INITIALIZATION
Note. When disconnecting the battery terminal, initialize the following systems after the terminal is reconnected.
| System Name | See Step No. |
|---|---|
| Back Door Power Window Control System | Step 1 |
SYSTEM NAME
INITIALIZE BACK DOOR POWER WINDOW CONTROL SYSTEM
Note. Resetting the power window regulator motor (initializing the pulse sensor) is necessary if: 1) the battery terminal cable is disconnected; 2) the back door ECU, wire harness, power window regulator switch, power window regulator assembly and power window regulator motor are replaced or removed/installed; or 3) the P/W fuse is replaced or removed. If resetting is not performed, the master switch assembly will not be able to operate the AUTO operation function, jam protection function and remote operation function.
- Turn the ignition switch ON.
- Open the power window halfway by pressing the power window switch.
- Fully pull up on the switch until the power window is fully closed and continue to hold the switch for at least 1 second.
- Check that the AUTO UP/DOWN function operates normally. If the AUTO UP/DOWN function operates normally, reset operations are complete. If abnormal, follow the steps (e) to (g) below.
- Disconnect the negative battery terminal cable for 10 seconds.
- Connect the battery terminal cable.
- Perform the steps (a) to (d) again.
CUSTOMIZE PARAMETERS
HINT
The following items can be customized.
Note. When a customer requests a change in a function, first make sure that customization of the function(s) is/are possible. Be sure to make a note of the current setting before customizing. When troubleshooting a function, first make sure that the function is not set to OFF. When troubleshooting, pay attention as there is a possibility that the function has been set to SMALL through customizing (Example: In case of the symptom in which "The key reminder buzzer operation does not function" is displayed, check that the key reminder buzzer operation is not set to SMALL, then perform troubleshooting).
METER
| DISPLAY (ITEM) | DEFAULT | CONTENTS | SETTING |
|---|---|---|---|
| KEY REMND VOLUM (Key reminder buzzer volume) | LARGE | Function that changes the volume of key reminder buzzer. | LARGE/MEDIUM/SMALL |
METER DESCRIPTION
WIRELESS DOOR LOCK
| DISPLAY (ITEM) | DEFAULT | CONTENTS | SETTING |
|---|---|---|---|
| WIRELESS OPER | ON | Turns wireless door lock function ON/OFF. | ON/OFF |
| OPEN DOOR WARN | ON | Sounds buzzer for 10 seconds when door is not completely closed and transmitter LOCK switch is pressed. | ON/OFF |
| AUTO LOCK DELAY | 30S | Controls amount of time from when doors are unlocked until they are locked by automatic lock function. | 60S/30S |
| UNLOCK/2OPER | ON | When UNLOCK switch is pressed once, this function unlocks only the designated door. When unlock switch is pressed again within 3 seconds, all doors unlock. If setting is OFF, pressing UNLOCK switch once unlocks all doors. | ON/OFF |
| LNT/LGT ON/UNLK | ON | Turns on room light when wireless door lock system is operated. | ON/OFF |
| ALARM FUNCTION | ON | Operates theft deterrent system when transmitter LOCK (PANIC) switch is held for 3 seconds. | ON/OFF |
| AUTO LOCK | OFF | Locks doors when the vehicle speed reaches a certain level. | ON/OFF |
| UNLK/KEY TWICE | ON | Unlocks only driver's door when driver's door key cylinder is turned to unlock once, and unlocks all doors when it is turned to unlock twice. In OFF setting, unlocks all doors when the cylinder is turned to unlock once. | ON/OFF |
| ALL UNLK/OPN-CL | OFF | Function that unlocks all doors when the driver door is opened after turning the ignition switch off. | ON/OFF |
| UNLOCK/PARK | OFF | Unlocks doors when shift lever is moved to P position from any position other than P while the ignition switch is ON. | ON/OFF |
WIRELESS DOOR LOCK
THEFT
| DISPLAY (ITEM) | DEFAULT | CONTENTS | SETTING |
|---|---|---|---|
| WARNING TIME | 15S | Changes warning time for PASSIVE MODE. | 5S/15S/27.5S/60S |
| PASSIVE MODE | OFF | Switches theft deterrent system from arming preparation state to armed state 30 seconds after key is removed from ignition key cylinder and driver side door is closed, even if doors are not locked by wireless or door key lock operation. | ON/OFF |
| WARN BY GLS SEN | ON | Function that switches the alarm warning on/off when glass breakage is detected. | ON/OFF |
THEFT
DOOR LOCK
| DISPLAY (ITEM) | DEFAULT | CONTENTS | SETTING |
|---|---|---|---|
| AUTO LOCK/SHIFT | ON | Locks doors when shift lever is moved from P to another position. | ON/OFF |
DOOR LOCK
ILLUMINATED ENTRY
| DISPLAY (ITEM) | DEFAULT | CONTENTS | SETTING |
|---|---|---|---|
| I/L ON/UNLOCK | ON | Illuminates interior light when ignition switch is turned from ACC to LOCK position. | ON/OFF |
| LIGHTING TIME | 15S | Changes lighting time after closing doors (light quickly fades out when ignition switch is turned on). | 15S/7.5S/30S |
ILLUMINATED ENTRY
LIGHT CONTROL
| DISPLAY (ITEM) | DEFAULT | CONTENTS | SETTING |
|---|---|---|---|
| SENSITIVITY | NORMAL | Sensitivity adjustment is difficult to confirm. Check by driving the customer's vehicle. | NORMAL/DARK2/DARK 1/LIGHT1/LIGHT2 |
| LIGHT OFF DELAY | 30S | Keeps headlights on for a certain period of time after closing all doors with ignition switch on, light control switch in HEAD or AUTO position, and headlights on. | OFF/30S/60S/90S |
| DISP EX ON SEN | NORMAL | Changes brightness of lights such as combination meter indicator light, A/C indicator lamp, and clock lamp. | NORMAL/DARK2/DARK1/LIGHT1/LIGHT2 |
| DISP OFF SEN | NORMAL | Changes brightness of lights such as combination meter indicator light, A/C indicator lamp, and clock lamp. | NORMAL/DARK2/DARK1/LIGHT1/LIGHT2 |
LIGHT CONTROL
GLOSSARY OF SAE AND TOYOTA TERMS
This glossary lists all SAE-J1930 terms and abbreviations used in this information in compliance with SAE recommendations, as well as their Toyota equivalents.
