ABS - Diagnostics: Other Toyota Sequoia I

SKID CONTROL ECU

For locations of skid control ECU terminals (Scheme 115) For voltage outputs from skid control ECU Terminals (Scheme 116)and (Scheme 117).

Scheme 115

Scheme 116

Scheme 117

TRANSLATE ECU

For locations of translate ECU terminals (Scheme 118) For voltage outputs from translate ECU terminals (Scheme 119)

Scheme 118

Scheme 119

VSC OFF (TRAC OFF) INDICATOR LIGHT, VSC OFF (TRAC OFF) SWITCH CIRCUIT.

Note. VSC system is only available with 4WD vehicles. TRAC system is only available on 2WD vehicles.
