WIRING DIAGRAM
See DTC P0710 TRANSMISSION FLUID TEMPERATURE SENSOR "A" CIRCUIT, DTC P0712 TRANSMISSION FLUID TEMPERATURE SENSOR "A" CIRCUIT LOW INPUT, DTC P0713 TRANSMISSION FLUID TEMPERATURE SENSOR "A" CIRCUIT HIGH INPUT .
See DTC P0504: BRAKE SWITCH "A"/"B" CORRELATION .
Scheme 286
Scheme 287
Scheme 288
Scheme 289
Scheme 290
- Read value of DATA LIST (STP signal). HINT: According to the DATA LIST displayed by the OBD II scan tool or hand-held tester, you can read the value of the switch, sensor, actuator and so on without parts removal. Reading the DATA LIST as the first step of troubleshooting is one method to shorten labor time. Warm up the engine. Turn the ignition switch off. Connect the OBD II scan tool or hand-held tester to the DLC3. Turn the ignition switch to the ON position. Push the "ON" button of the OBD II scan tool or the hand-held tester. When you use the hand-held tester: Select the item "DIAGNOSIS / ENHANCED OBD II / DATA LIST". According to the display on the tester, read the "DATA LIST". Standard: NOTE: In the table above, the conditions listed under "Normal Condition" are reference conditions. Do not depend solely on these reference conditions when deciding whether a part is faulty or not. OK: BRAKE PEDAL SPECIFIED CONDITION Brake Pedal Condition Specified Condition Depressed ON Released OFF NG: Go to step 2. OK: Go to step 3 .
- Inspect Stop Light Switch. PREPARATION: Remove the stop lamp switch assy. CHECK: Measure the resistance according to the value(s) in the table below. OK: NG: Replace Stop Light Switch (See «COMPONENTS»(ref-227600-S16850713632006040600000) ). OK: Go to next step.
- Check harness and connector (ECM - Stop Light Switch). PREPARATION: Install the stop lamp switch assy. CHECK: Measure the voltage according to the value(s) in the table below when the brake pedal is depressed and released. OK: NG: Repair or replace the harness or connector (See «HOW TO USE THE DIAGNOSTIC CHART AND INSPECTION PROCEDURE»(ref-227563-S16821795662006040600000) ). OK: Replace the ECM (See «ENGINE CONTROL MODULE (ECM)»(ref-227590-S42439373302006040600000) ).
