PRECAUTION

Note. When disconnecting the battery terminal, initialize the following system after the terminal is reconnected.

DIAGNOSIS PROCEDURE

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. METER GAUGE AND WARNING/INDICATOR GAUGE: GAUGE SPECIFICATIONS Item Detail Speedometer Vehicle speed sensor (Direct line). Tachometer ECM transmits engine speed to the meter to display. ODO/TRIP Meter Combination meter assy. Fuel Displays a fuel level according to a signal from the fuel sender gauge (Direct line). Water Temperature Displays engine coolant temperature according to a signal from the ECM (BEAN). Oil Pressure Receives a signal from the oil pressure sender (Direct line). Volt Meter Displays vehicle voltage according to a voltage from the IG terminal (Direct line). WARNING/INDICATOR: HINT: Combination meter bulb check is performed for 3 seconds after the ignition switch is turned ON. BUZZER: BUZZER SPECIFICATIONS Item Detail Key Reminder Buzzer is ON: Ignition switch is OFF, key is inserted, and door is open. Fasten Belt Buzzer is ON: Ignition switch is ON and seat belt is unfastened.
2. COMBINATION METER IN SEQUOIA HAS THE FOLLOWING FEATURES: Built-in buzzer for the reminder system (key and seat belt) Integrated trip and odometer knobs Press and release knob to scroll through trip "A", trip "B", and odometer features. Press and hold the trip knob to reset trip meter functions. Oil maintenance indicator When 4,500 miles have been traveled, after the ODO/TRIP switch is set, the maintenance indicator begins to blink for 15 seconds after the ignition switch is turned to the ON position. When 5,000 miles have been traveled, after the ODO/TRIP switch is set, the maintenance indicator comes on. Press and hold the trip knob to reset the oil maintenance indicator. Rotate knob to adjust interior illumination

CUSTOMIZE PARAMETERS

HINT

The following can be customized.

Note. After confirming whether the items of the customer's request are applicable or not as customized items, perform customization. Be sure to record the current value before customizing. When troubleshooting, pay attention as there is a possibility that the function has been set to SMALL through customizing (Example: In case of the symptom in which "The key reminder buzzer operation does not function" is displayed, check that the key reminder buzzer operation is not set to SMALL, then perform troubleshooting).

METER

METER SPECIFICATIONS

METER GAUGES

METER GAUGES SPECIFICATIONS

Scheme 46

Scheme 47

OTHERS

DIAGNOSIS PROCEDURE

Scheme 48

Scheme 49

Scheme 50

1. Disconnect the C5 and C6 connectors.
2. Measure the resistance of each terminal of the wire harness side connector. Standard: TERMINALS SPECIFIED CONDITION CHART Terminals No. Wiring Color Terminal Description Condition Specified Condition C5-5 - Body ground L-W - Body ground Compass and garage door opener Always Below 1 ohm C5-6 - Body ground L-R - Body ground Compass and garage door opener communication line Always Below 1 ohm C5-30 (*2) - Body ground W - Body ground Multiplex communication signal Always Below 1 ohm C5-31 - Body ground LG-R - Body ground Multiplex communication signal Always Below 1 ohm C5-32 - Body ground LG-B - Body ground Multiplex communication signal Always Below 1 ohm
3. Reconnect the C5 and C6 connectors.
4. Measure the voltage of each terminal of the wire harness side connector. Standard: TERMINALS SPECIFIED CONDITION CHART Terminals No. Wiring Color Terminal Description Condition Specified Condition C5-1 - Body ground R-B - Body ground Parking brake signal Parking brake warning light ON 6.7 to 12 V C5-1 - Body ground R-B - Body ground Parking brake signal Parking brake warning light OFF Below 1 V C5-2 - Body ground LG-R - Body ground CRUISE signal CRUISE indicator light ON Below 1 V C5-2 - Body ground LG-R - Body ground CRUISE signal CRUISE indicator light OFF 10 to 14 V C5-3 - Body ground B - Body ground Ignition switch signal (Start) Ignition switch OFF Below 1 V C5-3 - Body ground B - Body ground Ignition switch signal (Start) Ignition switch START 10 to 14 V C5-4 - Body ground G-Y - Body ground Seat belt condition signal (Driver side) D-BELT indicator light ON Below 1 V C5-4 - Body ground G-Y - Body ground Seat belt condition signal (Driver side) D-BELT indicator light OFF 10 to 14 V C5-13 - Body ground LG-R - Body ground Washer level signal WASH LVL indicator light ON Below 1 V C5-13 - Body ground LG-R - Body ground Washer level signal WASH LVL indicator light OFF 10 to 14 V C5-14 - Body ground L-O - Body ground O/D OFF indicator signal O/D OFF indicator light ON Below 1 V C5-14 - Body ground L-O - Body ground O/D OFF indicator signal O/D OFF indicator light OFF 10 to 14 V C5-15 ( (1) ) - Body ground Y-R - Body ground A/T oil temperature signal A/T OIL TEMP. warning light ON Below 1 V C5-15 ( (1) ) - Body ground Y-R - Body ground A/T oil temperature signal A/T OIL TEMP. warning light OFF 10 to 14 V C5-16 - Body ground LG-B - Body ground Security indicator light signal (Engine immobilizer system) Security indicator light ON 10 to 14 V C5-16 - Body ground LG-B - Body ground Security indicator light signal (Engine immobilizer system) Security indicator light OFF Below 1 V C5-17 - Body ground GR - Body ground Security indicator light signal (Theft deterrent system) Security indicator light ON 10 to 14 V C5-17 - Body ground GR - Body ground Security indicator light signal (Theft deterrent system) Security indicator light OFF Below 1 V C5-18 - Body ground V-W - Body ground CHECK ENGINE signal CHECK ENGINE warning light ON Below 1 V C5-18 - Body ground V-W - Body ground CHECK ENGINE signal CHECK ENGINE warning light OFF 10 to 14 V C5-19 - Body ground G-B - Body ground A/T shift position signal (L) A/T L indicator OFF Below 1 V C5-19 - Body ground G-B - Body ground A/T shift position signal (L) A/T L indicator ON 10 to 14 V C5-20 - Body ground GR-L - Body ground Tire pressure signal Tire pressure warning light ON 6.7 to 12 V C5-20 - Body ground GR-L - Body ground Tire pressure signal Tire pressure warning light OFF Below 1 V C5-21 - Body ground R - Body ground Injector signal Ignition switch ON Pulse generation C5-22 - Body ground W-G - Body ground Illumination signal Light control switch OFF Below 1 V C5-22 - Body ground W-G - Body ground Illumination signal Light control switch ON 10 to 14 V C5-23 - Body ground Y-G - Body ground Tachometer signal Engine running Pulse generation (See waveform 1) (Scheme 49) C5-24 - Body ground Y - Body ground Speed signal (Input) Ignition switch ON and turn the wheel slowly 10 to 14 V <--> Below 1 V C5-25 - Body ground G-O - Body ground Speed signal (Output) Ignition switch ON and turn the wheel slowly Pulse generation (See waveform 2) (Scheme 50) C5-26 - Body ground V - Body ground Power source for fuel sender gauge Ignition switch ON, fuel level is FULL Below 1 V C5-26 - Body ground V - Body ground Power source for fuel sender gauge Ignition switch ON, fuel level is EMPTY 4 to 7 V C5-27 - Body ground L-B - Body ground Oil pressure signal Oil pressure warning light ON Below 1 V C5-27 - Body ground L-B - Body ground Oil pressure signal Oil pressure warning light OFF 10 to 14 V C5-28 - Body ground B-R - Body ground Injector power signal Ignition switch ON 10 to 14 V C5-29 - Body ground B-Y - Body ground SRS warning light signal SRS warning light ON Below 1 V C5-29 - Body ground B-Y - Body ground SRS warning light signal SRS warning light OFF 8 to 14 V C5-33 - Body ground G-Y - Body ground Turn signal (R) Ignition switch ON, turn signal RH indicator OFF Below 1 V C5-33 - Body ground G-Y - Body ground Turn signal (R) Ignition switch ON, turn signal RH indicator ON 10 to 14 V C5-34 - Body ground L-Y - Body ground A/T shift position signal (P) A/T P indicator OFF Below 1 V C5-34 - Body ground L-Y - Body ground A/T shift position signal (P) A/T P indicator ON 10 to 14 V C5-35 - Body ground B-Y - Body ground A/T shift position signal (R) A/T R indicator OFF Below 1 V C5-35 - Body ground B-Y - Body ground A/T shift position signal (R) A/T R indicator ON 10 to 14 V C5-36 - Body ground G-R - Body ground A/T shift position signal (N) A/T N indicator OFF Below 1 V C5-36 - Body ground G-R - Body ground A/T shift position signal (N) A/T N indicator ON 10 to 14 V C5-37 - Body ground W-R - Body ground A/T shift position signal (D) A/T D indicator OFF Below 1 V C5-37 - Body ground W-R - Body ground A/T shift position signal (D) A/T D indicator ON 10 to 14 V C5-38 - Body ground L - Body ground A/T shift position signal (3) A/T 3 indicator OFF Below 1 V C5-38 - Body ground L - Body ground A/T shift position signal (3) A/T 3 indicator ON 10 to 14 V C5-39 - Body ground LG - Body ground A/T shift position signal (2) A/T 2 indicator OFF Below 1 V C5-39 - Body ground LG - Body ground A/T shift position signal (2) A/T 2 indicator ON 10 to 14 V C5-40 - Body ground B-R - Body ground RSCA OFF signal RSCA OFF indicator light OFF Below 1 V C5-40 - Body ground B-R - Body ground RSCA OFF signal RSCA OFF indicator light ON 8 to 14 V C6-1 - Body ground W-R - Body ground SLIP signal SLIP indicator light ON Below 1 V C6-1 - Body ground W-R - Body ground SLIP signal SLIP indicator light OFF 10 to 14 V C6-2 - Body ground R-G - Body ground VSC OFF signal ( (1) ) TRAC OFF signal ( (5) ) VSC OFF indicator light ON ( (1) ) TRAC OFF indicator light ON ( (5) ) Below 1 V C6-2 - Body ground R-G - Body ground VSC OFF signal ( (1) ) TRAC OFF signal ( (5) ) VSC OFF indicator light OFF ( (1) ) TRAC OFF indicator light OFF ( (5) ) 10 to 14 V C6-3 - Body ground P-L - Body ground TRAC signal VSC/TRAC indicator light ON Below 1 V C6-3 - Body ground P-L - Body ground TRAC signal VSC/TRAC indicator light OFF 10 to 14 V C6-4 - Body ground BR-Y - Body ground CTR DIFF LOCK signal CTR DIFF LOCK indicator light ON Below 1 V C6-4 - Body ground BR-Y - Body ground CTR DIFF LOCK signal CTR DIFF LOCK indicator light OFF 10 to 14 V C6-5 - Body ground Y-B - Body ground 4HI signal 4HI indicator ON Below 1 V C6-5 - Body ground Y-B - Body ground 4HI signal 4HI indicator OFF 10 to 14 V C6-6 - Body ground G-W - Body ground 4LO signal 4LO indicator ON Below 1 V C6-6 - Body ground G-W - Body ground 4LO signal 4LO indicator OFF 10 to 14 V C6-8 - Body ground Y - Body ground Charge signal Engine running Below 1 V C6-8 - Body ground Y - Body ground Charge signal Engine stopped 10 to 14 V C6-10 - Body ground Y-R - Body ground Ground (Speed) Always Below 1 V C6-11 - Body ground Y-B - Body ground Ground (Fuel sender gauge) Always Below 1 V C6-12 - Body ground BR - Body ground Ground Always Below 1 V C6-13 - Body ground LG - Body ground Height control indicator lamp signal (MAN.) Height control indicator lamp MAN. Indicator light ON Below 1 V C6-13 - Body ground LG - Body ground Height control indicator lamp signal (MAN.) Height control indicator lamp MAN. Indicator light OFF 10 to 14 V C6-14 - Body ground P - Body ground Height control indicator lamp signal (LO) Height control indicator lamp LO, Indicator light ON Below 1 V C6-14 - Body ground P - Body ground Height control indicator lamp signal (LO) Height control indicator lamp LO, Indicator light OFF 10 to 14 V C6-15 - Body ground B-L - Body ground Height control indicator lamp signal (N) Height control indicator lamp N, Indicator light ON Below 1 V C6-15 - Body ground B-L - Body ground Height control indicator lamp signal (N) Height control indicator lamp N, Indicator light OFF 10 to 14 V C6-16 - Body ground GR-R - Body ground Height control indicator lamp signal (HI) Height control indicator lamp HI, Indicator light ON Below 1 V C6-16 - Body ground GR-R - Body ground Height control indicator lamp signal (HI) Height control indicator lamp HI, Indicator light OFF 10 to 14 V C6-17 ( (3) ) - Body ground R-G - Body ground Hi-Beam signal Hi-Beam OFF Below 1 V C6-17 ( (3) ) - Body ground R-G - Body ground Hi-Beam signal Hi-Beam ON 10 to 14 V C6-18 ( (4) ) - Body ground GR-L - Body ground Hi-Beam signal Hi-Beam OFF Below 1 V C6-18 ( (4) ) - Body ground GR-L - Body ground Hi-Beam signal Hi-Beam ON 10 to 14 V C6-19 - Body ground G-B - Body ground Turn signal (L) Ignition switch ON, turn signal LH indicator OFF Below 1 V C6-19 - Body ground G-B - Body ground Turn signal (L) Ignition switch ON, turn signal LH indicator ON 10 to 14 V C6-21 - Body ground R-W - Body ground ABS signal ABS warning light ON 6.7 to 12 V C6-21 - Body ground R-W - Body ground ABS signal ABS warning light OFF Below 1 V C6-23 - Body ground W-R - Body ground Battery Always 10 to 14 V C6-24 - Body ground B-O - Body ground Ignition switch signal (ON) Ignition switch OFF Below 1 V C6-24 - Body ground B-O - Body ground Ignition switch signal (ON) Ignition switch ON 10 to 14 V (1) 4WD (2) w/ Driving position memory (3) w/o Daytime running light (4) w/ Daytime running light (5) 2WD Waveform 1 (Reference): WAVEFORM 1 REFERENCE CHART Condition Gauge set Engine idle speed 5 V/DIV, 10 ms/DIV Waveform 2 (Reference): WAVEFORM 1 REFERENCE CHART Condition Gauge set Driving at approx. 20 km/h (12 mph) 5 V/DIV, 20 ms/DIV

Scheme 51

Scheme 52

Scheme 53

DATA LIST

According to the DATA LIST displayed by the hand-held tester, you can read the values of the switches, sensors, actuators and so on without part removal. Reading the DATA LIST as the first step of troubleshooting is one method to shorten labor time.

1. Warm up the engine.
2. Turn the ignition switch off.
3. Connect the hand-held tester to the DLC3.
4. Turn the ignition switch to the ON position.
5. Operate the hand-held tester according to the steps on the display and select "DATA LIST".

DIAGNOSIS PROCEDURE
