PRECAUTION

HINT

All DTCs retained in the ECM will be erased when the negative (-) terminal cable is removed from the battery.

If necessary, read the DTC before removing the negative (-) terminal cable from the battery.

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

1. BEFORE WORKING ON FUEL SYSTEM, DISCONNECT CABLE FROM NEGATIVE (-) BATTERY TERMINAL
2. DO NOT SMOKE OR WORK NEAR AN OPEN FLAME WHEN WORKING ON FUEL SYSTEM
3. KEEP GASOLINE AWAY FROM RUBBER OR LEATHER PARTS
4. MAINTENANCE PRECAUTIONS To prevent engine misfire, these precautions should be taken. Check the battery terminals are proper connected. After repair, check that the ignition coil terminals and all other ignition system lines are reconnected securely. When cleaning the engine compartment, be especially careful to protect the electrical system from water. Observe the following when handling the air fuel ratio sensors and oxygen sensor. Do not drop the sensor or hit it against another object. The sensor should be free from any contact with water.
5. IF VEHICLE IS EQUIPPED WITH MOBILE RADIO SYSTEM (HAM, CB, ETC.) If the vehicle is equipped with a mobile communication system, refer to the precaution in the IN section.
6. AIR INDUCTION SYSTEM Removal of the engine oil dipstick, oil filler cap, PCV hose, may break the engine. Disconnection, looseness or cracks in the parts of the air induction system between the throttle body and cylinder head may result in air suction and break the engine.
7. ELECTRONIC CONTROL SYSTEM Before removing SFI wiring connectors, terminals, first disconnect the power by turning the ignition switch off or disconnecting the negative (-) terminal cable from the battery. HINT: Be sure to check DTCs before disconnecting the negative (-) terminal cable from the battery. When installing the battery, be especially careful to correctly connect the positive (+) and negative (-) cables. Do not give a severe impact to the SFI parts during removal or installation. Handle all SFI parts carefully, especially the ECM. Be careful during troubleshooting. Numerous transistor circuits are used and even slight terminal contact can cause further trouble. Do not open the ECM cover. When inspecting during rainy weather, take care to prevent entry of water. Also, when washing the engine compartment, prevent water from getting into the SFI parts and wiring connectors. Parts should be replaced as an assembly. Care should be taken when pulling out and inserting wiring connectors. Release the lock and pull out the connector, pulling on the connectors. Fully insert the connector and check that it is locked. Use SST for inspection or test of the injector or its wiring connector. SST 09842-30070
8. FUEL SYSTEM When disconnecting the high fuel pressure line, a large amount of gasoline will spill out. Observe the following procedures: Disconnect the circuit opening relay. Start the engine. After the engine has stopped on its own, turn the ignition switch off. Put a container under the connecting part of the pressure line. Slowly loosen the connection. Disconnect the high fuel pressure line. Reconnect the fuel pump connector. When connecting the union bolt (fuel pressure pulsation damper) on the high pressure pipe union, observe the following procedures: Always use 2 new gaskets. Tighten the union bolt by hand. Using SST, tighten the union bolt to the specified torque. SST 09612-24014 (09617-24011) Torque: 33 N.m (340 kgf.cm, 24 ft.lbf) for use with SST 39 N.m (400 kgf.cm, 29 ft.lbf) HINT: Use a torque wrench with a fulcrum length of 30 cm (11.81 in.). Observe the following precautions when removing or installing the injectors. Never reuse the O-ring. When placing a new O-ring on the injector, take care not to damage it in any way. Coat a new O-ring with spindle oil or gasoline before installing. Never use engine, gear or brake oil. Install the injector to the delivery pipe and intake manifold as shown in the illustration. Before installing the injector, apply spindle oil or gasoline on the place where the delivery pipe or the intake manifold touches the O-ring of the injector. Observe the following when disconnecting the fuel tube connector (quick type): Check if there is any dirt in the pipe and around the connector before disconnecting the fuel tube connector. If necessary, clean the dirt away. Disconnect the fuel pipe clamp from the connector. Be sure to disconnect them by hand. When the connector and the pipe are stuck, push and pull the connector. Then disconnect and pull it out. Do not use any tools at this time. Check if there is any dirt or other foreign matter on the seal surface of the disconnected pipe. If necessary, clean the dirt away. Do not damage the disconnected pipe and connector and prevent intrusion of foreign objects by covering them with a plastic bag. Observe the following when connecting the fuel tube connector (quick type): Check if there is any damage or foreign objects in the connected part of the pipe. Match the axis of the connector with the axis of the pipe, and push into the connector until a "click" sound is heard. If the connection is tight, apply a small amount of fresh engine oil on the tip of the pipe. After finishing the connection, pull the pipe and the connector to ensure it is secure. Check to make sure no fuel leak is present. If the result is not specified, repair or replace. Install the fuel pipe clamp to the connector. Check to make sure no fuel leak is present. If the result is not specified, repair or replace. Observe the following when disconnecting the fuel tube connector (metallic type): HINT: The structure of the metallic connector is shown on the left. Check if there is any dirt in the pipe and around the connector before disconnecting the fuel tube connector. If necessary, clean the dirt away. Assemble SST to the connecting part, as shown in the illustration. SST 09268-21010 Turn the SST, align the retainers inside the connector with the SST chamfered parts and insert the SST into the connector. While holding the SST, pull the connector towards the SST to put the retainers on the SST chamfered parts. Slide the SST and connector together towards the fuel tube assembly. Observe the following when connecting the fuel tube connector (metallic type): Check if there is any damage or foreign objects in the connected part of the pipe. Match the axis of the connector with the axis of the pipe, and push into the connector until a "click" sound is heard. If the connection is tight, apply a small amount of fresh engine oil on the tip of the pipe. After finishing the connection, pull the pipe and the connector to ensure it is secure. Check to make sure no fuel leak is present. If the result is not specified, repair or replace. Observer the following when handling the nylon tube: Pay attention not to turn the connected part of the nylon tube and the quick connector with tube when connecting them. Pay attention not to kink the nylon tube. Do not remove the nylon tube. Do not close the piping with the nylon tube by bending it. Check that there is any fuel leak after maintenance anywhere on the fuel system. Connect a hand-held tester to the Controller Area Network Vehicle Interface Module (CAN VIM). Then connect the CAN VIM to the Date Link Connector 3 (DLC3). Turn the ignition switch ON and push the hand-held tester main switch ON. NOTE: Do not start the engine. Enter the following menus: DIAGNOSIS / ENHANCED OBDII / ACTIVE TEST / FUEL PUMP / SPD. Please refer to the hand-held tester operator's manual for further details. Pinch the fuel return hose. The pressure in the high pressure line will rise to approx. 392 kPa (4 kgf/cm 2 , 57 psi). In this state, check to see that there are no leaks from any part of the fuel system. NOTE: Always pinch the hose. Avoid bending as it may cause the hose to crack. Turn the ignition switch OFF. Disconnect the hand-held tester and CAN VIM from the DLC3.

Scheme 70

Scheme 71

Scheme 72

1. CHECK FUEL PUMP OPERATION Connect a hand-held tester to the Controller Area Network Vehicle Interface Module (CAN VIM). Then connect the CAN VIM to the Date Link Connector 3 (DLC3). Turn the ignition switch ON, and push the hand-held tester main switch ON. NOTE: Do not start the engine. Enter the following menus: DIAGNOSIS / ENHANCED OBDII / ACTIVE TEST / FUEL PUMP / SPD Please refer to the hand-held tester operator's manual for further details. Check that the pulsation damper screw rises when the fuel pump operates. If operation is not as specified, check the fusible link, fuses, EFI main relay, fuel pump, ECM and wiring connections. Turn the ignition switch off. Disconnect the hand-held tester and CAN VIM from the DLC3.
2. CHECK FUEL PRESSURE Check the battery positive voltage is 12 V or more. Disconnect the negative (-) terminal cable from the battery. Remove the front fuel pipe from the LH delivery pipe. (See «REMOVAL»(ref-227590-S06939759882006040600000) ) Install the front fuel pipe and SST (pressure gauge) to the delivery pipe with the 3 lower gaskets and SST (adaptor). SST 09268-45014 (09268-41190, 90405-06167) Torque: 39 N.m (400 kgf.cm, 29 ft.lbf) Wipe off any splattered gasoline. Reconnect the negative (-) terminal cable to the battery. Connect a hand-held tester to the DLC3. (See step 1 in check fuel pump operation (a) to (e)) Measure the fuel pressure. Fuel pressure: 265 to 304 kPa (2.7 to 3.1 kgf/cm 2 , 38 to 44 psi) If pressure is high, replace the fuel pressure regulator. If pressure is low, check the fuel hoses and connections, fuel pump, fuel filter and fuel pressure regulator. Disconnect the hand-held tester and CAN VIM from the DLC3. Start the engine. Measure the fuel pressure at idle. Fuel pressure: 265 to 304 kPa (2.7 to 3.1 kgf/cm 2 , 38 to 44 psi) Stop the engine. Check that the fuel pressure remains as specified for 5 minutes after the engine has stopped. Fuel pressure: 147 kPa (1.5 kgf/cm 2 , 21 psi) or more If pressure is not as specified, check the fuel pump, pressure regulator and/or injectors. After checking fuel pressure, disconnect the negative (-) terminal cable from the battery and carefully remove the SST to prevent gasoline from splashing. SST 09268-45014 Reinstall the front fuel pipe to the LH delivery pipe. (See «INSTALLATION»(ref-227590-S08478508292006040600000) )
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
4. PERFORM INITIALIZATION (See «INITIALIZATION»(ref-227563-S28331174312006040600000) ) Some systems need initialization when disconnecting the cable from the negative battery terminal.
5. CHECK FOR FUEL LEAKS (See «SFI SYSTEM»(ref-227590-S12394961322006040600000) )

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. REMOVE FUEL TANK ASSEMBLY (See «REMOVAL»(ref-227590-S37500122092006040600000) )
2. DISCONNECT FUEL SUCTION TUBE Remove the 2 tube clips, and pull out the 2 fuel tubes. NOTE: Before this operation, check the connector for dirt, mud or other contamination. Clean if necessary. Be careful of mud. The connector's O-ring, which seals the pipe and connector, is easily contaminated. Do not use any tool in this operation. Do not bend or twist the nylon tube. Protect the connector by covering it with a plastic bag. When the pipe and connector are stuck, push and pull the connector to release and pull the connector out carefully.
3. REMOVE FUEL PUMP ASSEMBLY Using SST, loosen the fuel pump gauge retainer. SST 09808-14020 (09808-01410, 09808-01420, 09808-01430) HINT: A rib on the fuel pump gauge retainer fits into a tip of the SST. Remove the fuel pump gauge retainer. Remove the fuel suction tube. NOTE: Be careful not to bend the arm of the fuel sender gauge. Remove the gasket from the fuel tank.

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

1. REMOVE FUEL SENDER GAUGE Disconnect the sender gauge connector from the fuel suction plate No.1. Unlock the fuel sender gauge and slide to remove.
2. REMOVE FUEL SUB-TANK Disconnect the fuel pump harness connector from the fuel suction plate No.1. Disconnect the suction filter hose from the fuel sub-tank. Disconnect the 2 tubes from the tube clamps. Using a screwdriver with the tip wrapped in tape, disconnect the 3 snap-claws from the fuel suction support No.2. NOTE: Do not damage the fuel suction plate No.2 or fuel sub-tank. Disconnect the fuel suction plate No.1 with the fuel filter assembly from the fuel sub-tank.
3. REMOVE FUEL FILTER WITH FUEL PUMP Using a screwdriver with the tip wrapped in tape, disconnect the 2 snap-claws from the fuel suction support. NOTE: Do not damage the fuel filter assembly or fuel suction support. Remove the fuel filter assembly with fuel pump from the fuel suction support.
4. REMOVE FUEL PUMP Using a screwdriver with the tip wrapped in tape, disconnect the 5 snap-claws from the suction filter. NOTE: Do not damage the fuel filter assembly or suction filter. Remove the fuel suction filter with fuel pump from the fuel filter. Disconnect the fuel pump harness from the fuel pump. Remove the O-ring from the fuel pump.
5. REMOVE FUEL SUCTION PLATE NO.2 Using a screwdriver, remove the 2 E-rings from the suction plate No.2. Remove the suction plate No.2 and 2 springs from the fuel suction plate No.1.

Scheme 89

Scheme 90

1. INSPECT FUEL PUMP RESISTANCE Using an ohmmeter, measure the resistance between the terminals. Resistance: 0.2 to 3.0 ohm at 20° C (68° F) If the resistance is not as specified, replace the fuel pump.
2. INSPECT FUEL PUMP OPERATION Connect the lead wire to the fuel pump. Connect the positive (+) lead from the battery to terminal 1 of the connector, and the negative (-) lead to terminal 2. Check that the fuel pump operates. NOTE: These tests must be done quickly (within 10 seconds) to prevent the coil from burning out. Keep the fuel pump as far away from the battery as possible. Always do switching on the battery side. If operation is not as specified, replace the fuel pump and/or read wire. Disconnect the lead wire to the fuel pump.

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

1. REMOVE FUEL SUCTION PLATE NO.2 Install the 2 springs and suction plate No.2 to the suction plate No.1. Using a needle-nose pliers, install the 2 new E-rings to the suction plate No.2.
2. INSTALL FUEL PUMP Apply a light coat of gasoline or spindle oil to a new O-ring, and install it to the fuel pump. Connect the fuel pump harness connector to the fuel pump. Install the fuel pump with the suction filter to the fuel filter.
3. INSTALL FUEL FILTER Install the fuel filter to the fuel sub-tank.
4. INSTALL FUEL SUB-TANK Connect the fuel suction plate No.2 to the fuel sub-tank with the 3 snap-claws engaged. Connect the 2 tubes to the tube clamps. Connect the suction filter hose to the fuel sub-tank. Connect the fuel pump harness connector to the fuel suction plate No.1.
5. INSTALL FUEL SENDER GAUGE Install the fuel sender gauge to the fuel suction support. Connect the sender gauge connector to the fuel suction plate No.1.

Scheme 102

Scheme 103

Scheme 104

Scheme 105

1. INSTALL FUEL PUMP ASSEMBLY Install a new gasket to the fuel tank. Install the fuel pump assembly to the fuel tank. NOTE: Be careful not to bend the arm of the fuel sender gauge. Align the keyway of the fuel suction tube support with the key of the fuel suction plate No.1. Apply MP grease to the entire interior surface of the fuel pump gauge retainer. Align the triangle mark on the new fuel pump gauge retainer with the "S" mark on the fuel tank while pushing down the fuel suction tube. Attach the fuel pump gauge retainer. Rotate the fuel pump gauge retainer by hand. Use an SST to tighten the fuel pump gauge retainer by turning it one and a half times. The triangle mark on the fuel pump gauge retainer must be positioned between the "A" and "MAX." marks on the fuel tank. SST 09808-14020 (09808-01410, 09808-01420, 09808-01430) NOTE: Do not use other tools in this operation. Damage to the fuel pump gauge retainer and the fuel tank may result. HINT: A rib on the fuel pump gauge retainer fits into a tip of the SST.
2. CONNECT FUEL SUCTION TUBE Connect the fuel pump tube and return tube to the fuel tank with the tube joint clips. NOTE: Check that there are no scratches or foreign objects on the connecting part. Check that the fuel tube joint is inserted securely. Check that the tube joint clip is on the collar of the fuel tube joint. After installing the tube joint clip, check that the fuel tube joint has not been pulled off.
3. CHECK FOR FUEL LEAKS
4. INSTALL FUEL TANK ASSEMBLY (See «INSTALLATION»(ref-227590-S22177475142006040600000) )

Scheme 106

Scheme 107

Scheme 108

1. Disconnect the vacuum hose from intake air resonator.
2. Disconnect the fuel return hose from the pressure regulator. CAUTION: Put a shop towel under the pressure regulator.
3. Remove the 2 bolts, and pull out the pressure regulator.
4. Remove the O-ring from the pressure regulator.

Scheme 109

Scheme 110

1. INSTALL FUEL PRESSURE REGULATOR Apply a light coat of gasoline to a new O-ring, and install it to the pressure regulator. While turning the pressure regulator left and right, install it to the delivery pipe. Install the pressure regulator with the 2 bolts. Torque: 7.5 N.m (76 kgf.cm, 66 in..lbf) Connect the vacuum hose to intake air resonator. Connect the fuel return hose to the pressure regulator.
2. CHECK FOR FUEL LEAKS (See «SFI SYSTEM»(ref-227590-S12394961322006040600000) )

Scheme 111

1. REMOVE THROTTLE BODY COVER
2. REMOVE INTAKE AIR CONNECTOR
3. INSPECT INJECTOR RESISTANCE Disconnect the 8 injector connectors. Using an ohmmeter, measure the resistance between the terminals. Resistance: 13.4 to 14.2 ohm at 20° C (68° F) If the resistance is not as specified, replace the injector. Reconnect the 8 injector connectors.
4. REINSTALL INTAKE AIR CONNECTOR
5. REINSTALL THROTTLE BODY COVER

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

1. DISCHARGE FUEL SYSTEM PRESSURE (See «SFI SYSTEM»(ref-227590-S12394961322006040600000) )
2. REMOVE THROTTLE BODY COVER
3. REMOVE INTAKE AIR CONNECTOR
4. REMOVE FUEL PRESSURE PULSATION DAMPER Remove the pulsation damper, upper gasket, fuel main hose and lower gasket. NOTE: Put a shop rag under the delivery pipe. Slowly loosen the pulsation damper.
5. DISCONNECT PCV HOSE FROM PCV VALVE
6. DISCONNECT VSV FOR EVAP Disconnect the VSV connector for EVAP. Disconnect the EVAP hose. Remove the VSV for EVAP from the intake manifold.
7. REMOVE THROTTLE BODY COVER BRACKET Remove the bolt and throttle body cover bracket.
8. DISCONNECT ENGINE WIRES Disconnect the engine wire clamps from the No. 1 engine hanger and engine wire bracket. Disconnect the 2 wire clamps on the engine wire from the brackets on the RH delivery pipe.
9. REMOVE DELIVERY PIPES AND INJECTORS NOTE: Be careful not to drop the injectors when removing the delivery pipes. Do not apply any load to the injector in horizontal direction. Remove the bolt holding the clamp on the fuel return pipe to the LH delivery pipe. Remove the bolt, 2 union bolts, 4 gaskets and front fuel pipe. Disconnect the 8 injector connectors. Remove the 4 nuts holding the delivery pipes to the lower intake manifold. Remove the 2 delivery pipes, 8 injectors, and 8 insulators. Remove the O-ring and grommet from each injector.

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

1. INSPECT INJECTOR INJECTION CAUTION: Keep the injector clean of sparks during the test. Disconnect the fuel inlet hose (fuel tube connector) from the fuel filter. Connect SST (attachment and hose) to the fuel tube. SST 09268-41047 (09268-52011) Remove the pressure regulator from the delivery pipe. Install the O-ring to the fuel inlet of the pressure regulator. Connect SST (hose) to the fuel inlet of the pressure regulator with SST (union) and the 2 bolts. SST 09268-41047 (09268-41091) Torque: 7.5 N.m (76 kgf.cm, 66 in..lbf) Connect the fuel return hose to the fuel outlet of the pressure regulator. Install the O-ring to the injector. Connect SST (adaptor and hose) to the injector, and hold the injector and union with SST (clamp). SST 09268-41047 (09268-41110, 09268-41300) Put the injector into the graduated cylinder. CAUTION: Install a suitable vinyl hose onto the injector to prevent gasoline from splashing out. Connect a hand-held tester to the Controller Area Network Vehicle Interface Module (CAN VIM). Then connect the CAN VIM to the Date Link Connector 3 (DLC3). Connect the battery negative (-) cable to the battery. Turn the ignition switch ON, and push the hand-held tester main switch ON. NOTE: Do not start the engine. Enter the following menus: DIAGNOSIS / ENHANCED OBDII / ACTIVE TEST / FUEL PUMP / SPD Please refer to the hand-held tester operator's manual for further details. Connect SST (wire) to the injector and battery for 15 seconds, and measure the injection volume with a graduated cylinder. Test each injector 2 or 3 times. SST 09842-30070 Volume: 56 to 69 cm 3 (3.4 to 4.2 cu in.) per 15 seconds Difference between each injector: 13 cm 3 (0.8 cu in.) or less If the injection volume is not as specified, replace the injector.
2. INSPECT LEAKAGE Under the above conditions, disconnect the tester probes of SST (wire) from the battery and check fuel leakage from the injector. SST 09842-30070 Fuel drop: 1 drop or less per 12 minutes Turn the ignition switch off. Disconnect the negative (-) terminal cable from the battery. Remove the SST and fuel tube connector. SST 09268-41047, 09842-30070 Disconnect the hand-held tester and CAN VIM from the DLC3. Reconnect the fuel inlet pipe to the fuel tube.

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

1. INSTALL INJECTORS AND DELIVERY PIPES NOTE: Be careful not to drop the injectors when installing the delivery pipes. Do not apply any load to the injector on horizontal direction. Install a new grommet to each injector. Apply a light coat of gasoline to a new O-ring and install it to each injector. While turning the injector clockwise and counterclockwise, push it to the delivery pipes. Install the 8 injectors. Position the injector connector outward. Place the 8 new insulators on the intake manifold. Place the 2 delivery pipes and injectors assemblies on the lower intake manifold. Temporarily install the 4 nuts. Install the front fuel pipe with the bolt, 4 new gaskets and 2 union bolts. Torque: 39 N.m (400 kgf.cm, 29 ft.lbf) for union bolts 7.5 N.m (76 kgf.cm, 66 in..lbf) for bolt Install the bolt holding the clamp on the fuel return pipe to the LH delivery pipe. Torque: 7.5 N.m (76 kgf.cm, 66 in..lbf) Check that the injectors rotate smoothly. HINT: If the injectors do not rotate smoothly, the probable cause is incorrect installation of O-rings. Replace the O-ring of the injector that does not rotate smoothly. Position injector connector outward. Tighten the 4 nuts holding the delivery pipes to the lower intake manifold. Torque: 21 N.m (214 kgf.cm, 15 ft.lbf) Connect the 8 injector connectors.
2. INSTALL ENGINE WIRES Install the 2 wire clamps on the engine wire to the brackets on the RH delivery pipe. Connect the engine wire clamps to the No.1 engine hanger and engine wire bracket. Install the engine wire protector with the 2 bolts.
3. CONNECT PCV HOSE TO PCV VALVE
4. CONNECT VSV FOR EVAP TO UPPER INTAKE MANIFOLD Install the VSV for the EVAP to the upper intake manifold. Connect the EVAP hose. Connect the VSV connector for the EVAP.
5. INSTALL THROTTLE BODY COVER BRACKET Install the throttle body cover bracket with the bolt.
6. INSTALL FUEL PRESSURE PULSATION DAMPER (See «SFI SYSTEM»(ref-227590-S12394961322006040600000) )
7. INSTALL INTAKE AIR CONNECTOR
8. INSTALL THROTTLE BODY COVER

COMPONENTS

Scheme 130

Scheme 131

Scheme 132

Scheme 133

1. DISCHARGE FUEL SYSTEM PRESSURE (See «SFI SYSTEM»(ref-227590-S12394961322006040600000) )
2. REMOVE SPARE TIRE
3. DISCONNECT FUEL PUMP CONNECTOR
4. REMOVE FUEL TANK PROTECTOR Remove the 2 bolts, 2 nuts and fuel tank protector.
5. DISCONNECT FUEL MAIN TUBE AND RETURN TUBE (See «SFI SYSTEM»(ref-227590-S12394961322006040600000) )
6. DISCONNECT FUEL TANK VENT HOSE Push the connector deep into the charcoal canister to release the locking tab. Pinch portion A. Pull out the connector.
7. DISCONNECT INLET HOSE AND BREATHER HOSE Loosen the hose clamp bolt and disconnect the fuel inlet hose from the fuel filler pipe. Disconnect the breather tube. (See «SFI SYSTEM»(ref-227590-S12394961322006040600000) )
8. REMOVE FUEL TANK ASSEMBLY Set up a transmission jack under the fuel tank. Remove the 2 bolts and disconnect the 2 fuel tank bands from the fuel tank. Operate the transmission jack and remove the fuel tank.
9. REMOVE FUEL PUMP ASSEMBLY (See «REMOVAL»(ref-227590-S29994005872006040600000) )

Scheme 134

1. Check the fuel lines for cracks or leakage, and all connections for deformation.
2. Check the fuel tank vapor vent system hoses and connections for looseness, sharp bends or damage.
3. Check the fuel tank for deformation, cracks, fuel leakage or tank band looseness.
4. Check the filler neck for damage or fuel leakage.
5. Hose and pipe connections are as shown in the illustration. If a problem is found, repair or replace the parts as necessary.

Scheme 135

Scheme 136

Scheme 137

1. INSTALL FUEL PUMP ASSEMBLY (See «INSTALLATION»(ref-227590-S41299084302006040600000) )
2. INSTALL FUEL TANK ASSEMBLY Set up the fuel tank to the transmission jack. Operate the transmission jack and install the fuel tank. Install the 2 fuel tank bands with the 2 bolts. Torque: 62 N.m (632 kgf.cm, 45 ft.lbf)
3. CONNECT FUEL INLET HOSE AND BREATHER TUBE Connect the fuel inlet hose to the filler pipe and install the clamp. Connect the breather tube. (See «SFI SYSTEM»(ref-227590-S12394961322006040600000) )
4. DISCONNECT FUEL TANK VENT HOSE Connect the fuel tank vent hose to the charcoal canister.
5. CONNECT FUEL MAIN TUBE AND RETURN TUBE (See «SFI SYSTEM»(ref-227590-S12394961322006040600000) )
6. INSTALL FUEL TANK PROTECTOR Install the fuel tank protector with the 2 bolts and 2 nuts.
7. CONNECT FUEL PUMP CONNECTOR
8. CHECK FOR FUEL LEAKS
9. INSTALL SPARE TIRE

Scheme 138

Scheme 139

Scheme 140

Scheme 141

1. INSPECT OUTPUT VOLTAGE Apply battery voltage across terminals 1 (+B) and 2 (E2G). Connect the positive (+) tester probe to terminal 3 (VG), and the negative (-) tester probe to terminal 2 (E2G). Blow air into the MAF meter, and check if the voltage fluctuates.
2. INSPECT RESISTANCE Using an ohmmeter, measure the resistance between terminals 4 (THA) and 5 (E2). Resistance: 12.5 to 16.9 k ohm at -20° C (-4° F) 2.19 to 2.67 k ohm at 20° C (68° F) 0.50 to 0.68 k ohm at 60° C (140° F)
3. INSPECT MASS AIR FLOW METER If using a hand-held tester: Connect the hand-held tester to the DLC3. Turn the ignition switch to the ON position. Blow air into the MAF meter, and check that the air flow value of the CURRENT DATA changes. If operation is not as specified, check the MAF meter (see «DTC P0101: MASS OR VOLUME AIR FLOW CIRCUIT RANGE/ PERFORMANCE PROBLEM»(ref-227566-S00298576012006040600000) and «DTC P0110, P0112, P0113: INTAKE AIR TEMPERATURE CIRCUIT LOW/HIGH INPUT»(ref-227566-S11514151512006040600000) ) as well as the wiring and the ECM. If not using a hand-held tester: Turn the ignition switch to the ON position. Connect the positive tester probe of the voltmeter to terminal VG of the ECM and the negative tester probe of the voltmeter to terminal E2G of the ECM. Blow air into the air flow meter, and check if the voltage fluctuates. If operation is not as specified, check the MAF meter (see «DTC P0101: MASS OR VOLUME AIR FLOW CIRCUIT RANGE/ PERFORMANCE PROBLEM»(ref-227566-S00298576012006040600000) and «DTC P0110, P0112, P0113: INTAKE AIR TEMPERATURE CIRCUIT LOW/HIGH INPUT»(ref-227566-S11514151512006040600000) ), the wiring and the ECM.

Scheme 142

Scheme 143

Scheme 144

1. REMOVE THROTTLE BODY COVER
2. INSPECT SYSTEM OPERATION Inspect the throttle control motor for operating sound. Turn the ignition switch ON. When depressing the accelerator pedal, check the running sound of the motor. Also, check that there is no friction sound. If operation is not as specified, check the throttle control motor (see step 3 ), wiring and ECM. Inspect the accelerator pedal position sensor. Connect a hand-held tester to the Controller Area Network Vehicle Interface Module (CAN VIM). Then connect the CAN VIM to the Date Link Connector 3 (DLC3). Check that the MIL does not light up. When turning the accelerator pedal position sensor lever to the full-open position, check that the throttle valve opening percentage (THROTTLE POS) of the CURRENT DATA shown the standard value. Standard throttle valve opening percentage: 60% or more If operation is not as specified, check that the accelerator pedal position sensor (see «DTC P2120, P2122, P2123, P2125, P2127, P2128,P2138 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D&E" CIRCUIT LOW/HIGH & INPUT THROTTLE/PEDAL POSITION SENSOR/SWITCH "D&E" VOLTAGE CORRELATION»(ref-227566-S09773972092006040600000) ), wiring and ECM. If not using a hand-held tester, measure the voltage between terminals (VTA1-E2, VTA2-E2) of the ECM connector (See «DTC P0120, P0122, P0123, P0220, P0222, P0223, P2135: THROTTLE/PEDAL POSITION SENSOR SWITCH "A&B" CIRCUIT LOW/HIGH INPUT & THROTTLE PEDAL POSITION SWITCH "A&B" VOLTAGE CORRECTION»(ref-227566-S18183041242006040600000) ). Inspect the idle speed. Start the engine and check that the MIL does not light up. Allow the engine to warm up to normal operating temperature. Turn the A/C compressor ON to OFF, and check the idle speed. Idle speed (Transmission in neutral): 700 +/- 50 RPM NOTE: Perform inspection without an electrical load. After checking the above (a) to (c), perform the driving test and check that there is no sense of incongruity.
3. INSPECT THROTTLE CONTROL MOTOR Disconnect the throttle control motor connector. Using an ohmmeter, measure the motor resistance between terminals M+ and M-. Motor resistance: 0.3 to 100 ohm at 20° C (68° F) If the resistance is not as specified, replace the throttle body assembly (see «REMOVAL»(ref-227590-S27034458912006040600000) ). Reconnect the throttle control motor connector.
4. INSPECT THROTTLE POSITION SENSOR (See «DTC P0120, P0122, P0123, P0220, P0222, P0223, P2135: THROTTLE/PEDAL POSITION SENSOR SWITCH "A&B" CIRCUIT LOW/HIGH INPUT & THROTTLE PEDAL POSITION SWITCH "A&B" VOLTAGE CORRECTION»(ref-227566-S18183041242006040600000) ) If necessary, replace the throttle body assembly (see «REMOVAL»(ref-227590-S27034458912006040600000) ).
5. REINSTALL THROTTLE BODY COVER

Scheme 145

Scheme 146

Scheme 147

1. REMOVE THROTTLE BODY COVER
2. DRAIN ENGINE COOLANT
3. REMOVE INTAKE AIR CONNECTOR
4. REMOVE THROTTLE BODY Disconnect the throttle control connector. Disconnect the 2 water bypass hoses from the throttle body. Remove the nut and 3 bolts, and remove the throttle body from the intake manifold.

Scheme 148

Scheme 149

1. INSTALL THROTTLE BODY Install the throttle body with the nut and 3 bolts. Torque: 14 N.m (143 kgf.cm, 10 ft.lbf) Connect the 2 water bypass hoses to the throttle body. Connect the throttle control connector.
2. INSTALL INTAKE AIR CONNECTOR
3. FILL WITH ENGINE COOLANT (See «REPLACEMENT»(ref-227591-S31440048072006040600000) )
4. START ENGINE AND CHECK FOR ENGINE COOLANT LEAKS
5. INSTALL THROTTLE BODY COVER

Scheme 150

1. Remove the throttle body cover.
2. Remove the intake air connector.
3. Disconnect the oil control valve connector.
4. Using an ohmmeter, measure the resistance between the terminals. Resistance: 6.9 to 7.9 ohm at 20° C (68° F) If the resistance is not as specified, replace the valve.
5. Reconnect the oil control valve connector.
6. Reinstall the intake air connector.
7. Reinstall the throttle body cover.

Scheme 151

Scheme 152

1. REMOVE THROTTLE BODY COVER
2. REMOVE INTAKE AIR CONNECTOR
3. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE Disconnect the 2 camshaft oil control valve connectors. Remove the bolt, camshaft oil control valve and O-ring. Torque: 7.5 N.m (76 kgf.cm, 66 in..lbf) Remove the O-ring from the each camshaft oil control valve. HINT: At the time of installation, please refer to the following items. Use a new O-rings.
