Back Door Power Window Control System Toyota Sequoia I

Windows 9 illustrations ~182 words

Note. For manufactures precautions, see BODY ELECTRICAL SYSTEM . For circuit isolation/troubleshooting, see BACK DOOR POWER WINDOW SWITCH .

Scheme 28

Scheme 28: LOCATION
Scheme 28: LOCATION

Scheme 29

Scheme 29: INSPECTION
Scheme 29: INSPECTION

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36
  1. Inspect back door power window switch continuity : If continuity is not as specified, replace the switch.
  2. Inspect back door control switch continuity : If continuity is not as specified, replace the switch.
  3. Inspect window limit switch continuity : If continuity is not as specified, replace the back door power window regulator assembly.
  4. Inspect back door power window motor operation : Connect the positive (+) lead from the battery to terminal 2 and the negative (-) lead to terminal 1 and check that the motor turns counter clockwise. Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2 and check that the motor turns clockwise. If operation is not as specified, replace the back door power window motor.
