Cooling fan — Cooling fan circuit, except ev Toyota RAV4 III facelift
All systems — 34 systems
- Air conditioning 3
- Anti-lock brakes 2
- Anti-theft 4
- Body control modules 2
- Computer data lines 2
- Cooling fan 2
- Cruise control 2
- Defoggers 3
- Electronic power steering 2
- Engine performance 2.5l
- Engine performance ev
- Exterior lights 4
- Ground distribution 2
- Headlights 2
- Horn 2
- Instrument cluster 2
- Interior lights 4
- Memory systems
- Navigation 8
- Power distribution 2
- Power door locks 3
- Power mirrors 4
- Power seats 2
- Power top/sunroof
- Power windows 3
- Radio 4
- Shift interlock 4
- Starting/charging 3
- Supplemental restraints 2
- Transmission 2.5l 2
- Transmission ev
- Trunk, tailgate, fuel door 2
- Warning systems 4
- Wiper/washer 4
Components on these wiring diagrams 11
Click a component to highlight it on every diagram it appears on.
