Audio System & Visual System: Removal & Installation Toyota RAV4 III

INSTALLATION

1. INSTALL RADIO RECEIVER ASSEMBLY WITH BRACKET Install the No. 1 radio bracket to the radio receiver with the 4 bolts. see scheme 130: Locating No. 1 Radio Bracket Bolts Install the No. 2 radio bracket to the radio receiver with the 4 bolts. Connect all the connectors. Attach the 4 claws to install the radio receiver. Install the 4 bolts. see scheme 131: Locating No. 2 Radio Bracket Bolts see scheme 132: Identifying Claws And Bolts
2. INSTALL NO. 1 INSTRUMENT CLUSTER FINISH PANEL CENTER (see «INSTALLATION»(ref-265064-S40675824202007092000000) )
3. INSTALL NO. 2 INSTRUMENT CLUSTER FINISH PANEL CENTER (see «INSTALLATION»(ref-265064-S40675824202007092000000) )
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Identifying Stereo Component Amplifier Components (1 Of 3). Scheme 101

Identifying Stereo Component Amplifier Components (2 Of 3). Scheme 102

Identifying Stereo Component Amplifier Components With Torque Specifications (3 Of 3). Scheme 103

Scheme 104

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE REAR DOOR SCUFF PLATE RH (see «REMOVAL»(ref-265060-S25729907992007092000000) )
3. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
4. REMOVE PACKAGE TRAY TRIM POCKET SUB-ASSEMBLY (w/o Rear No. 2 Seat)
5. REMOVE TONNEAU COVER ASSEMBLY (w/o Rear No. 2 Seat)
6. REMOVE REAR FLOOR NO. 1 BOARD (w/o Rear No. 2 Seat)
7. REMOVE DECK BOARD ASSEMBLY (w/o Rear No. 2 Seat)
8. REMOVE NO. 2 SEAT HINGE COVER LH (w/ Rear No. 2 Seat) (see «REMOVAL»(ref-265062-S25446244072007092000000) )
9. REMOVE NO. 2 SEAT HINGE COVER RH (w/ Rear No. 2 Seat) (see «REMOVAL»(ref-265062-S25446244072007092000000) )
10. REMOVE NO. 2 SEAT LEG COVER LH (w/ Rear No. 2 Seat) (see «REMOVAL»(ref-265062-S25446244072007092000000) )
11. REMOVE NO. 2 SEAT LEG COVER RH (w/ Rear No. 2 Seat) (see «REMOVAL»(ref-265062-S25446244072007092000000) )
12. REMOVE REAR NO. 2 SEAT ASSEMBLY LH (w/ Rear No. 2 Seat) (see «REMOVAL»(ref-265062-S25446244072007092000000) )
13. REMOVE REAR NO. 2 SEAT ASSEMBLY RH (w/ Rear No. 2 Seat) (see «REMOVAL»(ref-265062-S25446244072007092000000) )
14. REMOVE REAR FLOOR NO. 3 BOARD
15. REMOVE REAR FLOOR NO. 2 BOARD
16. REMOVE REAR FLOOR NO. 1 MAT SUPPORT SIDE PLATE (see «REMOVAL»(ref-265060-S25729907992007092000000) )
17. REMOVE BACK DOOR WEATHERSTRIP
18. REMOVE REAR FLOOR FINISH PLATE (see «REMOVAL»(ref-265060-S25729907992007092000000) )
19. REMOVE REAR DECK TRIM COVER RH (w/ Rear No. 2 Seat) (see «REMOVAL»(ref-265060-S25729907992007092000000) )
20. REMOVE RECLINING REMOTE CONTROL LEVER BEZEL RH (w/o Rear No. 2 Seat) (see «REMOVAL»(ref-265062-S25446244072007092000000) )
21. REMOVE TETHER ANCHOR BRACKET SUB-ASSEMBLY (w/o Rear No. 2 Seat) (see «REMOVAL»(ref-265060-S25729907992007092000000) )
22. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH (w/o Rear No. 2 Seat) (see «REMOVAL»(ref-265060-S25729907992007092000000) )
23. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH (w/ Rear No. 2 Seat) (see «REMOVAL»(ref-265060-S25729907992007092000000) )
24. REMOVE STEREO COMPONENT AMPLIFIER ASSEMBLY Disconnect the connectors. Remove the 3 bolts and remove the stereo component amplifier. (Scheme 104): Removing Bolts And Stereo Component Amplifier

1. INSTALL STEREO COMPONENT AMPLIFIER ASSEMBLY Install the stereo component amplifier with the 3 bolts. Connect the connectors.
2. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (w/ Rear No. 2 Seat) (see «INSTALLATION»(ref-265060-S17943843122007092000000) ) see scheme 137: Installing Stereo Component Amplifier With Bolts
3. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (w/o Rear No. 2 Seat) (see «INSTALLATION»(ref-265060-S17943843122007092000000) )
4. INSTALL TETHER ANCHOR BRACKET SUB-ASSEMBLY (w/o Rear No. 2 Seat) (see «INSTALLATION»(ref-265060-S17943843122007092000000) )
5. INSTALL RECLINING REMOTE CONTROL LEVER BEZEL RH (w/o Rear No. 2 Seat) (see «INSTALLATION»(ref-265062-S41349305422007092000000) )
6. INSTALL REAR DECK TRIM COVER RH (w/ Rear No. 2 Seat) (see «INSTALLATION»(ref-265060-S17943843122007092000000) )
7. INSTALL REAR FLOOR FINISH PLATE (see «INSTALLATION»(ref-265060-S17943843122007092000000) )
8. INSTALL BACK DOOR WEATHERSTRIP
9. INSTALL REAR FLOOR NO. 1 MAT SUPPORT SIDE PLATE (see «INSTALLATION»(ref-265060-S17943843122007092000000) )
10. INSTALL REAR FLOOR NO. 2 BOARD
11. INSTALL REAR FLOOR NO. 3 BOARD
12. INSTALL REAR NO. 2 SEAT ASSEMBLY RH (w/ Rear No. 2 Seat) (see «INSTALLATION»(ref-265062-S41349305422007092000000) )
13. INSTALL REAR NO. 2 SEAT ASSEMBLY LH (w/ Rear No. 2 Seat) (see «INSTALLATION»(ref-265062-S41349305422007092000000) )
14. INSTALL NO. 2 SEAT LEG COVER RH (w/ Rear No. 2 Seat) (see «INSTALLATION»(ref-265062-S41349305422007092000000) )
15. INSTALL NO. 2 SEAT LEG COVER LH (w/ Rear No. 2 Seat) (see «INSTALLATION»(ref-265062-S41349305422007092000000) )
16. INSTALL NO. 2 SEAT HINGE COVER RH (w/ Rear No. 2 Seat) (see «INSTALLATION»(ref-265062-S41349305422007092000000) )
17. INSTALL NO. 2 SEAT HINGE COVER LH (w/ Rear No. 2 Seat) (see «INSTALLATION»(ref-265062-S41349305422007092000000) )
18. INSTALL DECK BOARD ASSEMBLY (w/o Rear No. 2 Seat)
19. INSTALL REAR FLOOR NO. 1 BOARD (w/o Rear No. 2 Seat)
20. INSTALL TONNEAU COVER ASSEMBLY (w/o Rear No. 2 Seat)
21. INSTALL PACKAGE TRAY TRIM POCKET SUB-ASSEMBLY (w/o Rear No. 2 Seat)
22. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH
23. INSTALL REAR DOOR SCUFF PLATE RH (see «INSTALLATION»(ref-265060-S17943843122007092000000) )
24. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Identifying Television Display Components. Scheme 105

Scheme 106

Scheme 107

Scheme 108

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE TELEVISION GARNISH Detach the 4 clips and remove the television garnish. (Scheme 106): Identifying Television Garnish Clips
3. REMOVE TELEVISION DISPLAY ASSEMBLY Disconnect the light connector. Remove the 4 bolts and television display.
4. REMOVE ROOF HEADLINING ASSEMBLY Remove the roof headlining (See «REMOVAL»(ref-265060-S25729907992007092000000) ). (Scheme 107): Locating Television Display Bolts
5. REMOVE TELEVISION BRACKET Remove the 4 bolts and television bracket. (Scheme 108): Removing Bolts And Television Bracket

1. INSTALL TELEVISION BRACKET Install the television bracket with the 4 bolts.
2. INSTALL ROOF HEADLINING ASSEMBLY Install the roof headlining (See «INSTALLATION»(ref-265060-S17943843122007092000000) ). see scheme 142: Installing Television Bracket With Bolts
3. INSTALL TELEVISION DISPLAY ASSEMBLY Install the television display with the 4 bolts. Torque: 12.8 N*m (130 kgf*cm, 48 in.*lbf) Connect the connector. see scheme 143: Locating Television Display Bolts
4. INSTALL TELEVISION GARNISH Attach the 4 clips to install the television garnish.
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Identifying Radio Antenna Components. Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE ANTENNA NUT Remove the antenna nut as shown in the illustration. (Scheme 110): Removing Antenna Nut
3. REMOVE ANTENNA ORNAMENT Remove the antenna ornament as shown in the illustration.
4. REMOVE FRONT FENDER LINER RH (see «REMOVAL»(ref-265092-S20173643722007092000000) )
5. REMOVE FRONT PILLAR GARNISH RH (see «REMOVAL»(ref-265060-S25729907992007092000000) ) (Scheme 111): Removing Antenna Ornament
6. REMOVE FENDER ANTENNA ASSEMBLY Disconnect the connector and detach the 3 clamps. (Scheme 112): Disconnecting Connector Remove the bolt and antenna. (Scheme 113): Removing Bolt And Antenna

Scheme 114

1. INSTALL FENDER ANTENNA ASSEMBLY Install the antenna with the bolt. see scheme 150: Installing Antenna With Bolt Attach the 3 clamps and connect the connector.
2. INSTALL FRONT PILLAR GARNISH RH (see «INSTALLATION»(ref-265060-S17943843122007092000000) )
3. INSTALL FRONT FENDER LINER RH (see «INSTALLATION»(ref-265092-S15807884112007092000000) ) see scheme 151: Connecting Connector
4. INSTALL ANTENNA ORNAMENT Install the antenna ornament as shown in the illustration. (Scheme 114): Installing Antenna Ornament
5. INSTALL ANTENNA NUT Install the antenna nut as shown in the illustration.
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Installing Antenna Nut. Scheme 115

Identifying Radio Antenna Cord Components. Scheme 116

Scheme 117

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (see «REMOVAL»(ref-265064-S01093574592007092000000) )
3. REMOVE COMBINATION METER ASSEMBLY (see «REMOVAL»(ref-265064-S01093574592007092000000) )
4. REMOVE NO. 2 INSTRUMENT CLUSTER FINISH PANEL CENTER (see «REMOVAL»(ref-265064-S01093574592007092000000) )
5. REMOVE NO. 1 INSTRUMENT CLUSTER FINISH PANEL CENTER (see «REMOVAL»(ref-265064-S01093574592007092000000) )
6. REMOVE RADIO RECEIVER ASSEMBLY WITH BRACKET (w/ Radio Receiver) (see «REMOVAL»(ref-281538-S04952023072008031700000) )
7. REMOVE INSTRUMENT PANEL REGISTER ASSEMBLY CENTER (see «REMOVAL»(ref-265064-S01093574592007092000000) )
8. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY (see «REMOVAL»(ref-265064-S01093574592007092000000) )
9. REMOVE FRONT PILLAR GARNISH LH (see «REMOVAL»(ref-265060-S25729907992007092000000) )
10. REMOVE FRONT PILLAR GARNISH RH (see «REMOVAL»(ref-265060-S25729907992007092000000) )
11. REMOVE INSTRUMENT PANEL SUB-ASSEMBLY UPPER (see «REMOVAL»(ref-265064-S01093574592007092000000) )
12. REMOVE ANTENNA CORD SUB-ASSEMBLY Disconnect the connector. Detach the 4 clamps and remove the antenna cord. (Scheme 117): Identifying Antenna Cord Clamps

Scheme 118

1. INSTALL ANTENNA CORD SUB-ASSEMBLY Install the antenna cord with the 4 clamps. Connect the connector. (Scheme 118): Identifying Antenna Cord Sub-Assembly Clips
2. INSTALL INSTRUMENT PANEL SUB-ASSEMBLY UPPER (see «INSTALLATION»(ref-265064-S40675824202007092000000) )
3. INSTALL FRONT PILLAR GARNISH LH (see «INSTALLATION»(ref-265060-S17943843122007092000000) )
4. INSTALL FRONT PILLAR GARNISH RH (see «INSTALLATION»(ref-265060-S17943843122007092000000) )
5. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY (see «INSTALLATION»(ref-265064-S40675824202007092000000) )
6. INSTALL INSTRUMENT PANEL REGISTER ASSEMBLY CENTER (see «INSTALLATION»(ref-265064-S40675824202007092000000) )
7. INSTALL RADIO RECEIVER ASSEMBLY WITH BRACKET (w/ Radio Receiver) (see «INSTALLATION»(ref-281538-S30384151742008031700000) )
8. INSTALL NO. 1 INSTRUMENT CLUSTER FINISH PANEL CENTER (see «INSTALLATION»(ref-265064-S40675824202007092000000) )
9. INSTALL NO. 2 INSTRUMENT CLUSTER FINISH PANEL CENTER (see «INSTALLATION»(ref-265064-S40675824202007092000000) )
10. INSTALL COMBINATION METER ASSEMBLY (see «INSTALLATION»(ref-265064-S40675824202007092000000) )
11. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (see «INSTALLATION»(ref-265064-S40675824202007092000000) )
12. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Identifying Noise Filter. Scheme 119

Scheme 120

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE NOISE FILTER Disconnect the connector. Remove the bolt and noise filter. (Scheme 120): Locating Noise Filter Blot

1. INSTALL NOISE FILTER Install the noise filter with the bolt. Connect the connector.
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Identifying Noise Filters. Scheme 121

Scheme 122

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE V-BANK COVER SUB-ASSEMBLY (see «REMOVAL»(ref-265058-S20822472272007092000000) )
3. REMOVE NO. 1 NOISE FILTER Disconnect the connector. Remove the bolt and noise filter.
4. REMOVE INTAKE AIR SURGE TANK ASSEMBLY (see «REMOVAL»(ref-265058-S20822472272007092000000) ) (Scheme 122): Identifying No. 1 Noise Filter
5. REMOVE NO. 2 NOISE FILTER Disconnect the connector. Remove the bolt and noise filter.

HINT

A bolt without a torque specification is shown in the standard bolt chart (See STANDARD BOLT ).

Identifying No. 2 Noise Filter. Scheme 123

1. INSTALL NO. 2 NOISE FILTER Install the noise filter with the bolt. Connect the connector.
2. INSTALL INTAKE AIR SURGE TANK ASSEMBLY (see «INSTALLATION»(ref-265058-S36368370862007092000000) ) see scheme 163: Identifying No. 2 Noise Filter
3. INSTALL NO. 1 NOISE FILTER Install the noise filter with the bolt. Connect the connector.
4. INSTALL V-BANK COVER SUB-ASSEMBLY (see «INSTALLATION»(ref-265058-S36368370862007092000000) )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Identifying Video Terminal And Console Rear End Panel. Scheme 124

Scheme 125

Scheme 126

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE CONSOLE REAR END PANEL (see «REMOVAL»(ref-265064-S01093574592007092000000) )
3. REMOVE VIDEO TERMINAL Detach the clamp. (Scheme 125): Identifying Clamp Detach the 4 claws and remove the video terminal. (Scheme 126): Detaching Claws And Remove Video Terminal

1. INSTALL VIDEO TERMINAL Attach the 4 claws to install the video terminal. see scheme 168: Attaching Claws To Install Video Terminal Attach the clamp.
2. INSTALL CONSOLE REAR END PANEL (see «INSTALLATION»(ref-265064-S40675824202007092000000) )
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Attaching Clamp. Scheme 127

Identifying Steering Pad Switch Components With Torque Specifications. Scheme 128

Scheme 129

Scheme 130

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE STEERING PAD ASSEMBLY (See «INSTALLATION»(ref-281539-S15888005562008031700000) )
3. REMOVE STEERING PAD SWITCH ASSEMBLY (w/o Telephone Microphone) Disconnect the connectors. Remove the screw. Detach the claw and remove the steering pad switch assembly. (Scheme 129): Detaching Claw And Remove Steering Pad Switch Assembly
4. REMOVE STEERING PAD SWITCH ASSEMBLY (w/ Telephone Microphone) Disconnect the connectors. Remove the 2 screws. Detach the 2 claws and remove the steering pad switch assembly. (Scheme 130): Detaching Claws And Remove Steering Pad Switch Assembly

Scheme 131

1. INSPECT STEERING PAD SWITCH ASSEMBLY Disconnect the steering pad switch assembly connector. (Scheme 131): Inspecting Steering Pad Switch Assembly Measure the resistance according to the value(s) in the table below. Standard resistance STANDARD RESISTANCE SPECIFICATIONS Tester Connection Condition Specified Condition 6 (AIM) - 8 (EAU) No switch is pushed Approx. 100 kohms 6 (AU1) - 8 (EAU) SEEK+ switch: push 0 to 2.5 ohms 6 (AU1) - 8 (EAU) SEEK- switch: push Approx. 0.3 kohms 6 (AU1) - 8 (EAU) VOL+ switch: push Approx. 1 kohms 6 (AU1) - 8 (EAU) VOL- switch: push Approx. 3.1 kohms 7 (AU2) - 8 (EAU) No switch is pushed Approx. 100 kohms 7 (AU2) - 8 (EAU) MODE switch: push 0 to 2.5 ohms 7 (AU2) - 8 (EAU) (*1) VOICE switch: push Approx. 3.1 kohms 7 (AU2) - 8 (EAU) (*1) ON HOOK switch: push Approx. 0.3 kohms 7 (AU2) - 8 (EAU) (*1) OFF HOOK switch: push Approx. 1 kohms HINT: *1: for Premium sound models If the result is not as specified, replace the steering pad switch assembly.

1. INSTALL STEERING PAD SWITCH ASSEMBLY (w/o Telephone Microphone) Attach the claw to install the steering pad switch assembly. Install the screw. Connect all connectors. see scheme 174: Installing Steering Pad Switch
2. INSTALL STEERING PAD SWITCH ASSEMBLY (w/ Telephone Microphone) Attach the 2 claws to install the steering pad switch assembly. Install the 2 screws. Connect all connectors.
3. INSTALL STEERING PAD ASSEMBLY (See «INSTALLATION»(ref-281539-S15888005562008031700000) )
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Identifying Microphone Assembly And Map Light Assembly. Scheme 132

Scheme 133

Scheme 134

1. REMOVE MAP LIGHT ASSEMBLY (see «REMOVAL»(ref-265096-S23284448352007092000000) )
2. REMOVE MICROPHONE ASSEMBLY Disconnect the connector. (Scheme 133): Locating Connector Disengage the 2 claws and remove the microphone assembly. (Scheme 134): Disengaging Claws And Remove Microphone Assembly

1. INSTALL MICROPHONE ASSEMBLY Engage the 2 claws and install the microphone assembly. see scheme 179: Engaging Claws And Install Microphone Assembly Connect the connector.
2. INSTALL MAP LIGHT ASSEMBLY (see «INSTALLATION»(ref-265096-S23903472272007092000000) )

Identifying Front No. 1 Speaker Components. Scheme 135

REMOVAL

HINT

1. Use the same procedures for the RH side and LH sides.
2. The procedures listed below are for the LH side.

Scheme 136

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (see «DISASSEMBLY»(ref-265086-S02181314432007092000000) )
3. REMOVE DOOR ASSIST GRIP COVER LH
4. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG LH
5. REMOVE FRONT ARMREST BASE PANEL UPPER LH (see «DISASSEMBLY»(ref-265086-S02181314432007092000000) )
6. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH (see «DISASSEMBLY»(ref-265086-S02181314432007092000000) )
7. REMOVE FRONT NO. 1 SPEAKER ASSEMBLY Disconnect the connector. Using a drill bit with a diameter of less than 4 mm (0.16 in.), drill out the 3 rivet heads and remove the speaker. NOTE: Do not drill the rivet at an angle as this will cause damage to the drill and drill hole. Line up the drill and rivet, and carefully drill out the rivet head. Be careful as the cut rivet will be very hot. Continue drilling and push out the remaining rivet fragments. Using a vacuum cleaner, remove the rivet fragments and shavings from the inside of the door. (Scheme 136): Drilling Out Rivet Heads Using Drill

HINT

1. Use the same procedures for the RH side and LH sides.
2. The procedures listed below are for the LH side.

Scheme 137

Scheme 138

Scheme 139

Scheme 140

1. INSTALL FRONT NO. 1 SPEAKER ASSEMBLY Using an air riveter or hand riveter, install the speaker with 3 new rivets. (Scheme 137): Installing Front No. 1 Speaker Using Hand Riveter NOTE: Do not pry the rivet with the riveter, as this will cause damage to the riveter and mandrel. (Scheme 138): Precaution For Prying Rivet With Riveter Confirm that the rivets are seated properly against the speaker. Do not tilt the riveter when installing the rivet to the speaker. Do not leave any space between the rivet head and speaker. (Scheme 139): Identifying Rivets Installation Do not leave any space between the speaker and door. Firmly hold together the 2 items while installing the rivet. Connect the connector.
2. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH (see «REASSEMBLY»(ref-265086-S20161197072007092000000) )
3. INSTALL FRONT ARMREST BASE PANEL UPPER LH (see «REASSEMBLY»(ref-265086-S20161197072007092000000) )
4. INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG LH
5. INSTALL DOOR ASSIST GRIP COVER LH
6. INSTALL FRONT DOOR LOWER FRAME BRACKET GARNISH LH (see «REASSEMBLY»(ref-265086-S20161197072007092000000) )
7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL (Scheme 140): Identifying Rivets Installation

Identifying Front No. 2 Speaker Components. Scheme 141

HINT

1. Use the same procedures for the RH side and LH sides.
2. The procedures listed below are for the LH side.

Scheme 142

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (see «DISASSEMBLY»(ref-265086-S02181314432007092000000) )
3. REMOVE DOOR ASSIST GRIP COVER LH
4. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG LH
5. REMOVE FRONT ARMREST BASE PANEL UPPER LH (see «DISASSEMBLY»(ref-265086-S02181314432007092000000) )
6. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH (see «DISASSEMBLY»(ref-265086-S02181314432007092000000) )
7. REMOVE FRONT NO. 2 SPEAKER ASSEMBLY Disconnect the connector. Remove the 2 screws and speaker. (Scheme 142): Removing Screws And Speaker

HINT

1. Use the same procedures for the RH side and LH sides.
2. The procedures listed below are for the LH side.

1. INSTALL FRONT NO. 2 SPEAKER ASSEMBLY install the speaker with the 2 screws. Connect the connector.
2. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY LH (see «REASSEMBLY»(ref-265086-S20161197072007092000000) )
3. INSTALL FRONT ARMREST BASE PANEL UPPER LH (see «REASSEMBLY»(ref-265086-S20161197072007092000000) )
4. INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG LH
5. INSTALL DOOR ASSIST GRIP COVER LH
6. INSTALL FRONT DOOR LOWER FRAME BRACKET GARNISH LH (see «REASSEMBLY»(ref-265086-S20161197072007092000000) )
7. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL

Identifying Stereo Component Speaker Components. Scheme 143

Scheme 144

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE BACK DOOR CENTER GARNISH (see «DISASSEMBLY»(ref-265086-S40098210832007092000000) )
3. REMOVE BACK DOOR SIDE GARNISH LH (see «DISASSEMBLY»(ref-265086-S40098210832007092000000) )
4. REMOVE BACK DOOR SIDE GARNISH RH (see «DISASSEMBLY»(ref-265086-S40098210832007092000000) )
5. REMOVE BACK DOOR TRIM BOARD (see «DISASSEMBLY»(ref-265086-S40098210832007092000000) )
6. REMOVE REAR STEREO COMPONENT SPEAKER ASSEMBLY Disconnect the connector. Using a drill bit with a diameter of less than 4 mm (0.16 in.), drill out the 3 rivet heads and remove the speaker. NOTE: Do not drill the rivet at an angle as this will cause damage to the drill and drill hole. Line up the drill and rivet, and carefully drill out the rivet head. Be careful as the cut rivet will be very hot. Continue drilling and push out the remaining rivet fragments. Using a vacuum cleaner, remove the rivet fragments and shavings from the inside of the door. (Scheme 144): Drilling Out Rivet Heads Using Drill

HINT

1. Use the same procedures for the RH side and LH sides.
2. The procedures listed below are for the LH side.

Scheme 145

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE DOOR ASSIST GRIP COVER LH
3. REMOVE REAR DOOR INSIDE HANDLE BEZEL PLUG LH
4. REMOVE REAR DOOR ARMREST BASE PANEL UPPER LH (see «DISASSEMBLY»(ref-265086-S34590737572007092000000) )
5. REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (see «DISASSEMBLY»(ref-265086-S34590737572007092000000) )
6. REMOVE REAR NO. 1 SPEAKER ASSEMBLY Disconnect the connector. Using a drill bit with a diameter of less than 4 mm (0.16 in.), drill out the 3 rivet heads and remove the speaker. NOTE: Do not drill the rivet at an angle as this will cause damage to the drill and drill hole. Line up the drill and rivet, and carefully drill out the rivet head. Be careful as the cut rivet will be very hot. Continue drilling and push out the remaining rivet fragments. Using a vacuum cleaner, remove the rivet fragments and shavings from the inside of the door. (Scheme 145): Drill Out Rivet Using Drill

HINT

1. Use the same procedures for the RH side and LH sides.
2. The procedures listed below are for the LH side.
