COMPONENTS — Part 2 Toyota RAV4 III

Interior 54 illustrations ~3073 words

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79
Scheme 79

Scheme 80

Scheme 80
Scheme 80

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88
  1. INSTALL NO. 1 ROOF SILENCER PAD w/o Sliding Roof: Install the 5 silencer pads. w/Sliding Roof: Install the 2 silencer pads.
  2. INSTALL NO. 3 ROOF SILENCER PAD
  3. INSTALL NO. 1 ROOF WIRE Only when replacing the roof headlining: Align the marking, and then install the wire harness with tape. HINT: Be careful that dirt or foreign objects do not stick to the adhesive part when peeling off the double-sided tape. Attach the roof wire harness along the adhesive part. NOTE: The roof wire harness should be attached securely.
  4. INSTALL NO. 1 ROOF HEADLINING SUPPORT
  5. INSTALL NO. 2 ROOF HEADLINING SUPPORT
  6. INSTALL NO. 3 ROOF HEADLINING SUPPORT
  7. INSTALL NO. 4 ROOF HEADLINING SUPPORT
  8. INSTALL ROOF HEADLINING ASSEMBLY w/o Sliding Roof: Install the headlining with the 4 clips. w/Sliding Roof: Install the headlining with the 2 clips. Connect the connector to the sliding roof drive gear. Connect the connector to the roof wire. Attach the clamp of the roof wire.
  9. INSTALL SUN ROOF OPENING TRIM MOULDING
  10. INSTALL SHOULDER BELT ANCHOR COVER RH (See «INSTALLATION»(ref-265097-S31911438002007092000000) )
  11. INSTALL CHILD RESTRAINT SEAT TETHER ANCHOR COVER (See appropriate step(s) under «INSTALLATION»(ref-265097-S42534652122007092000000) )
  12. INSTALL REAR ASSIST GRIP ASSEMBLY Attach the 4 claws to install the assist grip.
  13. INSTALL ASSIST GRIP COVER (for Rear Grip) Attach the 4 claws to install the 2 assist grip covers.
  14. INSTALL ASSIST GRIP SUB-ASSEMBLY Attach the 4 claws to install the assist grip.
  15. INSTALL ASSIST GRIP COVER (for Front Grip) Attach the 4 claws to install the 2 assist grip covers.
  16. INSTALL TELEVISION DISPLAY ASSEMBLY (w/Television Display) (See appropriate step(s) under «INSTALLATION»(ref-281538-S00230126002008031700000) )
  17. INSTALL TELEVISION GARNISH (w/Television Display) (See appropriate step(s) under «INSTALLATION»(ref-281538-S00230126002008031700000) )
  18. INSTALL ROOM LIGHT ASSEMBLY (See appropriate step(s) under «INSPECTION»(ref-265096-S39392598922007092000000) )
  19. INSTALL MAP LIGHT ASSEMBLY (See appropriate step(s) under «REASSEMBLY»(ref-265096-S39880498522007092000000) )
  20. INSTALL VANITY LIGHT ASSEMBLY (See appropriate step(s) under «INSTALLATION»(ref-265096-S20315218802007092000000) )
  21. INSTALL VISOR HOLDER Set the claws of the visor holder as shown in the illustration. Insert the visor holder to install it.
  22. INSTALL VISOR ASSEMBLY LH Attach the 2 claws to install the visor. Install portion A of the visor onto the visor holder. Attach the 4 claws to install the visor bracket cover.
  23. INSTALL VISOR ASSEMBLY RH HINT: Use the same procedures described for the LH side.
  24. INSTALL REAR ROOM PARTITION NET HOOK LH Install the net hook with the 2 screws.
  25. INSTALL REAR ROOM PARTITION NET HOOK RH HINT: Use the same procedures described for the LH side.
  26. INSTALL INNER ROOF SIDE GARNISH ASSEMBLY LH (w/o Rear No. 2 Seat) Attach the 8 clips to install the garnish.
  27. INSTALL INNER ROOF SIDE GARNISH ASSEMBLY LH (w/Rear No. 2 Seat) Attach the 8 clips to install the garnish. Connect the rear No. 2 seat belt's shoulder anchor. Connect the shoulder anchor with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) Attach the 2 claws to close the seat belt anchor cover.
  28. INSTALL INNER ROOF SIDE GARNISH ASSEMBLY RH HINT: Use the same procedures described for the LH side.
  29. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (w/o Rear No. 2 Seat) Install the belt hanger to the trim board. Connect the power outlet socket connector. Attach the 4 clips and 5 claws to install the trim board. Install the 2 screws and 2 bolts. Connect the rear No. 1 seat belt's floor anchor. Connect the floor anchor with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) Install the anchor cover.
  30. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (w/Rear No. 2 Seat) Install the belt hanger to the trim board. Connect the power outlet socket connector. Attach the 4 clips and 5 claws to install the trim board. Install the 2 screws and 2 bolts. Connect the rear No. 2 seat belt's floor anchor. Connect the floor anchor with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) Connect the rear No. 1 seat belt's floor anchor. Connect the floor anchor with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) Install the anchor cover.
  31. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (w/o Rear No. 2 Seat) Install the belt hanger to the trim board. Attach the 4 clips and 5 claws to install the trim board. Install the 2 screws and 2 bolts. Connect the rear No. 1 seat belt's floor anchor. Connect the floor anchor with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) Install the anchor cover.
  32. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (w/Rear No. 2 Seat) Install the belt hanger to the trim board. Attach the 4 clips and 5 claws to install the trim board. Install the 2 screws and 2 bolts. Connect the rear No. 2 seat belt's floor anchor. Connect the floor anchor with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) Connect the rear No. 1 seat belt's floor anchor. Connect the floor anchor with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) Install the anchor cover.
  33. INSTALL TETHER ANCHOR BRACKET SUBASSEMBLY (w/o Rear No. 2 Seat) Install the tether anchor bracket with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf)
  34. INSTALL RECLINING REMOTE CONTROL LEVER BEZEL LH (w/o Rear No. 2 Seat) (See appropriate step(s) under «INSTALLATION»(ref-265062-S04585806682007092000000) )
  35. INSTALL RECLINING REMOTE CONTROL LEVER BEZEL RH (w/o Rear No. 2 Seat) (See appropriate step(s) under «INSTALLATION»(ref-265062-S01585792672007092000000) )
  36. INSTALL REAR DECK TRIM COVER LH (w/Rear No. 2 Seat) Attach the 4 claws to install the trim cover. Install the bolt.
  37. INSTALL REAR DECK TRIM COVER RH (w/Rear No. 2 Seat) HINT: Use the same procedures described for the LH side.
  38. INSTALL REAR FLOOR FINISH PLATE Attach the 6 claws and 6 clips to install the finish plate.
  39. INSTALL BACK DOOR WEATHERSTRIP
  40. INSTALL REAR FLOOR NO. 1 MAT SUPPORT SIDE PLATE w/o Rear No. 2 Seat: Attach the 7 clips to install the side plate. Install the 4 screws. w/Rear No. 2 Seat: Attach the 8 clips to install the side plate.
  41. INSTALL REAR FLOOR NO. 3 BOARD
  42. INSTALL REAR FLOOR NO. 2 BOARD
  43. INSTALL REAR NO. 2 SEAT ASSEMBLY LH (w/Rear No. 2 Seat) (See appropriate step(s) under «INSTALLATION»(ref-265062-S41349305422007092000000) )
  44. INSTALL REAR NO. 2 SEAT ASSEMBLY RH (w/Rear No. 2 Seat) HINT: Use the same procedures described for the LH side.
  45. INSTALL NO. 2 SEAT LEG COVER LH (w/Rear No. 2 Seat) (See appropriate step(s) under «INSTALLATION»(ref-265062-S41349305422007092000000) )
  46. INSTALL NO. 2 SEAT LEG COVER RH (w/Rear No. 2 Seat) HINT: Use the same procedures described for the LH side.
  47. INSTALL NO. 2 SEAT HINGE COVER LH (w/Rear No. 2 Seat) (See «INSTALLATION»(ref-265062-S41349305422007092000000) )
  48. INSTALL NO. 2 SEAT HINGE COVER RH (w/Rear No. 2 Seat) HINT: Use the same procedures described for the LH side.
  49. INSTALL DECK BOARD ASSEMBLY (w/o Rear No. 2 Seat)
  50. INSTALL REAR FLOOR NO. 1 BOARD (w/o Rear No. 2 Seat)
  51. INSTALL TONNEAU COVER ASSEMBLY (w/o Rear No. 2 Seat)
  52. INSTALL PACKAGE TRAY TRIM POCKET SUBASSEMBLY (w/o Rear No. 2 Seat)
  53. INSTALL CENTER PILLAR GARNISH LH Attach the clip to install the garnish. Install the 2 screws.
  54. INSTALL CENTER PILLAR GARNISH RH HINT: Use the same procedures described for the LH side.
  55. INSTALL LOWER CENTER PILLAR GARNISH LH Attach the 2 claws and 2 clips to install the garnish. Connect the front seat outer belt's floor anchor. Connect the floor anchor with the bolt. Torque: 42 N*m (428 kgf*cm, 31 ft.*lbf) Install the anchor cover.
  56. INSTALL LOWER CENTER PILLAR GARNISH RH HINT: Use the same procedures described for the LH side.
  57. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH
  58. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH
  59. INSTALL REAR DOOR SCUFF PLATE LH Attach the 9 claws and 2 clips to install the scuff plate.
  60. INSTALL REAR DOOR SCUFF PLATE RH HINT: Use the same procedures described for the LH side.
  61. INSTALL INSTRUMENT PANEL SUB-ASSEMBLY (See «REASSEMBLY»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  62. INSTALL FRONT PILLAR GARNISH LH w/Curtain Shield Airbag: Remove the piece of cloth or nylon. Install the 4 wire harness clamps. w/Curtain Shield Airbag: Install 2 new clips labeled A to the vehicle body. Set the 3 claws of the pillar garnish to the area labeled B. Insert the tips of the clips labeled A into the pillar garnish's holes. Using needle-nose pliers, rotate the tips of clips labeled A 90°. Then push the pillar garnish toward the vehicle body to attach the base of the 2 clips labeled A. w/o Curtain Shield Airbag: Attach the 2 clips and 3 claws to install the garnish.
  63. INSTALL FRONT PILLAR GARNISH RH w/Curtain Shield Airbag: Remove the piece of cloth or nylon. w/Curtain Shield Airbag: Install 2 new clips labeled A to the vehicle body. Set the 3 claws of the pillar garnish to the area labeled B. Insert the tips of the clips labeled A into the pillar garnish's holes. Using needle-nose pliers, rotate the tips of clips labeled A 90°. Then push the pillar garnish toward the vehicle body to attach the base of the 2 clips labeled A. w/o Curtain Shield Airbag: Attach the 2 clips and 3 claws to install the garnish.
  64. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  65. INSTALL INSTRUMENT PANEL REGISTER ASSEMBLY CENTER (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  66. INSTALL RADIO RECEIVER (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  67. INSTALL NO. 2 INSTRUMENT CLUSTER FINISH PANEL CENTER (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  68. INSTALL NO. 1 INSTRUMENT CLUSTER FINISH PANEL CENTER (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  69. INSTALL COMBINATION METER ASSEMBLY (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  70. INSTALL INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  71. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH
  72. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH
  73. INSTALL COWL SIDE TRIM BOARD LH Attach the 3 claws to install the trim board. Install the cap nut.
  74. INSTALL COWL SIDE TRIM BOARD RH HINT: Use the same procedures described for the LH side.
  75. INSTALL FRONT DOOR SCUFF PLATE LH Attach the 10 claws to install the scuff plate.
  76. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedures described for the LH side.
  77. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Scheme 89

Scheme 89: COMPONENTS
Scheme 89: COMPONENTS

Scheme 90

Scheme 90
Scheme 90

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92

Scheme 93

Scheme 93
Scheme 93

Scheme 94

Scheme 94
Scheme 94

Scheme 95

Scheme 95
Scheme 95

Scheme 96

Scheme 96
Scheme 96

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100
Scheme 100

Scheme 101

Scheme 101
Scheme 101

Scheme 102

Scheme 102
Scheme 102

Scheme 103

Scheme 103: REMOVAL
Scheme 103: REMOVAL

Scheme 104

Scheme 104
Scheme 104

Scheme 105

Scheme 105
Scheme 105
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
  2. REMOVE FRONT SEAT ASSEMBLY LH Remove the front seat. for Manual Seat (see «REMOVAL»(ref-265062-S20109197492007092000000) ) for Power Seat (see «REMOVAL»(ref-265062-S02224705162007092000000) )
  3. REMOVE FRONT SEAT ASSEMBLY RH Remove the front seat: For Manual Seat (see «REMOVAL»(ref-265062-S20109197492007092000000) ) For Power Seat (see «REMOVAL»(ref-265062-S02224705162007092000000) )
  4. REMOVE REAR NO. 1 SEAT ASSEMBLY LH Remove the rear No. 1 seat (see «REMOVAL»(ref-265062-S27420568422007092000000) ).
  5. REMOVE REAR NO. 1 SEAT ASSEMBLY RH Remove the rear No. 1 seat (see «REMOVAL»(ref-265062-S17957792302007092000000) ).
  6. REMOVE NO. 1 CONSOLE UPPER PANEL GARNISH (See appropriate step(s) under «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  7. REMOVE NO. 2 CONSOLE UPPER PANEL GARNISH (See appropriate step(s) under «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  8. REMOVE UPPER CONSOLE PANEL SUB-ASSEMBLY (See appropriate step(s) under «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  9. REMOVE SWITCH BASE (See appropriate step(s) under «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  10. REMOVE CONSOLE CUP HOLDER BOX (See appropriate step(s) under «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  11. REMOVE UPPER REAR CONSOLE PANEL SUBASSEMBLY (See appropriate step(s) under «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  12. REMOVE CONSOLE REAR END PANEL (See appropriate step(s) under «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  13. REMOVE NO. 1 INSTRUMENT PANEL BRACKET COVER INNER LH (See appropriate step(s) under «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  14. REMOVE NO. 1 INSTRUMENT PANEL BRACKET COVER INNER RH (See appropriate step(s) under «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  15. REMOVE REAR CONSOLE BOX SUB-ASSEMBLY (See appropriate step(s) under «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  16. REMOVE FRONT DOOR SCUFF PLATE LH (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior)
  17. REMOVE FRONT DOOR SCUFF PLATE RH (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  18. REMOVE COWL SIDE TRIM BOARD LH (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  19. REMOVE COWL SIDE TRIM BOARD RH (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  20. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP LH
  21. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH
  22. REMOVE REAR DOOR SCUFF PLATE LH (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  23. REMOVE REAR DOOR SCUFF PLATE RH (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  24. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
  25. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
  26. REMOVE LOWER CENTER PILLAR GARNISH LH (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  27. REMOVE LOWER CENTER PILLAR GARNISH RH (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  28. REMOVE PACKAGE TRAY TRIM POCKET SUBASSEMBLY (w/o Rear No. 2 Seat)
  29. REMOVE TONNEAU COVER ASSEMBLY (w/o Rear No. 2 Seat)
  30. REMOVE REAR FLOOR NO. 1 BOARD (w/o Rear No. 2 Seat)
  31. REMOVE DECK BOARD ASSEMBLY (w/o Rear No. 2 Seat)
  32. REMOVE REAR NO. 2 SEAT ASSEMBLY LH (w/Rear No. 2 Seat) Remove the rear No. 2 seat (see «REMOVAL»(ref-265062-S25446244072007092000000) ).
  33. REMOVE REAR NO. 2 SEAT ASSEMBLY RH (w/Rear No. 2 Seat) Remove the rear No. 2 seat (see «REMOVAL»(ref-265062-S25446244072007092000000) ).
  34. REMOVE REAR FLOOR NO. 3 BOARD
  35. REMOVE REAR FLOOR NO. 2 BOARD
  36. REMOVE REAR FLOOR NO. 1 MAT SUPPORT SIDE PLATE (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  37. REMOVE BACK DOOR WEATHERSTRIP
  38. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  39. REMOVE REAR DECK TRIM COVER LH (w/Rear No. 2 Seat) (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  40. REMOVE REAR DECK TRIM COVER LH (w/Rear No. 2 Seat) (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  41. REMOVE RECLINING REMOTE CONTROL LEVER BEZEL LH (w/o Rear No. 2 Seat) (See «REMOVAL»(ref-265062-S27420568422007092000000) )
  42. REMOVE RECLINING REMOTE CONTROL LEVER BEZEL RH (w/o Rear No. 2 Seat) (See «REMOVAL»(ref-265062-S17957792302007092000000) )
  43. REMOVE TETHER ANCHOR BRACKET SUBASSEMBLY (w/o Rear No. 2 Seat) (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  44. REMOVE DECK TRIM SIDE PANEL ASSEMBLY LH (w/o Rear No. 2 Seat) (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  45. REMOVE DECK TRIM SIDE PANEL ASSEMBLY LH (w/Rear No. 2 Seat) (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  46. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH (w/o Rear No. 2 Seat) (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  47. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH (w/Rear No. 2 Seat) (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  48. REMOVE FRONT FLOOR CARPET ASSEMBLY Partially remove the floor carpet. HINT: It is not necessary to fully remove the floor carpet. Partially remove it so that the lock control cable can be removed in a later step.
  49. REMOVE FUEL LID LOCK CONTROL CABLE SUBASSEMBLY Remove the bolt and fuel lid lock open lever. Remove the tape and cable from the clamps as shown in the illustration. Turn the lock retainer counterclockwise and remove the cable from the retainer.
  50. REMOVE FUEL FILLER OPENING LID LOCK RETAINER Turn the lock retainer clockwise and remove the lock retainer as shown in the illustration.

Scheme 106

Scheme 106: INSTALLATION
Scheme 106: INSTALLATION

Scheme 107

Scheme 107
Scheme 107

Scheme 108

Scheme 108
Scheme 108
  1. INSTALL FUEL FILLER OPENING LID LOCK RETAINER Install the lock retainer and turn it counterclockwise as shown in the illustration.
  2. INSTALL FUEL LID LOCK CONTROL CABLE SUBASSEMBLY Install the cable and turn it clockwise (Scheme 107) Install the fuel lid lock open lever with the bolt. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Install the cable to the clamps (Scheme 108)
  3. INSTALL FRONT FLOOR CARPET ASSEMBLY
  4. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (w/Rear No. 2 Seat) (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  5. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (w/o Rear No. 2 Seat) (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  6. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (w/Rear No. 2 Seat) (See «REMOVAL»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  7. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (w/o Rear No. 2 Seat) (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  8. INSTALL TETHER ANCHOR BRACKET SUBASSEMBLY (w/o Rear No. 2 Seat) (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  9. INSTALL RECLINING REMOTE CONTROL LEVER BEZEL RH (w/o Rear No. 2 Seat) (See appropriate step(s) under «INSTALLATION»(ref-265062-S01585792672007092000000) )
  10. INSTALL RECLINING REMOTE CONTROL LEVER BEZEL LH (w/o Rear No. 2 Seat) (See appropriate step(s) under «INSTALLATION»(ref-265062-S04585806682007092000000) )
  11. INSTALL REAR DECK TRIM COVER RH (w/Rear No. 2 Seat) (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  12. INSTALL REAR DECK TRIM COVER LH (w/Rear No. 2 Seat) (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  13. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  14. INSTALL BACK DOOR WEATHERSTRIP
  15. INSTALL REAR FLOOR NO. 1 MAT SUPPORT SIDE PLATE (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  16. INSTALL REAR FLOOR NO. 2 BOARD
  17. INSTALL REAR FLOOR NO. 3 BOARD
  18. INSTALL REAR NO. 2 SEAT ASSEMBLY RH (w/Rear No. 2 Seat) Install the rear No. 2 seat (See appropriate step(s) under «INSTALLATION»(ref-265062-S41349305422007092000000) ).
  19. INSTALL REAR NO. 2 SEAT ASSEMBLY LH (w/Rear No. 2 Seat) Install the rear No. 2 seat (See appropriate step(s) under «INSTALLATION»(ref-265062-S41349305422007092000000) ).
  20. INSTALL DECK BOARD ASSEMBLY (w/o Rear No. 2 Seat)
  21. INSTALL REAR FLOOR NO. 1 BOARD (w/o Rear No. 2 Seat)
  22. INSTALL TONNEAU COVER ASSEMBLY (w/o Rear No. 2 Seat)
  23. INSTALL PACKAGE TRAY TRIM POCKET SUBASSEMBLY (w/o Rear No. 2 Seat)
  24. INSTALL LOWER CENTER PILLAR GARNISH RH (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  25. INSTALL LOWER CENTER PILLAR GARNISH LH (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  26. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH
  27. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH
  28. INSTALL REAR DOOR SCUFF PLATE RH (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  29. INSTALL REAR DOOR SCUFF PLATE LH (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  30. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH
  31. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH
  32. INSTALL COWL SIDE TRIM BOARD RH (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  33. INSTALL COWL SIDE TRIM BOARD LH (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  34. INSTALL FRONT DOOR SCUFF PLATE RH (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  35. INSTALL FRONT DOOR SCUFF PLATE LH (See «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/exteriorinterior-trim/#interior) )
  36. INSTALL REAR CONSOLE BOX SUB-ASSEMBLY (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  37. INSTALL NO. 1 INSTRUMENT PANEL BRACKET COVER INNER RH (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  38. INSTALL NO. 1 INSTRUMENT PANEL BRACKET COVER INNER LH (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  39. INSTALL CONSOLE REAR END PANEL (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  40. INSTALL UPPER REAR CONSOLE PANEL SUBASSEMBLY (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  41. INSTALL CONSOLE CUP HOLDER BOX (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  42. INSTALL SWITCH BASE (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  43. INSTALL UPPER CONSOLE PANEL SUB-ASSEMBLY (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  44. INSTALL NO. 2 CONSOLE UPPER PANEL GARNISH (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  45. INSTALL NO. 1 CONSOLE UPPER PANEL GARNISH (See appropriate step(s) under «INSTALLATION»(/toyota/rav4/iii-2005-2010/remont/gauges-instrument-panels/#instrument-panel) )
  46. INSTALL REAR NO. 1 SEAT ASSEMBLY LH Install the rear No. 1 seat (see «INSTALLATION»(ref-265062-S04585806682007092000000) ).
  47. INSTALL REAR NO. 1 SEAT ASSEMBLY RH Install the rear No. 1 seat (see «INSTALLATION»(ref-265062-S01585792672007092000000) ).
  48. INSTALL FRONT SEAT ASSEMBLY LH Install the front seat. for Manual Seat (see «INSTALLATION»(ref-265062-S17858948642007092000000) ) for Power Seat (see «INSTALLATION»(ref-265062-S04999364532007092000000) ).
  49. INSTALL FRONT SEAT ASSEMBLY RH Install the front seat. for Manual Seat (see «INSTALLATION»(ref-265062-S17858948642007092000000) ) for Power Seat (see «INSTALLATION»(ref-265062-S04999364532007092000000) ).
  50. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  51. CHECK SRS WARNING LIGHT Check the SRS warning light (see «DIAGNOSIS SYSTEM»(ref-281539-S07592235132008031700000) ).

See also:
• REMOVAL
• REMOVAL
