 2 nuts and wiper arms.
2. REMOVE COWL TOP VENTILATOR LOUVER Using a clip remover, remove the 6 clips. Remove the 8 screws and cowl top ventilator louver.
3. REMOVE HOOD TO COWL TOP SEAL Remove the hood to cowl top seal from the cowl top ventilator louver.
4. REMOVE WIPER MOTOR Disconnect the connector. Unfasten the 4 bolts. Disconnect the wiper motor from the wiper link, then remove the wiper motor.
5. REMOVE WIPER LINK Remove the 6 bolts. Remove the wiper link through the service hole.
6. REMOVE WASHER NOZZLE Disconnect the washer hose. Using a screwdriver, remove the nozzle. HINT: Tape the screwdriver tip before use. Employ the same manner described above to the other side.
